GE JP656SDSS Dimensions And Installation Information

JP656SD
GE 36" Built-In Clean Design Electric Cooktop
Dimensions and Installation Information (in inches)
Important: Requires a 5" free area between
the bottom of the cooktop to any combustible
material, i.e., shelving. Free area not required
when installing wall oven underneath cooktop.
Refer to installation instructions. Requires a
15" minimum from cooktop to adjacent overhead
cabinets. Units are furnished with a 48" flexible
armored cable.
Note: 36" Ribbon cooktops are approved for
use over select GE 30" Single Wall Ovens and
Warming Drawers. Refer to cooktop and wall
oven/warming drawer installation instructions
packed with product for current dimensional
data. If installed with a GE Telescopic Downdraft
System, consult both the cooktop and downdraft
installation instructions packed with product
before installing. Cooktop gas/electric supply
may need to be re-routed to install downdraft.
The countertop cutout requires 23-1/2" minimum
flat countertop surface and 25" minimum total
countertop depth. In addition, other clearances to
front edge of the countertop must be considered.
Consult cabinet and countertop manufacturer's
specs for flush mount installation prior to install.
Before installing, consult installation
instructions packed with product for current
dimensional data.
KW Rating
240V 8.7
208V 6.5
Breaker Size
240V 40 Amps
†
Note: Check local codes for
†
required breaker size
208V 40 Amps
†
For answers to your Monogram
®
questions, visit our website at geappliances.com
or call GE Answer Center service, 800.626.2000.
®
or GE appliance
* ADA qualified based
*
on Uniform Federal
Accessibility Standards
Specification Created 10/12
Listed by
Underwriters
Laboratories
321370
