- Page 1 O W N E R S M A N U A L S t a g e l i n e P h o n o S t a g e...
- Page 2 2.2 running in 2.3 mains supply 2.4 siting the equipment 2.5 if you have a problem Warnings Connection 4.1 mains lead 4.2 non-rewireable mains plugs 4.3 fuse carrier 4.4 plug fuses Stageline Phono Stage EC Declaration of Conformity to Appropriate Standards...
-
Page 3: Equipment Installation
1.0 Equipment installation Normally your Naim equipment will have been installed by the dealer who sold it to you even if you live outside their immediate vicinity. Your dealer is responsible for making sure that the system sounds exactly as it should and information given here is not intended to reduce this responsibility in any way. -
Page 4: Getting Started
2.2 running in Your Naim equipment will take a considerable time to run-in before it performs at its best. The duration varies, but under some conditions you will find that the sound continues to improve for as much as five weeks. Better and more consistent performance will be achieved if the system is left switched on for long periods. -
Page 5: Siting The Equipment
Legal consumer protection varies from country to country. In most territories a dealer must be prepared to take back any Naim equipment he has sold you if he cannot make it work to your satisfaction in your own home. A problem may be due to a fault in any part of the system or its installation so it is essential to make full use of your local dealer’s diagnostic skills on site. - Page 6 If there is a known problem in your locality it is advisable to arrange for a home demonstration before purchase to find out if Naim equipment is likely to be affected.
- Page 7 In order to comply with current European safety regulations it is essential that the Naim loudspeaker connectors supplied with amplifiers and loudspeakers are used. Do not under any circumstances allow anyone to modify your Naim equipment without first checking with the factory, your dealer, or your distributor.
- Page 8 4.3 fuse carrier Should the plug fuse carrier be damaged or lost, the correct replacement must be obtained from your dealer or from Naim direct. Do not use the plug until the fuse carrier is replaced. 4.4 plug fuses Replace only with ASTA or BS 1362 approved fuses.
- Page 9 • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult your Naim dealer or an experienced radio/TV technician for help.
- Page 10 Please confirm the type required with your dealer at time of purchase. Stageline can be powered either by a separate flatcap or Hi-cap, or from the dedicated supply built-in to the NAIT5 or NAC52 preamp.
- Page 11 Stageline connected to nait 5 output ch1 left ch2 right +Vin +Vin ground ch 2 output cable direction marker signal signal input out A out B AUX 2 AUX 1 tape tuner to left loudspeaker Interconnect Cables to right loudspeaker...
- Page 12 Stageline connected to nait 5 with ch1 left ch2 right power supply ground output Interconnect Cables 4 to 4 pin DIN 5 to5 pin DIN 4 to5 pin DIN to right loudspeaker to left loudspeaker link plug fitted signal signal...
- Page 13 SP1 2LN disturbances and immunity IEC 801-2 8KV (air gap) Products 4KV (contact) (performance criterion B) Stageline, nait 5, flatcap 2 power supply IEC 801-3 3V/m 20dB Safety (performance criterion A) HD 195-S6 IEC 801-4 1KV (AC lines) EN 60 065 0.5KV (signal lines)
- Page 14 OWNSL issue 1 May 2001 • • Naim Audio Southampton Road Salisbury England SP1 2LN Tel: +44 (0)1722 332266 www.naim-audio.com...
