Sharp XL-DK257N Service Manual
  1. Manuals
  2. Brands
  3. Sharp Manuals
  4. Stereo System
  5. XL-DK257N
  6. Service manual
Sharp XL-DK257N Service Manual

Sharp XL-DK257N Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
iPod is a registered trademark of Apple Inc.
[1]
[2]
[3]
Specifications...............................................
[4]
Name Of Parts .............................................
[1]
CD Section .................................................. 2-1
[2]
Test Mode .................................................... 2-2
[3]
Error Message Display Contents ................. 2-4
[1]
Disassembly ................................................ 3-1
[1]
Block Diagram ............................................. 4-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with
!
specified ones for maintaining the safety and performance of the set.
SHARP CORPORATION
SERVICE MANUAL
MICRO COMPONENT SYSTEM
MODEL
XL-DK257N Micro Component System consisting of
XL-DK257N (main unit) and CP-DK257N (speaker system).
• In the interests of user-safety (Required by safety regulations in
some countries) the set should be restored to its original condition
and only parts identical to those specified be used.
CONTENTS
[1]
Waveforms Of Servo Circuit ........................ 5-1
[2]
IC Voltage .................................................... 5-3
...... 1-1
...... 1-1
...... 1-2
LAYOUT
...... 1-3
[1]
Notes On Schematic Diagram ..................... 6-1
[2]
Types Of Transistor And LED ...................... 6-1
[3]
Schematic Diagram ..................................... 6-2
[4]
Charts Of Connecting Wires ...................... 6-10
[5]
Wiring Side of PWB ................................... 6-12
[1]
Troubleshooting ........................................... 7-1
[1]
Function Table Of IC .................................... 8-1
[2]
FL Display.................................................... 8-9
This document has been published to be used for
after sales service only.
- 1
The contents are subject to change without notice.
XL-DK257N
No. S2807XLDK257N
XL-DK257N

Advertisement

Table of Contents
loading

Related Manuals for Sharp XL-DK257N

Summary of Contents for Sharp XL-DK257N

  • Page 1: Table Of Contents

    XL-DK257N MODEL XL-DK257N Micro Component System consisting of XL-DK257N (main unit) and CP-DK257N (speaker system). • In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified be used.

  • Page 2: Precautions For Using Lead-Free Solder

    XL-DK257N PRECAUTIONS FOR USING LEAD-FREE SOLDER 1. Employing lead-free solder "MAIN, POWER, AMPLIFIER, HEADPHONE, MICOM REFLASH, DISPLAY, SPEAKER, VOLUME LED LIGHT UP, iPOD, CD PWB" of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWB and service manuals. The alphabetical character following LF shows the type of lead-free solder.

  • Page 3: Chapter 1. General Description

    XL-DK257N CHAPTER 1. GENERAL DESCRIPTION [1] Important Service Safety Precaution CAUTION : “These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so”.

  • Page 4: Specifications

    XL-DK257N [3] Specifications CD player General Type Single disc multi-play compact disc player Power source AC 120 V ~ 60 Hz Signal readout Non-contact, 3-beam semiconductor laser Power consumption 56 W pickup Dimensions Width: 7-1/16" (180 mm) D/A converter Multi bit D/A converter Height: 10-2/8"...
  • Page 5 XL-DK257N [4] Names Of Parts Front panel 1. Disc Tray 2. Power On/Stand-by Button 3. Disc Tray Open/Close Button 4. Timer Indicator 5. Disc or iPod Play or Pause button 6. Disc Stop Button 7. Volume Control 8. Audio In Jack 9.
  • Page 6 XL-DK257N Remote control 1. Remote Control Transmitter 2. Disc Clear/Dimmer, iPod Menu Button 3. Memory, iPod Enter Button 4. Disc Direct Search Buttons 5. Equalizer Mode Select Button 6. Extra Bass/Demo Button 7. Volume Up and Down Buttons 8. Power On/Stand-by Button 9.

  • Page 7: Chapter 2. Adjustments

    XL-DK257N CHAPTER 2. ADJUSTMENTS [1] CD Section 1. CD SECTION • Adjustment Since this CD system incorporates the following automatic adjustment functions, readjustment is not needed when replacing the pickup. Therefore, different PWBs and pickups can be combined freely. Each time a disc is changed, these adjustments are performed automatically.

  • Page 8: Test Mode

    XL-DK257N [2] Test Mode • Setting the test mode During AC unplug, plug-in AC while pressing down the POWER button and CD button. Then, press the CD button to enter the test mode. T E S T IL isn’t done OPEN/CLOSE operation is using manual.
  • Page 9 XL-DK257N STOP and return to Step 1 Everytime << DISPLAY >> key input a) Focus Balance = FB : XX b) Focus Gain = FG : XX c) Tracking Balance = TB : XX d) Tracking Gain = TG : XX...

