E-MANUAL
imagine the possibilities
Thank you for purchasing this Samsung
product. To receive more complete service,
please register your product at
www.samsung.com/register
Model __________ Serial No. ____________

Advertisement

Table of Contents
loading

Related Manuals for Samsung Smart TV UE37D5520

Summary of Contents for Samsung Smart TV UE37D5520

  • Page 1 E-MANUAL imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Model __________ Serial No. ____________...

  • Page 2: Table Of Contents

    • System Menu • Anti-theft Kensington Lock • Using Channel menu (Watch TV) • Support Menu • Connections Common Interface Slot • Schedule Manager • Troubleshooting • Channel List • Licence • Channel Manager Advanced Features • Retuning Channels • My Downloads • Anynet+ Basic Features • AllShare™ for LCD 550 series and above • Picture Menu • Sound Menu...

  • Page 3: Using The Info Button

    Scroll ◄, ► to view information for a desired programme while watching the current channel. ● Scroll ▲, ▼ to view information for other channels. If you want to move to the currently selected channel, press the ENTERE button. ▶...

  • Page 4: Guide

    ❑ ❑ Using❑Channel❑menu❑(Watch❑TV)❑ Press the CONTENT button to select Watch❑TV, then select the desired menu. Each screen will be displayed. ❑ ■ Guide The EPG (Electronic Programme Guide) information is provided by Watch TV broadcasters. Using programme Guide schedules provided by broadcasters, Schedule❑Manager...
  • Page 5 Using❑Guide Guide ❑2:10❑Tue❑1❑Jun DTV Air 3 five Home and Away 18:00 - 18:30 Drama Dani is devastated when scott makes clear his views on marriage... 800 five Channel❑View❑-❑All Today 19:00 19:30 20:00 20:30 1❑❑❑❑❑❑❑❑❑❑Discovery American❑Chopper Tine❑Team 2❑❑❑❑❑❑❑❑❑❑DiscoveryH&L Dark❑Angel Tsunami❑Pri... The❑Curious...
  • Page 6 Green (-24❑Hours): Viewing the list of programmes to be broadcasted before 24 hours. Yellow (+24❑Hours): Viewing the list of programmes to be broadcasted after 24 hours. Blue (Ch.❑Mode): Select the type of channels you want to display on the Channel❑ List window. (All,❑TV,❑Radio,❑Data/Other,❑Favourites❑1-5) 5 ;...

  • Page 7: Schedule Manager

    Using❑Timer❑Viewing You can set a desired channel to be displayed automatically at the intended time. Set the current time first to use this function. Press the ENTERE button to add programme to schedule manually.
  • Page 8 It is available when you select Once in Repeat. ● Start❑Time: You can set start time you want. If you want to edit or cancel the schedule, select the reserved schedule on the Schedule❑List, and select the or Cancel❑Schedules. Edit ◀...

  • Page 9: Channel List

    ● TV: Shows all currently available TV channels. ● Radio: Shows all currently radio channels. ● Data/Other: Shows all currently available MHP or other channels. ● Analogue: Shows all currently available analogue channels. ● Favourites❑1-5: Shows all favourite channels. English...
  • Page 10 Favourites❑1-5 will be displayed when you set Add❑to❑Favourites. If you want to view favourite channels you added, press the CH❑LIST button and use L (CH❑Mode) button to move Favourites❑1-5. Using the remote control buttons with the Channel❑List. ● Red (Antenna): Switches to Air,...
  • Page 11 ● ● E (Watch/Information): Watches the channel you select. / Displays details of the selected programme. ● k●(Page): Move to next or previous page. Channel❑Status❑Display❑Icons Icon Operations An analogue channel. A reserved programme. ◀ ▶ A locked channel. English...
  • Page 12 Press the CH❑LIST button, then select a desired digital channel. Press the (Programme❑View) button. Press the ▲ / ▼ buttons to select the desired programme, then press the ENTERE●or INFO button. Select Timer❑Viewing, then press the ENTERE button when done.

  • Page 13: Channel Manager

    ❑ ■ Channel❑Manager You can edit the channel to your preference. ● ) Channels: Shows the channel list according to channel type. ● ) Favourites❑1-5: Shows Channel❑Manager Selected❑item:❑4❑❑❑❑❑❑❑❑❑ChannelNumber favourite channels. ● ) Satellite: Shows the channel list according to satellite signal.
  • Page 14 Channel❑Status❑Display❑Icons Icon Operations An analogue channel. A channel selected. A channel set as a favourite. A locked channel. Displays the Channel❑Manager option menu. ◀ ▶ English...
  • Page 15 Set each channel using the menu options (Watch, Channel❑Manager Add❑to❑ Favourites/Edit❑Favourites,❑Lock/Unlock,❑Edit❑Channel❑Name,❑Edit❑Channel❑ Number,❑Delete,❑Select❑All/Deselect❑All,❑Reorder❑ for LCD 570 series Option menu items may differ depending on the channel status. Select a channel and press the TOOLS button. Select a function and change its settings. ◀ ▶ English...
  • Page 16 If the channel is already added to favourite channel, will Edit❑Favourites be shown. Press the ENTERE button to select Favourites❑1-5, then press the ◀ ▶ button. One favourite channel can be added in several of Favourites among Favourites❑1-5. English...
  • Page 17 ● Lock/Unlock: Lock a channel so that the channel cannot be selected and viewed. NOTE ● This function is available only when the is set to On. Channel❑Lock ● The PIN input screen appears. Enter your 4-digit PIN, Change the PIN using the Change❑PIN...
  • Page 18 ● Delete: You can delete a channel to display the channels you want. ● Deselect❑All: Deselect all the selected channels. You can only select Deselect❑All when one or more channels are selected. ● Select❑All: Select all the channels in the channel list.

  • Page 19: Retuning Channels

    ❑ ■ Antenna❑(Air❑/❑Cable❑/❑Satellite❑ )❑t for LCD 570 series Before your television can begin memorising the available channels, you must specify the type of signal source that is connected to the TV (i.e. an Air, Cable Satellite❑ ❑system). for LCD 570 series ◀...
  • Page 20 ❑ ■ Country (depending on the country) The PIN input screen appears. Enter your 4 digit PIN number. ● Digital❑Channel: Change the country for digital channels. ● Analogue❑Channel: Change the country for analogue channels. ◀ ▶ English...

