CAM6.6T-S1 System
6-Zone, 6-Source
AM/FM Receiver and
UNO-S1 Smart Keypads
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Russound CAM66T 1

Summary of Contents for Russound CAM66T 1

  • Page 1 CAM6.6T-S1 System 6-Zone, 6-Source AM/FM Receiver and UNO-S1 Smart Keypads INSTRUCTION MANUAL...

  • Page 2: Important Safeguards

    It is not necessary to make any other D.The appliance does not appear to operate normally; or changes. If you have any questions please call Russound Inc. at 1-800-638-8055 or 603-659-5170 E. The appliance has been dropped or the enclosure is damaged.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS USER SECTION Product Introduction ......................6 Component Guide CAM6.6 Controller.......................7 UNO-S1 Keypad ........................8 UNO-S2 Keypad (Optional)....................9 SRC2 Remote Control......................10 Operation UNO-S1 Keypad Operation ....................11 UNO-S1 User Menu ......................12 Optional UNO-S2 Keypad Operation ..................13 Optional UNO-S2 User Menu ....................14 Internal Source - AM/FM Tuner UNO-S1 Keypad Control.....................15 UNO-S2 Keypad Control ....................16-17...
  • Page 4 TABLE OF CONTENTS Source IR Input Connections ....................30 Common IR Input Connection .....................31 Speaker Connections ......................32 Zone Fixed/Variable Audio Output ..................33 12VDC Home Theater Trigger In/Out ..................34 12VDC Mute Trigger In/Out....................35 RNET Link In/Out.......................36 RS-232 Interface .......................37 Optional Internal Source AM/FM Tuner Antennas....................38-40 Initial Install Test........................41 Programming...

  • Page 5: User Section

    USER SECTION Component Guides Explains front panel features of the CAM6.6 controller, UNO-S1 keypad, optional UNO-S2 keypad and SRC2 remote control. Operation Step-by-step outline of the system's normal operation, plus a look at adjustable features available through the User Menu.

  • Page 6: Product Introduction

    Master. If the party moves to the sunroom and porch, that room’s keypad can be set to Master instead. Here at Russound we are proud to continue providing innovative and intuitive audio product solutions to the world. When you link the industry-leading CAM6.6T-S1system with Russound’s commitment to...

  • Page 7: Component Guide Cam6.6 Controller

    USER COMPONENT GUIDE CAM6.6 Controller-Front Panel MAIN POWER SWITCH - Supplies power to the CAM6.6 ROOM LED ON/OFF INDICATORS - Indicates when a room is on (green) or off (red) Main Power and Zone Status The power switch for the CAM6.6 controller is “on” in the up position. Any active room (1-6) is indicated on the front of the controller by a green LED, which shows red when the room is inactive.

  • Page 8: Uno-S1 Keypad

    USER COMPONENT GUIDE UNO-S1 Keypad 102.5 LCD PANEL - 5-character backlit display shows status of the room, source, volume, and more SOURCE SELECT BUTTON - Scrolls through the sources directly connected to the CAM6.6. Press and hold brings up the USER MENU for loudness, bass, treble, etc. VOLUME UP/DOWN BUTTONS - Raises and lowers the volume for the room IR RECEIVER - Receives IR signals and passes them to the controller and source equip- ment.

  • Page 9: Uno-S2 Keypad (Optional)

    USER COMPONENT GUIDE Optional UNO-S2 Keypad CD PLAYER 1 LCD PANEL - 12-character backlit display shows status of the room, source, volume, and more SOURCE SELECT BUTTON - Scrolls through the sources directly connected to the CAM6.6. Press and hold brings up the USER MENU for loudness, bass, treble, etc. VOLUME UP/DOWN BUTTONS - Raises and lowers the volume for the room IR RECEIVER - Receives IR signals and passes them to the controller and source equip- ment.

  • Page 10: Src2 Remote Control

    (e.g., VCR, DVD, or CD player) with these buttons. SOURCE - Directly select sources connected to the Russound controller while in the Russound mode. F1 AND F2 BUTTONS - Selects and saves Favorite 1 or Favorite 2 preset selections.

  • Page 11: Operation

    USER OPERATION UNO-S1 Keypad Zone On/Off Press and release to turn on the UNO used to enter the User Menu with a press and System Keypad. This also turns on the corre- hold action. (See next page for User Menu) sponding CAM6.6’s room, and any presets previ- Volume Up/Down Buttons ously assigned will be activated, including set-...

  • Page 12: Uno-S1 User Menu

    USER USER MENU SETTINGS UNO-S1 User Menu Operation The User Menu allows the user to adjust the Party Mode command from affecting this room. audio properties and control functions of a par- When another UNO Systems Keypad selects the ticular room. same source, a DND message will scroll on the the LCD panel, alerting the user the source is in To enter or exit the User Menu, press and hold...

