Connect the
External Preamp
Line Out to the
RP1000 Amp Loop
Return.
PREAMP
stompbox Output
to the RP1000
Stomp Loop Return.
Amp Loop with Pre-Amp In Line
Connect your guitar
to the RP1000's Input.
Connect the
RP1000 Amp
Loop Send to
the External
Preamp Input.
POWER AMP WITH SPEAKER CABS
Stomp Loop
Connect your guitar
to the RP1000's Input.
Connect the Connect the
RP1000 Stomp
Loop Send to the
stompbox Input.
Amp/Mixer switch on 1/4"
outputs is set to AMP.
Connect the RP1000's
1/4" Line Outputs to the
Power Amp inputs.
Amp/Mixer switch on 1/4"
outputs is set to AMP.
Connect the RP1000's
Left (mono) Line Output
to the amp's Input.
