HPFF12(E)/HPFF12CM(E)
NOTIFICATION APPLIANCE CIRCUIT EXPANDER
INSTALLATION & OPERATION MANUAL
P/N 53576:B • ECN 10-0569 • 11/24/2010

Advertisement

Table of Contents
loading

Related Manuals for Honeywell HPFF12

Summary of Contents for Honeywell HPFF12

  • Page 1 HPFF12(E)/HPFF12CM(E) NOTIFICATION APPLIANCE CIRCUIT EXPANDER INSTALLATION & OPERATION MANUAL P/N 53576:B • ECN 10-0569 • 11/24/2010...
  • Page 2 (especially in bedrooms), smoking in bed, and violent explosions (caused by escaping gas, improper storage of Limit-C1-2-2007 flammable materials, etc.). HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 3: Installation Precautions

    HARSH™, NIS™, and NOTI•FIRE•NET™ are all trademarks; and Acclimate® Plus™, FlashScan®, NION®, NOTIFIER®, ONYX®, ONYXWorks®, UniNet®, VeriFire®, and VIEW® are all registered trademarks of Honeywell International Inc. Echelon® is a registered trademark and LonWorks™ is a trademark of Echelon Corporation. ARCNET® is a registered trademark of Datapoint Corporation. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation.
  • Page 4 •Brief description of content you think should be improved or corrected •Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 5: Table Of Contents

    2.3.4: HPP31076 Optional Class A (Style Z) Adaptor................29 2.4: Mounting Addressable Modules ........................... 30 2.4.1: Mounting Modules from Honeywell Fire Systems ................30 2.4.2: Mounting Six-Circuit Modules from Honeywell Fire Systems ............31 2.5: Power-Limited Wiring Requirements ........................31 2.5.1: Power-Limited Wiring, Standard Chassis ..................32 2.5.2: Power-Limited Wiring, FACP Cabinet .....................33...
  • Page 6 Appendix A: Device Compatibility ..................53 A.1: Optional Modules ..............................53 A.2: Notification Appliances............................53 A.2.1: System Sensor — 24 VDC .......................53 A.2.2: Gentex — 24 VDC ...........................54 A.2.3: Cooper-Wheelock ..........................55 A.2.4: Amseco .............................57 A.2.5: Faraday..............................57 HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 7 Alarm Systems, UL 864, 9th Edition. Operation of this product with products not tested for UL 864, 9th Edition has not been evaluated. Such operation requires the approval of the local Authority Having Jurisdiction (AHJ). HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 8 HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 9: Section 1: System Overview

    It contains an internal battery charger capable of charging up to 26.0 AH (amp hour) batteries. The HPFF12 is a wall cabinet unit that can accommodate up to two 18 AH batteries. It can be configured to internally house one addressable control or relay module, a six-circuit relay module, or a six-circuit control module.

  • Page 10: Features

    – If the local Authority Having Jurisdiction (AHJ) requires the fire protection system to have matching locks, the units’ locks may be swapped in the field to accommodate Honeywell Fire Systems branded panels: Honeywell, Notifier, Gamewell FCI, Silent Knight, and Fire- Lite Alarms.

  • Page 11: Start-Up Procedure

    Connect the primary source wiring while observing the following: • HPFF12 and HPFF12CM: make certain the primary source is 120 VAC, 60 Hz, 5.0 A. • HPFF12E and HPFF12CME: make certain the primary source is 240 VAC, 50 Hz, 2.80 A.

  • Page 12: Jumpers

    The HPFF power supplies are comprised internally of two basic components: a 24 VDC power supply and a Control circuit board. The HPFF12 models have an installed 12.0 A power supply. Jumpers are located on the control circuit board; see Figure 1.1, “Control Circuit Board”.

  • Page 13: Led Indicators

    Refer to Section 1.1, “Control Circuit Board”, on page 15 for terminal locations. Primary AC Power — TB1 (on 24 VDC power-supply circuit board) • HPFF12 and HPFF12CM: 120 VAC, 60 Hz, 5.0 A. • HPFF12E and HPFF12CME: 240 VAC, 50 Hz, 2.80 A.
  • Page 14 • Voltage rating: 24 VDC filtered. • Current: – Maximum for any one circuit: 3.0 A. – Maximum total continuous for all outputs: HPFF12, HPFF12CM, HPFF12E, HPFF12CME: 12.0 A • Output circuit types: – four Class B (Style Y); or –...
  • Page 15 Signal 1 –IN Signal 1 +OUT J1 Charger Disable Signal 1 –OUT) Signal 2 +IN Signal 2 –IN Signal 2 +OUT Signal 2 –OUT Ground Fault Disable Alarm Polarity Shown Figure 1.1 Control Circuit Board HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 16 System Overview Specifications Figure 1.2 HPFF12 24 VDC Power Supply Circuit Board HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 17: Section 2: Installation

