VI. DETECTING JAMS
A. Outline
Table 7-601 shows the sensors used to monitor the presence/absence and movement of copy
paper.
Notation
PS5 Pre-transfer sensor
PS6 Post-transfer sensor
PS7 Separation sensor
PS9 Multifeeder pickup sensor
PS12 Internal delivery sensor
PS21 Pickup vertical path 1 sensor
PS26 Pickup vertical path 2 sensor
PS27 Pickup vertical path 3 sensor
PS28 Re-pickup path sensor
PS30 Pre-registration sensor
PS31 External delivery sensor
PS32 Delivery vertical path 1 sensor
PS33 Delivery vertical path 2 sensor
PS34 Duplexing path sensor
PS35 Duplexing reversal paper sensor
PS36 Duplexing tray paper sensor
PS37 Duplexing inlet paper sensor
PS69 Transparency sensor
PS70 Registration sensor
PS71 Pre-cleaning paper sensor
COPYRIGHT © 1999 CANON INC.
Name
Table 7-601
CANON CLC1120/1130/1150 REV.0 MAR. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 7 PICK-UP / FEEDING SYSTEM
CLC1120/1130 only
CLC1130/1150 only
CLC1150 only
CLC1150 only
CLC1150 only
CLC1150 only
CLC1150 only
CLC1150 only
CLC1150 only
Remarks
7-45
