Playing back Pictures Contents ([NORMAL PLAY]) ........60 • Displaying Multiple Screens (Multi Playback) ........61 • Using the Playback Zoom ....62 Before Use • Enlarge the focus point (display focus point) ......63 Quick Guide ..........5 • Switching the [PLAYBACK] Mode ..63 Standard Accessories .......7 Deleting Pictures ........64 Names of the Components .......8...
Page 4
Connecting to other equipment Playing Back Pictures on a TV Screen ..........183 • Playing back pictures using the AV cable (supplied)....183 • Playing back pictures on a TV with an SD Memory Card slot ....184 • Playing back on the TV with HDMI socket ........185 Saving the recorded still pictures and motion pictures........190...
Before Use Before Use Quick Guide This is an overview of how to record and play back pictures with the camera. For each step, be sure to refer to the pages indicated in brackets. plug-in type Charge the battery. (P16) •...
Page 6
Before Use Play back the pictures. 1 Press [(]. 2 Select the picture you want to view. (P60) - 6 -...
Before Use Standard Accessories Check that all the accessories are supplied before using the camera. • The accessories and their shape will differ depending on the country or area where the camera was purchased. For details on the accessories, refer to Basic Operating Instructions. •...
Before Use Names of the Components Lens (P213) Flash (P69) Self-Timer indicator (P77) AF assist lamp (P147) Lens hood attachment part (P15) [Q.MENU] button (P30)/Delete button (P64) 9 10 111213 [DISPLAY] button (P66) LCD monitor (P66, 209) Flash open button (P69) Diopter adjustment dial (P44)
Page 9
Before Use 16 Cursor buttons 2/ Self-Timer button (P77) 4/ Function button (P32) Assign [REC] Mode menu to 4 button. It is convenient to register [REC] Mode menu that is used often. [FILM MODE]/[ASPECT RATIO]/[QUALITY]/[METERING MODE]/[WHITE BALANCE]/[I.EXPOSURE]/[GUIDE LINE]/ REC AREA]/[REMAINING DISP.] 1/ ISO (P80) 3/ Exposure compensation (P78)/...
Page 10
38 Card/Battery door (P21) 39 DC coupler cover (P22) • When using an AC adaptor, ensure that the Panasonic DC coupler (optional) and AC adaptor (optional) are used. For connection details, refer to P22. - 10 -...
Before Use Rotating the LCD monitor At the time when this camera is purchased, the LCD monitor is stowed in the camera body. Bring out the LCD monitor as shown below. 1 Open the LCD monitor. (Maximum 180o) 2 It can be rotated 180o forwards. 3 Return the monitor to its original position.
Before Use Operating the Rear Dial There are 2 ways to operate the rear dial, rotating left or right, and by pressing. Rotating: Selection of items or setting of values is performed during the various settings. Pressing: Operations that are the same as [MENU/SET] button, such as selection of settings and exiting the menu, are performed during the various settings.
Before Use Attaching the Lens Cap/Shoulder Strap ∫ Lens Cap • When you turn the camera off or carry the camera, attach the lens cap to protect the surface of the lens. Pass the string through the hole on the camera.
Page 14
Before Use ∫ Shoulder Strap • We recommend attaching the shoulder strap when using the camera to prevent it from dropping. Pass the shoulder strap through the hole at the shoulder strap eyelet. Pass the shoulder strap through the stopper and fasten the shoulder strap.
Before Use Attaching the Lens Hood In bright sunlight or backlight, the lens hood will minimise lens flare and ghosting. The lens hood cuts off excess lighting and improves the picture quality. • Check that the camera is turned off. •...
The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certified by Panasonic. (Batteries which do not support this function cannot be used). Panasonic cannot in any way guarantee the quality, performance or safety of batteries which have been manufactured by other companies and are not genuine Panasonic products.
Page 17
Preparation plug-in type Connect the charger to the electrical outlet. • Disconnect the charger from the electrical socket and detach the battery after charging is completed. • The AC cable does not fit entirely into the AC input terminal. A gap will remain as shown on the 90°...
Page 18
Preparation ∫ Charging Charging time Approx. 155 min • The indicated charging time is for when the battery has been discharged completely. The charging time may vary depending on how the battery has been used. The charging time for the battery in hot/cold environments or a battery that has not been used for long time may be longer than normal.
CIPA is an abbreviation of [Camera & Imaging Products Association]. • Temperature: 23 oC/Humidity: 50%RH when LCD monitor is on. • Using a Panasonic SD Memory Card (32 MB). • Using the supplied battery. • Starting recording 30 seconds after the camera is turned on. (When the Optical Image Stabilizer Function is set to [AUTO].)
Page 20
Preparation ∫ Playback (When using the LCD monitor/Viewfinder) Playback time Approx. 330 min Note • The operating times and number of recordable pictures will differ according to the environment and the operating conditions. For example, in the following cases, the operating times shorten and the number of recordable pictures is reduced.
Turn the power switch to [OFF] and confirm that the lens barrel is retracted. • Close the flash. • We recommend using a Panasonic card. Slide the release lever in the direction of the arrow and open the card/battery door.
Page 22
• Be careful not to catch the cable when closing the Card/battery door. Note • Always use a genuine Panasonic AC adaptor (optional). • When using an AC adaptor, use the AC cable supplied with the AC adaptor. • If the AC adaptor and DC coupler are not necessary, then remove them from the digital camera.
Preparation About the Built-in Memory/the Card The following operations can be performed using this unit. • When a card has not been inserted: Pictures can be recorded in the built-in memory and played back. • When a card has been inserted: Pictures can be recorded on the card and played back.
Page 24
Check that the PC and other equipment are compatible when SDXC Memory Card using the SDXC Memory Cards. (48 GB, 64 GB) http://panasonic.net/avc/sdcard/information/SDXC.html • Only cards bearing the SDHC logo (indicating that the card conforms to SD video standards) may be used as 4 GB to 32 GB cards.
Preparation Setting Date/Time (Clock Set) • The clock is not set when the camera is shipped. Turn the camera on. A [MENU/SET] button B Cursor buttons • The lens barrel extends. • If the language select screen is not displayed, proceed to step Press [MENU/SET].
Preparation Press 2/1 to select the items (year, month, day, hour, minute, display sequence or time display format), and press 3/4 to set. A: Time at the home area B: Time at the travel destination (P130) • Select either [24HRS] or [AM/PM] for the time display format.
Preparation Setting the Menu The camera comes with menus that allow you to choose the settings for taking pictures and playing them back as you like and menus that enable you to have more fun with the camera and use it more easily. In particular, the [SETUP] menu contains some important settings relating to the camera’s clock and power.
Preparation Setting menu items This section describes how to select the Programme AE Mode (P53), and the same setting can be used for the [MOTION PICTURE] mode menu, [PLAYBACK] menu and [SETUP] menu as well. Example:To change the [AF MODE] from [ ] (1-area-focusing) to [ ] (Face Detection) in Ø...
Page 29
Preparation Press [MENU/SET] to set. Press [MENU/SET] to close the menu. Switching to other menus e.g.: Switching to the [SETUP] menu Press [MENU/SET] to display the menu. Press 2. Press 4 to select the [SETUP] menu icon [ Press 1. •...
Preparation Using the quick menu By using the quick menu, some of the menu settings can be easily found. • Some of the menu items cannot be set by the modes. Press [Q.MENU] when recording. Press 3/4/2/1 to select the menu item and the setting and then press [MENU/ SET] to close the menu.
Preparation Perform these settings if you need to. About the Setup Menu [CLOCK SET], [ECONOMY] and [AUTO REVIEW] are important items. Check their settings before using them. • In the Intelligent Auto Mode, only [CLOCK SET], [WORLD TIME], [BEEP], [LANGUAGE] and [STABILIZER DEMO.] (P40) can be set.
Page 32
Preparation Up to 3 current camera settings can be registered as custom settings. [CUST. SET MEM.] (Recording Mode only) • Refer to P116 for details. Assign [REC] Mode menu to 4 button. It is convenient to register [REC] Mode menu that is used often. (Recording Mode only) [Fn BUTTON SET] [FILM MODE]/[ASPECT RATIO]/[QUALITY]/...
Page 33
Preparation Set the pattern of the guide lines displayed when taking pictures. You can also set whether or not to have the recording information displayed when the guide lines are displayed. (P66) [GUIDE LINE] [REC. INFO.]: [PATTERN]: [OFF]/[ON] • The [PATTERN] setting is fixed to [ ] in the Intelligent Auto Mode.