  • Page 10: Standard Specification Of Stereo System Error Message Display Contents

    XL-DK257N [3] Standard Specification Of Stereo System Error Message Display Contents Error Contents DISPLAY Notes Focus Not Match/IL Time Over. ‘NO DISC’ TUNER PLL Unlock. PLL Unlock. 87.50 AMP abnormal detection and +B PROTECTION display In case AMP abnormal detection or +B PROTECTION had occurred, the unit will automatically enter to stand-by mode and Timer indicator will flashing as below.

  • Page 11: Chapter 3. Mechanical Description

    XL-DK257N CHAPTER 3. MECHANICAL DESCRIPTION [1] Disassembly Caution on disassembly Top Cabinet Front Panel Follow the below-mentioned notes when disassembling the unit and reassembling it, to keep it safe and ensure excellent performance: 1) Take cassette tape and compact disc out of the unit.
  • Page 12 XL-DK257N Rear Panel (P2)x4 Special (H1)x2 CD Mechanism Ø3x10mm CD Changer Unit Speaker PWB Figure 4 Front Panel Display PWB (J2)x1 (J4)x6 Figure 8 Ø 2.6x10mm (J1)x1 (J3)x1 SUB PWB USB PWB (K1)x2 Ø 2.6x10mm Jack PWB (L1)x1 Special Figure 5...
  • Page 13 XL-DK257N STEP PROCEDURE FIGURE REMOVAL Woofer 1. Net Frame Ass’y.... (A1) X 1 9, 10 2. Catching Holder..... (A2) X 4 3. Screw ......(A3) X 4 4. Screw ......(A4) X 4 Tweeter 1. Screw ......(B1) X 2 Speaker Box Net Frame Ass’y...

  • Page 14: Chapter 4. Block Diagram

    XL-DK257N CHAPTER 4. DIAGRAMS [1] Block Diagram Figure 1: BLOCK DIAGRAM (1/2) 4 – 1...
  • Page 15 XL-DK257N 120V/60Hz Figure 2: BLOCK DIAGRAM (2/2) 4 – 2...
  • Page 16 XL-DK257N [2] CD Block Diagrams Figure 4-3: CD BLOCK DIAGRAM (1/2) 4 – 3...
  • Page 17 XL-DK257N PA016AW Figure 4-4: CD BLOCK DIAGRAM (2/2) 4 – 4...

  • Page 18: Chapter 5. Circuit Description

    XL-DK257N CHAPTER 5. CIRCUIT DESCRIPTION [1] Waveforms Of Servo Circuit TMAX LPFO LRCKI BCKI 5 – 1...
  • Page 19 XL-DK257N [2] Voltage VOLTAGE VOLTAGE VOLTAGE VOLTAGE 0.02 0.01 1.53 3.26 1.63 1.52 0.03 1.63 0.76 3.03 3.27 0.98 1.52 0.03 0.02 0.70 0.59 1.52 0.03 1.74 0.01 3.27 1.63 0.70 1.63 3.27 1.53 1.63 3.27 0.03 3.27 1.68 1.63 4.53...
  • Page 20 XL-DK257N IC701 IC601 IC705 VOLTAGE VOLTAGE VOLTAGE VOLTAGE 2.60m 3.50m 4.10 8.43 2.60m -0.20m 4.10 8.49 3.13 1.88 4.10 3.77 3.13 3.28 0.40m 2.39 2.00m 3.04 4.10 0.49 3.12 2.80m 4.12 0.49 3.13 2.30m 4.10 0.49 1.30m 2.00m 4.12 0.49 0.50m...
  • Page 21 XL-DK257N IC702 IC851 IC852 VOLTAGE VOLTAGE VOLTAGE VOLTAGE 5.10 13.24 -26.44 -26.42 -26.40 -28.77 13.00 88.4m -26.40 -26.41 17.60 4.76 -26.40 -26.40 3.24 -26.41 3.20 -24.06 3.27 -17.00 3.24 -26.40 0.00 -24.07 IC853 Q905 0.00 -9.89 3.29 -26.40 VOLTAGE VOLTAGE 1.51...
  • Page 22 XL-DK257N -MEMO- 5 – 5...

  • Page 23: Chapter 6. Circuit Schematics And Parts

    XL-DK257N CHAPTER 6. CIRCUIT SCHEMATICS AND PARTS LAYOUT [1] Notes On Schematic Diagram • Resistor: • Schematic diagram and Wiring Side of P.W.Board To differentiate the units of resistors, such symbol as this model subject change K and M are used: the symbol K means 1000 ohm improvement without prior notice.

