Panasonic KX-TG7733S Operating Instructions Manual

Link-to-cell bluetooth cellular convergence solution with 3 handset

Hide thumbs Also See for KX-TG7733S:

Brochure & specs (2 pages)

Service manual (105 pages)

Manual (40 pages)

Table Of Contents

Table of Contents

Quick Links

Summary of Contents for Panasonic KX-TG7733S

Page 1 Please read these operating instructions before using the unit and save them for future reference. Consulte “Guía Rápida Española”, página 73. For assistance, visit our Web site: http://www.panasonic.com/help for customers in the U.S.A. or Puerto Rico. Please register your product: http://www.panasonic.com/prodreg...
Page 2: Table Of Contents
Table of Contents Introduction Caller list ............44 Model composition ........3 Using Bluetooth Devices Accessory information ........4 Copying phonebook from a cellular phone Important Information (phonebook transfer) ........46 Using a Bluetooth wireless headset (optional) For your safety ..........7 for landline calls .........47 Important safety instructions ......8 For best performance ........8 Answering System for Landline...
Page 3: Introduction
– KX-TG7741 series Single handset models: Intercom calls can be made between handsets by purchasing and registering one or more optional handsets (page 5). Intercom calls can be made between the base unit and handset. For assistance, please visit http://www.panasonic.com/help...
Page 4: Accessory Information
Order number AC adaptor/PNLV226Z Telephone line cord/ PQJA10075Z Wall mounting adaptor/ PNKL1001Y1 Rechargeable batteries/ HHR-4DPA Handset cover PNYNTGA470BR Belt clip/PNKE1132Z1 Charger/PNLC1029ZS – KX-TG7731/KX-TG7741 KX-TG7732/KX-TG7742 KX-TG7733/KX-TG7743 KX-TG254SK KX-TG7745 The handset cover comes attached to the handset. For assistance, please visit http://www.panasonic.com/help...
Page 5 Introduction Additional/replacement accessories Please contact your nearest Panasonic dealer for sales information (page 82). Accessory item Order number Rechargeable HHR-4DPA batteries R To order, please call 1-800-332-5368 or visit http://www.panasonic.com/batterystore Battery type: – Nickel metal hydride (Ni-MH) – 2 x AAA (R03) size for each handset...
Page 6 : 1 max. (for a wireless hands-free conversation: page 47) Your cellular phone and headset must be Bluetooth wireless technology compatible. For more details and the list of compatible cellular phones, please visit our Web site: http://www.panasonic.com/link2cell For assistance, please visit http://www.panasonic.com/help...
Page 7: Important Information
Confirm that smoke has stopped emitting and contact external RF energy. the Panasonic Call Center at 1-800-211-PANA (1-800-211-7262). CAUTION R Unplug from power outlets and never touch the inside of the product if its casing has Installation and location been broken open.
Page 8: Important Safety Instructions
Failure to follow these instructions may cause the batteries to swell or explode. Base unit location/avoiding noise Attention: The base unit and other compatible Panasonic units use radio waves to communicate with each other. R For maximum coverage and noise-free communications, place your base unit: –...
Page 9: Other Information
ENERGY STAR guidelines for energy efficiency. ENERGY STAR is a U.S. registered mark. Other information CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. For assistance, please visit http://www.panasonic.com/help...
Page 10: Specifications
0 °C – 40 °C (32 °F – 104 °F), 20 % – 80 % relative air humidity (dry) Note: R Design and specifications are subject to change without notice. R The illustrations in these instructions may vary slightly from the actual product. For assistance, please visit http://www.panasonic.com/help...
Page 11: Getting Started
Getting Started n Charger Setting up Connections R Use only the supplied Panasonic AC adaptor PNLV226. Hooks R If you do not connect the telephone line cord and use only cellular lines, set the To power outlet cellular line only mode to use this unit more conveniently (page 20).
Page 12: Note When Setting Up
R Even after the batteries are fully charged, telephone line jack using a Panasonic the handset can be left on the base unit or T-adaptor (page 5).
