Additional informatino for using sony wall-mount bracket (su-wl500)

Hide thumbs Also See for KDL-46Z4100/S - Bravia Z Series Lcd Television:

Download this manual See also: Service Manual, User Manual

Additional Information for

Using Sony Wall-Mount Bracket (SU-WL500)

Compatible TV models for this Wall-Mount Bracket information:

KDL-40Z4100

KDL-40VL160

KDL-46Z4100

KDL-46VL160

For product protection and safety reasons, Sony strongly recommends that you use the

Wall-Mount Bracket model designed for your TV and that the wall-mounting of your TV

is performed by Sony dealers or licensed contractors.

To Customers

Please provide your licensed contractor with this installation supplement as well as the instructions

(supplied with the SU-WL500 Wall-Mount Bracket). Read these documents carefully for safety and proper

installation.

To Sony Dealers and Contractors

Provide full attention to safety during the installation, periodic maintenance and examination of this

product.

Sufficient expertise is required in installing this product, especially to determine the strength

of the wall for withstanding the TV's weight. Be sure to entrust the attachment of this product

to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during

the installation. Sony is not liable for any damage or injury caused by mishandling or improper

installation.

For proper installation, follow your wall-mount bracket instructions and the directions below.

Additional Information for Using Sony Wall-Mount Bracket (SU-WL500)

− −

4-04-599-13()

Page 1 TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.
Page 2 The wall that the TV will be installed on should be capable of supporting a weight of at least four times that of the TV. Refer to your TV’s operating instructions for its weight. Step 3: Installing the Base Bracket on the wall Refer to the Instructions for SU-WL500. Additional Information for Using Sony Wall-Mount Bracket (SU-WL500) − −...
Page 3 When installing the Mounting Hook on the TV. When installing the TV onto the Base Bracket. * Hook positions “c” cannot be used for the models in the table above. Additional Information for Using Sony Wall-Mount Bracket (SU-WL500) − −...
Page 4 • When moving the TV, do not squeeze the bottom of the front panel too strongly. • Remove the screws or install the Mounting Hook on a stable and level surface. Additional Information for Using Sony Wall-Mount Bracket (SU-WL500) − 4 −...