  • Page 13: Optional Uno-S2 Keypad Operation

    USER OPERATION Optional UNO-S2 Keypad Zone On/Off Press and release to turn on the UNO used to enter the User Menu with a press and System Keypad. This also turns on the corre- hold action. (See next page for User Menu) sponding CAM6.6’s room, and any presets previ- Volume Up/Down Buttons ously assigned will be activated, including set-...

  • Page 14: Optional Uno-S2 User Menu

    USER USER MENU SETTINGS Optional UNO-S2 User Menu Operation The User Menu allows the user to adjust the 7. DO NOT DSTRB - On or Off (default) audio properties and control functions of a par- Do Not Disturb means do not disturb this room ticular room.

  • Page 15: Internal Source - Am/Fm Tuner

    USER INTERNAL SOURCE - AM/FM TUNER UNO-S1 Keypad Control UNO-S1 Keypad Control of Tuner Selecting the desired frequency Selecting the tuner Press and hold to activate manual On the UNO-S1 keypad, press to select the tuning. Once active, press to scroll AM/FM tuner by choosing the tuner’s preas- through frequencies.

  • Page 16: Uno-S2 Keypad Control

    USER INTERNAL SOURCE - AM/FM TUNER UNO-S2 Keypad Control UNO-S2 Keypad Control of Tuner of six called banks, and there are six banks. Selecting the tuner Each preset and each bank can be given a cus- tom name of your choice. On the UNO-S2 keypad, press to select the To select a bank, press and hold...
  • Page 17 USER INTERNAL SOURCE - AM/FM TUNER UNO-S2 Keypad Control 92.5 MHz FM TUNER SELECTION - SCAN - (press and hold) Scans through tuned sta- Select source number tions with 5-second preview before next station assigned to AM/FM TUNER (1) MUTE - Mutes/unmutes tuner audio output TUNE UP/DOWN - Used for manual station selection...

  • Page 18: Src2 Remote Control

    USER INTERNAL SOURCE - AM/FM TUNER SRC2 Remote Control SRC2 Control of Tuner Frequency Scan Selecting the tuner To scan, press and hold then release . The To select the tuner, push and choose the tuner scans through tuned stations with a 5-second source number preassigned to the AM/FM tuner (1), preview before moving to the next station.

  • Page 19: Src2 Remote Control

    USER INTERNAL SOURCE - AM/FM TUNER SRC2 Remote Control POWER - Power managed by CAM6.6 RUSSOUND SELECTION - “R” must be the selected source for control of the NUMERIC INPUT - (press) Number buttons for CAM6.6 and any connected compo- direct input of frequency nents.
  • Page 20 CAUTION Do not connect the controller's main power feed until all other connections have been made and verified. Live connection or removal of the keypad wiring or other wiring when the system is powered can cause communication problems in the network. Double-check terminations during each phase of the installation to prevent accidental damage.

  • Page 21: Installer Section

    INSTALLER SECTION Getting Started Includes an installation overview, including tools needed and wiring instructions. Component Guides Reviews front and back panel features of the CAM6.6 controller and the UNO-S1 keypad. Keypad Installation Explains UNO-S1 keypad installation and wiring. Making Connections Details front and back panel connections of the controller and the keypad.

  • Page 22: Getting Started

    • Check for any visible signs of damage. If you encounter any concealed damage, con- • What are the intended listening zones? sult your Russound dealer before proceeding • What system options and accessories to install the unit. might be required for features such as local •...

  • Page 23: Wiring Instructions

    INSTALLER WIRING INSTRUCTIONS RJ-45 Connections The CAT-5 T568A wiring standard shown on the right is used for the RJ-45 terminations. Keypad Wiring • Confirm ahead of time that you can drill an For the UNO-S1 keypad, the following connec- outlet hole easily and in an unobtrusive spot tions are used to terminate the CAT-5 wire to the to connect wires with the CAM6.6.

  • Page 24: Component Guide

    COMPONENT GUIDE CAM6.6 Controller-Rear Panel CAM6.6 RNET LINK IN AND LINK OUT - Links multiple CAM6.6’s, also links future Russound components that are RNET compatible RS-232 INTERFACE - The RS-232 Interface allows the zones to be controlled by PC or other devices that have an RS-232 Interface. The RS-232 Interface also allows for firmware updates and programming.
  • Page 25 INSTALLER COMPONENT GUIDE CAM6.6 Controller-Rear Panel OPTIONAL INTERNAL SOURCE - Factory installed optional internal source, AM/FM radio module AC 240V-AC 110V Switch - Switches A/C input voltage between 110VAC and 240VAC AC 120/240 INPUT - Grounded 3-terminal plug detachable power cord connection for the CAM6.6 FUSE HOLDER - Holds a replaceable fuse for A/C input connection 110VAC operation - F 3A H 250V, 240VAC operation;...

