Multimedia Projector
PLC-XU115
MODEL
Owner's Manual
Network Supported
□ Wireless LAN
IEEE802.11b/g
□ Wired LAN
100-Base-TX/10-Base-T
Memory Viewer
□ SD Card Memory Viewer
* Refer to the owner's manuals below for details
about network and memory viewer function.
■
Network Set-up and Operation
Memory viewer
■
Advertisement
Table of Contents
Related Manuals for Sanyo PLC XU115 - XGA LCD Projector
Summary of Contents for Sanyo PLC XU115 - XGA LCD Projector
- Page 1 Multimedia Projector Network Supported □ Wireless LAN IEEE802.11b/g PLC-XU115 MODEL □ Wired LAN 100-Base-TX/10-Base-T Memory Viewer □ SD Card Memory Viewer * Refer to the owner’s manuals below for details about network and memory viewer function. ■ Network Set-up and Operation Memory viewer ■ Owner’s Manual...
-
Page 3: Features And Design
Features and Design This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. Compact Design Security Function ◆ ◆ This projector is designed compact in size and weight. The Security function helps you to ensure security It is easy to carry and installed anywhere you wish to of the projector. With the Key lock function, you can use. lock the operation on the top control or remote control (p.54). PIN code lock function prevents unauthorized Capable of 60-degree Projection ◆... -
Page 4: Table Of Contents
Table of Contents Features and Design . . . . . . . . . . . . . . . . . . . Input Source Selection (RGB(PC digital), RGB(AV HDCP)) Table of Contents . -
Page 5: To The Owner
A BREAKDOwN OR A DISASTER . IF THE PROjECTOR countries in the other area of the world. COMES IN CONTACT wITH OIL OR CHEMICALS, IT MAy BECOME DETERIORATED . Your SANYO product is designed and manufactured with high quality materials and components which can be recycled CAUTION and reused. -
Page 6: Safety Instructions
Safety Instructions All the safety and operating instructions should be read Do not install the projector near the ventilation duct of before the product is operated. air-conditioning equipment. Read all of the instructions given here and retain them This projector should be operated only from the type for later use. Unplug this projector from AC power supply of power source indicated on the marking label. If you before cleaning. Do not use liquid or aerosol cleaners. -
Page 7: Air Circulation
Safety Instructions Air Circulation Moving the Projector Openings in the cabinet are provided for ventilation. To When moving the projector, replace the Lens Cap and ensure reliable operation of the product and to protect it retract adjustable feet to prevent damage to the lens from overheating, these openings must not be blocked and cabinet. -
Page 8: Installing The Projector In Proper Directions
Safety Instructions Installing the Projector in Proper Directions Use the projector properly in specified positions. Improper positioning may reduce the lamp life and result in severe accident or fire hazard. This projector can project the picture upward, downward, or backward, perpendicular to the plane of the screen as shown in the figure below. 50º 50º Bottom Front Bottom Front 40º 40º Downward Upward Upward Downward (Usual) 180º 0º Be sure to set the Lamp control in High and the Fan control in On 3 in the setting menu when using the projector inclined at between +40 degrees to +140 degrees to the horizontal plane at altitudes between 0 and approximately 1,600 meters above sea level. Be sure to set the Fan control in On 2 when using the projector at higher altitudes than the altitudes described above, regardless of the installation position of the projector. (p.56). Positioning Precautions Avoid positioning the projector as described below when installing. 10˚ Do not roll the projector more than 10 degrees from side to side. +50º 0º... -
Page 9: Compliance
– I ncrease the separation between the equipment and receiver. – C onnect the equipment into an outlet on a circuit different from that to which the receiver is connected. – C onsult the dealer or an experienced radio/TV technician for help. Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules. Do not make any changes or modifications to the equipment unless otherwise specified in the instructions. If such changes or modifications should be made, you could be required to stop operation of the equipment. Model Number : PLC-XU115 Trade Name : Sanyo Responsible party : SANYO FISHER COMPANY Address : 21605 Plummer Street, Chatsworth, California 91311 Telephone No. : (818)998-7322 AC Power Cord Requirement The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it. AC Power Cord for the United States and Canada: AC Power Cord used in the United States and Canada is listed by the Underwriters Laboratories (UL) and certified by the Canadian Standard Association (CSA). -
Page 10: Part Names And Functions
Part Names and Functions Front Infrared Remote Receiver ① wIRELESS Indicator ② Focus Ring ③ Projection Lens ④ Zoom Lever ⑤ Lens Cap ⑥ CAUTION Do not turn on a projector with lens cap attached. High temperature from light beam may damage lens cap and result in fire hazard. -
Page 11: Rear Terminal
Part Names and Functions Rear Terminal ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ R/C jACK VIDEO IN ① ⑧ When using the wired remote control, connect Connect the composite video output signal to this the wired remote control to this jack with a remote jack (p.20). -
