Indicates the MIDI Transmit Channel used in the Keyboard display.
Indicates the MIDI Transmit Channel used in the Drum Pad display.
Tapping this changes the screen to the Keyboard display.
This window lets you set the parameters common to the Keyboard and Drum Pad displays.
Keyboard Arp & Drum Pad Owner's Manual
Utility window
Sets the MIDI Transmit Channel from the Keyboard display.
Sets the MIDI Transmit Channel from the Drum Pad display.
When set to "kbd-ch," the Drum Pad display lets you control Arpeggio playback via the Keyboard Transmit Channel.
Determines the connection method between the iPad and MIDI instrument.
cable: Should be selected when connected via the i-MX1.
wireless: Should be selected when connected via wireless Network MIDI.
NOTE
When set to "wireless," please make the Wi-Fi setup in Settings > Wi-Fi in your iPad.
Selects the MIDI port of the instrument in case of wireless connection.
Determines the Velocity transmitted when tapping a key in the Keyboard display.
Determines the MIDI Control Change number assigned to "ASSIGN1" in the Slider section of the Keyboard display.
Determines the MIDI Control Change number assigned to "ASSIGN2" in the Slider section of the Keyboard display.
Determines the Modulation speed when [MODULATION] is tapped in the Keyboard display.
Tapping this calls up the Owner's Manual.
Tapping here initializes all the settings.
Indicates the program version.
Title bar
Tapping this changes the screen to the Drum Pad display.
Each lamp flashes according to the MIDI in/out messages.
Tapping this opens or closes the Utility window.
2