  • Page 26: Uno-S1 Keypad Front Panel

    OS Update Port - Used to update the UNO-S1 keypad operating system firmware. If an update is released, it will be available online through the Document Center on www.russound.com. Look for it in the “Firmware and Downloads” section under Multi-Zone product type. The Advanced Programming Cable is available from Russound, Part #2500-...

  • Page 27: Uno-S1 Keypad Rear Panel

    INSTALLER COMPONENT GUIDE UNO-S1 Keypad-CAT-5 Connection CAT-5 Connection Caution: The UNO-S1 Keypad uses a 110-punchdown Take care when using an impact 110 punchdown terminal to provide a simple installation and tool, as this may overspread the contact points. strong connection for CAT-5 cable’s eight con- Use of the impact tool may propel stray bits of wire ductors.

  • Page 28: Keypad Installation

    INSTALLER UNO-S1 KEYPAD-INSTALLATION Keypad Location The best infrared remote performance is achieved Route CAT-5 wire to the junction box from the with the keypad away from any direct sunlight, CAM6.6. plasma TV, and low voltage lighting controls. Also Use the supplied 110 punchdown tool to con- consider convenience when choosing a location.

  • Page 29: Uno-S2 Keypad Installation

    INSTALLER MAKING CONNECTIONS UNO-S1 Keypad Port Connection The UNO System Keypad Ports are located on CAT-5 T568A RJ-45 wiring configuration, use the back of the CAM6.6 in the top left of center. CAT-5 from the RJ-45 Wall Plate to the keypad. Connections made at the UNO Keypad Ports are If using more than one keypad on a zone, con- made using CAT-5 T568A RJ-45 wire configura-...

  • Page 30: Source Audio Input Connections

    CAM6.6 optional internal source is used, the Connections. Source 1 input is not available, and the switch 1. Using an IR emitter (the Russound 845.1 is next to it is set to “Internal Source Output.” If the recommended) attach the end of the emitter Optional Internal Source is not installed, or if you ”...

  • Page 31: Common Ir Input Connection

    MAKING CONNECTIONS Common IR Connection Common IR Connections IR emitter with a 1/8’’ plug. The Russound The Common IR jack on the rear of the CAM6.6 845.1 single IR emitter is recommended, or use allows control of any source equipment without an IR connecting block such as the Russound that source being selected on the keypad.

  • Page 32: Speaker Connections

    INSTALLER MAKING CONNECTIONS Speaker Connections The speakers are connected to the CAM6.6 WHITE -- L+ (left channel positive) using modular snap connectors. Each of these GREEN -- L- (left channel negative) color-coded connectors is designated for the speaker set of a particular amplified zone. To BLACK -- R- (right channel negative) avoid confusion, connect one zone speaker set RED -- R+ (right channel positive)

  • Page 33: Zone Fixed/Variable Audio Output

    Zone 1 and Zone 2. Each of these zone audio if additional amplification is desired (e.g., output connections features a stereo line out Russound R235LS two-channel amplifier). Use RCA connection plus a switch to allow for either quality RCA signal cables to ensure a constant a fixed or a variable line level output.

  • Page 34: 12Vdc Home Theater Trigger In/Out

    12VDC trigger device or component being shared with a home theater system. When such as the Russound ACT-1 triggered outlet. the last zone on the CAM6.6 is turned off, 12VDC The connections for the trigger out are made presence to the trigger input will prevent the using a two-conductor cable with 1/8”...

  • Page 35: 12Vdc Mute Trigger In/Out

    INSTALLER MAKING CONNECTIONS 12VDC Mute Trigger In/Out 12VDC Mute Trigger In 12VDC Mute Trigger Out When 12VDC is applied to the Mute Trigger In, Mute Trigger Out 12VDC output is used for trig- the system will fully mute any source that is con- gering an external amplifier, muting device or nected to the Source Audio Input.

  • Page 36: Rnet Link In/Out

    The RNET Link In and Link Out can be used to The RNET Link In and Link Out is also used to connect two to six CAM6.6 or CAV6.6 con- connect the CAM6.6 to other Russound prod- trollers. The connection is made using a CAT-5 ucts with RNET.

  • Page 37: Rs-232 Interface

    Document Center at PC for programming of the controller. The RS- www.russound.com. Look for the Technical 232 com port is located on the back of the Documents under Multi-source/Multi-room CAM6.6 and uses a DB-9 cable connection. For products.