Page 12: Top Control
Part Names and Functions Top Control ① ⑦ ② ⑧ ⑨ ③ ⑩ ④ ⑤ ⑥ ① LAMP REPLACE indicator ⑦ wARNING indicator Lights yellow when the projection lamp reaches its – L ights red when the projector detects an abnormal end of life (pp.61, 69). condition. – B links red when the internal temperature of the ② ON/STAND–By button projector exceeds the operating range (pp.58, 69). -
Page 13: Remote Control
Part Names and Functions Remote Control ① L-CLICK button Act as the left mouse button for wireless mouse operation. (p.15) ② POwER ON/STAND-By button Turn the projector on or off. (pp.22-23) ③ wIRED REMOTE jack Connect the remote control cable(not supplied) to this jack when using as a wired remote control.Wireless remote control does not work when the remote control cable is connected to the projector ④ SIGNAL EMISSION indicator ① Lights red while the laser beam is being emitted from the laser light window or a signal is being sent from the remote control to the projector. ⑤ LASER LIGHT window A laser beam is emitted from here (p.14). -
Page 14: Laser Pointer Function
Part Names and Functions Laser Pointer Function This remote control emits a laser beam from the laser light window. Press the LASER button to activate the laser pointer. The signal emission indicator lights red and the red laser beam is emitted. If the LASER button is pressed for more than one minute or if it is released, the laser light goes off. The laser emitted is a Class II laser. Do not look into the laser light window or point the laser beam at yourself or other people. The following is the caution label for the laser beam. CAUTION: Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Never look directly into the laser light window while a laser is emitted, otherwise eye damage may result. The caution label is put on the remote control. Signal Emission Indicator Laser Light Window Pointer Function You can move the Spotlight or Pointer of the projector with the remote control to emphasize a part of the projected image. -
Page 15: Wireless Mouse Operation
Part Names and Functions wireless Mouse Operation The remote control can be used as a wireless mouse for your computer. Before operating the wireless mouse, connect your computer and the projector with a USB cable (not supplied). See “Connecting to a PRESENTATION POINTER Computer” on page 19. When the Pointer button function is used, the wireless mouse is not Move the pointer on the screen available. -
Page 16: Remote Control Battery Installation
Part Names and Functions Remote Control Battery Installation Open the battery Install new batteries Replace the compartment lid. into the compartment. compartment lid. Press the lid Two AAA size downward and slide it. batteries For correct polarity (+ and –), be sure battery terminals are in contact with pins in compartment. To ensure safe operation, please observe the following precautions : ● Use two (2) AAA or LR03 type alkaline batteries. ● Always replace batteries in sets. ● Do not use a new battery with a used battery. ● Avoid contact with water or liquid. ● Do not expose the remote control to moisture or heat. ● Do not drop the remote control. ● If the battery has leaked on the remote control, carefully wipe the case clean and install new batteries. ● Risk of an explosion if battery is replaced by an incorrect type. -
Page 17: Installation
Installation Positioning the Projector For projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the screen. Notes: • The brightness in the room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain the best image. • All measurements are approximate and may vary from the actual sizes. A ： B ＝ 9 ： 1 37.4’ (11.4 m) 23.6’ (7.2 m) 300"... -
Page 18: Connecting The Ac Power Cord
Installation Connecting the AC Power Cord This projector uses nominal input voltages of 100-120 V or 200–240 V AC and it automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system. If you are not sure of the type of power being supplied, consult your authorized dealer or service station. -
Page 19: Connecting To A Computer
Installation Connecting to a Computer Cables used for connection • VGA Cable (Mini D-sub 15 pin) * • DVI-VGA Cable • DVI Cable • USB Cable • Audio Cables (*One cable is supplied; other cables are not supplied with the projector.) Monitor Monitor Monitor Monitor Audio Output USB port External Audio Equipment Output Input Output Output Audio Input USB cable VGA cable VGA cable DVI-VGA cable cable Audio cable (stereo) COMPUTER IN 2/ MONITOR COMPUTER IN 1 Audio cable COMPONENT DVI-I (stereo) AUDIO OUT... -
Page 20: Connecting To Video Equipment
Installation Connecting to Video Equipment Cables used for connection • Video and Audio Cable (RCA x 3) • S-VIDEO Cable • Audio Cable (Cables are not supplied with the projector. ) Composite Video and Audio Output S-video Output (Video) External Audio Equipment S-video cable Video and audio cable Audio Input VIDEO AUDIO IN S-VIDEO Audio cable (stereo) KB3AC AUDIO OUT (stereo) Notes: • When the AUDIO OUT is plugged-in, the projector's built- in speaker is not available. Unplug the power cords of • The S-VIDEO jack connection overrides the VIDEO both the projector and external jack connection when selecting AUTO in the Input Menu equipment from the AC outlet... -