Page 34
Preparation When the Auto Review function is activated or when playing back, white saturated areas appear blinking in black and white. [HIGHLIGHT] [OFF]/[ON] • If there are any white saturated areas, we [ON] [OFF] recommend compensating the exposure towards negative (P78) referring to the histogram (P68)
Page 35
Preparation In Manual Focus, the assistance screen appears on the centre of the screen to facilitate focusing on the subject. [OFF] [MF ASSIST] [ON]: The centre of the screen is enlarged over the whole screen. • Refer to for details. You can conserve the battery life by setting these menus.
Page 36
Preparation If you selected the Viewfinder in a Recording Mode, the display will automatically switch to the LCD monitor when playing back [PLAY ON LCD] the pictures. [OFF]/[ON] • Refer to for details. Set the length of time that the picture is displayed after taking it. [OFF] [1SEC.] o [AUTO REVIEW]...
Page 37
Preparation Select the USB communication system after or before connecting the camera to your PC or your printer with the USB connection cable (supplied). y [SELECT ON CONNECTION]: Select either [PC] or [PictBridge(PTP)] if you connected the x [USB MODE] camera to a PC or a printer supporting PictBridge.
Page 38
Preparation Set the format for the HDMI output when playing back on the HDMI compatible high definition TV connected with this unit using the HDMI mini cable (optional). [AUTO]: The output resolution is automatically set based on the information from the connected TV. [1080i]: [HDMI MODE] The interlace method with 1080 available scan lines is used for...
Page 39
Preparation Set the screen that is displayed when the mode dial is set to [OFF]: The recording screen in the currently selected Advanced Scene Mode (P91) or Scene Mode (P96) } [SCENE MENU] appears. [AUTO]: The Advanced Scene Mode or Scene Mode menu screen appears.
Page 40
Preparation Set the language displayed on the screen. ~ [LANGUAGE] • If you set a different language by mistake, select [~] from the menu icons to set the desired language. Displays the amount of jitter the camera has detected. ([STABILIZER DEMO.]) The camera’s features are displayed as slide shows.
Preparation Holding and using your camera Tips for taking good pictures • Do not cover the flash, the AF assist lamp A or the microphone B with your fingers or other objects. • Hold the camera gently with both hands, keep your arms still at your side and stand with your feet slightly apart.
Page 42
Preparation LCD Monitor This is convenient as it allows you to take pictures from various angles by adjusting the LCD monitor. (P11) ∫ Taking pictures at a normal angle ∫ Taking pictures at a high angle ∫ Taking pictures at a low angle Open the LCD monitor 180o toward you, Open the LCD monitor 180o toward you, and adjust the angle.
Page 43
Preparation ∫ Taking pictures with the camera held vertically Open the LCD monitor and rotate it to an angle that makes it easy to see. • Do not cover the AF assist lamp, the microphone with your fingers or other objects. Taking pictures at a normal angle Taking pictures at a high angle Taking pictures at a low angle...
Page 44
Preparation Direction Detection Function Pictures recorded with the camera held vertically are played back vertically (rotated). (Only when [ROTATE DISP.] (P175) is set to [ON]) • The Direction Detection Function may not operate correctly if recording is performed with the camera aimed up or down.
Basic Mode switching Basic Selecting the [REC] Mode, and record still picture or motion picture Turn the camera on. • The power lamp 2 lights when you turn this unit on 1. Switching the mode by rotating the mode dial. Align a desired mode with part A.
Page 46
Basic ∫ Advanced Aperture-Priority AE Mode (P85) The shutter speed is automatically determined by the aperture value you set. Shutter-Priority AE Mode (P85) The aperture value is automatically determined by the shutter speed you set. Manual Exposure Mode (P86) The exposure is adjusted by the aperture value and the shutter speed which are manually adjusted.
Basic A Shutter button B Motion picture button Taking the still picture Press the shutter button halfway to focus. Press the shutter button fully (push it in further), and take the picture. ∫ For more details, refer to the explanation of each recording mode. Recording the motion picture Press the motion picture button to start the recording.
Basic ñ [REC] Mode: Taking pictures using the automatic function (Intelligent Auto Mode) The camera will set the most appropriate settings to match the subject and the recording conditions so we recommend this mode for beginners or those who want to leave the settings to the camera and take pictures easily.
Basic Scene Detection When the camera identifies the optimum scene, the icon of the scene concerned is displayed in blue for 2 seconds, after which its colour changes to the usual red. > [i-PORTRAIT] ¦ [i-SCENERY] [i-MACRO] • [i-NIGHT PORTRAIT] Only when [ ] is selected [i-NIGHT SCENERY]...
Basic AF Tracking Function It is possible to set the focus to the specified subject. Press [FOCUS]. • ] is displayed in the upper left of the screen. • AF Tracking frame is displayed in the centre of the screen. •...
Basic Settings in Intelligent Auto Mode ∫ [REC] Mode menu ¢1 [PICTURE SIZE] (P133)/[COLOR EFFECT]/[FACE RECOG.] (P121)/ [MOTION DEBLUR] • [COLOR EFFECT] can set the colour effects of [STANDARD], [Happy] or [B/W]. When [Happy] is selected, it is possible to automatically take a picture with a higher level of brilliance for the colour brightness and vividness.
Page 52
Basic ¢1 The settings which can be selected are different from when other [REC] Modes are used. ¢2 When [MOTION DEBLUR] is set to [ON], and maximum ISO sensitivity level becomes [ISO6400]. ¢3 When a face is not recognised, it will be fixed to [ ] when recording still pictures, and to [ Ø...
Basic ³ [REC] Mode: Taking pictures with your favourite settings (Programme AE Mode) The camera automatically sets the shutter speed and the aperture value according to the brightness of the subject. You can take pictures with greater freedom by changing various settings in [REC] menu. Set the mode dial to [ A Mode dial •...
Basic Focusing Aim the AF area at the subject, and then press the shutter button halfway. When the subject is When the subject Focus focused is not focused Focus indication Blinks AF area White>Green White>Red ¢1 Sound Beeps 2 times Beeps 4 times A Focus indication B AF area (normal)
Basic Preventing jitter (camera shake) When the jitter alert [ ] appears, use [STABILIZER] (P146), a tripod, the Self-Timer (P77) or the remote shutter (DMW-RSL1; optional) (P207) • Shutter speed will be slower particularly in the following cases. Keep the camera still from the moment the shutter button is pressed until the picture appears on the screen.
Basic Programme shift In Programme AE Mode, you can change the preset aperture value and shutter speed without changing the exposure. This is called programme shift. You can make the background more blurred by decreasing the aperture value or record a moving subject more dynamically by slowing the shutter speed when taking a picture in Programme AE Mode.
Basic [REC] Mode: Taking Pictures with the Zoom Using the Optical Zoom/Using the Extra Optical zoom (EZ)/Using the Intelligent Zoom/Using the Digital Zoom You can zoom-in to make people and objects appear closer or zoom-out to record landscapes in wide angle. To make subjects appear even closer (maximum of 50.6k), do not set the picture size to the highest setting for each aspect ratio (X/Y/W/ The zoom magnification can be increased by approximately 1.3k without noticeable deterioration in the picture by the Intelligent Resolution Technology when the Intelligent...
Page 58
Basic ∫ Types of zooms Feature Optical Zoom Extra Optical Zoom (EZ) Maximum ¢ 50.6k magnification Picture No deterioration No deterioration quality [PICTURE SIZE] with (P133) Conditions None selected. Screen display ] is displayed. Feature Intelligent Zoom Digital Zoom 96k (including Optical Zoom 24k) 202k (including Extra Optical Zoom (including Optical Zoom 24k) 50.6k)
Page 59
Basic ∫ Extra Optical Zoom mechanism As an example, if you set to [ ] (3 million pixels worth), it will take pictures with the 3M (3 million pixels worth) in the centre of the 14M (14.1 million pixels worth) of the MOS sensor allowing you to take more magnified pictures.
Basic ¸ [PLAYBACK] Mode: Playing back Pictures ([NORMAL PLAY]) Press [(]. • During recomposition of the Burst Picture group information, the currently retrieving information icon [ ] will appear. For details, refer to “ About retrieval of Burst Picture group P154 ”...