  • Page 38: Optional Internal Source Am/Fm Tuner Antennas

    INSTALLER MAKING CONNECTIONS Optional Internal Source - AM/FM Tuner Antennas AM Antenna FM Antenna Connect the included loop antenna for AM recep- Attach the included FM antenna for FM reception tion to the Optional Internal Source panel, attach- to the Optional Internal Source panel by pushing ing the GND (ground) and AM ends to the appro- the F-type quick-connect termination of the anten- priately marked connections.
  • Page 39 INSTALLER MAKING CONNECTIONS Optional Internal Source - AM/FM Tuner Antennas Connecting an Alternate Outdoor Antenna for AM reception. Use a 75-ohm to 300-ohm for AM/FM balun at the AM connection on the tuner, and attach the 75-ohm coax cable to the balun. The diagram below depicts a suggested installa- tion option of an alternate outdoor FM antenna For best performance for FM reception, it is rec-...
  • Page 40 INSTALLER MAKING CONNECTIONS Grounding Outdoor Antennas Antenna Lead In Wire Electric Service Equipment Grounding Conductors Power Service Grounding Electrode System Ground Clamps Grounding an Outdoor Antenna The diagram above gives a general depiction of how an outdoor antenna should be grounded. For If the tuner is used with an outdoor antenna, the complete guidelines on antenna grounding proce- antenna must be grounded against static...

  • Page 41: Initial Install Test

    4. Check to see that the keypad is connected to the Zone #3 Keypad Port and verify the CAT-5 is properly terminated at both ends. If none of these steps produce successful results, call Russound Tech Support for further assistance.

  • Page 42: System Programming Overview

    INSTALLER SYSTEM PROGRAMMING OVERVIEW This manual includes items that are designed to assist in the programming process. Forms (Pages 44-46) Three blank reproducible forms are included as planning tools when determining sources, settings and zone preferences. The Source and Zone Information forms and the Macro Editor form should be completed before programming and referred to during the installation menu process.

  • Page 43: System Programming Overview

    INSTALLER SYSTEM PROGRAMMING OVERVIEW 3. Basic Setup (SOURCE SETUP) (Pages 50-52) This procedure is mandatory to set up each source for keypad source control and is the cornerstone of the programming process. 4. Peripheral Setup (Pages 48-50) (FOR OPTIONAL INTERNAL SOURCE) This procedure provides setup and naming procedures for the tuner.

  • Page 44: Setup Forms

    INSTALLER SETUP FORMS...

  • Page 45: Zone Information Form

    INSTALLER SETUP FORMS...

  • Page 46: Macro Editor Form

    INSTALLER SETUP FORMS...

  • Page 47: Installation Menu Overview

    INSTALLER INSTALLATION MENU OVERVIEW There are three item types in the installation menu: Menu Item – Acts as a folder that holds procedures and/or feature parameters. Procedure – A sequence of feature parameters to perform a guided operation, such as configuring an UNO key.

  • Page 48: Peripheral Setup

    INSTALLER INSTALLATION MENU The following items make up the Installation Menu: PERIPH SETUP (PerSu) SOURCE SETUP (SrcSu) ZONE SETUP (ZonSu) CTRLR SETUP (CtlSu) POWER MGT (PwMgt) LEARN IR (LrnIR) MACRO EDITOR (MacEd) SYSTEM INFO (SInfo) PERIPH SETUP (PerSu) Peripheral Setup allows the CAM6.6’s optional internal source to be configured. The following items can be found in the PERIPH SETUP menu: MEM NAME (MemNm) BANK NAME (BnkNm)
  • Page 49 INSTALLER INSTALLATION MENU 2. BANK NAME – Use the volume up/down keys to select a character and left/right (BnkNm) keys to change a character position. A blinking cursor indicates placement of the character being entered. Names can be from 1 to 5 characters in length.

  • Page 50: Source Setup

    INSTALLER INSTALLATION MENU SYSTEM INFO (SInfo) System Info shows the tuner’s manufacturing build properties. See Periph Setup - Flow Chart on page 64 BUILD TIME (BTime) BUILD DATE (BDate) VERSION (Ver) 1. BUILD TIME Displays the firmware Build Time of the tuner. (BTime) 2.
  • Page 51 INSTALLER INSTALLATION MENU 2. SOURCE NAME – Select the name for the source (e.g., DVD, Aux 2, Jazz, etc.). (Name) 3. COMMAND TYPE – Select the type of command template (e.g., CD, TV, etc.). Selecting (CmdTp) the command type template will tell the CAM 6.6 how to configure the key’s command and text for the source component.
  • Page 52 INSTALLER INSTALLATION MENU 9. AUTO PLAY? – “Yes” tells the CAM6.6 to issue a PLAY command whenever the (AtoPl) source is selected for listening. This option is skipped if the source type (COMMAND TYPE) chosen does not have a PLAY command associated with it.
  • Page 53 INSTALLER INSTALLATION MENU i. MACRO - Macro loads a series of commands which are processed when (Macro) activated. ii. MACRO ID – Enter the macro ID number. Menu advances to SAVE CHANGES (MacID) (step 9) e. All Other Selections: Procedure advances to DEVICE CODE (step 7) 7.
  • Page 54 INSTALLER INSTALLATION MENU 1. SOURCE NUM – Select the source number this function will be configured for. (Src #) 2. USE NUM IR? – Tells the system whether the source component has numeric (NumIR) scrolling, such as 100-disc CD player. A selection of “no” disables Numeric IR and advances to SAVE CHANGES 3.
  • Page 55 INSTALLER INSTALLATION MENU 9. SUFFIX CMD – Tells the system whether a command will be issued after the selection of the numerical value (e.g., 1, 2 Enter ). If “no,” proce- (Sufix) dure advances to SAVE CHANGES (step 13) 10. COMMAND TYPE – Select the type of source command (e.g., CD, TV, etc.).