Page 21: Connecting To Component Video Equipment
Installation Connecting to Component Video Equipment Cables used for connection • Audio Cables • Scart-VGA Cable • Component Cable • Component-VGA Cable (Cables are not supplied with this projector.) RGB Scart 21- Component Video Output pin Output (Y, Pb/Cb, Pr/Cr) Audio Output Component cable External Audio Equipment Scart-VGA Audio cable cable (stereo) Component- VGA cable Audio Input COMPUTER/ COMPONENT COMPUTER IN 2/COMPONENT IN AUDIO IN Audio cable (stereo) KB3AC AUDIO OUT (stereo) Notes: • When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available. -
Page 22: Basic Operation
Basic Operation Turning On the Projector Complete peripheral connections (with a computer, VCR, etc.) before turning on the projector. Connect the projector’s AC power cord into an AC outlet. The POWER indicator lights red. Open the lens cap (see pages 10,60). Press the POWER ON/SYAND-BY button on the top control or on the remote control. The POWER indicator The preparation display will disappear lights green and the cooling fans start to operate. The after 30 seconds. preparation display appears on the screen and the count down starts. -
Page 23: Turning Off The Projector
Basic Operation Turning Off the Projector Press the POWER ON/STAND-BY button on the top control or on the remote control, and “Power off?” appears on the screen. Press the POWER ON/STAND-BY button again to turn off the projector. The POWER indicator starts to blink red, and the cooling fans keep running. (You can select the level of fans’ quietness and speed. See “Fan” on “Power off?” disappears after 4 seconds. -
Page 24: How To Operate The On-Screen Menu
Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Top Control Menu. For each adjustment and setting procedure, refer to the respective sections in this manual. MENU button Press the MENU button on the top control or the remote control to display the On-Screen Menu. -
Page 25: Menu Bar
Basic Operation Menu Bar For detailed functions of each menu, see “Menu Tree” on pages 67-68. For computer source Guide window PC System Menu Image Select Menu Screen Menu Setting Menu wireless Menu Show the selected Used to select Used to select an Used to adjust size Used to set See owner’s manual Menu of the On- computer system image mode among of the image [Normal/ the projector’s “Network Set-up and Screen Menu. (p.32). Dynamic, Standard, Real, T r u e / W i d e / F u l l / operating Operation”. -
Page 26: Zoom And Focus Adjustment
Basic Operation Zoom and Focus Adjustment Rotate the Zoom Lever to zoom in and out. Rotate the Focus Ring to adjust the focus of the image. Zoom Lever Focus Ring Auto Setup Function Auto setup function is provided to automatically correct Keystone distortion according to the projector’s tilt and adjust Top Control the computer display parameters (Fine sync, Total dots, and Picture position) by just pressing the AUTO SETUP/CANCEL button on the top control or the AUTO SET/CANCEL button AUTO SETUP/CANCEL on the remote control. The operational setup for the Auto button setup can be changed in the Setting menu. Refer to page 47... -
Page 27: Sound Adjustment
Basic Operation Sound Adjustment Top Control Direct Operation VOLUME+/- Volume buttons Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Remote Control Mute POINT▲button Press the MUTE button on the remote control to temporarily ◄) VOL- ( button turn off the sound. To turn the sound back on, press the ►) VOL+ ( button MUTE button again or press the VOLUME +/– buttons. The Mute function is also effective for the AUDIO OUT jack. -
Page 28: Remote Control Operation
Basic Operation Remote Control Operation Using the remote control for some frequently used operations is advisable. Just pressing one of the buttons enables you to make the desired operation quickly without calling up the On-Screen Menu. COMPUTER/VIDEO/NETwORK button Remote Control Press the COMPUTER, VIDEO, or NETWORK button on the remote control to select the input source. See pages 30- VIDEO button 31, 40-41 for details. COMPUTER button Refer to the owner's manual "Network Set-up and Operation"... -
Page 29: Image Button
Basic Operation NO SHOw button Press the NO SHOW button on the remote control to black out the image. To restore to normal, press the NO SHOW button again or press any other button. When a projected image is captured and set as “User” in the Logo selection (p.49), the screen changes each time you press the NO SHOW button as follows. -
Page 30: Computer Input
Computer Input Input Source Selection (RGB: Computer 1 (Analog)/Computer ) Direct Operation INPUT button Top Control Choose either Computer 1 (Analog) or Computer 2 by Computer 1 (Analog) pressing the INPUT button on the top control or press the COMPUTER button on the remote control. -
Page 31: Input Source Selection (Rgb(Pc Digital), Rgb(Av Hdcp))