Basic Displaying Multiple Screens (Multi Playback) Rotate the zoom lever towards [L] (W). 1 screen>12 screens>30 screens>Calendar screen display (P165) A Number of the selected picture and the total number of recorded pictures B Burst icon [˜] • Rotate the zoom lever towards [Z] (T) to return to the previous screen.
Basic Using the Playback Zoom Rotate the zoom lever towards [Z] (T). 1k>2k>4k>8k>16k • When you rotate the zoom lever towards [L] (W) after enlarging the picture, the magnification becomes lower. • When you change the magnification, the zoom position indication A appears for about 1 second, and the position of the enlarged section can be moved by pressing 3/4/2/1.
Basic Enlarge the focus point (display focus point) This unit will remember the focus point during the recording, and it can be enlarged with that point as a centre. Press [FOCUS] during image playback. • Focus point may not be the centre of enlargement when it is at the edge of the image.
Basic ¸ [PLAYBACK] Mode: Deleting Pictures Once deleted, pictures cannot be recovered. • Pictures on the built-in memory or the card, which are being played back will be deleted. • You can also delete pictures from the [PLAYBACK] mode Menu. (P180) To delete a single picture Select the picture to be deleted, and then...
Basic To delete multiple pictures (up to 100) or all the pictures Press [‚]. Press 3/4 to select [DELETE MULTI] or [DELETE ALL] and then press [MENU/SET]. • [DELETE ALL] > step Press 3/4/2/1 to select the picture, and then press [DISPLAY] to set. (Repeat this step.) •...
Advanced (Recording pictures) Advanced (Recording pictures) About the LCD Monitor/Viewfinder ∫ Selecting the screen to be used Press [DISPLAY] to change. A [DISPLAY] button • When the menu screen appears, the [DISPLAY] button is not activated. During Playback Zoom (P62), while playing back motion pictures (P157) and during a slide show (P160), you can...
Page 67
Advanced (Recording pictures) ∫ Out-of-frame display Recording information is displayed on the bottom and right edges of the screen. You can therefore concentrate on the subject when taking pictures without being obstructed by information displayed on the screen. ∫ Monitor priority When [PLAY ON LCD] is set to [ON] on the [SETUP] menu (P36), the LCD monitor is turned on when switching from Recording Mode to Playback Mode.
Page 68
Advanced (Recording pictures) ∫ About the Histogram A histogram is a graph that displays brightness along the horizontal axis (black to white) and the number of pixels at each brightness level on the vertical axis. It allows you to easily check a picture’s exposure. Examples of histogram 1 Properly Exposed 2 Under Exposed...
Advanced (Recording pictures) [REC] Mode: Taking Pictures using the Built-in Flash A To open the flash Press the flash open button. B To close the flash Press the flash until it clicks. • Be sure to close the flash when not in use. •...
Page 70
Advanced (Recording pictures) Item Description of settings The flash is automatically activated when the recording conditions make ‡: AUTO it necessary. The flash is automatically activated when the recording conditions make it necessary. It is activated once before the actual recording to reduce the red-eye AUTO/Red-Eye phenomenon (eyes of the subject appearing red in the picture) and then ¢...
Page 71
Advanced (Recording pictures) ∫ Available flash settings by Recording Mode The available flash settings depend on the Recording Mode. (±: Available, —: Not available, ¥: Initial setting of Advanced Scene Mode and Scene Mode) ‡ ‰ Œ ‡ ‰ Œ ¢1 ñ...
Page 72
Advanced (Recording pictures) ∫ The available flash range to take pictures • The available flash range is an approximation. Available flash range sensitivity Wide Tele ¢ ¢ AUTO 30 cm (0.99 feet) to 9.5 m (31.16 feet) 1.0 m (3.28 feet) to 5.1 m (16.73 feet) ISO100 30 cm (0.99 feet) to 3.3 m (10.82 feet) 1.0 m (3.28 feet) to 1.8 m (5.90 feet)
Page 73
Advanced (Recording pictures) ∫ Shutter speed for each flash setting Flash setting Shutter speed (Sec.) Flash setting Shutter speed (Sec.) ‡ ¢1 ¢1 1/60 to 1/2000th to 1/2000th ‰ Œ ¢1 It may vary depending on the [MIN. SHTR SPEED] setting (P145). •...
Advanced (Recording pictures) [REC] Mode: Taking Close-up Pictures This mode allows you to take close-up pictures of a subject, e.g. when taking pictures of flowers. You can take pictures of a subject as close as 1 cm (0.04 feet) from the lens by rotating the zoom lever upmost to Wide (1k).
Advanced (Recording pictures) [REC] Mode: Taking Pictures with Manual Focus Use this function when you want to fix the focus or when the distance between the lens and the subject is determined and you do not want to activate Auto Focus. Set the focus selector switch to [MF].
Page 76
Advanced (Recording pictures) ∫ MF assistance If [MF ASSIST] (P35) in the setup menu is set to [ON], when you rotate the rear dial, MF assistance is activated and the screen is enlarged allowing you to focus on the subject more easily.
Advanced (Recording pictures) [REC] Mode: Taking Pictures with the Self-Timer Press 2 [ë]. Press 3/4 to select a mode. • You can also press 2 [ë] to select. • If you set [10S/3PICTURES], after 10 seconds the camera takes 3 pictures at about 2 second intervals. Press [MENU/SET].
Advanced (Recording pictures) [REC] Mode: Compensating the Exposure Use this function when you cannot achieve appropriate exposure due to the difference in brightness between the subject and the background. Look at the following examples. Under exposed Properly exposed Overexposed Compensate the exposure Compensate the towards positive.
Advanced (Recording pictures) [REC] Mode: Taking Pictures using Auto Bracket In this mode, 3 pictures are automatically recorded in the selected exposure compensation range each time the shutter button is pressed. You can select the picture with the desired exposure from the 3 pictures with different exposures. With Auto Bracket d1 EV 1st picture 2nd picture...
Advanced (Recording pictures) [REC] mode: Setting the Light Sensitivity This allows the sensitivity to light (ISO sensitivity) to be set. Setting to a higher figure enables pictures to be taken even in dark places without the resulting pictures coming out dark.
Page 81
Advanced (Recording pictures) ∫ About [ ] (Intelligent ISO sensitivity control) The camera automatically sets the optimum ISO sensitivity and shutter speed to suit the movement of the subject and brightness of the scene to minimise the jitter of the subject. •...
Advanced (Recording pictures) [REC] Mode: Taking Pictures using Burst Mode Pictures are taken continuously while the shutter button is pressed. Select the ones you really like from the pictures you have taken. Burst speed can be selected to match the recording conditions or subjects. Pictures recorded in burst mode will be recorded as a burst picture group (P153).
Page 83
Advanced (Recording pictures) Burst speed Features 2 pictures/second Suitable for moderate action shots. Maximum recordable pictures: 100 5 pictures/second It is suitable for recording fast movements, such as a bird beating its wings. 11 pictures/second Maximum recordable pictures: 15 It is suitable for recording split second actions that are hard to see with the naked eye, such as water splashing.
Page 84
Advanced (Recording pictures) Note • When [AF-CONTINUOUS] is set, focus prediction will be performed in a possible range to prioritise the burst speed. Therefore, if you try to take a picture of a subject that is moving fast, it may have trouble with focusing or it may take time to focus. •...
Advanced (Recording pictures) [REC] Mode: Taking pictures by specifying the aperture/ shutter speed Aperture-Priority AE Set the aperture value to a higher number when you want a sharp focus background. Set the aperture value to a lower number when you want a soft focus background. Set the mode dial to [ Rotate the rear dial to set the aperture value.
Advanced (Recording pictures) [REC] Mode: Taking picture by setting the exposure manually Determine the exposure by manually setting the aperture value and the shutter speed. Set the mode dial to [ ² • The Manual Exposure Assistance appears for about 10 seconds. Rotate the rear dial to set the aperture and shutter speed.
Advanced (Recording pictures) [REC] mode: Taking pictures while adjusting colour ( My Colour Mode) You can take pictures with a desired effect by previewing the subject on the LCD monitor or viewfinder and setting the desired effect. Set the mode dial to [ Press 3/4 to select an item.
Page 89
Advanced (Recording pictures) Press [MENU/SET] to set. • When you press the shutter button halfway before pressing [MENU/SET], the setting will be cancelled. • Recording screen is displayed. ∫ Readjust the My Colour settings Return to step on page by pressing [MENU/SET]. Note •...