  • Page 21: Auto Tuning

    Auto❑Tuning (depending on the country) Scans for a channel automatically and stores in the TV. Automatically allocated programme numbers may not correspond to actual or desired programme numbers. If a channel is locked, the PIN input window appears. ● Auto❑Tuning Air❑/❑Cable❑/❑Satellite❑...
  • Page 22 – Search❑Mode (Full❑/❑Network❑/❑Quick): Scans for all channels with active broadcast stations and stores them in the TV. If you select Quick, you can set up the Network,❑Network❑ID,❑ manually by pressing the Frequency,❑Modulation Symbol❑Rate button on the remote control.
  • Page 23 Symbol❑Rate: Displays available symbol rates. ● Cable❑Search❑Option (depending on the country & cable channels only) Sets additional search options such as the frequency and symbol rate for a cable network search. Start❑frequency❑/❑Stop❑frequency: Set the start or stop frequency (differs in ◀...
  • Page 24 When❑Antenna❑Source❑is❑set❑to❑Air,❑Cable❑or❑Satellite: ● Digital❑Channel❑Tuning: Scans for a digital channel manually and stores in the TV. Press the (New) button to search the digital channels. When scanning has finished, a channel is updated in the channel list. ◀ ▶ – → When selecting Antenna Air:❑Channel,❑Frequency,❑Bandwidth...
  • Page 25 – (programme mode): When tuning is complete, the broadcasting stations in your area have been assigned to position numbers from P0 to P99. You can select a channel by entering the position number in this mode. – (aerial channel mode) / (cable channel mode): These two modes ◀...
  • Page 26 Network❑Search❑(Disable❑/❑Enable): Enable / Disable network search using the up/down buttons. ● Signal❑Quality: Display the current status of broadcasting signal. Information on a satellite and its transponder is subject to change depending ◀ ▶ on the broadcasting conditions. When setting is completed, move to...
  • Page 27 ◀ ▶ Satellite: Selects the satellite for receiving digital broadcasts. Transponder: Selects a transponder from the list or adds a new transponder. DiSEqC❑Mode: Selects DiSEqC mode for the selected LNB. Lower❑LNB❑Oscillators: Sets the LNB oscillators to a lower frequency. English...
  • Page 28 During using this function, the sound will be mute temporarily. SatCR/Unicable❑Settings(On❑/❑Off): Enable or disable single cable installation ◀ ▶ support. Slot❑Number: Select the SatCR user slot number for this receiver. Choose it in the range of 1 to 8. English...
  • Page 29 Slot❑Frequency: Enter the appropriate frequency to receive the signal from SatCR. It has the entire range from 950MHz to 2150NHz. The predefined values are 1210MHz, 1420MHz, 1680MHz, 2040MHz. Detect❑Slot❑Frequency: Detect the signal frequency automatically for the selected slot number. Verify❑Slot❑Frequency: Verify that the entered frequency corresponds to the selected slot number.
  • Page 30 ● Positioner❑Settings: Configures the antenna positioner. Positioner❑(On❑/❑Off): Enables or disables the positioned control. Positioner❑Type❑(USALS❑/❑DiSEqC❑1.2): Sets the positioned type between DiSEqC 1.2 and USALS(Universal Satellite Automatic Location System). – My❑Longitude: Sets the longitude for my location. – My❑Latitude: Sets the latitude for my location.
  • Page 31 User❑Mode: Sets the position of satellite antenna according to each satellite. If you store the current position of satellite antenna according to a certain satellite, when the signal of that satellite is needed, the satellite antenna can be moved to pre-populated position.
  • Page 32 – Signal❑Quality: Display the current status of broadcasting signal. Installer❑Mode: Sets limits to the scope of movement of satellite antenna or reset the position. Generally, installation guide uses this function. – Limit❑Position❑(East❑/❑West): Selects the direction of the positioner Limit.
  • Page 33 Store❑Current❑Position: Stores the current position as the selected positioner Limit. – Go❑to❑Zero: Moves the antenna to the reference position. – Reset❑Positioner❑Limit: Allows the antenna to rotate over the full arc. ● Reset❑All❑Setting❑(OK❑/❑Cancel): All satellite settings will be reset to the initial values. ◀...
  • Page 34 ❑ ■ Edit❑Channel❑Number❑(Disable❑/❑Enable) (depending on the country) Use this to change channel number. When channel number is changed, channel information is not updated automatically. ◀ ▶ English...
  • Page 35 ❑ ■ Fine❑Tune❑ (analogue channels only) If the signal is weak or distorted, fine tune the channel manually. Fine tuned channels are marked with an asterisk “*”. To reset the fine-tuning, select Reset. ◀ ▶ English...
  • Page 36 ❑ ■ Transfer❑Channel❑List (depending on the country) Imports or exports the channel map. You should connect a USB storage to use this function. The PIN number input screen appears. Enter your 4 digit PIN number. ● Import❑from❑USB: Import channel list from USB.
  • Page 37 ❑ ❑ Changing❑the❑Preset❑Picture❑Mode ❑ MENUm❑→❑Picture❑→❑Picture❑Mode❑→❑ENTERE ❑ ■ Picture❑Mode Select your preferred picture type. When connecting a PC, you can only make changes to the Entertain Standard. ● Dynamic: Suitable for a bright room. ● Standard: Suitable for a normal environment.
  • Page 38 Adjust screen viewing Angle to optimize screen quality according to your viewing position. ● Samsung❑MagicAngle: When viewing the screen at an angle from below or bove by setting the appropriate mode for each position you can obtain a similar picture quality as viewing the screen directly from the front. ◀ ▶...
  • Page 39 NOTE ● In analogue TV, Ext., modes of the PAL system, the Tint❑(G/R) function is not available. ● When connecting a PC, you can only make changes to Backlight, and Sharpness. Contrast, Brightness ◀ ▶ ● Settings can be adjusted and stored for each external device connected to the TV.
  • Page 40 Set the various picture options such as picture size and aspect ratio. ● Picture❑Size: Your cable box/satellite receiver may have its own set of screen sizes as well. However, we highly recommend you use 16:9 mode most of the time. Auto❑Wide: Automatically adjusts the picture size to the 16:9 aspect ratio.
  • Page 41 4:3: Sets the picture to basic (4:3) mode. Do not watch in 4:3 format for a long time. Traces of borders displayed on the left, right and centre of the screen may cause image retention (screen burn) which are not covered by the warranty.
  • Page 42 Press the u or d button to select Position. Press the ENTERE button. ◀ ▶ Press the u, d, l or r button to move the picture. ● Depending on the input source, the picture size options may vary. ●...
  • Page 43 ● 4:3❑Screen❑Size❑(16:9❑/❑Wide❑Zoom❑/❑Zoom❑/❑4:3): Available only when picture size is set to Auto❑Wide. You can determine the desired picture size at the 4:3 WSS (Wide Screen Service) size or the original size. Each European ◀ ▶ country requires different picture size.