Computer Input Input Source Selection (RGB(PC digital), RGB(AV HDCP)) Direct Operation Top Control INPUT button Choose Computer 1(Digital) by pressing the INPUT button on the top control or press the COMPUTER button on the Computer 1 (Analog) remote control. Before using these buttons, correct input source should be Computer 1 (Digital) selected through Menu operation as described below. -
Page 32: Computer System Selection
Computer Input Computer System Selection This projector automatically tunes to various types of computers based on VGA, SVGA, XGA, SXGA, WXGA, or UXGA with its Multi-scan system and Auto PC Adjustment. If a computer is selected as a signal source, this projector automatically detects the signal format and tunes to project a proper image without any additional settings. (Signal formats provided in this projector are shown on pages 70-71.) One of the following messages may appear when: The projector cannot recognize the connected PC System Menu Auto signal conforming to the provided PC Systems. The “Auto” is displayed on the System Menu box and the Auto PC Adjustment function works to display proper images. If the image is not... -
Page 33: Auto Pc Adjustment
Computer Input Auto PC Adjustment Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots, Horizontal and Vertical positions to conform to your computer. Direct Operation Remote Control The Auto PC adjustment function can be operated directly by pressing the AUTO PC button on the remote control. AUTO PC button Menu Operation PC Adjust Menu Auto PC Adj . Press the MENU button to display the On-Screen PC Adjust Menu icon Menu. Use the Point buttons to move the red ◄► frame pointer to the PC Adjust Menu icon. Use the Point buttons to move the red frame ▲▼... -
Page 34: Manual Pc Adjustment
Computer Input Manual PC Adjustment Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has five independent memory areas to store those parameters manually adjusted. It allows you to recall the setting for a specific computer. PC Adjust Menu Press the MENU button to display the On-Screen Menu. Use the Point buttons to move the red ◄►... - Page 35 Computer Input Display area H Use the Point buttons to adjust the horizontal area ◄► displayed by this projector. Display area V Use the Point buttons to adjust the vertical area displayed ◄► by this projector. Move the red frame pointer to the desired item and Reset press the SELECT button. To reset the adjusted data, select Reset and press the SELECT button. A confirmation box appears and then select [Yes]. All adjustments will return to their previous figures. Mode free This Mode has stored To clear adjusted data To clear the stored data, select Mode free and then press parameters.
-
Page 36: Image Mode Selection
Computer Input Image Mode Selection Direct Operation Remote Control IMAGE button Select the desired image mode from among Dynamic, Dynamic Standard, Real, Blackboard (Green), Image 1, Image 2, Image 3, and Image 4 by pressing the IMAGE button on the remote control. Standard Dynamic Real For viewing pictures in a bright room. IMAGE button Blackboard (Green) Standard Normal picture mode preset on the projector. Image 1 Real Picture mode with improved halftone for graphics. -
Page 37: Image Adjustment
Computer Input Image Adjustment Press the MENU button to display the On-Screen Menu. Image Adjust Menu Use the Point buttons to move the red frame pointer ◄► to the Image Adjust Menu icon. Use the Point buttons to move the red frame pointer ▲▼ Image Adjust Menu icon to the desired item and then press the SELECT button Move the red frame to display the adjustment dialog box. Use the Point ◄► pointer to the desired buttons to adjust the setting value. item and then press the SELECT button. Contrast Press the Point button to decrease the contrast; press the ◄ Point button to increase the contrast (from 0 to 63). ► Brightness Press the Point button to decrease the brightness; press ◄ Selected Image mode the Point button to increase the brightness (from 0 to 63). ► Color temp . Use the Point buttons to select the desired Color temp. -
Page 38: Screen Size Adjustment
Computer Input Store To store the adjusted data, select Store and press the SELECT button. Use the Point buttons to select one ▲▼ Image Mode Menu from Image 1 to 4 and press the SELECT button. Move the red frame A confirmation box appears and then select [Yes]. Stored pointer to an image data can be called up by selecting an “Image (1–4)” in the item to be set and t h e n p r e s s t h e Image Mode Selection on page 36. SELECT button. Quit Exit the Image Adjust Menu. -
Page 39: For Zooming In And Out The Images
Computer Input Custom Adjust the screen scale and position manually with this function. Press the SELECT button at Custom and the “Custom” is displayed on the screen for a few seconds and then the Aspect dialog box appears. Scale H/V .. Adjust the Horizontal/Vertical screen scale. H&V .... When set to “On,” the aspect ratio is fixed. The “Scale V” appears dimmed and becomes unavailable. Adjust “Scale H,”... -
Page 40: Video Input
Video Input Input Source Selection (Video, S-video) Direct Operation Top Control INPUT button Choose Video by pressing the INPUT button on the top INPUT button control or the VIDEO button on the remote control. Computer 1 (Analog) Before using these buttons, correct input source should be selected through menu operation as described below. Computer 1 (Digital) Computer Video wired... -
