- Page 1 Quick Installation Guide Wireless Home Audio Stereo Speaker Kit Wired Accessory DMSPK50...
- Page 2 Thank you Front for making a great decision and choosing to purchase the Linksys by Cisco Stereo Speaker Kit. The speakers can be used with most stereo audio amplifiers and receivers, but are designed to be a perfect match for the Linksys Director (DMC250).
-
Page 3: Installation Overview
Installation Overview This Quick Installation Guide will guide you through connecting each To ensure proper operation and sound quality, the cables must be two-wire cable to a speaker at one end, and your audio amplifier at connected to the speakers correctly. Do not allow any cable strands the other end. -
Page 4: Connecting The Speakers
1 Connecting the Speakers Power off your Director (or other audio amplifier). Connect the other end of the speaker wire with the line to the appropriate L (left) or R (right) coded output terminal on the Director. Locate the two-wire speaker cables provided. Each two-wire cable is color coded with a line on one of the wires, so it is easy to identify at both ends. - Page 5 2 Enhancing Your Sound The speakers can be placed on stands, in bookshelves or on cabinets. A larger stereo image can be created by separating the position of the speakers. Ideally the speakers should be placed at listening height, in a symmetrical triangle with the listening position. Place the speakers approximately 1 foot (0.3 m) from the rear wall or object.
- Page 6 2 Enhancing Your Sound Avoid sound reflections in front of the speaker by aligning the front edge of the speaker with the edge of the surface it has been placed on. The back of the speakers have a vented port opening. Do not block the vented port opening, as it will reduce the bass and/or create a rattling sound. An equal distance to the corners and side walls for both speakers will give the most natural and precise reproduction.
-
Page 7: Troubleshooting
• Make sure you’ve followed all of the guidelines for placement and positioning. • Check the documentation for the amplifier for additional troubleshooting tips. WEB: If you need additional support, contact us on the web at www.linksys.com/support... - Page 8 Make your music fun again.