  • Page 56: Zone Setup

    INSTALLER INSTALLATION MENU 2. COMMAND TYPE – Select the type of source command (e.g., CD, TV, etc.). (CmdTp) a. Selected: Learned IR Choose Learned IR if the pre-programmed IR code library does (LrnIR) not support the source component. i. LEARNED SRC – Select the learned source bank to be assigned to the source (LnSrc) component.

  • Page 57: Controller Setup

    INSTALLER INSTALLATION MENU Zone Setup allows the installer to adjust properties of the UNO Keypad controlled CAM6.6 zone. This series of menus allows the system’s zones to be configured for these properties: ZON VOL TRIM (ZonVT) SYSON ENABLE (SysOn) PARTY ENABLE (PtyEn) MASTER ENABL (MstEn) MUTE ENABLE (MutEn) 1.

  • Page 58: Power Management

    INSTALLER INSTALLATION MENU All settings including source equipment IR commands will need to be reentered. An “Are you sure?” prompt and a “no” response allows the installer to cancel the reset; a “yes” at the prompt will load factory/default settings. POWER MANAGEMENT (PwMgt) The CAM6.6 is capable of managing the power state of the connected source equipment.
  • Page 59 INSTALLER INSTALLATION MENU i. MACRO - Macro loads a series of commands which are processed when (Macro) activated. ii. MACRO ID – Enter the macro ID number. Menu advances to POWER OFF CMD (MacID) (step 6) e. All Other Selections: Procedure advances to DEVICE CODE (step 4) 4.

  • Page 60: Learn Ir

    INSTALLER INSTALLATION MENU 9. KEY FUNCTION (f) – Select Keypad function. (KeyFn) 10. SAVE CHANGES? (f) – Select “yes” to save the changes. (Save?) LEARN IR (LrnIR) This procedure allows IR commands to be learned into the system and be centrally stored in the main controller to let the system access the same IR codes that operate the source equipment.
  • Page 61 INSTALLER INSTALLATION MENU 1. MACRO ID – Number of Macro up to 132 including any previously named (MacID) macros. 2. MACRO NAME – Name of Macro (optional). (MacNm) 3. COMMAND NUM – Number of Command up to 10. (Cmd#) 4. COMMAND TYPE – Select the type of source command (e.g., CD, TV, etc.).

  • Page 62: System Info

    INSTALLER INSTALLATION MENU SYSTEM INFO (SInfo) System Info allows the installer to view the controller’s manufacturing build properties. See System Info - Flow Chart on page 75 #CONTROLLERS (#Ctls) BUILD TIME (BTime) BUILD DATE (BDate) VERSION (Ver) 1. #CONTROLLERS Displays the number of CAM6.6 controllers in the system. (#Ctls) 2.

  • Page 63: Setup Menu Flow Charts

    INSTALLER SETUP MENU FLOW CHARTS...
  • Page 64 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 65 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 66 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 67 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 68 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 69 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 70 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 71 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 72 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 73 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 74 INSTALLER SETUP MENU FLOW CHARTS...

  • Page 75: Setup Menu Flow Charts

    INSTALLER SETUP MENU FLOW CHARTS...