Page 41: Input Source Selection (Component, Rgb Scart 21-Pin)
Video Input Input Source Selection (Component, RGB Scart 1-pin) Direct Operation Top Control INPUT button Choose Computer 2 by pressing the INPUT button on the top control or press the COMPUTER button on the remote Computer 1 (Analog) control. Before using these buttons, correct input source should be Computer 1 (Digital) selected through Menu operation as described below. -
Page 42: Video System Selection
Video Input Video System Selection Press the MENU button to display the On-Screen Menu. Use the Point buttons to move the red ◄► frame pointer to the AV System Menu icon. Use the Point buttons to move the red arrow ▲▼ pointer to the desired system and then press the SELECT button. AV System Menu (Video or S-Video) Video or S-Video Auto The projector automatically detects an incoming video system, and adjusts itself to optimize its performance. AV System Menu icon When Video System is PAL-M or PAL-N, select the system The selected system is manually. displayed. PAL/SECAM/NTSC/NTSC ./PAL-M/PAL-N Move the pointer to the If the projector cannot reproduce proper video image, desired system and press... -
Page 43: Image Mode Selection
Video Input Image Mode Selection Direct Operation IMAGE button Remote Control Dynamic Select the desired image mode from among Dynamic, Standard, Cinema, Blackboard (Green), Image 1, Image 2, Image 3, and Image 4 by pressing the IMAGE button on the Standard remote control. Cinema Dynamic For viewing pictures in a bright room. Blackboard (Green) IMAGE button Standard Normal picture mode preset on the projector. Image 1 Cinema Image ... -
Page 44: Image Adjustment
Video Input Image Adjustment Press the MENU button to display the On-Screen Menu. Image Adjust Menu Use the Point buttons to move the red frame pointer ◄► to the Image Adjust Menu icon. Use the Point buttons to move the red frame ▲▼ Image Adjust Menu icon pointer to the desired item and then press the SELECT button to display the adjustment dialog box. Use the Move the red frame Point buttons to adjust the setting value. pointer to the desired ◄►... - Page 45 Video Input Sharpness Press the Point button to decrease the sharpness of the ◄ image; press the Point button to increase the sharpness ► of the image (from 0 to 15). Gamma Use the Point buttons to adjust the gamma value to ◄► obtain a better balance of contrast (from 0 to 15). Noise reduction Noise interference on the screen can be reduced. Select one of the following options to get smoother images. Off ..Disabled. L1 ..Lower reduction L2 ..Higher reduction Progressive An interlaced video signal can be displayed in progressive mode. Select one of the following options.
-
Page 46: Screen Size Adjustment
Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. Screen Menu Press the MENU button to display the On-Screen Menu. Use the Point buttons to move the red ◄► frame pointer to the Screen Menu icon. Use the Point buttons to move the red frame Screen Menu icon ▲▼ pointer to the desired function and then press the SELECT button. -
Page 47: Setting
Setting Setting This projector has a Setting menu that allows you to set up Setting Menu (Language) the other various functions described below. Press the MENU button to display the On-Screen Menu. Use the Point buttons to move the red ◄► Setting Menu icon frame pointer to the Setting Menu icon. Set the red frame pointer to the item Use the Point buttons to move the red frame ▲▼... - Page 48 Setting Keystone Keystone This function is used to store or reset the keystone correction when the AC power cord is unplugged. Use the Point buttons to switch between each option. ◄► Store .. Keep the keystone correction even when the AC power cord is unplugged. Use the Point ◄► Reset .. Release the keystone correction when the AC buttons to switch power cord is unplugged.
- Page 49 Setting Logo (Logo and Logo PIN code lock settings) This function allows you to customize the screen logo with Logo select, Capture, and Logo PIN code lock functions. Note: Logo select • When “On” is selected in the Logo PIN code lock function, Logo select and Capture functions cannot be selected.
- Page 50 Setting Logo PIN code lock Logo PIN code lock This function prevents an unauthorized person from changing the screen logo. Off .... The screen logo can be changed freely from the Logo Menu (p.49). On .... The screen logo cannot be changed without a Logo PIN code. If you want to change the Logo PIN code lock setting, press the SELECT button and the Logo PIN code dialog box appears. Enter a Logo PIN code by following the steps below. The initial Logo PIN code is set to “4321” at the factory.
- Page 51 Setting Ceiling Ceiling When this function is set to “On,” the picture will be top/ bottom and left/right reversed. This function is used to project the image from a ceiling-mounted projector. Rear When this function is set to “On,” the picture will be left/right Rear reversed. This function is used to project the image from rear of the screen. Input search This function detects the input signal automatically. When a signal is found, the search will stop. Use the Point ◄►...