Page 13: Intelligent Eco Mode
F G H I J Charge contacts Speaker HEADSET indicator Message counter MERASEN CELL 1 indicator CELL 2 indicator MnN (STOP) MjN/MkN (VOL.: Volume up/down) N (Repeat/Skip) N (PLAY) Message indicator MLOCATORN MANSWER ON/OFFN ANSWER ON/OFF indicator For assistance, please visit http://www.panasonic.com/help...
Page 14 N (PLAY) Ringer indicator Message indicator Message indicator MjN/MkN (VOL.: Volume up/down) Speaker N (Repeat/Skip) MjN/MkN (VOL.: Volume up/down) MHEADSETN M N (SP-PHONE: Speakerphone) HEADSET indicator N (TALK) MCELL 1N CELL 1 indicator Headset jack For assistance, please visit http://www.panasonic.com/help...
Page 15: Belt Clip
Equalizer is set. (page 24) Speakerphone is on. (page 22) Ringer volume is off. (page 35, 37) Silent mode is on. (page 40) Call sharing mode is off. (page 38) Alarm is on. (page 40) Handset number Battery level For assistance, please visit http://www.panasonic.com/help...
Page 16 Green A cellular phone is connected. (On) Ready to make/receive cellular calls. Green – The cellular line is in use. (Flashing) – Phonebook entries are being copied from a cellular phone (page 46). For assistance, please visit http://www.panasonic.com/help...
Page 17: Initial Settings
12-hour clock format is used. When Spanish is selected, 24-hour clock format is used. R The date and time may be incorrect after a power failure. In this case, set the date and time again. For assistance, please visit http://www.panasonic.com/help...
Page 18: Link To Cell
R The Bluetooth word mark and logos are R If not required, go to step 5. owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic MOFFN Corporation is under license. All other Note: trademarks identified herein are the R Make sure that your cellular phone is set to property of their respective owners.
Page 19: Link To Cell Settings
You can set the interval. The default handset and base unit use your cellular setting is “1 min”. phone’s ringer tone. Caller information is not announced even if the Talking Caller ID is turned on. For assistance, please visit http://www.panasonic.com/help...
Page 20 – you press MSP-PHONEN on the base unit MMENUN#157 while the cellular line only mode is turned on. (KX-TG7741 series: page 3) For assistance, please visit http://www.panasonic.com/help...
Page 21 R Please make note of your new PIN. The unit does not reveal the PIN to you. If you forget your PIN, see page 68. MMENUN#619 Enter the new 4-digit PIN. a MOKN Enter the new 4-digit PIN again. a MSAVEN For assistance, please visit http://www.panasonic.com/help...
Page 22: Making/Answering Calls Using The Handset
A pause is sometimes required when making R The unit starts dialing when: calls using a PBX or long distance service. – only 1 cellular phone is registered. When storing a calling card access number For assistance, please visit http://www.panasonic.com/help...
Page 23: Answering Calls
For CELL 1: MMENUN#6281 disconnected. For CELL 2: MMENUN#6282 R If another phone is connected to the same To change the landline ringer line, you can also take the call by lifting its volume: handset. MMENUN#160 For assistance, please visit http://www.panasonic.com/help...
Page 24 R This feature is not available while using the R Please contact your service provider/ speakerphone. telephone company for details and availability of this service in your area. Call share You can join an existing outside call. For assistance, please visit http://www.panasonic.com/help...
Page 25 Making/answering a landline call the call cannot be transferred to the handset during a conversation on a cellular line by the cellular phone. Perform the following with the handset. Press MMENUN during a cellular call. For assistance, please visit http://www.panasonic.com/help...
Page 26 To answer a 2nd call: R To hold the 2nd call: MMENUN a MbN: “Hold” a MSELECTN To hang up the 2nd call and return to the 1st call (cellular call), press MOFFN, then press MCELLN. For assistance, please visit http://www.panasonic.com/help...
Page 27: Making/Answering Calls Using The Base Unit
R You can also answer the cellular call by pressing MCELL 1N or MCELL 2N. MSP-PHONEN Speak into the microphone. Dial the phone number. When you finish talking, press When the other party answers, speak into MSP-PHONEN. the microphone. For assistance, please visit http://www.panasonic.com/help...