  • Page 44 Position: Adjust the PC’s screen positioning if it does not fit the TV screen. Press the ▲ or ▼ button to adjust the Vertical-Position. Press the ◄ or ► button to adjust the Horizontal-Position.
  • Page 45 ◀ ▶ Depending on the version of Windows and the video card, the actual screens on your PC may differ in which case the same basic set-up information will almost always be applied. (If not, contact your computer manufacturer or Samsung Dealer.)
  • Page 46 Navigate to the “Settings” tab on the display dialog-box. ● The correct size setting (resolution] ● If a vertical-frequency option exists on your display settings dialog box, the correct value is “60” or “60 Hz”. Otherwise, just click “OK” and exit the dialog ◀ ▶ box. English...
  • Page 47 ❑ ❑ Changing❑the❑Picture❑Options ❑ ■ Advanced❑Settings ❑ MENUm❑→❑Picture❑→❑Advanced❑Settings❑→❑ENTERE (available in mode) Standard❑/❑Movie You can adjust the detailed setting for the Advanced❑Settings screen including colour and contrast. ► Black Tone : Off When connecting a PC, you can Dynamic Contrast : Medium...
  • Page 48 Shadow❑Detail: Increase the brightness of dark images. ● Gamma: Adjust the primary colour intensity. ● RGB❑Only❑Mode❑(Off❑/❑Red❑/❑Green❑/❑Blue): Displays the Red, Green and Blue colour for making fine adjustments to the hue and saturation. ● Colour❑Space❑(Auto❑/❑Native): Adjust the range of colours available to create the image. ◀...
  • Page 49 ● White❑Balance: Adjust the colour temperature for a more natural picture. R-Offset❑/❑G-Offset❑/❑B-Offset: Adjust each colour’s (red, green, blue) darkness. R-Gain❑/❑G-Gain❑/❑B-Gain: Adjust each colour’s (red, green, blue) brightness. Reset: Resets the to it’s default settings. White❑Balance ● Flesh❑Tone: Emphasize pink “Flesh Tone.”...
  • Page 50 ❑ ■ Picture❑Options ❑ MENUm❑→❑Picture❑→❑Picture❑Options❑→❑ENTERE When connecting a PC, you can only Picture❑Options make changes to the Colour❑Tone. Colour Tone : Standard ► ● Colour❑Tone❑(Cool❑/❑Standard❑/❑ Digital Noise Filter : Auto MPEG Noise Filter : Auto Warm1❑/❑Warm2) HDMI Black Level : Normal...
  • Page 51 ● Digital❑Noise❑Filter❑(Off❑/❑Low❑/❑Medium❑/❑High❑/❑Auto❑/❑Auto❑Visualisation): If the broadcast signal received by your TV is weak, you can activate the Digital❑Noise❑Filter feature to reduce any static and ghosting that may appear on the screen. When the signal is weak, try other options until the best picture is displayed.
  • Page 52 HDMI ● Film❑Mode❑(Off❑/❑Auto1❑/❑Auto2): Sets the TV to automatically sense and process film signals from all sources and adjust the picture for optimum quality. Available in TV mode, AV, COMPONENT (480i / 1080i) and HDMI (1080i). If the screen does not seem natural, change its option to Off❑/ Auto1❑/...
  • Page 53 ❑ ■ Reset❑Picture❑(OK❑/❑Cancel) Resets your current picture mode to its default settings. ◀ ▶ English...
  • Page 54 Movie: Provides the best sound for movies. ● Clear❑Voice: Emphasizes voices over other sounds. ◀ ▶ ● Amplify: Increase the intensity of high-frequency sound to allow a better listening experience for the hearing impaired. Speaker❑Select is set to External❑Speaker, Sound❑Mode is disabled.
  • Page 55 MENUm❑→❑Sound❑→ Sound❑Effect ❑ ■ Sound❑Effect (standard sound mode only) Use the up and down arrow keys to select an option, and then press ENTERE. ● SRS❑TruSurround❑HD❑(Off❑/❑On) (standard sound mode only) This function provides a virtual 5.1 channel surround sound experience ◀...
  • Page 56 ● Equalizer Use Equalizer to customize sound setting for each speaker. Balance: Adjusts the balance between the right and left speaker. (Bandwidth Adjustment): Adjusts the 100Hz❑/❑300Hz❑/❑1kHz❑/❑3kHz❑/❑10kHz level of specific bandwidth frequencies. Reset: Resets the equalizer to its default settings. Speaker❑Select is set to❑External❑Speaker,...
  • Page 57 When sound is emitted from both the main speaker and the audio receiver, ◀ ▶ a sound echo may occur due to the decoding speed difference between the main speaker and the audio receiver. In this case, use the TV Speaker function. Audio❑Format option may differ depending on the broadcast. 5.1ch Dolby digital sound is only available when connecting an external speaker through an optical cable.
  • Page 58 ● Audio❑Description❑ (not available in all locations) (digital channels only) This function handles the Audio Stream for the AD (Audio Description) which is sent along with the Main audio from the broadcaster. Audio❑Description❑(Off❑/❑On): Turn the audio description function on or off.
  • Page 59 ● DTV❑Audio❑Level❑(MPEG❑/❑HE-AAC): (digital channels only) This function allows you to reduce the disparity of a voice signal (which is one of the signals received during a digital TV broadcast) to a desired level. According to the type of broadcast signal, can be MPEG❑/❑HE-AAC...
  • Page 60 By connecting to 5.1ch speakers in a Dolby Digital setup, maximize your interactive 3D sound experience. Audio❑Delay: Correct audio-video sync problems, when watching TV or ◀ ▶ video, and when listening to digital audio output using an external device such as an AV receiver (0ms ~ 250ms). English...
  • Page 61 Line between loud and soft sounds at night time. Line: Set the output level for signals greater or less than -31dB (reference) to either -20dB or -31dB. RF: Set the output level for signals greater or less than -20dB (reference) to either -10dB or -20dB.
  • Page 62 ❑ ■ Speaker❑Settings ● Speaker❑Select❑(External❑Speaker❑/❑TV❑Speaker) A sound echo may occur due to a difference in decoding speed between the main speaker and the audio receiver. In this case, set the TV to External❑ Speaker. When Speaker❑Select is set to External❑Speaker, the volume and MUTE buttons will not operate and the sound settings will be limited.
  • Page 63 Night: This mode provides an improved sound experience compared to Normal mode, making almost no noise. It is useful at night. To use the volume control on the source device connected to the TV as shown below, set Auto❑Volume to Off on the TV. Otherwise, a change to the volume control of the source device may not be applied.
  • Page 64 ❑ ■ Reset❑Sound❑(OK❑/❑Cancel) Reset all sound settings to the factory defaults. ◀ ▶ English...
  • Page 65 NICAM Stereo Mono❑→❑Dual I Dual Dual I II❑ ❑Dual If the stereo signal is weak and an automatic switching, occurs, then switch to the mono. Only activated in stereo sound signal. Only available when the Source is set to TV.
  • Page 66 You can check the current network and Internet status. ◀ ▶ ❑ ■ AllShare❑Settings ❑ → ENTERE MENUm❑→❑Network❑→ AllShare❑Settings Selects whether to use the call arrivals text message contents, and schedules set on the network. For details on set up options, refer to the “AllShare™” instructions. English...
  • Page 67 You can attach your TV to your LAN using cable in three ways: ● You can attach your TV to your LAN by connecting the LAN port on the back of your TV to an external modem using a LAN cable. See the diagram below.
