What’s in the box/Setting up the speakers BDV-EF420 Connecting your TV BDV-EF220 Connecting other devices Main unit The on-screen Easy Setup Front speakers Subwoofer Playing a disc and using other functions...
Page 3
What’s in the box Speaker-bottom covers (2) Foot pads (2) Screws (with washer) (2) Screws (without washer) (6) Remote (BDV-EF420) (BDV-EF220) (BDV-EF420) (BDV-EF420) R6 (size AA) batteries (2) FM wire antenna (aerial) Dock for iPod/iPhone Video cord USB cable (BDV-EF420) (BDV-EF420) (TDM-iP30)
Page 4
Start by positioning the speakers according to the labels on the rear panel. SUBWOOFER FRONT L FRONT R Main unit...
Page 5
Next, connect the speakers to the main unit. For BDV-EF420, refer to the supplied “Speaker Installation Guide” for assembling the speakers.
Page 6
To enjoy high-quality video and audio, connect via a High Speed HDMI cable (not supplied). If your TV has no HDMI ARC jack, you also need a digital optical cord (not supplied) to enjoy TV sound through the system speakers.
Page 7
To connect your set-top box, game For FM radio, connect the supplied You can also connect your iPod or console, or digital satellite receiver, wire antenna (aerial) and extend it iPhone to the system and your TV make an audio connection to the for the best reception.
Page 8
Network settings can be found in and home network via a LAN the home menu (page 12). cable (not supplied). If you use For further details, visit: the optional USB Wireless LAN http://support.sony-europe.com/ Adapter, Wi-Fi is available. To a broadband router...
Page 9
Connect the AC power cord (mains lead) to a wall outlet (mains).
Press / to turn the system on. To ready the system for use, Once [Easy Initial Settings are “SETUP” appears in the front go through the on-screen Easy complete.] appears on the panel display. Initial Settings using the supplied screen, select [Finish] and the remote.
Page 11
To play a disc, press , then place the disc on the disc tray. Press again to close the disc tray. If playback does not start automatically, select in the [Video], [Music], or [Photo] category, and press Enjoy! ...
To access more features, simply press Examples: HOME. Listen to the radio through the system’s speakers Preset radio stations Access Internet content Play your iPod or iPhone through the system’s speakers ...
Presetting radio stations Press FUNCTION repeatedly until “FM” appears in the front panel display. Press and hold TUNING +/– until auto scanning starts. Press OPTIONS. Press / to select [Preset Memory], then press . Press / to select the preset FUNCTION number you want, then press .
Also consult the Operating Instructions on the following website: http://support.sony-europe.com/ The power does not turn on. Check that the AC power cord (mains lead) is securely ...
Page 16
This quick start guide saves paper To save natural resources, Sony has drastically reduced paper by no longer including full printed manuals. However, full operating instructions, and more, can be found online: http://support.sony-europe.com/ 4-418-867-41(1) 2012 Sony Corporation Printed in Malaysia...