Advanced (Recording pictures) Adjusting the custom settings to achieve desired effects By selecting [CUSTOM], you can take pictures with colour, brightness and saturation adjusted to desired levels. In step 2 on page 88, select [CUSTOM] and press 1. Press 3/4 to select an item and 2/1 to adjust. Item Adjustment contents This will adjust the colour of the...
Advanced (Recording pictures) [REC] Mode: Taking expressive portraits and landscape pictures (Advanced Scene Mode) You can take high-quality pictures of such subjects as people, scenery, sporting events and activities, people in night scenes and flowers in accordance with the surrounding conditions.
Advanced (Recording pictures) [PORTRAIT] The person stands out from the background and has a healthier complexion. [NORMAL PORTRAIT] Shades the background and photographs skin colour beautifully. [SOFT SKIN] Makes the skin surface appear especially smooth. • When [SOFT SKIN] is selected, if a part of the background is a coloured similar to the colour of the person’s skin, it also may show some smoothing.
Advanced (Recording pictures) [SCENERY] This allows you to take pictures of a wide landscape. [NORMAL SCENERY] The focus adjusts onto far away subjects as a priority. [NATURE] The best setting for photographing natural scenery. [ARCHITECTURE] This setting takes sharp photographs of architecture. The guide lines are displayed. (P33) [CREATIVE SCENERY] The shutter speed...
Advanced (Recording pictures) [CLOSE-UP] This mode allows you to take close-up pictures of a subject, e.g. when taking pictures of flowers. [FLOWER] Flowers outdoors are recorded with natural colours in macro settings. The guide lines are displayed. (P67) [FOOD] You can take pictures of food with a natural hue without being affected by the ambient light in restaurants etc.
Advanced (Recording pictures) [NIGHT PORTRAIT] This allows you to take pictures of a person and the background with near real-life brightness. [NIGHT PORTRAIT] Uses when taking photographs of people with night scenery as a background. • Open the flash. (You can set to [ •...
Advanced (Recording pictures) [REC] Mode: Taking pictures that match the scene being recorded (Scene Mode) When you select a Scene Mode to match the subject and recording situation, the camera sets the optimal exposure and hue to obtain the desired picture. Set the mode dial to [ Press 3/4/2/1 to select the Scene Mode.
Advanced (Recording pictures) [PANORAMA ASSIST] You can take pictures with connections suitable for creating panorama images. ∫ Setting the recording direction Press 3/4 to select the recording direction and then press [MENU/SET]. • The horizontal/vertical guideline will be displayed. Take the picture. •...
Advanced (Recording pictures) [PARTY] Select this when you want to take pictures at a wedding reception, an indoor party etc. This allows you to take pictures of people and the background with near real-life brightness. ∫ Technique for Party Mode •...
Advanced (Recording pictures) [BABY1]/ [BABY2] This takes pictures of a baby with a healthy complexion. When you use the flash, the light from it is weaker than usual. It is possible to set different birthdays and names for [BABY1] and [BABY2]. You can select to have these appear at the time of playback, or have them stamped on the recorded image using [TEXT STAMP] (P168).
Advanced (Recording pictures) [PET] Select this when you want to take pictures of a pet such as a dog or a cat. You can set your pet’s birthday and name. You can select to have these appear at the time of playback, or have them stamped on the recorded image using [TEXT STAMP] (P168).
Advanced (Recording pictures) [FLASH BURST] This will take pictures in burst with the flash. It is useful for when taking pictures continuously in a dark area. Pictures recorded will be recorded together as a single burst picture group. ∫ Picture size and aspect ratio Press 3/4 to select the picture size and aspect ratio and then press [MENU/ SET] to set.
Advanced (Recording pictures) [PANNING] When you move the camera to follow a subject moving in one direction such as a runner or car, the background becomes a blur and the subject stays focused. This effect is called “panning”. This mode allows you to obtain this effect easier. ∫...
Advanced (Recording pictures) [STARRY SKY] This allows you to take vivid pictures of a starry sky or a dark subject. ∫ Setting the shutter speed Select a shutter speed of [15 SEC.], [30 SEC.] or [60 SEC.]. Press 3/4 to select the number of seconds and then press [MENU/SET]. •...
Advanced (Recording pictures) [FIREWORKS] This mode allows you to take beautiful pictures of fireworks exploding in the night sky. ∫ Technique for Fireworks Mode We recommend performing the following steps to prefocus on the point the pictures will be taken so that you do not miss taking pictures of the fireworks when they are fired. 1 Aim the camera at an object, such as a distant light, that is about the same distance from the camera as the point where the fireworks will rise.
Advanced (Recording pictures) [BEACH] This allows you to take even more vivid pictures of the blue colour of the sea, sky etc. It also prevents under exposure of people under strong sunlight. Note • The initial setting for [AF MODE] is [š]. •...
Advanced (Recording pictures) [HIGH SPEED MOVIE] This will record 220 frames/second, recording very fast movement that cannot be seen with the naked eye as a motion picture. Start recording by pressing the motion picture button. • Release the motion picture button right after you press it. Stop the recording by pressing the motion picture button again.
Advanced (Recording pictures) [REC] Mode: Advanced (Recording pictures) Recording Motion Picture This can record full high definition motion pictures compatible with the AVCHD format or motion pictures recorded in Motion JPEG. Audio will be recorded in stereo. • Close the flash. (It is recommended that you close the flash when recording motion pictures. However, leaving the flash open will not result in a significant difference in sound quality.) Select the mode A Mode dial...
Page 108
Advanced (Recording pictures) Start recording by pressing the motion picture button. A Available recording time B Elapsed recording time • Release the motion picture button right after you press • The audio is also recorded simultaneously from the built-in microphone on this unit. (Motion pictures cannot be recorded without audio.) •...
Page 109
Advanced (Recording pictures) • Refer to P150 for the [MOTION PICTURE] Mode menu. • The flash setting is fixed to [Œ]. • Refer to P238 for information about the available recording time. • The available recording time displayed on the screen may not decrease regularly. •...
Advanced (Recording pictures) Taking pictures or taking pictures with Burst while recording Motion Pictures Still pictures can be recorded even while recording a motion picture. It is also possible to record with burst. ∫ Taking a still picture while recording a motion picture During motion picture recording, press the shutter button fully to record a still picture.
Advanced (Recording pictures) Note • Refer to for settings in Intelligent Auto Mode. • Due to conditions such as the ones below, a different scene may be identified for the same subject. – Subject conditions: When the face is bright or dark, the size of the subject, the colour of the subject, the distance to the subject, the contrast of the subject, when the subject is moving –...
Page 112
Advanced (Recording pictures) Press 3/4 to select the item and then press [MENU/SET]. When [AVCHD(1080i)] is selected in step Aspect ¢1 Item Quality (bit rate) ratio High 1920k1080 pixels ([FSH]) ¢2 Approx. 17 Mbps quality Full high (Sensor 16:9 definition output is 1920k1080 pixels ([FH])
Page 113
¢2 Models launched before December 2008, and some models launched in 2009 (FS, LS series). • To play back AVCHD motion pictures recorded with this unit on Panasonic Blu-ray Disc Players (DMP-BD30/DMP-BD31/DMP-BD50) it is necessary to update the firmware of the Blu-ray Disc Player.
Advanced (Recording pictures) [REC] Mode: Recording Motion Picture with Manual Settings (Creative Motion Picture Mode) It is possible to manually change the aperture and shutter speed and record motion pictures. Switching the [EXPOSURE MODE] allows you to use settings such as those when mode dial is switched to [³], [±], [´] and [²].
Page 115
For this reason, some motion pictures recorded in [MOTION JPEG] may not be ¢ played back with Panasonic digital cameras (LUMIX) (Motion pictures recorded with a Panasonic digital camera (LUMIX) can be played back on this model.) ¢ Models launched before December 2008, and some models launched in 2009 (FS, LS series).
Advanced (Recording pictures) [REC] Mode: Registering Personal Menu Settings (Registering custom settings) It is possible to register up to 3 sets of current camera settings as custom sets. • Set to the mode dial to the desired mode and select the desired menu settings in advance. Select [CUST.
Advanced (Recording pictures) [REC] Mode: Taking pictures in Custom Mode You can select one of your own custom settings saved with [CUST. SET MEM.] to suit the picture-taking conditions. Initial setting of the Programme AE Mode is registered as the custom settings initially. Set the mode dial to [ A Display custom settings Press 3/4 to select the custom settings you want...