  • Page 68 ● You can attach your TV to your LAN by connecting the LAN port on the back of your TV to a IP Sharer which is connected to an external modem. Use LAN cable for the connection. See the diagram below.
  • Page 69 Depending on how your network is configured, you may be able to attach your TV to your LAN by connecting the LAN port on the back of your TV directly to a network wall outlet using a LAN cable. See the diagram below.
  • Page 70 Dynamic Host Configuration Protocol (DHCP). Modems and routers that support DHCP automatically provide the IP address, subnet mask, gateway, and DNS values your TV needs to access the Internet so you do not have to enter them manually. Most home networks are Dynamic Networks.
  • Page 71 ❑ ■ Network❑Setup❑(Auto) Use the Automatic Network Setup when connecting your TV to a network that supports DHCP. To set up your TV’s cable network connection automatically, follow these steps: How❑to❑set❑up❑automatically Go to Network❑Settings screen. To enter it, follow the directions of Network❑...
  • Page 72 If it fails to set automatically, check Network❑Settings Wired❑network❑and❑Internet❑connection❑completed. the connection of LAN port. MAC❑Address 00:40:30:30:20:10 IP❑Address 192.168.10.21 If you cannot find network Subnet❑Mask 255.255.255.0 Gateway 192.168.10.1 connection values or if you want DNS❑Server 203.248.252.2 to set connection manually, set it Internet❑is❑connected❑successfully.
  • Page 73 ❑ ■ Network❑Setup❑(Manual) Use the Manual Network Setup when connecting your TV to a network that requires a Static IP address. Getting❑the❑Network❑Connection❑Values To get the Network connection values on most Windows computers, follow these steps: Right click the Network icon on the bottom right of the screen.
  • Page 74 How❑to❑set❑up❑manually To set up your TV’s cable network connection manually, follow these steps: Follow Steps 1 through 2 in the “How to set up automatically” procedure. Select the❑IP❑Settings on network test screen. IP❑Mode to Manual. IP❑Settings Press the ▼ button on your remote ►...
  • Page 75 Enter the IP❑Address, Subnet❑Mask, Gateway, and values. DNS❑Server Use the number buttons on your remote to enter numbers and the arrow buttons to move from one entry field to another. When done, select the OK. The network connection screen appears, and network setting is done.
  • Page 76 ❑ ❑ Connecting❑to❑a❑Wireless❑Network❑ For LCD 550 series and above To connect your TV to your network wireless, you need a wireless router or modem and a Samsung Wireless LAN Adapter (WIS09ABGN, WIS09ABGN2, WIS10ABGN), which you connect to your TV’s back or side panel USB port. See the illustration below.
  • Page 77 Samsung’s Wireless LAN adapter is sold separately and is offered by select retailers, Ecommerce sites. Samsung’s Wireless LAN adapter supports the IEEE 802.11a/b/g and n communication protocols. Samsung recommends using IEEE 802.11n. When you play video over a network connection, the video may not be played smoothly.
  • Page 78 To use a wireless network, your TV must be connected to a wireless IP sharer (either a router or a modem). If the wireless IP sharer supports DHCP, your TV can use a DHCP or static IP address to connect to the wireless network.
  • Page 79 ● If HIGH PURE THROUGHPUT (Greenfield) 802.11n mode is selected and the Encryption type is set to WEP, TKIP or TKIP AES (WPS2Mixed) for your wireless router, Samsung TVs will not support a connection in compliance with new Wi-Fi certification specifications.
  • Page 80 ● If your router, modem, or device is not certified, it may not connect to the TV via the “Samsung Wireless LAN Adapter.” ● Ensure the TV is turned off before you connect the Samsung Wireless LAN Adapter. ● Connection Methods: You can setup the wireless network connection on five ways.
  • Page 81 Samsung Wireless LAN Adapter. In such a case, establish a connection using one of the following methods or connect the Samsung Wireless LAN Adapter using a USB cable in a place that is not affected by radio interference. Method 1...
  • Page 82 ◀ ▶ Wireless LAN Adapter. Attach the Samsung Wireless LAN Adapter to the back of the TV near the top, using double-sided adhesive tape. The Samsung Wireless LAN Adapter should be installed in an interference- free area in order to avoid interference between the adapter and tuner.
  • Page 83 Access or Security Key. The Security Key is based on a Pass Phrase, typically a word or a series of letters and numbers of a specified length you were asked to enter when you set up security for your wireless network.
  • Page 84 Add❑ Network and enter the correct network❑Name❑(SSID) and Security key to establish the connection. If the Security screen pop-up appears, go to step 6. If you select the wireless router which does not have security, go to step 7. English...
  • Page 85 You should be able to find the ◀ ▶ Pass Phrase on one of the set up screens you used to set up your router or modem. The network connection screen appears, and network setting is done. If it fails to set Security key(Security or PIN), select or IP❑Settings.
  • Page 86 ❑ ■ Network❑Setup❑(Manual) Use the Manual Network Setup when connecting your TV to a network that requires a Static IP address. Getting❑the❑Network❑Connection❑Values To get the Network connection values on most Windows computers, follow these steps: Right click the Network icon on the bottom right of the screen.
  • Page 87 IP❑Settings on network test screen. IP❑Mode to Manual. Press the ▼ button on your remote to go to the first entry field. Enter the IP❑Address,❑Subnet❑Mask, Gateway, and DNS❑Server values. Use the number buttons on your remote to enter numbers and the arrow ◀...
  • Page 88 ❑ ■ Network❑Setup❑(WPS(PBC)) How❑to❑set❑up❑using❑WPS(PBC) If your router has a WPS (PBS) button, follow these steps: Go to Network❑Settings screen. To enter it, follow the directions of Network❑ Settings. Select the WPS(PBC). Network❑Settings Select❑a❑network❑connection❑type. Press the WPS(PBC) button on your router within 2 minutes. Your Wired ◀...
  • Page 89 TV and samsung wireless router by placing samsung wireless router within 1foot(25cm) from samsung TV. If your wireless router does not support One❑Foot❑Connection, you must connect using one of the other methods. You can check for equipment that supports One❑Foot❑Connection...
  • Page 90 ◀ ▶ 6.❑ Place the wireless router in a desired location. If the wireless router settings change or you install a new wireless router, you must perform the One❑Foot❑Connection procedure again, beginning from Step 1.
  • Page 91 ❑ ■ Network❑Setup❑(Ad-Hoc) You can connect to a mobile device supporting Ad-hoc without an wireless router through the “Samsung Wireless LAN Adapter”. When connecting mobile device, you can use files on device or connect internet using AllShare or Multimedia function.