- Page 52 Setting Standby mode This function is available when operating the projector via network. Normal .. Supply the power to the network function even after turning off the projector. You can turn on/ off the projector via network, modify network environment, and receive an e-mail about projector status while the projector is powered off.
-
Page 53: Lamp Control
Setting On start When this function is set to “On,” the projector will be automatically turned on just by connecting the AC power cord to a wall outlet. Note: • Be sure to turn off the projector properly (see “Turning Off the Projector” on page 23). If the projector is turned off in the incorrect sequence, the On start function does not work properly. Lamp control This function allows you to change brightness of the screen. -
Page 54: Key Lock
Setting Key lock Security (Key lock and PIN code lock ) This function allows you to use the Key lock and PIN code lock function to set the security for the projector operation. On 1 Key lock This function locks the top control and remote control buttons to prevent operation by unauthorized persons.. Unlocked.. Lock the operation of the top control. To unlock, use the remote control.. lock the operation of the remote control. To unlock, use the top control. - Page 55 Setting Enter a PIN code Enter a PIN code Use the Point buttons to enter a number. Press the ▲▼ Point button to fix the number and move the red frame ► pointer to the next box. The number changes to “.” If you fixed an incorrect number, use the Point button to move ◄ the pointer to the number you want to correct, and then enter the correct number. Repeat this step to complete entering a four-digit number. After a correct PIN code is entered, the following dialog After entering the four-digit number, move the pointer to...
- Page 56 Setting This function provides the following options in the cooling fans’ operation when the projector is turned off (p.23). L1 ..Normal operation L2 ..Slower and lower-sound than the normal operation (L1), but it takes more time to cool the projector On 1 down. Fan control Choose the running speed of cooling fans from the following options according to the ground elevation under which you use the projector. Off..Normal speed. Set this function to “Off” when using the projector in non-high altitude environment. On 1... Faster than Off mode. Select this mode when using Fan Control Setting the projector in high altitudes (about 1,200 meters or more above the sea level) where the fans have less cooling effect. On 2..Faster than On 1 mode. Select this mode when using the projector in higher altitudes than above 50º...
-
Page 57: Filter Counter
Setting Filter counter Filter counter This function is used to set a frequency for the filter cleaning. When the projector reached a specified time between cleanings, a Filter warning icon appears on the screen, On 1 notifying the cleaning is necessary. After cleaning the filter, Use the Point buttons ◄► be sure to select RESET and set the timer. The Filter to set the timer. Select warning icon will not turn off until the filter counter is reset. -
Page 58: Maintenance And Cleaning
Maintenance and Cleaning warning Indicator The WARNING indicator shows the state of the function which protects the projector. Check the state of the WARNING indicator and the POWER indicator to take proper maintenance. The projector is shut down and the wARNING Top Control indicator is blinking red . WARNING When the temperature inside the projector reaches a blinking red certain level, the projector will be automatically shut down to... -
Page 59: Cleaning The Filter
Maintenance and Cleaning Cleaning the Filters Filters prevents dust from accumulating on the optical elements inside the projector. Should the filters become clogged with dust particles, it will reduce cooling fans’ effectiveness and may result in internal heat buildup and adversely affect the life of the projector. If a “Filter warning” icon appears on the screen, clean the filters immediately. Clean the filter by following the steps below. -
Page 60: Attaching The Lens Cap
Maintenance and Cleaning Attaching the Lens Cap Lens Cap When moving this projector or while not using it over an extended period of time, replace the lens cap. Attach the lens cap according to the following procedures. Pass the string through a hole of the lens cap. Turn over the projector and remove the screw with a screwdriver. String for the lens cap Attach the string with lens cap to a hole at the bottom of the Secure it to the hole Hole projector and secure it with a screw. -
Page 61: Lamp Replacement
Maintenance and Cleaning Lamp Replacement When the projection lamp of the projector reaches its end of Top Control life, the Lamp replacement icon appears on the screen and LAMP REPLACE indicator lights yellow. Replace the lamp with a new one promptly. The timing when the LAMP REPLACE LAMP REPLACE indicator should light is depending on the lamp mode. -
Page 62: Resetting The Lamp Counter
Maintenance and Cleaning Resetting the Lamp Counter Be sure to reset the Lamp counter after the lamp is replaced. When the Lamp counter is reset, the LAMP REPLACE indicator stops lighting and the Lamp replacement icon disappears. Press the MENU button to display the On-Screen Menu. Use the Point buttons to move the red ◄►... -
Page 63: Appendix