Advanced (Recording pictures) [REC] mode: Change tone of the colour for the picture to be taken (Film Mode) Just as each type of film for film cameras has its own colour tone and contrast characteristics, Film Mode allows you to select up to 9 different “digital films”, colour tones, in the same way as you would select different films for film cameras.
Advanced (Recording pictures) Adjusting each Film Mode to the desired setting Press 2/1 to select a film. Press 3/4 to select an item and 2/1 to adjust. • Registered settings are memorised even if the camera is turned off. Press 3/4 to select the [MEMORY] and then press [MENU/SET].
Advanced (Recording pictures) Multi Film Bracket It will take pictures changing the type of film in accordance with the setting every time the shutter button is pressed. (Up to 3 pictures) • You can also set from the Quick Menu. (P30) Press 2/1 to select [MULTI FILM].
Advanced (Recording pictures) [REC] Mode: Taking a picture with Face Recognition function Face Recognition is a function which finds a face resembling a registered face and prioritises focus and exposure automatically. Even if the person is located towards the back or on the end of a line in a group photo, the camera can still take a clear picture. [FACE RECOG.] is initially set to [OFF] on the camera.
Advanced (Recording pictures) Face Settings You can register information such as names and birthdays for face images of up to 6 people. Registration can be facilitated by taking multiple face images of each person. (up to 3 pictures/registration) ∫ Point of recording when registering the face images [Good example for •...
Page 123
Advanced (Recording pictures) Registering face image of new person Select [FACE RECOG.] on the [REC] Mode menu and then press 1. (P28) Press 3/4 to select [MEMORY] and then press [MENU/SET]. Press 3/4/2/1 to select the Face Recognition frame that is not registered, and then press [MENU/SET].
Page 124
Advanced (Recording pictures) Select item to edit with 3/4, and then press 1. • You can register up to 3 face images. Item Description of settings It is possible to register names. Press 4 to select [SET] and then press [MENU/SET]. Enter the name.
Advanced (Recording pictures) Change or delete the information for a registered person You can modify the pictures or information of an already registered person. You can also delete the information of the registered person. Select [FACE RECOG.] from the [REC] Mode menu, and then press 1.
Advanced (Recording pictures) Auto Registration When [AUTO REGISTRATION] is set to [ON], the registration screen will display automatically after taking a picture of a face that has a high number of appearances. • 3 is the typically required number for the registration screen to display. (Taking pictures while set to Burst, Auto Bracket, White Balance Bracket, Multi Film Bracket, or taking still pictures while recording motion pictures are not counted) •...
Advanced (Recording pictures) [REC] Mode: Useful Functions at Travel Destinations Recording which Day of the Vacation and the Location of the Vacation For details on the [SETUP] menu settings, refer to P28. If you set the departure date and the location of the vacation in advance, the number of days that have passed since the departure date (which day of the vacation it is) is recorded when you take the picture.
Advanced (Recording pictures) Press 3/4/2/1 to set the return date (year/ month/day), and then press [MENU/SET]. • If you do not want to set the return date, press [MENU/SET] while the date bar is displayed. Press 4 to select [LOCATION] and then press 1. Press 4 to select [SET] and then press [MENU/ SET].
Page 129
Advanced (Recording pictures) ∫ Cancelling the Travel Date The Travel Date is automatically cancelled if the current date is after the return date. If you want to cancel the Travel Date before the end of the vacation, select [OFF] on the screen shown in step , and then press [MENU/SET] twice.
Advanced (Recording pictures) Recording Dates/Times at Overseas Travel Destinations (World Time) For details on the [SETUP] menu settings, refer to P28. You can display the local times at the travel destinations and record them on the pictures you take. • Select [CLOCK SET] to set the current date and time in advance.
Page 131
Advanced (Recording pictures) Press 3 to select [DESTINATION] and then press [MENU/SET] to set. C Depending on the setting, the time at the travel destination area or the home area is displayed. Press 2/1 to select the area the travel destination is in and then press [MENU/SET] to set.
Advanced (Recording pictures) Using the [REC] Mode menu [FILM MODE] For details on [REC] mode menu settings, refer to P28. You can select colour characteristics for your pictures from among 9 sets, much as you would select a film for a film camera. Select the Film Mode setting according to the conditions and the nature of the recording.
Advanced (Recording pictures) [PICTURE SIZE] For details on [REC] Mode menu settings, refer to P28. Set the number of pixels. The higher the numbers of pixels, the finer the detail of the pictures will appear even when they are printed onto large sheets. Applicable modes: ∫...
Advanced (Recording pictures) Note • “EZ” is an abbreviation of “Extra Optical Zoom”. • A digital picture is made of numerous dots called pixels. The higher the numbers of pixels, the finer the picture will be when it is printed on a large piece of paper or displayed on a PC monitor.
Advanced (Recording pictures) [SENSITIVITY] For details on [REC] Mode menu settings, refer to P28. This allows the sensitivity to light (ISO sensitivity) to be set. Setting to a higher figure enables pictures to be taken even in dark places without the resulting pictures coming out dark.
Advanced (Recording pictures) [WHITE BALANCE] For details on [REC] Mode menu settings, refer to P28. In sunlight, under incandescent lights or in other such conditions where the colour of white takes on a reddish or bluish tinge, this item adjusts to the colour of white which is closest to what is seen by the eye in accordance with the light source.
Page 137
Advanced (Recording pictures) ∫ Setting the White Balance manually Set the White Balance value. Use to match the condition when taking photographs. Select [ ] or [ ] and then press 1. Aim the camera at a sheet of white paper etc. so that the frame in the centre is filled by the white object only and then press [MENU/SET].
Page 138
Advanced (Recording pictures) ∫ White Balance Bracket Bracket setting is performed based on the adjustment values for the White Balance Fine Adjustment, and 3 pictures with different colours are automatically recorded when the shutter button is pressed once. Press [DISPLAY] in step of the “Finely adjusting the White Balance”...
Advanced (Recording pictures) [FACE RECOG.] For details on [REC] Mode menu settings, refer to P28. Specify a person’s face and use the Face Recognition functions. Applicable modes: [OFF]/[ON]/[MEMORY]/[SET] Note • Refer to P121 for details. [AF MODE] For details on [REC] Mode menu settings, refer to P28. This allows the focusing method that suits the positions and number of the subjects to be selected.
Page 140
Advanced (Recording pictures) ∫ About [š] (Face Detection) The following AF area frames are displayed when the camera detects the faces. Yellow: When the shutter button is pressed halfway, the frame turns green when the camera is focused. White: Displayed when more than one face is detected. Other faces that are the same distance away as faces within the yellow AF areas are also focused.
Page 141
Advanced (Recording pictures) Note • If it fails to lock, AF area will flash in red, and disappear. Try to lock again. • AF tracking will not operate when the subject is not specified, the subject is lost, or has failed to be tracked.
Advanced (Recording pictures) [PRE AF] For details on [REC] Mode menu settings, refer to P28. The camera will adjust focus automatically depending on the settings. Applicable modes: [OFF]: ]: Quick AF ] is displayed on the screen. ¢ ]: Continuous AF ] is displayed on the screen.
Advanced (Recording pictures) [AF/AE LOCK] For details on [REC] Mode menu settings, refer to P28. Take a picture with the focus or exposure locked. This is a technique for setting the focus and the exposure in advance when the subject is outside the focus area or when the contrast is too sharp and the appropriate exposure cannot be achieved.
Advanced (Recording pictures) [METERING MODE] For details on [REC] Mode menu settings, refer to P28. Type of optical measurement to measure brightness can be changed. Applicable modes: [C]: Multiple This is the method in which the camera measures the most suitable exposure by judging the allocation of brightness on the whole screen automatically.
Advanced (Recording pictures) [MIN. SHTR SPEED] For details on [REC] Mode menu settings, refer to P28. You can take a picture brightly in dark places by setting [MIN. SHTR SPEED] slower. Also, you can set it faster to reduce the blur of the subject. Applicable modes: [AUTO], [1/250], [1/125], [1/60], [1/30], [1/15], [1/8], [1/4], [1/2], [1] Minimum shutter speed setting...
Advanced (Recording pictures) [DIGITAL ZOOM] For details on [REC] Mode menu settings, refer to P28. This can enlarge subjects even more than the Optical Zoom, the Extra Optical Zoom or Intelligent Zoom Applicable modes: [OFF]/[ON] Note • Refer to for details. •...