  • Page 92 If network does not operate normally, check the Network❑Name❑(SSID) Security❑key again. An incorrect Security❑key may cause a malfunction. If a device is connected once, it is displayed in list. Network❑Setting When you connect it again, you can find it in network setting list. ◀ ▶ English...
  • Page 93 ◀ ▶ your TV may not be able to connect to the Internet. If this is the case, you must enter your ID or password when connecting to the Internet. The internet connection may fail because of a firewall problem. If this is the case, contact your Internet service provider.
  • Page 94 The current time will appear every time you press the INFO button. ● Clock: Setting the clock is for using various timer features of the TV. If you disconnect the power cord, you have to set the clock again. Clock❑Mode: Set up the current time manually or automatically.
  • Page 95 – Manual: Set the current time manually. Depending on the broadcast station and signal, the auto time set up may not be correct. In this case, set the time manually. Clock❑Set: Set the manually. Day,❑Month,❑Year,❑Hour Minute Available only when Clock❑Mode is set to Manual.
  • Page 96 ❑ ❑ Using❑the❑Sleep❑Timer ❑ MENUm❑→❑System❑→❑Time❑→❑Sleep❑Timer❑→❑ENTERE ● Sleep❑Timer t: Automatically shuts off the TV after a preset period of time. (30, 60, 90, 120, 150 and 180 minutes). To cancel Sleep❑Timer, select Off. ❑ ❑ Setting❑the❑On❑/❑Off❑Timer ❑ MENUm❑→❑System❑→❑Time❑→❑On❑ On❑Timer❑1 ◀ ▶...
  • Page 97 TV): Select the desired channel. – (when the is set to USB): Select a folder in the Music❑/❑Photo Source USB device containing music or photo files to be played when the TV is turned on automatically. English...
  • Page 98 NOTE ● If there is no music file on the USB device or the folder containing a music file is not selected, the Timer function does not operate correctly. ● When there is only one photo file in the USB device, the Slide Show will not play.
  • Page 99 Once Setup: Select Off,❑Once,❑Everyday,❑ Off❑Time Mon~Fri,❑Mon~Sat,❑Sat~Sun Manual to set at you convenience. If you select Manual, you can set up the day you want to activate the timer. L❑Move❑❑●U❑Adjust❑❑❑E❑Enter❑❑❑R❑Return The c mark indicates the day is ◀ ▶ selected. Off❑Time: Set the hour, minute.
  • Page 100 Enter your 4-digit PIN. Change the PIN using the option. Change❑PIN ● Channel❑Lock❑(Off❑/❑On): Lock channels in Channel Manager, to prevent unauthorized users, such as children, from watching unsuitable programme. ◀ ▶ Only available when the Input source is set to TV. English...
  • Page 101 Programme❑Rating❑Lock (depending on the country): Prevent unauthorized users, such as children, from watching unsuitable programme with a user- defined 4-digit PIN code. If the selected channel is locked, the “\” symbol will be displayed. The items of differs depending on the country.
  • Page 102 If you turn the TV off while watching in mode, the PIP window will ◀ ▶ disappear. ● You may notice that the picture in the PIP window becomes slightly unnatural when you use the main screen to view a game or karaoke. English...
  • Page 103 Channel: Select the channel for the sub-screen. ● (Õ / Ã): Select a size for the sub-picture. Size ● Position (à / – / — / œ): Select a position for the sub-picture. ◀ ▶ ● Sound❑Select❑(Main❑/❑Sub): You can choose the desired sound (Main Sub) in mode.
  • Page 104 This Energy❑Saving❑(Off❑/❑Low❑/❑Medium❑/❑High❑/❑Picture❑Off) adjusts the brightness of the TV in order to reduce power consumption. If you select Picture❑Off, the screen is turned off, but the sound remains on. Press any button except volume button to turn on the screen.
  • Page 105 ● No-Signal❑Power❑Off❑(Off❑/❑15❑min❑/❑30❑min❑/❑60❑min): To avoid unnecessary energy consumption, set how long you want the TV to remain on if it’s not receiving a signal. Disabled when the PC is in power saving mode. ● Auto❑Power❑Off❑(Off❑/❑On): The TV will be automatically turned off when no user operation is received for 4 hours.
  • Page 106 ❑ ■ Language ● Menu❑Language: Set the menu language. ● Teletext❑Language(depending on the country): Set a desired language for teletext. English is the default in cases where the selected language is unavailable in the broadcast. ◀ ▶ ● Preference❑(Primary❑Audio❑Language❑/❑Secondary❑Audio❑Language❑/❑ Primary❑Subtitle❑Language❑/❑Secondary❑Subtitle❑Language❑/❑Primary❑...
  • Page 107 If the programme you are watching does not support the Hearing❑ Impaired function, Normal automatically activates even if the Hearing❑ Impaired mode is selected. ◀ ▶ English is the default in cases where the selected language is unavailable in the broadcast. English...
  • Page 108 MHEG❑(Multimedia❑and❑Hypermedia❑Information❑Coding❑Experts❑Group) An International standard for data encoding systems used in multimedia and hypermedia. This is at a higher level than the MPEG system which includesdata-linking hypermedia such as still images, character service, animation, graphic and video files as well as multimedia data. MHEG is user runtime interaction technology and is being applied to various fields including ◀...
  • Page 109 ❑ ■ Auto❑Protection❑Time ● Auto❑Protection❑Time❑(Off❑/❑2❑hours❑/❑4❑hours❑/❑8❑hours❑/❑10❑hours): If the screen remains idle with a still image for a certain period of time defined by the user, the screen saver is activated to prevent the formation of ghost images on the screen. ◀...
  • Page 110 ❑ ■ General ● Game❑Mode❑(Off❑/❑On): When connecting to a game console such as PlayStation™ or Xbox™, you can enjoy a more realistic gaming experience by selecting game mode. NOTE ● Precautions and limitations for game mode – To disconnect the game console and connect another external device, set Game❑Mode❑to...
  • Page 111 Standard Sound❑Mode is set to Movie. ● Menu❑Transparency❑(Bright❑/❑Dark): Set the Transparency of the menu. ● Boot❑Logo❑(Off❑/❑On): Display Samsung logo when the TV is turned on. ● TV❑name❑ : Make changes the TV❑name. for LCD 550 series and above ◀ ▶...
  • Page 112 ❑ ■ Anynet+(HDMI-CEC) For details on set up options, refer to the “Anynet+(HDMI-CEC)” instructions. ◀ ▶ English...
  • Page 113 ❑ ■ DivX®❑Video❑On❑Demand Shows the registration code authorized for the TV. If you connect to the DivX web site and register, you can download the VOD registration file. If you play the VOD registration using My❑Downloads, the registration is completed.
  • Page 114 ● Application❑Info: View information on the CAM inserted into the CI slot and on the “CI or CI+ CARD” which is inserted into the CAM. You can install the CAM anytime whether the TV is on or off. Purchase a CI CAM module at your nearest dealer or by phone.
  • Page 115 ❑ ■ Network❑Remote❑Control❑ for LCD 550 series and above Turn on/off or give permission to Samsung mobile phones devices to connect with and control the TV. You must have a Samsung Mobile phone/device which supports Network Remote Control. For more details, refer to each device’s manual.