  • Page 76: Reference Section Ir Device Code List

    INSTALLER IR CODES Device Codes for TVs: 0180, 0030 Signature 0016 Kenwood 0030, 0019 Sony 0000, 1100 Konka 0628, 0632, 0638, 0703, 0707 Soundesign 0180, 0178, 0179 0030, 0019 0056 Squareview 0171 Admiral 0093, 0463 0047, 0747, 0054, 0154, 0156, Starlite 0180 Advent...
  • Page 77 INSTALLER IR CODES Philips 1818, 1061 Dynatech 0000 Protec 0072 Pioneer 1010 Electrohome 0037 Pulsar 0039 Princeton 0113, 0295 Electrophonic 0037 Quasar 0035, 0162, 1162, 0454, 1035 Samsung 1190, 1204 Emerex 0032 0035, 0060, 0760, 0048, 1035, 1060, 0807, 0149, 0042, 0240 Sensory Science 1126 Emerson 0037, 0184, 0000, 0121, 1278,...
  • Page 78 Aiwa 0157 One For All 0167 Device Codes for Tuner/Amp: Cal i f orni a Audi o Labs 0029 RadioShack 0240 Carver 0157, 0179 Russound 1232, 1233 0531 Classic 1297 Sanyo 0336 Aiwa 1089, 1405, 0158, 1388 0000 Security System 0167...

