Server Systems SR2520SAFR,
SR2520SAXR and SR2520SAXSR
Spares / Parts List and Configuration Guide
A reference guide to help customers order the necessary components to configure production
®
Intel
SR2520SA Value 2U Integrated Server Systems
Enterprise Platforms and Services Marketing
Revision 1.8
April, 2010
Advertisement
Related Manuals for Sharp MX-5110N
Summary of Contents for Sharp MX-5110N
- Page 1 ® Intel Server Systems SR2520SAFR, SR2520SAXR and SR2520SAXSR Spares / Parts List and Configuration Guide A reference guide to help customers order the necessary components to configure production ® Intel SR2520SA Value 2U Integrated Server Systems Revision 1.8 April, 2010 Enterprise Platforms and Services Marketing...
- Page 2 Disclaimer ® INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT,...
-
Page 4: Table Of Contents
Table of Contents Table of Contents ..........................4 ® Production Intel SR2520SA Server System Details ............... 5 Production Server System Order Codes ..................7 SR2520SA Unique Spares and Accessories .................. 9 SR2520SA Optional Spares and Accessories ................10... -
Page 5: Production Intel Sr2520Sa Server System Details
® Production Intel SR2520SA Server System Details ® The following Intel production SR2520SA Server Systems are offered as pre-integrated server systems. Each SKU includes a ® production version of the Intel Server Board S5000VSA with the rack chassis and the most widely-used key options. ®... - Page 6 • ® One production Intel SR2520SA 2U Rack Mount Server chassis Hot-swap static SATA backplane with Drive Activity and Drive Failure LEDs Supporting up to six (6) hot-swap SATA 3.5-inch hard disk drives Four (4) 3.5-inch hard disk drive carriers and two (2) blank (empty) carriers. ...
-
Page 7: Production Server System Order Codes
Production Server System Order Codes Product Code MM # Qty. Per Description SR2520SA/S5000VSA4DIMMR 2U integrated platform. Includes SR2520SAFR 892236 0073585819 server board, 2U fixed 3.5-inch SATA drive chassis with non- 7311 redundant cooling, USB-based slim-line floppy drive, and 600-W fixed power supply SR2520SAFRNA 893528 0073585819... - Page 8 power supply modules. Install Tip: Connect the power to the backplane, connecting the first two blue SAS ports on the motherboard to the two blue SAS Ports on the SAS BP and the IPMB on BP to the motherboard. SR2520SAXSRNA 902306 0073585819 SR2520SA/S5000VSASASR 2U integrated platform.
-
Page 9: Sr2520Sa Unique Spares And Accessories
SR2520SA Unique Spares and Accessories Product Code MM # Qty. Descrip tion Included ASR600WPSU 903006 0073585817 SR2520SA second 600-W Redundant Power Supply 6989 FSR600WFPS 886906 0073585819 SR2520SA spare 600-W Fixed Power Supply 1098 FSR2520PDB 887429 0073585819 Spare power distribution board for SR2520SA redundant 1104 power supply systems. -
Page 10: Sr2520Sa Optional Spares And Accessories
SR2520SA Optional Spares and Accessories Product Code MM # Qty. Per Descrip tion ADRBEZBLACK 857675 0073585816 SR2520SA locking Black Bezel 5129 FXX10DVCARBLK 880265 0073585818 Black 3.5-inch hot-swap drive carrier spare 1938 AXXBASICRAIL 881096 0073585818 Spare Basic slide rail kit – does not support a cable management arm.