  • Page 116: Support Menu

    ❑ ❑ Support❑Menu ❑ MENUm❑→❑Support❑→❑e-Manual❑→❑ENTERE ❑ ■ e-Manual You can read the introduction and instructions about the TV features stored in your TV. For the detailed information about e-Manual Screen, refer to “How to view the e-Manual” in User Manual. ◀...

  • Page 117: Sound Menu

    Picture❑Test❑(Yes❑/❑No): Use to check for picture problems. ● Sound❑Test❑(Yes❑/❑No): Use the built-in melody sound to check for sound problems. If you hear no sound from the TV’s speakers, before performing the sound test, make sure Speaker❑Select is set to TV❑Speaker...
  • Page 118 Adjust your antenna to increase signal strength. ● Troubleshooting: If the TV seems to have a problem, refer to this description. If none of these troubleshooting tips apply, contact the Samsung customer service centre.
  • Page 119 2011/01/18_000001 “www.samsung.com” to a USB memory device. By❑USB Current❑Version the software already By❑Online installed in the TV. By❑Channel Alternative❑Software ----/--/--_------ Software is represented as “Year/ Standby❑Mode❑Upgrade :❑Off Month/Day_Version”. ◀ ▶ U❑Move❑❑❑❑E❑Enter❑❑❑❑R❑Return * It may differ depending on the model. English...
  • Page 120 When software is ◀ ▶ upgraded, video and audio settings you have made will return to their default settings. We advise you to to write down your settings so that you can easily reset them after the upgrade. English...
  • Page 121 By❑Channel: Upgrade the software using the broadcasting signal. If the function is selected during the software transmission period, ◀ ▶ software will be automatically searched and downloaded. The time required to download the software is determined by the signal status. English...
  • Page 122 LCD 450 series and above automatically performed at selected time. Since the power of the unit is turned on internally, the screen may be turned on slightly for the product. This phenomenon may continue for more than 1 hour until the software upgrade is ◀...
  • Page 123 ❑ ■ Contact❑Samsung View this information when your TV does not work properly or when you want to upgrade the software. You can find information regarding our call centres, and how to download products and software. ❑ ■ Contents❑Home You can enjoy useful and various contents.
  • Page 124 ❑ ❑ Using❑the❑My❑Downloads Enjoy photos, music and/or movie files saved on a USB Mass Storage Class (MSC) device and/or your PC. Press the CONTENT button to select My❑Downloads. My Downloads Press ▲/▼ button to select desired Videos menu (Videos, Photos, Music), Photos then press the ENTERE button.
  • Page 125 Connect a USB device containing photo, music and/or movie files to the USB❑jack on the side of the TV. When USB is connected to the TV, popup window appears. Then you can select New❑device❑connected. * It may differ depending on the model. ◀ ▶ English...
  • Page 126 Devices should be connected directly to the TV’s USB port. ● Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss.
  • Page 127 LCD 550 series and above ● Do not disconnect the USB device while it is loading. ● The higher the resolution of the image, the longer it takes to display on the screen. ● The maximum supported JPEG resolution is 15360 x 8640 pixels.
  • Page 128 ● If more than 2 PTP devices are connected, you can only use one at a time. ● If more than two MSC devices are connected, some of them may not be recognized.
  • Page 129 ● If an over-power warning message is displayed while you are connecting or using a USB device, the device may not be recognized or may malfunction. ● If the TV has been no input during time set in Auto❑Protection❑Time, the Screensaver will run.
  • Page 130 ● If a USB device connected to the TV is not recognized, the list of files on the device is corrupted or a file in the list is not played, connect the USB device to the PC, format the device and check the connection.
  • Page 131 You are recommended to locate both TV and PC in same subnet. The ◀ ▶ first 3 parts of the IP address of the TV and PC should be the same and only the last part (the host address) should be changed. (e.g. IP Address: 123.456.789.**)
  • Page 132 Using a LAN cable, connect between the external modem and the PC onto which the AllShare PC Software programme will be installed. – You can connect the TV to the PC directly without connecting it through a Sharer (Router). Functions that are not supported when connecting to a PC through a network: ●...
  • Page 133 ● The sorting method may vary. ● The � (REW), µ (FF) or � (Pause) buttons may not work depending on the content information. If you experience any file stuttering issue while playing a video over a wireless network, we recommend using a wired network.
  • Page 134 You can select the desired Yellow (Edit❑Mode); Selects the desired music. The check Contents mode or Device name. box is shown in the screen to check the music you want. It is only available in Music. (Page); Move to next or previous page.
  • Page 135 � (Play) button. – The selected file name is ◀ ▶ displayed on the top with its L Jump T Tools R Return playing time. – If video time information is unknown, play time and progress bar are not displayed. English...
  • Page 136 During video playback, you can search using ◄ and ► button. – You can use (�) (REW) and (µ) (FF) buttons during playback. In this mode, you can enjoy movie clips contained on a Game, but you cannot play the Game itself. ●...
  • Page 137 (fps) (Mbps) DivX 3.11/4. 1920 x 1080 6 ~ 30 x/5.1/6.0 XviD 1920 x 1080 6 ~ 30 MP3 / AC3 / *.avi H.264 BP/MP/ LPCM / ADPCM / 1920 x 1080 6 ~ 30 *.mkv DTS Core ◀ ▶...
  • Page 138 (Mbps) DivX 3.11/4. 1920 x 1080 6 ~ 30 x/5.1/6.0 XviD 1920 x 1080 6 ~ 30 MP3 / AC3 / *.asf H.264 BP/MP/ LPCM / ADPCM / 1920 x 1080 6 ~ 30 MPEG4 SP/ASP 1920 x 1080 6 ~ 30 ◀...
  • Page 139 Bit❑rate❑ File❑Extention Container Video❑Codec Resolution Audio❑Codec (fps) (Mbps) H.264 BP/MP/ 1920 x 1080 6 ~ 30 MP3 / ADPCM / MPEG4 SP/ *.mp4 1920 x 1080 6 ~ 30 XVID 1920 x 1080 6 ~ 30 H.264 BP/MP/ ◀ ▶...
  • Page 140 Bit❑rate❑ File❑Extention Container Video❑Codec Resolution Audio❑Codec (fps) (Mbps) MPEG1 1920 x 1080 24/25/30 *.mpg AC3 / MPEG / MPEG2 1920 x 1080 24/25/30 *.mpeg LPCM / AAC H.264 1920 x 1080 6 ~ 30 MPEG2 1920 x 1080 24/25/30 ◀...
  • Page 141 Other❑Restrictions NOTE ● Video content will not play, or not play correctly, if there is an error in the content or the container. ● Sound or video may not work if the contents have a standard bit rate/ frame rate above the compatible Frame/sec listed in the table above.
  • Page 142 Supports up to H.264, Level 4.1 Supports up to WMA 7, 8, 9, STD, 9 PRO ● ● H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 WMA Lossless, Voice Lossless, Voice is and AVCHD are not supported. not supported.
  • Page 143 1.❑ Press the ◄/►/▲/▼ button to Music select the desired Music in the file list. Press the ENTERE button or � (Play) button. – You can use � (REW) ◀ ▶ and❑µ❑(FF) buttons during playback. E Pause L Pages T Tools R Return English...
  • Page 144 Only displays the files with MP3 file extension. Other file extensions are not displayed, even if they are saved on the same USB device. If the sound is abnormal when playing MP3 files, adjust the in the Equalizer Sound menu. (An over-modulated MP3 file may cause a sound problem.) Playing❑selected❑music...
  • Page 145 E Pause L Previous/Next T Tools R Return slide show. ● During the slide show, all files in the file list will be displayed in order. When you press the � (Play) button in the file list, slide show will be started immediately.
  • Page 146 Music files can be automatically played during the Slide Show if the Background❑Music is set to On. ❑ ❑ My❑Downloads❑-❑Additional❑Functions Videos/Music/Photos❑Play❑Option❑menu During playing a file, press the TOOLS button. Category Operation Videos Music Photos You can move the other file Title❑Search...
  • Page 147 Category Operation Videos Music Photos You can play movie and music Repeat❑Mode files repeatedly. You can adjust the picture size to Picture❑Size your preference. You can adjust the picture Picture❑Mode setting. ◀ ▶ Sound❑Mode You can adjust the sound setting.
  • Page 148 Category Operation Videos Music Photos You can enjoy video in one of supported languages as required. The function is only Subtitle❑Language enabled when stream-type files which support multiple audio formats are played. You can play the video with Subtitles. This function only Subtitle❑Setting...
  • Page 149 Category Operation Videos Music Photos Start❑Slide❑Show❑/❑ You can start or pause a Slide Show. Pause❑Slide❑Show You can select the slide show Slide❑Show❑Speed speed during the slide show. You can on/off background Background❑Music music when watching a Slide Show. ◀ ▶...
  • Page 150 Videos Music Photos You can select background Background❑Music❑ music when watching a Slide Setting Show. You can zoom into images in full Zoom screen mode. You can rotate images in full Rotate screen mode. You can see detailed information ◀...
  • Page 151 What❑is❑Anynet+?❑ ❑ Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it.
  • Page 152 If you want to hear 5.1 channel audio, connect the DIGITAL AUDIO OUT (OPTICAL) jack on the DVD / Satellite Box (i.e. Anynet Device 1 or 2) directly to the Amplifier or Home Theatre, not the TV. ●...