  • Page 79: Ir Keycode List

    INSTALLER KEY CODES TV (HDTV) KEY FUNCTION UNO-S1 TV (HDTV) KEY FUNCTION UNO-S1 TV (HDTV) Digit 1 Pause Pause Learned Only Digit 2 Record Recrd Learned Only Digit 3 Menu Menu Menu (Picture) Digit 4 Menu Up MenuU Menu Up, Adjust Up Digit 5 Menu Dn MenuD...
  • Page 80 INSTALLER KEY CODES TV (HDTV) KEY FUNCTION UNO-S1 TV (HDTV) KEY FUNCTION UNO-S1 TV (HDTV) Off, Power On/Off PIP Chan Up PIPCU PIP Channel Up Learned Only PIP Chan Dn PIPCD PIP Channel Down Learned Only Input 1 In 1 VID1,Video,TVp1 Learned Only Input 2...
  • Page 81 INSTALLER KEY CODES CABLE KEY FUNCTION UNO-S1 CABLE KEY FUNCTION UNO-S1 CABLE Digit 1 Pause Pause Pause Digit 2 Record Recrd Record Digit 3 Menu Menu Menu, Settings Digit 4 Menu Up MenuU Menu Up Digit 5 Menu Dn MenuD Menu Down Digit 6 Menu Left...
  • Page 82 INSTALLER KEY CODES CABLE KEY FUNCTION UNO-S1 CABLE KEY FUNCTION UNO-S1 CABLE Off, Power On/Off PIP Chan Up PIPCU Learned Only Learned Only PIP Chan Dn PIPCD Learned Only Learned Only Input 1 In 1 A,VID1,Video,TVp1 Learned Only Input 2 In 2 B,VID2,TVp2 Learned Only...
  • Page 83 INSTALLER KEY CODES VIDEO ACC KEY FUNCTION UNO-S1 VIDEO ACC KEY FUNCTION UNO-S1 VIDEO ACC Digit 1 Pause Pause Pause Digit 2 Record Recrd Record Digit 3 Menu Menu Menu, Home Digit 4 Menu Up MenuU Menu Up Digit 5 Menu Dn MenuD Menu Dn...
  • Page 84 INSTALLER KEY CODES VIDEO ACC KEY FUNCTION UNO-S1 VIDEO ACC KEY FUNCTION UNO-S1 VIDEO ACC Off, Power On/Off PIP Chan Up PIPCU PIP Channel Up Learned Only PIP Chan Dn PIPCD PIP Channel Down Learned Only Input 1 In 1 VID1,Video,TVp1 Learned Only Input 2...
  • Page 85 INSTALLER KEY CODES SAT/DSS KEY FUNCTION UNO-S1 SAT/DSS KEY FUNCTION UNO-S1 SAT/DSS Digit 1 Pause Pause Pause Digit 2 Record Recrd Record Digit 3 Menu Menu Menu (PVR, Tivo) Digit 4 Menu Up MenuU Menu Up Digit 5 Menu Dn MenuD Menu Down Digit 6...
  • Page 86 INSTALLER KEY CODES SAT/DSS KEY FUNCTION UNO-S1 SAT/DSS KEY FUNCTION UNO-S1 SAT/DSS Off, Power On/Off PIP Chan Up PIPCU Learned Only Learned Only PIP Chan Dn PIPCD Learned Only Learned Only Input 1 In 1 VID1,Video,TVp1 Learned Only Input 2 In 2 VID2,TVp2 Learned Only...
  • Page 87 INSTALLER KEY CODES KEY FUNCTION UNO-S1 KEY FUNCTION UNO-S1 VCR Pause Pause Pause Digit 1 Record Recrd Record Digit 2 Menu Menu Menu (PVR,Tivo) Digit 3 Menu Up MenuU Menu Up Digit 4 Menu Dn MenuD Menu Down Digit 5 Menu Left MenuL Menu Left...
  • Page 88 INSTALLER KEY CODES KEY FUNCTION UNO-S1 VCR KEY FUNCTION UNO-S1 VCR Off, Power On/Off PIP Chan Up PIPCU Learned Only Learned Only PIP Chan Dn PIPCD Learned Only Learned Only Input 1 In 1 VID1,Video,TVp1 Learned Only Input 2 In 2 VID2,TVp2 Learned Only Input 3...
  • Page 89 INSTALLER KEY CODES LASER DISC KEY FUNCTION UNO-S1 LASER DISC KEY FUNCTION UNO-S1 LASER DISC Digit 1 Pause Pause Pause Digit 2 Record Recrd Learned Only Digit 3 Menu Menu Menu, Program Digit 4 Menu Up MenuU Menu Up 5Digit 5 Menu Dn MenuD Menu Down 6Digit 6...
  • Page 90 INSTALLER KEY CODES LASER DISC KEY FUNCTION UNO-S1 LASER DISC KEY FUNCTION UNO-S1 LASER DISC Off, Power On/Off PIP Chan Up PIPCU Learned Only Learned Only PIP Chan Dn PIPCD Learned Only Learned Only Input 1 In 1 VID1,Video,TVp1 Learned Only Input 2 In 2 VID2,TVp2...
  • Page 91 INSTALLER KEY CODES KEY FUNCTION UNO-S1 DVD KEY FUNCTION UNO-S1 DVD Digit 1, Traack 1 Pause Pause Pause Digit 2, Track 2 Record Recrd Record Digit 3, Track 3 Menu Menu Disk Menu Digit 4, Track 4 Menu Up MenuU Menu Up Digit 5, Track 5 Menu Dn MenuD Menu Dn...
  • Page 92 INSTALLER KEY CODES KEY FUNCTION UNO-S1 DVD KEY FUNCTION UNO-S1 DVD Off, Power On/Off PIP Chan Up PIPCU Learned Only Learned Only PIP Chan Dn PIPCD Learned Only Learned Only Input 1 In 1 VID1,Video,TVp1 Learned Only Input 2 In 2 VID2,TVp2 Learned Only Input 3...
  • Page 93 INSTALLER KEY CODES RECEIVER KEY FUNCTION UNO-S1 RECEIVER KEY FUNCTION UNO-S1 RECEIVER Pause Pause Pause Digit 1 Record Recrd Record Digit 2 Menu Menu Disk menu, Menu Digit 3 Menu Up MenuU Menu Up, Adjust Up Digit 4 Menu Dn MenuD Menu Dn, Adjust Dn Digit 5...
  • Page 94 INSTALLER KEY CODES RECEIVER KEY FUNCTION UNO-S1 RECEIVER KEY FUNCTION UNO-S1 RECEIVER Off, Power On/Off PIP Chan Up PIPCU Learned Only Learned Only PIP Chan Dn PIPCD Learned Only Learned Only Input 1 In 1 Learned Only Input 2 In 2 Tuner Learned Only Input 3...
  • Page 95 INSTALLER KEY CODES AMP/MISC AUDIO KEY FUNCTION UNO-S1 AMP/MISC AUDIO KEY FUNCTION UNO-S1 AMP/MISC AUDIO Digit 1 Pause Pause Pause Digit 2 Record Recrd Record Digit 3 Menu Menu Menu, Program Digit 4 Menu Up MenuU Menu Up, Adjust Up Digit 5 Menu Dn MenuD...
  • Page 96 INSTALLER KEY CODES AMP/MISC AUDIO KEY FUNCTION UNO-S1 AMP/MISC AUDIO KEY FUNCTION UNO-S1 AMP/MISC AUDIO Off, Power On/Off PIP Chan Up PIPCU Learned Only Learned Only PIP Chan Dn PIPCD Learned Only Learned Only Input 1 In 1 Learned Only Input 2 In 2 Tuner...
  • Page 97 INSTALLER KEY CODES KEY FUNCTION UNO-S1 CD KEY FUNCTION UNO-S1 CD Pause Pause Pause Digit 1, Track 1,Dsc1 Record Recrd Record Digit 2, Track 2,Dsc2 Menu Menu Disk, Edit Digit 3, Track 3,Dsc3 Menu Up MenuU Menu Up Digit 4, Track 4,Dsc4 Menu Dn MenuD Menu Down Digit 5, Track 5,Dsc5...
  • Page 98 INSTALLER KEY CODES KEY FUNCTION UNO-S1 KEY FUNCTION UNO-S1 Off, Power On/Off PIP Chan Up PIPCU Learned Only Learned Only PIP Chan Dn PIPCD Learned Only Learned Only Input 1 In 1 Learned Only Input 2 In 2 Tuner Learned Only Input 3 In 3 DVD, LD...