    Place backbox over the top screw, level and secure. Mark and drill the left and right upper and lower mounting holes. Note: outer holes (closest to sidewall) are used for 16" O.C. stud mounting. Install remaining fasteners. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 18 Installation Backbox Mounting Figure 2.1 Standard Cabinet: Dimensions HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 19 Backbox Mounting Installation Semi-Flush Mounting Do not recess box more than 3.875” into wall to avoid covering venting holes on top of box. Figure 2.2 Standard Cabinet: Dimensions for Wall-mounting HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 20 NOTE: See EQ Series Install Sheet PN 53412 for door-mounting details and measurements Top View of Backbox for B and C size backboxes. Figure 2.3 FACP Cabinet-Mounting Details: Backbox-Mounting Holes and Chassis- Mounting Studs (EQBB-D4 shown) HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 21: Chassis-Mounting In Facp Cabinets

    For the bottom-most chassis-mounting plate only, install four #8-32 keps nuts on the plate’s studs as shown in Figure 2.6. This will properly space the battery well away from the backbox’s mounting hardware. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 22 Install battery well by resting the bottom on top of the studs and securing the top with two #8-32 keps nuts as shown in Figure 2.7. Attach plug to transformer. (Ships unplugged.) Figure 2.5 Attaching Transformer Plug HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 23 NOTE: This can be done before or after attaching chassis-mounting plate to backbox. Note: Two-row and three-row mounting is equivalent. Figure 2.6 Installing Chassis-Mounting Plates onto Backbox (EQBB-D4 Shown) HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 24 Secure top of battery well with two #8-32 kep nuts. Figure 2.7 HPFF12CM: Chassis-Mounting in Backbox (EQBB-D4 Shown) See power-limited wiring “HPFF12CM(E) Power-Limited Wiring, EQBB-D4 Backbox” on page 33. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 25 Chassis-Mounting in FACP Cabinets Installation Figure 2.9 One HPFF12CM Module in an EQBB-B4 Backbox Figure 2.8 Two HPFF12CM Modules in an EQBB-C4 Backbox See power-limited wiring “HPFF12CM(E) Power-Limited Wiring, EQBB-D4 Backbox” on page 33. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 26: Nac Circuit Wiring

    3. Do not complete a continuous circuit around the screw terminal. There must be two separate wires on either side of the screw at the terminal block. “T-tapping” is absolutely NOT ALLOWED. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 27: 2: Two Nacs Configured For Class A (Style Z)

    3. Do not complete a continuous circuit around the screw terminal. There must be two separate wires on either side of the screw at the terminal block. “T-tapping” is absolutely NOT ALLOWED. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 28: 3: Mixing Class B And Class A Nacs

    3. Do not complete a continuous circuit around the screw terminal. There must be two separate wires on either side of the screw at the terminal block. “T-tapping” is absolutely NOT ALLOWED. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 29: 4: Hpp31076 Optional Class A (Style Z) Adaptor

    3. Do not complete a continuous circuit around the screw terminal. There must be two separate wires on either side of the screw at the terminal block. “T-tapping” is absolutely NOT ALLOWED. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 30: Mounting Addressable Modules

    Mounting Addressable Modules 2.4 Mounting Addressable Modules The HPFF12 and the HPFF12E are designed to mount Honeywell Fire Systems addressable control or relay modules on the Control circuit board inside the power supply cabinet. This allows power to be fed from the Auxiliary output directly to the module, if needed, without running the power wires outside the cabinet.

  • Page 31: 2: Mounting Six-Circuit Modules From Honeywell Fire Systems

    Figure 2.15 for the wall cabinet. This allows wiring to remain in the cabinet. However, the six- output module cannot be mounted as shown in the HPFF12CM(E) units when used in the large equipment enclosure. An optional multi-module chassis is available from Honeywell Fire Systems. See Section 2.5, “Power-Limited Wiring Requirements”.

  • Page 32: 1: Power-Limited Wiring, Standard Chassis

    Specific Application: nonpower-limited Power & SLC are circuits appear power-limited close together. AC Circuits Output Circuits Nonpower- Power-limited limited Battery connections Nonpower-limited Figure 2.17 Power-Limited Wiring Example: HPFF12(E) Shown with Multi-module HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 33: 2: Power-Limited Wiring, Facp Cabinet

    Maintain 0.25" in. vertical separation where power-limited and non-power-limited circuits appear to “cross” (e.g. Relay Contacts and AC Power, or HPP31076 NACs and battery connections). Figure 2.18 Power-Limited Wiring Example: EQBB-D4 with HPFF12CM(E) HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 34 Installation Power-Limited Wiring Requirements Ground Stud Wire Nut TB1 on 24 VDC circuit board Ground Line Neutral Ground Figure 2.19 Power-Limited Wiring Example: EQBB-D4 AC Wiring (Expanded) HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 35: Section 3: Programming Options