  • Page 153: Anynet

    Anynet+❑Menu ❑ TOOLST❑→❑Anynet+❑(HDMI-CEC)❑→❑ENTERE The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected to the TV. Anynet+❑Menu Description Changes Anynet+ mode to TV broadcast mode. View❑TV Shows the Anynet+ device list. Device❑List ◀ ▶ (device_name) Shows the connected device menus.
  • Page 154 Anynet+❑Menu Description Shows the play menu of the connected device. E.g. If a DVD (device_name) recorder is connected, the play menu of the DVD recorder will TOOLS appear. Shows the title menu of the connected device. E.g. If a DVD...
  • Page 155 Auto❑Turn❑Off❑(No❑/❑Yes): Setting an Anynet+ Device to turn off automatically ◀ ▶ when the TV is turned off. is set to Yes, running external devices will turn off at the Auto❑Turn❑Off same time as the TV powers off. May not be enabled depending on the device.
  • Page 156 Anynet+ devices connected to the TV are listed in Device❑List. If you cannot find a device you want, press the button to refresh the list. Select a device and press the ENTERE button. You can switch to the selected device. Only when you set Anynet+❑(HDMI-CEC)
  • Page 157 ❑ ❑ Listening❑through❑a❑Receiver❑ You can listen to sound through a receiver (i.e Home Theatre) instead of the TV speaker. Select and set to On. Receiver Press the EXIT button to exit. If your receiver supports audio only, it may not appear in the device list.
  • Page 158 NOTE ● You can only control Anynet+ devices using the TV remote control, not the buttons on the TV. ● The TV remote control may not work under certain conditions. If this occurs, reselect the Anynet+ device. ◀ ▶ English...
  • Page 159 ❑ ❑ Troubleshooting❑for❑Anynet+ Problem Possible❑Solution ● Check if the device is an Anynet+ device. The Anynet+ Anynet+ does not work. system supports Anynet+ devices only. ● Only one receiver (home theatre) can be connected. ● Check if the Anynet+ device power cord is properly connected.
  • Page 160 (initial setup), etc.) ● When connecting or removing the HDMI cable, please ◀ ▶ make sure to search devices again or turn your TV off and on again. ● Check if the Anynet+ Function of Anynet+ device is set English...
  • Page 161 Problem Possible❑Solution ● Check if the Anynet+ device is properly connected to I want to start Anynet+. the TV and check if the❑Anynet+❑(HDMI-CEC) is set to in the System menu. ● Press the TOOLS button to display the Anynet+ menu and select a menu you want.
  • Page 162 Problem Possible❑Solution ● You cannot use the remote control when you are The message “Connecting❑to❑Anynet+❑ configuring Anynet+ or switching to a view mode. device...” appears on the ● Use the remote control when the Anynet+ setting or screen. switching to view mode is complete.
  • Page 163 You can connect an Anynet+ device using the HDMI cable only. Some HDMI cables may not support Anynet+ functions. ● If it is terminated by an abnormal situation such as disconnecting the HDMI cable or power cord or a power failure, please repeat the device scan. English...
  • Page 164 Problem Possible❑Solution ● Connect the optical cable between TV and the receiver. The TV sound is not output through the receiver. ◀ ▶ English...
  • Page 165 AllShare™ connects your TV and compatible Samsung mobile phones / devices through a network. In addition, you can play media contents including videos, photos and music saved on your mobile phones or the other devices (such as your PC) by controlling them on the TV via the network.

  • Page 166: Allshare

    ❑ ❑ Setting❑Up❑AllShare™ ❑ MENUm❑→❑Network❑→❑AllShare❑Settings❑→❑ENTERE ❑ ■ AllShare❑Settings AllShare❑Settings ● Media❑(On❑/❑Off): Enables or disables the media function. When the media function is on, Media contents play Media ► can be controlled by mobile phones or other devices that support DLNA ◀ ▶...
  • Page 167 ❑ ■ Media Shows a list of mobile phones or connected devices which have been set up with this TV for using the Media function. function is available in all devices which support DLNA DMC. Media ● Allow / Deny: Allows/Blocks the devices.
  • Page 168 Using❑the❑Media❑Function❑ You can play media contents including videos, photos and music saved on your mobile phones or the other devices (such as your PC) by controlling them on the TV via the network. ● To turn off the media contents transmission from the devices, set Media in the AllShare❑Settings.