Page 28: Useful Features During A Call
R While a cellular line is on hold, the CELL 1 or CELL 2 indicator flashes red. While a landline call is on hold, the SP-PHONE indicator flashes. For assistance, please visit http://www.panasonic.com/help...
Page 29 Transferring a cellular call from a cellular phone to the base unit During a conversation using a cellular phone, press MCELL 1N or MCELL 2N. R The cellular call is transferred to the base unit. For assistance, please visit http://www.panasonic.com/help...
Page 30: Shared Phonebook
Character to one of 3 groups. You can search for & ’ – phonebook entries by group. The group ringer tone feature is available for Caller ID subscribers (page 43). For assistance, please visit http://www.panasonic.com/help...
Page 31 MSELECTN 2 times Searching by query MOFFN You can narrow down the search to enter the first characters of a name. Erasing entries N a * Erasing an entry Find the desired entry (page 31). a MERASEN For assistance, please visit http://www.panasonic.com/help...
Page 32 MMENUN on the handset in step 1 to change the dialing mode temporarily to tone. When adding entries to the phonebook, we recommend adding * (TONE) to the beginning of phone numbers you wish to chain dial (page 30). For assistance, please visit http://www.panasonic.com/help...
Page 33: Programming
Play new msg. – – #323 (msg.: message) Play all msg. – – #324 – – #325 Erase all msg. Greeting – #302 Record greeting Check greeting – #303 – #304 Pre-recorded (Reset to pre-recorded greeting) For assistance, please visit http://www.panasonic.com/help...
Page 34 – – #327 Answer on – – #328 Answer off Main menu: “V.M. access” (V.M.: Voice mail) Operation Code Listening to voice mail messages. #330 Main menu: “Intercom” Operation Code Paging the desired unit. #274 For assistance, please visit http://www.panasonic.com/help...
Page 35 1: <On (with #6141 (limited) Talking CID)> #6142 2: On (without Talking CID) 0: Off Registration – #6241 #6242 Phonebook – – #618 transfer Headset – #621 Add new device – #622 Connect Disconnect Registration – #621 For assistance, please visit http://www.panasonic.com/help...
Page 36 “Set date & time” Sub-menu 1 Sub-menu 2 Settings Code – – #101 Date and time Alarm – 1: Once #720 2: Daily 0: <Off> Time – 1: <Caller ID #226 – *1, *10 adjustment auto> 0: Manual For assistance, please visit http://www.panasonic.com/help...
Page 37 1: <On> 0: Off #332 VM tone detect Message alert – 1: <On> 0: Off #340 – 1–6: Level 1–6 <3> #145 – LCD contrast (Display contrast) – 1: <On> 0: Off #165 – Key tone For assistance, please visit http://www.panasonic.com/help...
Page 38 If you select one of the melody ringer tones, the ringer tone continues to play for several seconds even if the caller has already hung up. You may either hear a dial tone or no one on the line when you answer the call. For assistance, please visit http://www.panasonic.com/help...
Page 39 *16 Generally, the line mode setting should not be changed. This setting automatically maintains receiver volume at the proper level depending on the current telephone line condition. Set the line mode to “A” if telephone line condition is not good. For assistance, please visit http://www.panasonic.com/help...
Page 40: Special Programming
Silent mode allows you to select a period of “Handset 1” to “Handset 6” is displayed. time during which the handset will not ring for MMENUN#104 outside calls. This feature is useful for time periods when you do not want to be disturbed, For assistance, please visit http://www.panasonic.com/help...
Page 41 R When editing, press the desired dial key to n From the caller list: add, MCLEARN to erase. MFN CID R When viewing, “Block w/o num” is displayed if the blocking incoming calls without phone number feature is turned on. For assistance, please visit http://www.panasonic.com/help...
Page 42: Registering A Unit
R When you purchase an additional handset, refer to the additional handset’s installation manual for registration. Deregistering a handset A handset can cancel its own registration to the base unit, or other handsets registered to For assistance, please visit http://www.panasonic.com/help...