    **Split Alarm is Signal Input I controlling NAC outputs 1 and 2, and Signal Input 2 controlling NAC outputs 3 and 4. ***Silencing is visual strobe activation but audible horn is silenced for the initiating device. Table 3.1 DIP Switch Settings HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 36: Programmable Features

    The filtered feature is used to provide a steady-on output with full-wave rectified unfiltered input, and can be used to reduce or eliminate spurious outputs that are caused by noise on the inputs. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 37: 2: Synchronization Type

    UL 864 9th Edition. NOTE: Always use supervised monitoring of TB2’s AC FAIL and TROUBLE contacts and to set DIP switch 7 for a delay for UL 864 9th Edition compliance. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 38: 4: Split Alarm And Silencing

    Signal Input 1 ON and Signal Input 1 OFF will silence all four NAC outputs while keeping visual strobe activation. NOTE: See Section 5.1 and 5.2 for proper alarm input wiring when DIP switch 8 is programmed in the OFF position. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 39: Section 4: Trouble Supervision

    The delay is based on operational conditions (time remaining in the first 24 hours, time in stand-by, and time in alarm) and will extinguish if the battery charging has time to reach its float voltage. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 40: 1: Tb2: Ac Fail Contacts

    FACP or initiating device. The four connections +IN, –IN, +OUT, and – OUT are used to connect either from a two-wire/Class B (Style Y) NAC with an end-of-line resistor (ELR) or a four-wire/Class A (Style Z) NAC. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 41: 4: Trouble Memory

    NAC output while in alarm. To clear the permanently latched overload condition, the AC must be cycled and the battery momentarily disconnected, or just press SW2 (microprocessor reset) on the Control circuit board. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 42: Section 5: Applications

    The same gauge wire must be used if two conductors are connected to the same terminal of any terminal block. Do not complete a continuous circuit around the screw terminal. There must be two separate wires on either side of the screw at the terminal block. “T-tapping” is absolutely NOT ALLOWED. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 43: Controlling And Silencing Four Nacs

    The same gauge wire must be used if two conductors are connected to the same terminal of any terminal block. Do not complete a continuous circuit around the screw terminal. There must be two separate wires on either side of the screw at the terminal block. “T-tapping” is absolutely NOT ALLOWED. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 44: Split Alarm And Selective Silence

    The same gauge wire must be used if two conductors are connected to the same terminal of any terminal block. Do not complete a continuous circuit around the screw terminal. There must be two separate wires on either side of the screw at the terminal block. “T-tapping” is absolutely NOT ALLOWED. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 45: 2: Split Alarm Mode

    The same gauge wire must be used if two conductors are connected to the same terminal of any terminal block. Do not complete a continuous circuit around the screw terminal. There must be two separate wires on either side of the screw at the terminal block. “T-tapping” is absolutely NOT ALLOWED. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 46: Connecting Multiple Units

    Connecting Multiple Units 5.4 Connecting Multiple Units Two or more HPFF8 and/or HPFF12 units can be connected to each other to provide additional NAC extenders for a system; see wiring in Figures 5.5–5.10 and in the HPFF8 manual PN 53499.
  • Page 47 The total line impedance for interconnected units cannot be such that it creates a voltage drop > 2 VDC. Zline total =2V/(1 Unit + 1 ELR) Example: Zline total = 2V/(12.26 mA + (24-2)/4.7K) =118.1 ohms HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 48: Section 6: Power Supply Requirements

    Use Table 6.1 to determine the total amount of current, in AC amperes, that must be supplied to the system. Current Number Total Current Device Type Draw of Devices per Device (AC Amps) HPFF12/HPFF12CM HPFF12E/HPFF12CME 2.80 Sum Column for AC Branch Current Required Table 6.1 120/240 VAC Branch Circuit Requirements HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 49: Calculating The System Current Draw

    34 for 3.0 Amp loaded NAC Faraday 132 total 33 for 3.0 Amp loaded NAC Gentex 144 total 36 for 3.0 Amp loaded NAC Table 6.3 Maximum Number of Notification Appliances per Extender HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 50: 2: How To Calculate System Current Draw

    Current limitation on TB4 NAC circuits is 3.0 Amps per NAC. Current limitation on TB4 AUX Output is 2.0 Amps. Total current draw cannot exceed 12.0 Amps in alarm. Table 6.4 System Current Draw Calculations HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 51: Calculating The Battery Size

    HPFF12CM is a chassis mount (CM) model that can fit two 12AH batteries. It is used for a multi- pack option that allows up to four HPFF8/12 units mounted in large equipment enclosures. Note: HPFF12 cannot be mounted in the top position of the large equipment enclosure. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 52: Nac Circuit Loop Wiring Requirements

    0.66 Ohms. The NAC loop current draw multiplied by total wire resistance on any single NAC circuit cannot exceed 2.0 volts. NOTE: For loads smaller than 3 Amps, use the second calculation. HPFF12 NAC Expander — P/N 53576:B 11/24/2010...