  • Page 169: Analogue Channel Teletext Feature

    ❑ ❑ Analogue❑Channel❑Teletext❑Feature The index page of the Teletext service gives you information on how to use the service. For Teletext information to be displayed correctly, channel reception must be stable. Otherwise, information may be missing or some pages may not be displayed.
  • Page 170 Teletext. ● 4●(size): Displays the teletext on the upper half of the screen in double-size. To move the text to the lower half of the screen, press it again. For normal display, press it once again. ● 9 (hold): Holds the display at the current page, in the case that there are several secondary pages that follow automaticially.
  • Page 171 Press the colour corresponding to the topic of your choice. A new colourcoded page is displayed. Items can be selected in the same way. To display the previous or next page, press the corresponding coloured button.
  • Page 172 The❑Teletext❑pages❑are❑organized❑according❑to❑six❑categories: Part Contents Selected page number. Broadcasting channel identity. Current page number or search indications. Date and time. Text. Status information. FASTEXT information. ◀ ▶ English...

  • Page 173: Anti-Theft Kensington Lock

    Refer to the manual provided with the Kensington Lock for additional information on proper use. Please find a “K” icon on the rear of the TV. A kensington slot is beside the “K” icon. The position and color may ◀...
  • Page 174 Wrap the Kensington lock cable around a large, stationary object such as desk or chair. Slide the end of the cable with the lock attached through the looped end of the Kensington lock cable. Insert the locking device into the Kensington slot on the product Lock the lock.

  • Page 175: Connections Common Interface Slot

    * It may differ depending on the model. The pairing information containing a telephone number, the “CI or CI+ CARD” ID, the Host ID and other information will be displayed in about 2~3 minutes. If an error message ◀ ▶...
  • Page 176 NOTE ● You must obtain a “CI or CI+ CARD” from a local cable service provider. ● When removing the “CI or CI+ CARD”, carefully pull it out with your hands since dropping the “CI or CI+ CARD” may cause damage to it.

  • Page 177: Troubleshooting

    ❑ ❑ Troubleshooting If you have any questions about the TV, first refer to this list. If none of these troubleshooting tips apply, please visit “www.samsung.com”, then click on Support. Issues Solutions❑and❑Explanations Picture Quality First of all, please perform the Picture❑Test...
  • Page 178 Issues Solutions❑and❑Explanations ● If you have an analogue cable/set top box, upgrade to a The TV image does not look as good as it digital set top box. Use HDMI or Component cables to did in the store. deliver HD (high definition) picture quality.
  • Page 179 Low signal level or bad quality can cause picture distortion. This is not a TV issue. ● Mobile phones used close to the TV (cca up to 1m) may cause noise in picture on analog and digital TV. ◀ ▶...
  • Page 180 ● Try resetting the picture to view the default picture settings. (go to MENU - Picture❑-❑Reset❑Picture) ● If the picture size is set to Screen❑Fit, change it to 16:9. There is a dotted line ◀ ▶ on the edge of the ●...
  • Page 181 TV audio is properly operating. (go to MENU - ◀ ▶ Support❑-❑Self❑Diagnosis❑-❑Sound❑Test) If the audio is OK, the sound problem may caused by the source or signal. ● Please check the volume of the device (Cable/Sat Box, There is no sound or the sound is too low DVD, Blu-ray etc) connected to your TV.
  • Page 182 HDMI when you have a ◀ ▶ HDMI connected to your TV). ● If you are using a DVI to HDMI cable, a separate audio cable is required. ● Reboot the connected device by reconnecting the device’s power cable.
  • Page 183 Make sure the wall outlet is working. ● Try pressing the POWER button on the TV to make sure the problem is not the remote. If the TV turns on, refer to “The remote control does not work” below. English...
  • Page 184 Make sure the AC power cord is plugged in securely to the wall outlet and the TV. ● When watching TV from an antenna or cable connection, ◀ ▶ the TV will turn off after 10 ~ 15 minutes if there is no signal. English...
  • Page 185 Set your external devices’ (Cable/Set top Box, DVD, Blu-ray etc) video outputs to match the connections to the TV input. For example, if an external device’s output is HDMI, it should be connected to an HDMI input on the TV. ●...
  • Page 186 Compression of video contents may cause picture The picture is distorted: macro block distortion. especially on fast moving pictures such as error small block, sports and action movies. dots, pixelization ● A low signal can cause picture distortion. This is not a TV issue. English...
  • Page 187 Set your PC’s output resolution so it matches the “Mode❑Not❑ Supported” message resolutions supported by the TV. appears. ● This is normal; “PC” is always shown on the source list, “PC” is always shown on the source list, regardless of whether a is connected. even if a is not connected.
  • Page 188 Samsung Wireless USB dongle is required to use a The wireless network connection failed. wireless network. ● Make sure the Network Connection is set to Wireless. ● Make sure the TV is connected to a wireless IP sharer (Router). ● Network❑Settings Network menu. Software Upgrade ◀...
  • Page 189 Issues Solutions❑and❑Explanations Others ● HD channels will have black bars on either side of the The picture will not display in full screen. screen when displaying up scaled SD (4:3) contents. ● Black bars on the top and bottom will appear during movies that have aspect ratios different from your TV.
  • Page 190 ● Programme the Cable/Set top box remote control to The cable/set top box remote control doesn’t operate the TV. Refer to the Cable/Set user manual for turn the TV on or off, the SAMSUNG TV code. or adjust the volume.
  • Page 191 Remove the stand base from the TV and reassemble it. TV is tilted to the right or left side. ● Make sure the TV is placed on a flat surface. If you There are difficulties assembling the stand can not remove the screws from the TV, please use a base.
  • Page 192 Loss of audio or video can be caused by using overly rigid or thick cables. Make sure the cables are flexible enough for long term use. If mounting the TV to the wall, we recommend using cables with 90 degree connectors.
  • Page 193 If you are using a CAM CARD (CI/CI+), check that it is The message “Scramble❑signal” installed into the common interface slot. “Weak❑Signal/No❑ ● If there is still a problem, pull the CAM CARD out of the Signal” appears. TV and insert it into the slot again. ◀ ▶ ●...

  • Page 194: Licence

    5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks. & DTS 2.0+ ◀ ▶ Digital Out and the DTS logos are trademarks of DTS, Inc. Product Includes software. © DTS, Inc. All Rights Reserved. English...
  • Page 195 ® DivX Certified device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup ◀ ▶ menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD.
  • Page 196 SRS Labs, Inc. TheaterSound technology is incorporated under licence from SRS Labs, Inc. Open❑Source❑Licence❑Notice In the case of using open source software, Open Source Licences are available on the product menu. Open Source Licence Notice is written only English. ◀...

Table of Contents