Page 43: Caller Id Service
You can select the desired ringer tone to a phonebook is displayed and logged in the group that each phonebook entry is assigned caller list. For assistance, please visit http://www.panasonic.com/help...
Page 44: Caller List
The next time someone calls from the same Press MCN to search from the most recent area code, caller information is customized by call, or MDN to search from the oldest call. the unit as follows: For assistance, please visit http://www.panasonic.com/help...
Page 45 Storing caller information to the phonebook M N CID MbN: Select the desired entry. R To edit the number, press MSELECTN, then press MEDITN repeatedly until the phone number is shown in the desired format. MSAVEN For assistance, please visit http://www.panasonic.com/help...
Page 46: Using Bluetooth Devices
“Auto”: Download all entries from the cellular phone automatically. Go to step 5. “Manual”: Copy entries you selected. R “Select mode” menu is displayed only when the cellular phone supports PBAP (Phone Book Access Profile) for Bluetooth connection. For assistance, please visit http://www.panasonic.com/help...
Page 47: Using A Bluetooth Wireless Headset (Optional) For Landline Calls
R If you cannot hang up the call using your If you cannot connect the headset and base headset; unit using the headset, you can connect using – press MnN (STOP) on the base unit. the unit. (KX-TG7731 series: page 3) For assistance, please visit http://www.panasonic.com/help...
Page 48 While your headset is on a landline call: To join the conversation with the handset, press M Adjusting your headset receiver volume Base unit Press MjN or MkN repeatedly while using your headset. For assistance, please visit http://www.panasonic.com/help...
Page 49: Answering System For Landline
R If you adjust the speaker volume while message, the same message is still listening to messages or having a announced to callers even though their conversation, the speaker volume for call messages are not recorded. screening is turned on again. For assistance, please visit http://www.panasonic.com/help...
Page 50: Greeting Message
Listening to messages MMENUN#304 using the handset MYESN a MOFFN When new messages have been recorded: – “New message” is displayed. For assistance, please visit http://www.panasonic.com/help...
Page 51: Remote Operation
This code prevents unauthorized If pressed within the first 5 seconds of a parties from listening to your messages message, the previous message is remotely. The default setting is “111”. played. To resume playback: For assistance, please visit http://www.panasonic.com/help...
Page 52 R You can either hang up, or enter your remote access code again and begin Note: remote operation (page 51). R If you do not press any dial keys within 10 seconds after a voice guidance prompt, the unit disconnects your call. For assistance, please visit http://www.panasonic.com/help...
Page 53: Answering System Settings
It is necessary MMENUN#340 to check the number of rings required to MbN: Select the desired setting. a activate the voice mail service provided MSAVEN a MOFFN For assistance, please visit http://www.panasonic.com/help...
Page 54 Answering System for Landline Note: R While message alert is on, battery operating time is shortened (page 12). For assistance, please visit http://www.panasonic.com/help...
Page 55: Voice Mail Service For Landline
MPAUSEN to add pauses (page 22) The default setting is “On”. between the access number and the password as necessary. Contact your MMENUN#332 service provider/telephone company for the MbN: Select the desired setting. a required pause time. MSAVEN a MOFFN For assistance, please visit http://www.panasonic.com/help...
Page 56 # until the handset beeps. Base unit KX-TG7741 series: page 3 To listen to voice mail messages, you have to dial your voice mail access number manually. For assistance, please visit http://www.panasonic.com/help...
Page 57: Intercom/Locator
R To stop paging, press MINTERCOMN. When you finish talking, press MINTERCOMN. Answering an intercom call Handset Press M N to answer the page. When you finish talking, press MOFFN. Base unit KX-TG7741 series: page 3 For assistance, please visit http://www.panasonic.com/help...
Page 58: Transferring Calls, Conference Calls
R To page all handsets, press 0 or wait for a few seconds. Wait for the paged party to answer. R If paged party does not answer, press MINTERCOMN to return to the outside call. To complete the transfer: Press MSP-PHONEN. For assistance, please visit http://www.panasonic.com/help...