  • Page 99: Home Control

    INSTALLER KEY CODES HOME CONTROL KEY FUNCTION UNO-S1 HOME CONTROL KEY FUNCTION UNO-S1 HOME CONTROL Pause Pause Pause Digit 1 Record Recrd Record Digit 2 Menu Menu Menu Digit 3 Menu Up MenuU Menu Up, Mode Digit 4 Menu Dn MenuD Menu Dn, Timer Digit 5...
  • Page 100 INSTALLER KEY CODES HOME CONTROL KEY FUNCTION UNO-S1 HOME CONTROL KEY FUNCTION UNO-S1 HOME CONTROL Off, Power On/Off PIP Chan Up PIPCU Learned Only Learned Only PIP Chan Dn PIPCD Learned Only Learned Only Input 1 In 1 Source/Scene 1 Learned Only Input 2 In 2...

  • Page 101: Source Names

    INSTALLER SOURCE NAMES UNO-S1 UNO-S2 UNO-S1 UNO-S2 UNO-S1 UNO-S2 CustomName3 DVD 3 DVD Player 3 Aux 1 AUX 1 CustomName4 FDoor Front Door Aux 2 AUX 2 CustomName5 Hers Her Music Blues Blues CustomName6 His Music Cable Cable CustomName7 www. Intrnet Radio Cbl 1 Cable 1...

  • Page 102: Source Names

    INSTALLER SOURCE NAMES UNO-S1 UNO-S2 UNO-S1 UNO-S2 RepTV ReplayTV Tun 1 Tuner 1 Rock Rock Tun 2 Tuner 2 Satellite Tun 3 Tuner 3 Sat 1 Satellite 1 Sat 2 Satellite 2 Sat 3 Satellite 3 VCR 1 VCR 1 SatRd Sat Radio VCR 2...

  • Page 103: Sample Configurations

    SAMPLE CONFIGURATIONS MULTIPLE CONTROLLERS WITH ONE TUNER Sharing a single CAM6.6T (internal tuner) with multiple Output/Input Switch = Internal Source Output controllers RCA cable connected to Source 1 This arrangement can support up to six CAM6.6 units CAM6.6 (no tuner installed) - for up to 36 zones/6 sources.
  • Page 104 SAMPLE CONFIGURATIONS MULTIPLE CONTROLLERS WITH TWO TUNERS System with two CAM6.6T (internal tuner) controllers CAM6.6T (1) - Controller Setup Menu: Controller ID = 1 The configuration below is suitable for 7 to 12 zones Peripheral Setup Menu: Controller ID = 1 that will have access to the tuner in the controller to which its keypad is connected only.
  • Page 105 SAMPLE CONFIGURATIONS MULTIPLE CONTROLLERS WITH THREE TUNERS Sharing an ST2 Dual Tuner with multiple CAM6.6 con- to Source 2 input on CAM6.6T (1) trollers (with and without tuners) RCA cable connected from ST2 Tuner 2 audio output to Source 3 input on CAM6.6T (1) The configuration below is suitable for 7 to 12 zones that can access the ST2 Dual Tuner and the CAM6.6T CAM6.6 (no tuner installed) -...

  • Page 106: Sample Configurations

    SAMPLE CONFIGURATIONS MULTIPLE CONTROLLERS WITH ST2 DUAL TUNER Sharing an ST2 Dual Tuner with multiple CAM6.6 con- to Source 1 input on CAM6.6 (1) trollers (no built-in tuners) RCA cable connected from ST2 Tuner 2 audio output to Source 2 input on CAM6.6 (1) The configuration below is suitable for 7 to 12 zones that can all access the ST2 Dual Tuner.

  • Page 107: Technical Specifications

    TECHNICAL SPECIFICATIONS Dimensions: 17"W x 12"D x 3.5"H (43 x 30.5 x 9 cm) Weight: 18 lbs. (8.1 kg) Power Supply: 110 or 240 VAC Fuse Rating: 110V input; F3A H 250V US and Canada 240V input; T1.25A H 250V Europe Frequency Response: 20Hz-20kHz +/- 1dB Watts per channel:...

  • Page 108: Warranty

    In these cases, repairs will be made on the basis of the retail value of the parts and labor. To return for repairs, the unit must be shipped to Russound at the owner's expense, along with a note explaining the nature of service required. Be sure to pack the unit in a corrugated container with at least three (3) inches of resilient material to protect the unit from damage in transit.
  • Page 109 NOTES...
  • Page 110 NOTES...
  • Page 111 NOTES...
  • Page 112 Russound 5 Forbes Road, Newmarket, NH 03857 tel 603.659.5170 • fax 603.659.5388 28-0111 Rev. 1 11/23/05 e-mail: tech@russound.com Copyright © 2004, 20-05 Russound ® All rights reserved. www.russound.com...