Advanced (Recording pictures) [AF ASSIST LAMP] For details on [REC] Mode menu settings, refer to P28. Illuminating the subject makes it easier for the camera to focus when recording in low light conditions that make focusing difficult. Applicable modes: [OFF]: The AF assist lamp does not turn on.
Advanced (Recording pictures) [FLASH SYNCHRO] For details on [REC] Mode menu settings, refer to P28. [2ND] (2nd synchro) activates the flash just before the shutter closes when taking pictures of moving objects such as cars using a slow shutter speed. Applicable modes: [1ST]: The normal method when taking pictures with the...
Advanced (Recording pictures) [CONVERSION] For details on [REC] Mode menu settings, refer to P28. With the optional conversion lenses, you can record even more faraway pictures and take close-up pictures of smaller subjects. Applicable modes: [OFF] When you attach the tele conversion lens. When you attach the close-up lens.
Advanced (Recording pictures) Using the [MOTION PICTURE] Mode menu • The [REC] Mode menus below will also be displayed in Creative Motion Picture Mode. – [FILM MODE]/[SENSITIVITY]/[ISO LIMIT SET]/[WHITE BALANCE]/[AF MODE]/ [METERING MODE]/[I.EXPOSURE]/[DIGITAL ZOOM]/[STABILIZER]/[AF ASSIST LAMP]/ [CONVERSION] [REC MODE] For details on [MOTION PICTURE] Mode menu settings, refer to P28. This sets up the data format of motion pictures.
Advanced (Recording pictures) [CONTINUOUS AF] For details on [MOTION PICTURE] Mode menu settings, refer to P28. It will continually keep on focusing to the subject that the focus was once set. Applicable modes: [OFF]/[ON] Note • When set to [OFF], it may take time for motion picture recording to start. •...
Advanced (Recording pictures) Entering Text It is possible to enter babies’ and pets’ names and the names of travel destinations when recording. (Only alphabetical characters and symbols can be entered.) Display the entry screen and press to move to the character selection section.
Advanced (Recording pictures) ¸ [PLAYBACK] Mode: Playing Back Burst Pictures ∫ About the burst picture group Pictures taken with Burst or Flash Burst are recorded collectively as a burst picture group with burst icon [˜]. A Burst icon • Continuous Playback and Multi Playback in a group unit is possible. •...
Page 154
Advanced (Recording pictures) ∫ About retrieval of Burst Picture group information If you delete or change the file names of pictures stored in the built-in memory using a PC, or pictures stored the memory card using a PC or other device, the camera will automatically retrieve the new information and recompose the burst picture groups when you switch it on again.
Advanced (Recording pictures) ¸ [PLAYBACK] Mode: Editing Burst Pictures You can edit the pictures in the burst picture group as single pictures or in group units (including all pictures in group). ∫ Editing single pictures within a burst picture group •...
Page 156
Advanced (Recording pictures) ∫ Editing in burst picture group units All pictures in the burst picture group are edited at once. • For burst picture groups, the following editing menu can be used. – [TITLE EDIT] (P166), [TEXT STAMP] (P168), [RESIZE] (P171), [FAVORITE] (P176), [PRINT SET] (P177), [PROTECT] (P179), [DELETE] (P180), [FACE REC EDIT] (P181), [COPY] (P182)
Motion pictures in AVCHD format that can be played back on this unit are [AVCHD] motion pictures that were recorded with this unit, AVCHD format (including [AVCHD Lite]) motion pictures recorded with Panasonic digital cameras (LUMIX) only. Motion pictures Press 2/1 to select a picture with a...
Advanced (Recording pictures) Playing Back [HIGH SPEED MOVIE] You can play back the motion pictures recorded with scene mode set to [HIGH SPEED MOVIE] according to your preference, such as with slow motion playback or fast forward playback. Press 2/1 to select a picture with a [HIGH SPEED MOVIE] icon [ ], and then press 3 to play back.
Advanced (Recording pictures) ¸ [PLAYBACK] Mode: Creating Still Pictures From a Motion Picture You can create a single still picture from a recorded motion picture. Press 3 to pause Motion Picture playback. Press [MENU/SET]. Press 3 to select [YES] and then press [MENU/SET].
Advanced (Playback) ¸ [PLAYBACK] Mode: Advanced (Playback) Playing Back Pictures in Sequence (Slide Show) You can play back the pictures you have taken in synchronisation with music, and you can do this in sequence while leaving a fixed interval between each of the pictures. You can also put together a slide show composed of only still pictures, only motion pictures, only pictures of a particular category, or only favourites.
Advanced (Playback) slide show ∫ Operations performed during The cursor displayed during playback is the same as 3/4/2/1. • The menu screen is restored when [‚] is pressed. A Play/Pause B Stop ¢ C Back to previous picture ¢ D Ahead to next picture ¢...
Advanced (Playback) ¸ [PLAYBACK] Mode: Selecting Pictures and Playing them Back ([MODE PLAY]/[CATEGORY PLAY]/[FAVORITE PLAY]) [MODE PLAY] Playback in [PICTURE], [AVCHD], or [MOTION JPEG] can be selected. Select [MODE PLAY] on the Playback Mode menu. Press 3/4 to select the item and then press [MENU/SET].
Advanced (Playback) [CATEGORY PLAY] This mode allows you to search images by Scene Mode or other categories (such as [PORTRAIT], [SCENERY] or [NIGHT SCENERY]) and sort the pictures into each of the categories. You can then play back the pictures in each category. Select [CATEGORY PLAY] on the Playback Mode menu.
Advanced (Playback) [FAVORITE PLAY] You can play back the pictures you have set as [FAVORITE] (P176) (Only when [FAVORITE] in [SETUP] menu is set to [ON] and there are pictures which have been set to [FAVORITE]). Select [FAVORITE PLAY] on the Playback Mode menu. - 164 -...
Advanced (Playback) ¸ [PLAYBACK] Mode: Using the [PLAYBACK] Mode menu You can use various functions in Playback Mode to rotate pictures, set protection for them etc. • With [TEXT STAMP], [RESIZE], [CROPPING] or [LEVELING], a new edited picture is created. A new picture cannot be created if there is no free space on the built-in memory or the card so we recommend checking that there is free space and then editing the picture.
Advanced (Playback) [TITLE EDIT] You can add text (comments) to pictures. After text has been registered, it can be included in prints using [TEXT STAMP] (P168). (Only alphabetic characters and symbols can be entered.) Names set in [BABY1]/[BABY2] and [PET] in Scene Mode or [LOCATION] in Travel Date are also recorded as the titles.
Advanced (Playback) [VIDEO DIVIDE] Recorded motion picture can be d in two. It is recommended for when you want to divide a part you need with a part you do not need. divide It cannot be restored once divided. Select [VIDEO DIVIDE] on the [PLAYBACK] Mode menu.
Advanced (Playback) [TEXT STAMP] You can stamp the recording date/time, name, location, Travel Date or title onto the recorded pictures. It is suitable for regular size printing. (Pictures with a Picture Size larger than [ ] will be resized when stamping the date etc. on them.) Select [TEXT STAMP] on the [PLAYBACK] Mode menu.
Page 169
Advanced (Playback) Press 3/4 to select text stamp items, and then press 1. Press 3/4 to select the settings, and then press [MENU/SET]. Item Setting item [OFF] [SHOOTING DATE] [W/OTIME]: Stamp the year, month and date. Stamp the year, month, day, hour and minutes. [WITHTIME]: [OFF] Stamps names registered in name settings for...
Page 170
Advanced (Playback) Press [MENU/SET]. • If you set [TEXT STAMP] for a picture with a picture size larger than [ ], the picture size will become smaller as shown below. Aspect ratio setting Picture size > > > > • When selecting [ ] or [ ], press 3 to select [YES] for stamping [AGE], and then...
Advanced (Playback) [RESIZE] Reducing the picture size (number of pixels) To allow easy posting to web pages, attachment to e-mail etc., picture size (number of pixels) is reduced. Select [RESIZE] on the [PLAYBACK] Mode menu. (P28) Press 3/4 to select the item and then press [MENU/SET].
Advanced (Playback) [CROPPING] You can enlarge and then crop the important part of the recorded picture. Select [CROPPING] on the [PLAYBACK] Mode menu. (P28) Press 3/4 to select [SINGLE] or [SINGLE IN BURST GROUP], and then press [MENU/SET]. • When [SINGLE IN BURST GROUP] is selected, press 3/4/2/1 to select burst picture group, and press [MENU/SET] to proceed to step Press 2/1 to select the picture and then press [MENU/SET].