Page 59: Useful Information
Tuck the telephone line cord inside the wall mounting adaptor (A). Connect the AC adaptor cord and telephone line cord (B). Hook AC adaptor cord For assistance, please visit http://www.panasonic.com/help...
Page 60 (B). 83 mm inches) 102 mm (4 inches) Charger Drive the screws (not supplied) into the wall. 25.4 mm Wall phone plate (1 inch) 83 mm 102 mm inches) (4 inches) Screws Hooks For assistance, please visit http://www.panasonic.com/help...
Page 61: Error Messages
Register the handset (page 42). Requires subscription to R You must subscribe to a Caller ID service. Once you Caller ID. receive caller information after subscribing to a Caller ID service, this message will not be displayed. For assistance, please visit http://www.panasonic.com/help...
Page 62: Troubleshooting
Bluetooth device such as a Bluetooth headset, turn it off or disconnect it from your cellular phone. R Some cellular phones may require you to enter the base unit PIN to register. Confirm that you entered the correct PIN. For assistance, please visit http://www.panasonic.com/help...
Page 63 Cancel unused handset registrations from the base unit (page 42). Battery recharge Problem Cause/solution R Battery charge is low. Fully charge the batteries (page 12). The handset beeps and/or flashes. For assistance, please visit http://www.panasonic.com/help...
Page 64 R If someone is talking on a cellular call or using the headset, you cannot use the cellular feature. There can be only one active Bluetooth connection at a time. R The cellular phone is being used separately from your system. For assistance, please visit http://www.panasonic.com/help...
Page 65 Caller information is displayed R Depending on your service provider/telephone company, or announced late. the unit may display or announce the caller’s information at the 2nd ring or later. R Move closer to the base unit. For assistance, please visit http://www.panasonic.com/help...
Page 66 After subscribing, you may need to contact your service provider/telephone company again to activate this specific service, even if you already subscribed to both Caller ID and Call Waiting with Caller ID services (CWID). For assistance, please visit http://www.panasonic.com/help...
Page 67 AC adaptor to the base unit. Wait a feature. few seconds and try again. R The headset has not connected to the base unit yet, even though you performed the connecting procedure setting. Wait a few seconds and try again. For assistance, please visit http://www.panasonic.com/help...
Page 68 Bluetooth PIN Problem Cause/solution I cannot remember the PIN. R Change the PIN using the following method. MMENUN#619 *7000 Enter the new 4-digit PIN. a MOKN Enter the new 4-digit PIN again. a MSAVEN a MOFFN For assistance, please visit http://www.panasonic.com/help...
Page 69 Insert the batteries and charge fully before use. If the unit does not work properly, contact an authorized service center. Caution: R To avoid permanent damage, do not use a microwave oven to speed up the drying process. For assistance, please visit http://www.panasonic.com/help...
Page 70: Fcc And Other Information
(if But if advance notice isn't practical, the applicable) when using this phone. Consult telephone company will notify the customer with your audiologist or Hearing Aid as soon as possible. Also, you will be For assistance, please visit http://www.panasonic.com/help...
Page 71 If this equipment does cause units. harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is For assistance, please visit http://www.panasonic.com/help...
Page 72 Useful Information Compliance with TIA-1083 standard: Telephone handsets identified with this logo have reduced noise and interference when used with T-Coil equipped hearing aids and cochlear implants. Compatible with Hearing Aid T-Coil TIA-1083 For assistance, please visit http://www.panasonic.com/help...
Page 73: Guía Rápida Española
Guía Rápida Española Guía Rápida Española Instalación Unidad base L Use solo el adaptador de corriente Panasonic PNLV226 incluido. “Clic” Oprima firmemente el contacto. Gancho Correcto Incorrecto A la toma de corriente A la toma de teléfono de línea “Clic”...
