HP Media Center m7100 - Desktop PC Quick Setup

Remote Control
7
Install AA batteries in
remote control.
Power Connection
9
Computer to electrical outlet
Grounded connection or connection to surge protector is recommended
Power On
11
Turn on monitor, computer, and sound system.
FM antenna
8 Select models only
FM signal to computer
Modem
10
Connect modem cable to computer.
Recovery, built-in
HP has preinstalled the System Recovery software on
the hard drive in case you need to recover the original
software that came with your PC.
• There are no CDs to lose — it's on your hard drive.
• It's faster than traditional CD Recovery methods.
• It's easy. Just use Software Repair Wizard to begin.
If you would still like a set of Recovery CDs, you can use
this tool to create your own for future use.
See your user documentation for complete instructions.
Your PC may look different from the ones shown here. Component, connector location, type,
and number vary by model.
LAN (Ethernet)
Digital Audio Out Digital Audio In
S-video TV/RF-In cable/
antenna connector
Composite
S-video 2 Video 2
1394
FireWire
USB 2.0
PS/2 Keyboard connector PS/2 Mouse connector VGA monitor port
Audio Line Out Audio Line In
Microphone connector
1394
USB 2.0 ports
®
FireWire (IEEE 1394) port Modem (Line In RJ-11)
Audio in right Audio in left LCD connector
FM-In radio Composite (TV Out)
antenna connector
Audio 2
®