Page 173
Advanced (Playback) Press 3 to select [YES] and then press [MENU/ SET]. Press [‚] to return to the menu screen. • Press [MENU/SET] to close the menu. Note • Depending on the cut size, the picture size of the cropped picture may become smaller than that of the original picture.
Advanced (Playback) [LEVELING] Minute tilting of the image can be adjusted. Select [LEVELING] on the [PLAYBACK] Mode menu. (P28) Press 3/4 to select [SINGLE] or [SINGLE IN BURST GROUP], and then press [MENU/SET]. • When [SINGLE IN BURST GROUP] is selected, press 3/4/2/1 to select burst picture group, and press [MENU/SET] to proceed to step Press 2/1 to select the picture, and then press [MENU/SET].
Advanced (Playback) [ROTATE DISP.] This mode allows you to automatically display pictures vertically if they were recorded holding the camera vertically. Select [ROTATE DISP.] on the [PLAYBACK] Mode menu. (P28) Press 4 to select [ON] and then press [MENU/ SET]. •...
Advanced (Playback) [FAVORITE] This can only be used when [FAVORITE] in setup menu is set to [ON]. You can do the following if a mark has been added to pictures and they have been set as favourites. – Play back only the pictures set as favourites. ([FAVORITE PLAY]) –...
Advanced (Playback) [PRINT SET] DPOF “Digital Print Order Format” is a system that allows the user to select which pictures to print, how many copies of each picture to print and whether or not to print the recording date on the pictures when using a DPOF compatible photo printer or photo printing store. For details, ask at your photo printing store.
Page 178
Advanced (Playback) ∫ Cancelling all the [PRINT SET] settings Select [CANCEL] on the screen shown in step and then press [MENU/SET]. Press 3 to select [YES] and then press [MENU/SET]. Press [MENU/SET] to close the menu. • You cannot select [CANCEL] if not even one picture has been set for printing. ∫...
Advanced (Playback) [PROTECT] You can set protection for pictures you do not want to be deleted by mistake. • “ For details about the icon display during burst picture group playback, refer to About display of ” [FAVORITE], [PRINT SET] and [PROTECT] icons during playback of burst picture groups. on P156.
Advanced (Playback) [DELETE] Pictures can be deleted. Pictures cannot be restored once deleted. Select [DELETE] on the [PLAYBACK] Mode menu. (P28) Press 3/4 to select the item and then press [MENU/SET]. • When [SINGLE IN BURST GROUP] or [MULTI IN BURST GROUP] is selected, press 3/4/2/1 to select Burst Picture Group, and press [MENU/SET] to proceed to step [SINGLE]...
Advanced (Playback) [FACE REC EDIT] You can delete or change the information relating to Face Recognition for the selected picture. Select [FACE REC EDIT] on the [PLAYBACK] Mode menu. (P28) Press 3/4 to select [REPLACE] or [DELETE] and then press [MENU/SET]. Press 2/1 to select the picture and then press [MENU/SET].
• Only pictures recorded with a Panasonic digital camera (LUMIX) will be copied. (Even if the pictures were recorded with a Panasonic digital camera, you may not be able to copy them if they were edited with a PC.) •...
Connecting to other equipment ¸ [PLAYBACK] Mode: Connecting to other equipment Playing Back Pictures on a TV Screen Playing back pictures using the AV cable (supplied) Preparations: Set the [TV ASPECT]. (P37) Turn this unit and the TV off. 1 Yellow: to the video input socket 2 White: to the audio input socket 3 Red: to the audio input socket A Align the marks, and insert.
Depending on the TV model, pictures may not be displayed on the full screen. • Motion pictures recorded with [AVCHD] can be played back on Panasonic TVs (VIERA) with the AVCHD logo mark. In all other cases, connect the camera to the TV using the AV cable (supplied) and playback the motion picture.
HDMI compatible high definition TV and then play back the recorded high definition images, you can enjoy them in high resolution with high quality sound. If you connect this unit to a Panasonic TV compatible with VIERA Link, linked operations (VIERA Link) are possible. (P187) Preparations: Check the [HDMI MODE].
Page 186
Depending on the [ASPECT RATIO], bands may be displayed on the top and bottom or the left and right of the pictures. • Always use a genuine Panasonic HDMI mini cable (RP-CDHM15, RP-CDHM30; optional). Part numbers: RP-CDHM15 (1.5 m) (5 feet), RP-CDHM30 (3.0 m) (10 feet) •...
Page 187
What is the VIERA Link? • This function allows you to use your remote control for the Panasonic TV for easy operations when this unit has been connected to a VIERA Link compatible device using a HDMI mini cable (optional) for automatic linked operations. (Not all operations are possible.) •...
Page 188
Connecting to other equipment ∫ Usable functions Operate with the remote control for the TV. This is displayed initially when using the VIERA Link. Select the image. 3/4/2/1: [OK]: Go to one screen display. Pictures in Burst Picture Group are played Multi Playback back with Multi Playback.
Page 189
Available linked operations between this unit and a Panasonic TV is different depending on the types of Panasonic TVs even if they are compatible with VIERA Link. Refer to the operating instructions of the TV for the operations that support on the TV.
Connecting to other equipment Saving the recorded still pictures and motion pictures Methods to export still pictures and motion pictures to other devices will vary depending on the file format. (JPEG, RAW, AVCHD, or Motion JPEG). Here are a few suggestions. Copy the playback image using an AV cable File formats that can be used: [AVCHD], [Motion JPEG] Copy images played back with this unit to DVD disc, hard disk, or video using a DVD...
Connecting to other equipment Copying to a PC using “PHOTOfunSTUDIO 5.2 HD Edition” File formats that can be used: [JPEG], [RAW], [AVCHD], [Motion JPEG] It is possible to acquire still pictures and motion pictures recorded in [AVCHD] or [MOTION JPEG] formats, or create conventional standard quality DVD video from the motion picture that was recorded as [AVCHD], using “PHOTOfunSTUDIO 5.2 HD Edition”...
(Doing so will cause recorded images to be erased so do not choose to format.) If the card is not recognised, please refer to the below support site. http://panasonic.net/avc/sdcard/information/SDXC.html • You can easily print out or mail the pictures you have imported. Use of the “PHOTOfunSTUDIO 5.2 HD Edition”...
Page 193
Connecting to other equipment Acquiring of still pictures and [MOTION JPEG] motion pictures (other than [AVCHD] motion pictures) Preparations: Turn on the camera and the PC. Remove the card before using the pictures in the built-in memory. A USB connection cable (supplied) •...
Page 194
Connecting to other equipment Double-click on [Removable Disk] in [My Computer]. • When using a Macintosh, the drive is displayed on the desktop. (“LUMIX”, “NO_NAME” or “Untitled” is displayed.) Double-click [DCIM] folder. Using a drag-and-drop operation, move the pictures you want to acquire or the folder storing those pictures to any different folder on the PC.
Page 195
Connecting to other equipment ∫ Viewing the contents of the built-in memory or card using the PC (folder composition) Folders and images processed in the PC cannot be played back on the camera. It is recommended to use the “PHOTOfunSTUDIO 5.2 HD Edition” bundled software on the CD-ROM (supplied) when you write the image from PC to a card.
Connecting to other equipment Printing the Pictures If you connect the camera to a printer supporting PictBridge, you can select the pictures to be printed out and instruct that printing be started on the camera’s LCD monitor. • Burst pictures will be displayed as a list, and not as a group. •...
Connecting to other equipment Note • Do not use any other USB connection cables except the supplied one. Use of cables other than the supplied USB connection cable may cause malfunction. • Turn the camera off before connecting or disconnecting the AC adaptor (optional). •...
Connecting to other equipment Selecting multiple pictures and printing them Press 3. PictBridge Press 3/4 to select an item and then press MULTI SELECT [MENU/SET]. SELECT ALL PRINT SET(DPOF) • If the print check screen has appeared, select [YES], and print FAVORITE the pictures.
Connecting to other equipment Print Settings Select and set the items both on the screen in step of the MULTI SELECT “Selecting a single picture and printing it” and in step of the PRINT START “Selecting multiple pictures and printing them” procedures. PRINT WITH DATE NUM.