Appendix Troubleshooting Before calling your dealer or service center for assistance, check the items below once again. – M ake sure you have properly connected the projector to peripheral equipment as described on pages 19-21. – M ake sure all equipment is connected to AC outlet and the power is turned on. – W hen the projector does not project an image from the connected computer, restart the computer. Problem: – Solutions No power – Plug the power cord of the projector into the AC outlet. – See if the POWER indicator lights red. – W ait until the POWER indicator stops blinking to turn on the projector again. The projector can be turned on after the POWER indicator turns red. See page 22. – Check the WARNING indicator. If the WARNING indicator lights red, projector cannot be turned on. See page 58. – Check the projection lamp. See page 61. – Unlock the Key lock function for the projector. See page 54. The initial display is not shown . – Make sure "Off" or "Countdown off" are not chosen at display function.(see page 48) The initial display is not same – Make sure "User" or "Off" are not chosen at Logo (select) as the default set . - Page 64 Appendix No image – Check the connection between your computer or video equipment and the projector. See pages 19-21. – See if the input signal is correctly output from your computer. Some laptop computers may need to change the setting for monitor output when connecting to a projector. See your computer’s instruction manual for the setting. – It takes about 30 seconds to display an image after turning on the projector. See page 22. – C heck the Input signal, color system, video system or computer system mode. – Make sure the temperature is not out of the specified Operating Temperature ( 41˚F–95˚F [5˚C–35˚C]) – When "No Show" is operating, the image cannot be displayed. Press the NO SHOW button or any other button on the remote control. No sound – Check the audio cable connection from audio input source. – Adjust the audio source. – Press the Volume + button. See page 27. – Press the Mute button. See page 27. – When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available – Is the image projected? You will hear the sound only when the image is projected. The color is strange . – Check the Input signal, color system,video system or computer system mode. – Make sure the "Blackboard" is not selected on Image select menu.(see page 36,43) Some displays are not seen – Check the Display function. See page 48.
- Page 65 Appendix The image is distorted or runs off . – Check "PC adjustment" menu or "Screen" menu and adjust them. (page 33-34, 38-39) PIN code dialog box appears – PIN code lock is being set. Enter a PIN code (the “1234” or numbers at start-up . you have set). See pages 22, 54–55. Page Up/Down function does – Make sure your computer is connected to the projector with USB not work . cable.(see page 19) – Check cable connection between the projector and your computer. (see page 19) The Remote Control does – Check the batteries. not work . – Make sure no obstruction is between the projector and remote control.
- Page 66 Appendix wARNING : High voltages are used to operate this projector . Do not attempt to open the cabinet . If problems still persist after following all operating instructions, contact the dealer where you purchased the projector or the service center. Specify the model number and explain about the problem. We will advise you how to obtain service. This symbol on the nameplate The CE Mark is a Directive conformity means the product is Listed mark of the European Community (EC).
-
Page 67: Menu Tree
Appendix Menu Tree Computer Input/Video Input Input Computer 1 (Analog) Go to System Computer 1 (Digital) RGB (PC digital) RGB (AV HDCP) Quit Computer 2 RGB Go to System Component Go to System RGB (Scart) Quit Video Auto Go to System Video Go to System S-video Go to System Quit Wired See owner’s manual “Network Set-up and Operation” Wireless See owner’s manual “Network Set-up and Operation” N/A ..not applicable Sound Sound Volume 0–63 Mute On/Off Quit... -
Page 68: Image Adjust
Appendix Video Input Setting Setting System Auto Language 16 languages provided. 1080i Quit 1035i Auto setup Auto PC adj. 720p On/Off 575p Auto keystone 480p Auto 575i Manual 480i Keystone Store/Reset System Auto Blue back On/Off Display On/Countdown off/Off SECAM Logo Logo select NTSC NTSC 4.43 Default PAL-M User PAL-N Capture Yes/No Logo PIN code lock... -
Page 69: Indicators And Projector Condition
Appendix Indicators and Projector Condition Check the indicators for projector condition. Indicators Projector Condition LAMP WARNING POWER REPLACE red/green yellow The projector is off. (The AC power cord is unplugged.) The projector is in stand-by mode. Press the POWER ON/STAND- BY button to turn on the projector. The projector is operating normally. The projector is preparing for stand-by or the projection lamp is being cooled down. The projector cannot be turned on until cooling is completed and the POWER indicator stops blinking. The projector is in the Power management mode. The temperature inside the projector is abnormally high. The projector cannot be turned on. When the projector is cooled down enough and the temperature returns to normal, the POWER ... -
Page 70: Compatible Computer Specifications
Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V-, H-Frequency mentioned below and less than 140 MHz of Dot Clock for analog signal and 110 MHz of Dot Clock for digital signal. When selecting these modes, PC adjustment can be limited. ON-SCREEN H-Freq . V-Freq . ON-SCREEN H-Freq . V-Freq . RESOLUTION RESOLUTION DISPLAy (KHz) (Hz) DISPLAy (KHz) (Hz) VGA 1 640 x 480 31.47 59.88 SXGA 1 1152 x 864 64.20 70.40 VGA 2 720 x 400 31.47 70.09 SXGA 2 1280 x 1024 62.50 58.60 VGA 3 640 x 400... - Page 71 Appendix When the input signal is digital from DVI terminal, refer to the chart below. ON-SCREEN H-Freq . V-Freq . ON-SCREEN H-Freq . V-Freq . RESOLUTION RESOLUTION DISPLAy (KHz) (Hz) DISPLAy (KHz) (Hz) D-VGA 640 x 480 31.47 59.94 D-SXGA1 1280 x 1024 63.98 60.02 D-480p 640 x 480 31.47 59.88 D-SXGA2 1280 x 1024 60.276 58.069 D-575p 768 x 575 31.25 50.00 D-SXGA3 1280 x 1024 31.65...