  • Page 53: Appendix A: Device Compatibility

    • Control Modules – Single-input: Fire•Lite CMF-300, Notifier FCM-1, Notifier NC-100, Gamewell-FCI AOM- 2SF, ADT M300CADT, Johnson Controls M300CJ, Honeywell TC810N1013, Honeywell XLS-CM-N, Silent Knight SD500-ANM, System Sensor M500S. – Six-input: Fire•Lite CMF-300-6, Notifier XP6-C, Gamewell-FCI MMO-6SF, System Sensor SC-6.

  • Page 54: A.2.2: Gentex - 24 Vdc

    (K=outdoor), market (A=Canada) and / or markings (P=Plain, SP=Spanish, FR=French, B=Bi-lingual and PG=Portugese). (UL 864 9th Edition). A.2.2 Gentex — 24 VDC Use only 24 V devices with HPFF12 products. MODEL NUMBER & NOMENCLATURE (Gentex) GEC-24-15,GEC-24-30,GEC-24-60,GEC-24-75,GEC-24-110,GEC-24-15/75W Horn/Strobe...

  • Page 55: A.2.3: Cooper-Wheelock

    Notification Appliances Device Compatibility A.2.3 Cooper-Wheelock Cooper-Wheelock Notification Use only 24 V devices with HPFF12 products. MODEL NUMBER & NOMENCLATURE (Cooper-Wheelock) 7002T-24 Horn with Strobe AES-DL1-WM-24-VF-R, AES-EL1-WM-24-VF-R Multi-Tone Signals AES-DL1-LSM-24, AES-EL1-LSM-24 Horn Strobe AH-24, AH-24WP Horn AMT-12/24 Multi-Tone Horn AMT-24-IS-VFR, AMT-24-LS-VFR, AMT-24-LSM-VFR,AMT-241575-FR Multi-Tone Horn Strobe...
  • Page 56 WMT-24-FR, WM1T-24-FR, WM3T-24-FR Strobes AS-24MCC-FW, CH90-24-MCC-FW, E90-24MCC-FW, ET90-24MCC-FW, HS-24-R/W, MIZ-24S-R/W, RSS-24MCC-FW, NH-12/24R/W Cooper-Wheelock Speakers Use only 24 V devices with HPFF12 products. MODEL NUMBER & NOMENCLATURE (Cooper-Wheelock) E70, E70-R, E90, E90-W Speaker ET70, ET90 Speaker with Strobe E70-24MCW Speaker Strobe...

  • Page 57: A.2.4: Amseco

    Notification Appliances Device Compatibility A.2.4 Amseco Use only 24 V devices with HPFF12 products. Compatible with the following: SH24W-153075, SAD24-153075, SAD24-75110, SL24W-75110, SL24C-3075110, SLB24-75 RSD24-153075, RSD24-75110, SH24W-75110, SH24W-3075110, SHB24-75, SCM24W-153075, SCM24W-75110, SCM24C-3075110, SCM24C-177, H24W, H24R A.2.5 Faraday Use only 24 V devices with HPFF12 products.
  • Page 58 Device Compatibility Notification Appliances HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 59 HPFF12CM installation 21 Class A (Style Z) Adaptor 29 HPP31076 29 Class B (Style Y) 26 clearing the permanently latched overload condi- tion 41 Initiating Device Signal Inputs (TB3 on Control conduit knockouts 31 HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 60 – power-limited wiring requirements 31 – UL power-limited wiring requirements 31 Primary Power (defined) also see AC power Primary power supply (defined) 49 Programming DIP Switches, see Dip switch set- wall-mounting 19 tings HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 61 Connecting multiple units 46 Control Panel Circuit Board 15 NAC applications 42 NACs 26 separating power-limited from non-power- – limited circuits 31 Split alarm mode 45 System Sync 46 – Wire specifications 13 Wiring size 52 HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 62 W–W Index HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
  • Page 63 Manufacturer's Return Material Authorization form. The replacement part shall come from Manufacturer's stock and may be new or refurbished. THE FOREGOING IS DISTRIBUTOR'S SOLE AND EXCLUSIVE REMEDY IN THE EVENT OF A WARRANTY CLAIM. Warn-HL-08-2009.fm HPFF12 NAC Expander — P/N 53576:B 11/24/2010...