Page 200
Connecting to other equipment [PAPER SIZE] Item Description of settings Settings on the printer are prioritised. [L/3.5qk5q] 89 mmk127 mm [2L/5qk7q] 127 mmk178 mm [POSTCARD] 100 mmk148 mm [16:9] 101.6 mmk180.6 mm [A4] 210 mmk297 mm [A3] 297 mmk420 mm [10k15cm] 100 mmk150 mm [4qk6q]...
Page 201
Connecting to other equipment [PAGE LAYOUT] (Layouts for printing that can be set with this unit) Item Description of settings Settings on the printer are prioritised. 1 picture with no frame on 1 page á 1 picture with a frame on 1 page â...
Others Others Using the Conversion Lens (optional) With the optional conversion lenses, you can record even more faraway pictures and take close-up pictures of smaller subjects. Refer to P149 for details. Preparations: Remove the lens cap and lens hood. Attach the lens adapter. •...
Page 203
Others Select [CONVERSION] on the [REC] menu. (P28) • P149 Refer to for [CONVERSION]. Press 3/4 to select [ ], and then press [MENU/SET] to set. • Set in same way to select [ ] too. • Always set to [OFF] when the conversion lens is taken off. Note •...
Others Using the Protector/Filter (optional) The MC protector (DMW-LMC52; optional) is a transparent filter which affects neither the colours nor the amount of light, so it can always be used to protect the camera’s lens. The ND filter (DMW-LND52; optional) reduces the amount of light to approximately 1/8th (equal to adjusting the aperture value 3 increments) without affecting the colour balance.
Others Using an external flash (optional) After attaching the external flash, the effective range will be increased when compared to the camera’s built in flash. Preparations: • Turn off the camera and close the built-in flash. ∫ Using the dedicated flash (DMW-FL220, DMW-FL360, DMW-FL500; optional) Attach the dedicated flash to the hot shoe A and then turn on the camera and the dedicated flash.
Page 206
Others Note • You can set the aperture value, the shutter speed and the ISO sensitivity on the camera even when attaching the external flash. • Some commercial external flashes have synchro terminals with high-voltage or reversed polarity. Using such extra flashes may cause a malfunction or the camera may not operate normally.
• Slide it to the other side to cancel [LOCK]. Note • Always use a genuine Panasonic remote shutter (DMW-RSL1; optional). • You cannot operate the camera with the remote shutter in the following cases. – When the Sleep Mode is cancelled •...
Others Using the External Microphone (optional) If you use the stereo microphone (DMW-MS1; optional), you can switch to either stereo or monaural sound recording. It is also possible to reduce the wind noise efficiently by switching the [WIND CUT OFF/ ON] switch to [ON].
Others Cautions for Use Optimal use of the camera Take care not to drop or knock the unit or put a lot of pressure on it. • Take care not to knock or drop the bag/case that you inserted the camera in as the shock may cause damage to the camera, lens or LCD monitor.
Page 213
Others Cleaning Before cleaning the camera, remove the battery or the DC coupler (optional), or disconnect the power plug from the outlet. Then wipe the camera with a dry soft cloth. • When the camera is soiled badly, it can be cleaned by wiping the dirt off with a wrung wet cloth, and then with a dry cloth.
Page 214
Others Battery The battery is a rechargeable lithium ion battery. Its ability to generate power comes from the chemical reaction that takes place inside it. This reaction is susceptible to the surrounding temperature and humidity. If the temperature is too high or too low, the operating time of the battery will become shorter.
Page 215
Information including personal information may be altered or vanish due to erroneous operation, effect of static electricity, accident, malfunction, repair, or other handlings. Please note in advance that Panasonic is not liable in any way for any direct or indirect damage from the alteration or vanishing of information or personal information.
Page 216
About the picture data • Recorded data may be damaged or lost if the camera breaks down due to inappropriate handling. Panasonic will not be liable for any damage suffered due to loss of recorded data. About tripods or unipods •...
Others Message Display Confirmation messages or error messages will be displayed on the screen in some cases. The major messages are described below as examples. [THIS MEMORY CARD IS WRITE-PROTECTED] > The Write-Protect switch on the card is moved to [LOCK]. Move the switch back to unlock (P24) [NO VALID PICTURE TO PLAY] >...
Page 218
Others [BUILT-IN MEMORY ERROR FORMAT BUILT-IN MEMORY?] • This message will be displayed when you formatted the built-in memory on a PC. > Format the built-in memory on the camera again. (P39) The data on the built-in memory will be deleted. [MEMORY CARD ERROR FORMAT THIS CARD?] •...
Page 219
[THIS BATTERY CANNOT BE USED] • The battery cannot be recognised by the camera. > Use a genuine Panasonic battery. If this message is displayed even when a genuine Panasonic battery is used, contact the dealer or your nearest Service Centre. •...
Others Troubleshooting First, try out the following procedures (P220–229). If the problem is not resolved, it may be improved by selecting [RESET] (P36) on the [SETUP] menu when taking pictures. Battery and power source The camera cannot be operated even when it is turned on. •...
Page 221
Others Recording The picture cannot be recorded. • Is the mode dial correctly set? • Is there any memory remaining on the built-in memory or the card? > Delete the pictures which are not necessary to increase the available memory. (P64) The recorded picture is whitish.
Page 222
Others Taking pictures using Auto Bracket is not possible. • Is the number of recordable pictures 2 or less? The recorded picture looks rough. Noise appears on the picture. • Is the ISO sensitivity high or the shutter speed slow? (ISO sensitivity is set to [AUTO] when the camera is shipped.
Page 223
Others Reddish horizontal streaks appear on the LCD monitor during recording. • This is characteristic of MOS sensors which serve as the camera’s pickup sensors. It appears when the subject has a bright part. Some unevenness may occur in the surrounding areas, but this is not a malfunction.
Page 224
Others LCD monitor/Viewfinder The LCD monitor/Viewfinder turns off although the camera is turned on. • LCD monitor will turn off when [AUTO LCD OFF] (P35) of the [ECONOMY] Mode is activated. [This does not happen when using the AC adaptor (optional).] The LCD monitor/Viewfinder becomes darker or brighter for a moment.
Page 225
Others Playback The picture being played back is rotated and displayed in an unexpected direction. • [ROTATE DISP.] (P175) is set to [ON]. The picture is not played back. There are no recorded pictures. • Did you press [(]? • Is there a picture on the built-in memory or the card? >...
Page 226
> Connect the camera to the TV with the AV cable (supplied), or with the HDMI mini cable (optional), and then play back the motion pictures on the camera. (P183, 185) > Motion pictures recorded in [AVCHD] can be played back on Panasonic televisions (VIERA) with the AVCHD logo. - 226 -...
Page 227
The card is not recognised by the PC. (SDXC memory card is used) > Check if your PC is compatible with SDXC memory cards. http://panasonic.net/avc/sdcard/information/SDXC.html > A message prompting to format the card may be displayed when connecting, but do not format.
Page 228
Others Others An unreadable language was selected by mistake. > Press [MENU/SET], select the [SETUP] menu icon [ ] and then select the [~] icon to set the desired language. (P40) A red lamp sometimes turns on when the shutter button is pressed halfway. •...
Page 229
Others When pictures are taken using the zoom, they are slightly distorted and the areas around the subject contain colours which are not actually present. • At some magnification levels, the pictures taken are slightly distorted or the outlines and other areas in the pictures taken are coloured, but this is not a malfunction.
Others Number of Recordable Pictures and Available Recording Time • The number of recordable pictures and the available recording time are an approximation. (These vary depending on the recording conditions and the type of card.) • The number of recordable pictures and the available recording time varies depending on the subjects.
Page 238
Others ∫ Available recording time (when recording motion pictures) File format [AVCHD(1080i)] [AVCHD(720p)] Recording quality setting Built-in Memory Cannot be used. (Approx. 40 MB) 512 MB 2 min 00 s 3 min 00 s 2 min 00 s 3 min 00 s 1 GB 6 min 00 s 8 min 00 s...
Page 239
Others File format [MOTION JPEG] Recording quality setting Built-in Memory Cannot be used. 1 min 18 s Cannot be used. (Approx. 40 MB) 512 MB 1 min 30 s 3 min 50 s 4 min 00 s 11 min 10 s 1 min 28 s 1 GB 3 min 30 s...
Page 240
Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. • HDAVI Control™ is a trademark of Panasonic Corporation. • QuickTime and the QuickTime logo are trademarks or registered trademarks of Apple Inc., used under license therefrom.