-
Page 72: Technical Specifications
Appendix Technical Specifications Mechanical Information Projector Type Multi-media Projector Dimensions (W x H x D) 334 mm x 78 mm x 257.5mm (Not including adjustable feet) Net Weight 3.6 kg Feet Adjustment 0˚ to 8.9˚ Panel Resolution LCD Panel System 0.8” TFT Active Matrix type, 3 panels Panel Resolution 1,024 x 768 dots Number of Pixels 2,359,296 (1,024 x 768 x 3 panels) Signal Compatibility Color System PAL, SECAM, NTSC, NTSC4.43, PAL-M, and PAL-N High Definition TV Signal 480i, 480p, 575i, 575p, 720p, 1035i, and 1080i Scanning Frequency H-sync. 15 kHz–100 kHz, V-sync. 50–100 Hz Optical Information Projection Image Size (Diagonal) Adjustable from 40” to 300” Throw Distance 3.1' (0.93m) - 37.6' (11.47m) Projection Lens F1.7–2.5 lens with f=19.2 mm–30.2 mm with manual zoom and focus Projection Lamp 275 W Interface Video Input Jack RCA Type x 1 S-video Input Jack... -
Page 73: Optional Parts
Appendix Accessories Owner’s Manual Quick Reference Guide AC Power Cord Remote Control and Batteries VGA Cable Serial Control Cable Lens Cap with String PIN Code Label Network Application (CD-ROM) Soft Carrying Case ● The specifications are subject to change without notice. ● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels. Optional Parts The parts listed below are optionally available. When ordering those parts, specify the item name and Model No. to the sales dealer. Model No. COMPONENT~VGA Cable : POA-CA-COMPVGA SCART~VGA Cable : POA-CA-SCART VGA-Cable (10 m) : KA-MC-DB10 REMOTE CONTROL CABLE (10m) : KA-VC-RC10 REMOTE CONTROL CABLE (0m) : POA-MC-RC30... -
Page 74: Pj Link Notice
Appendix Pj Link Notice This projector is compliant with PJLink Standard Class 1 of JBMIA (Japan Business Machine and Information System Industries Association). This projector supports all commands defined by PJLink Class 1 and is verified conformance with PJLink Standard Class 1. For PJ Link password, see page 49 on the owner’s manual “Network Set-up and Operation.” Projector Input PJLink Input Parameter Computer1 (Analog) RGB 1 RGB (PC digital) DIGITAL 1 Computer1 (Digital) RGB (AV HDCP) DIGITAL 2 RGB 2 Computer2 Component RGB 3 RGB (Scart) RGB 4 Auto VIDEO 1 Video Video VIDEO 2 S-video VIDEO 3 Wired NETWORK 1 Wireless NETWORK 2 PJLink is a registered trademark of JBMIA and pending trademark in some countries. -
Page 75: Configurations Of Terminals
Appendix Configurations of Terminals COMPUTER IN /COMPONENT IN /MONITOR OUT (ANALOG) Terminal: Analog RGB (Mini D-sub 15 pin) +5V Power / --- Red (R/Cr) Input/ R Output Green (G/Y) Input/ G Output Ground (Vert.sync.) Blue (B/Cb) Input/ B Output Ground ----- DDX Data / --- Ground (Horiz.sync.) Horiz. sync. Input (Composite H/V sync.) Ground (Red) Vert. sync. Ground (Green) DDC Clock / --- Ground (Blue) DVI-I TERMINAL (DIGITAL/ANALOG) Analog Red Input C1 C2 Analog Green Input Analog Blue Input Analog Horiz. sync... -
Page 76: Pin Code Number Memo
Appendix PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No . Factory default set No: 1 2 3 4* Logo PIN Code Lock No . Factory default set No: 4 3 2 1* *Should the four-digit number be changed, the factory set number will be invalid. While the projector is locked with the PIN code. Put the label below (supplied) on in a prominent place of the projector's body while it is locked with a PIN code. -