Page 74 Después de que suene un pitido, sostenga el auricular a una distancia aproximada de 20 cm (8 pulgadas) y hable con claridad en el micrófono (máx. de 2 minutos). Oprima {ALTO} para dejar de grabar. s {OFF} Para obtener ayuda, visite http://www.panasonic.com/help (solo en ingls)
Page 75 L La marca denominativa y los logotipos de Bluetooth son propiedad de Bluetooth SIG, Inc. y cualquier uso de dichas marcas por parte de Panasonic Corporation se hace bajo licencia. Todas las demás marcas comerciales que se identifican en el presente pertenecen a sus respectivos propietarios.
Page 76 También puede reconectar manualmente el teléfono celular a la unidad base sin esperar a que la función de conexión automática reanude la conexión. Para conectarlo o desconectarlo: Para CELL 1: {MENU} (6251 (suena un pitido largo.) Para CELL 2: {MENU} (6252 (suena un pitido largo.) {OFF} Para obtener ayuda, visite http://www.panasonic.com/help (solo en ingls)
Page 77 {SP-PHONE} s Marque el número telefónico. Para hacer llamadas por la línea terrestre {SP-PHONE} Para contestar llamadas {SP-PHONE} Para colgar Oprima {+} o {-} repetidamente mientras habla. Para ajustar el volumen del altavoz Para obtener ayuda, visite http://www.panasonic.com/help (solo en ingls)
Page 78 Contestador encendido/apagado llamadas. {6} (PLAY) Para escuchar mensajes Contestador de llamadas de la línea terrestre (Auricular) Para escuchar mensajes nuevos: Para escuchar mensajes {MENU} (323 Para escuchar todos los mensajes: {MENU} (324 Para obtener ayuda, visite http://www.panasonic.com/help (solo en ingls)
Page 79 L Para otros teléfonos celulares (no registrados), necesita buscar y seleccionar la unidad base. Es posible que requiera el NIP de la unidad base (predeterminado: “0000”). L Las entradas que se están copiando aparecen en el auricular. Auricular: Espere a que aparezca “Completo”. s {OFF} Para obtener ayuda, visite http://www.panasonic.com/help (solo en ingls)
Page 80 Oprima {SP-PHONE} en la unidad base. *1 Serie KX-TG7731 L Solo puede cambiar entre la unidad base y su audífono. Encienda el audífono. Para ello, consulte las instrucciones de operación de su audífono. Para obtener ayuda, visite http://www.panasonic.com/help (solo en ingls)
Page 81 L Si ocurre el mismo problema aunque el auricular se encuentre enseguida de la unidad base, llame a soporte al cliente de Panasonic al 1-800-211- PANA (1-800-211-7262). L Sí, puede añadir hasta 6 auriculares (incluyendo los que se venden con ¿Es posible añadir otro...
Page 82: Appendix
TTY users (hearing or speech impaired users) can call 1-877-833-8855. Accessory Purchases (United States and Puerto Rico) Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting our Web Site at: http://www.pstc.panasonic.com or, send your request by E-mail to: npcparts@us.panasonic.com...
Page 83: Warranty (For United States And Puerto Rico)
If your product does not work properly because of a defect in materials or workmanship, Panasonic Corporation of North America (referred to as “the warrantor”) will, for the length of the period indicated on the chart below, which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or...
Page 84 L Send the unit to PSTC (Panasonic) Exchange Center, prepaid and adequately insured. L Do not send your unit to Panasonic Corporation of North America listed on the back cover or to executive or regional sales offices. These locations do not repair consumer products.
Page 85: Index
Index Eco mode: 13 Equalizer: 24 Index Error messages: 61 Flash: 24, 28 3-way conference: 25, 29 Groups: 30, 43 Additional handset: 42 Handset Alarm: 40 Deregistration: 42 Answering calls: 23, 27 Locator: 57 Answering system Name: 40 Call screening: 49 Registration: 42 Erasing messages: 50, 51, 52 Hold: 23, 28...
Page 86 Index Wall mounting: 59...
Page 87 Notes...
Page 88 Date of purchase (found on the bottom of the base unit) Name and address of dealer Attach your purchase receipt here. One Panasonic Way, Secaucus, New Jersey 07094 © Panasonic System Networks Co., Ltd. 2011 *TG7731* Printed in China *TG7731*...