  • Page 24: Schematic Diagram

    XL-DK257N [3] Schematic Diagram NTP18N06 GD1A4 GD1A4 GD1A4 ZJ27D 0.22 NTP18N06 47/10 47/10 100/16 Figure 6-1: MAIN SCHEMATIC DIAGRAM (1/6) 6 – 2...
  • Page 25 XL-DK257N LUG2 A980AW Figure 6-2: MAIN SCHEMATIC DIAGRAM (2/6) 6 – 3...
  • Page 26 XL-DK257N FROM HEADPHONE PWB-A4 TO CHASSIS TO MICOM SECTION Figure 6-3: MAIN SCHEMATIC DIAGRAM (3/6) 6 – 4...
  • Page 27 XL-DK257N IN4004S IN4004S CNP301 ZX11AW Figure 6-4: MAIN SCHEMATIC DIAGRAM (4/6) 6 – 5...
  • Page 28 XL-DK257N Figure 6-5: MAIN SCHEMATIC DIAGRAM (5/6) 6 – 6...
  • Page 29 XL-DK257N TO MICOM SECTION JP41 100µH ZD862 ZJ15B D851 HSS4148 +13V FROM CLAMP SECTION Figure 6-6: MAIN SCHEMATIC DIAGRAM (6/6) 6 – 7...
  • Page 30 XL-DK257N AMPLIFIER SECTION Figure 6-7: AMPLIFIER & SPEAKER SCHEMATIC DIAGRAM (1/2) 6 – 8...
  • Page 31 XL-DK257N (CHASSIS) L921 L920 Z0055 Z0055 SPEAKER PWB-B2 Figure 6-8: AMPLIFIER & SPEAKER SCHEMATIC DIAGRAM (2/2) 6 – 9...
  • Page 32 XL-DK257N CHASSIS GND 1.3V Figure 6-9: POWER SCHEMATIC DIAGRAM (1/2) 6 – 10...
  • Page 33 XL-DK257N PT801 PA105AW PA078AW Figure 6-10: POWER SCHEMATIC DIAGRAM (2/2) 6 – 11...
  • Page 34 XL-DK257N VOLUME LED LIGHT-UP PWB-B3 RP767 (1/4) 270P 1000 1000 Figure 6-11: DISPLAY & VOLUME LED LIGHT-UP SCHEMATIC DIAGRAM (1/2) 6 – 12...
  • Page 35 XL-DK257N 270P 1000P 1000P Figure 6-12: DISPLAY & VOLUME LED LIGHT-UP SCHEMATIC DIAGRAM (2/2) 6 – 13...
  • Page 36 XL-DK257N MICOM SECTION CNP701B WZY18AW Figure 6-13: MICOM & HEADPHONE SCHEMATIC DIAGRAM (1/6) 6 – 14...
  • Page 37 XL-DK257N MICOM REFLASH PWB-A7 SYSTEM MICOM REFLASH PWB 2.7K Figure 6-14: MICOM & HEADPHONE SCHEMATIC DIAGRAM (2/6) 6 – 15...
  • Page 38 XL-DK257N HEADPHONE PWB-A4 HEADPHONE D714 MA111 D715 MA111 B026AW Figure 6-15: MICOM & HEADPHONE SCHEMATIC DIAGRAM (3/6) 6 – 16...
  • Page 39 XL-DK257N CNP701B WZY18AW Figure 6-16: MICOM & HEADPHONE SCHEMATIC DIAGRAM (4/6) 6 – 17...
  • Page 40 XL-DK257N 2.7K FROM MAIN SECTION (AUDIO PRO OUTPUT Figure 6-17: MICOM & HEADPHONE SCHEMATIC DIAGRAM (5/6) 6 – 18...
  • Page 41 XL-DK257N TO AMP SECTION N SECTION RO OUTPUT) Figure 6-18: MICOM & HEADPHONE SCHEMATIC DIAGRAM (6/6) 6 – 19...
  • Page 42 XL-DK257N (CHASSIS) Figure 6-19: iPOD SCHEMATIC DIAGRAM (1/2) 6 – 20...
  • Page 43 XL-DK257N Figure 6-20: iPOD SCHEMATIC DIAGRAM (2/2) 6 – 21...
  • Page 44 XL-DK257N Figure 6-21: CD SERVO SCHEMATIC DIAGRAM (1/2) 6 – 22...
  • Page 45 XL-DK257N PA016AW Figure 6-22: CD SERVO SCHEMATIC DIAGRAM (2/2) 6 – 23...

  • Page 46: Charts Of Connecting Wires

    XL-DK257N [4] Charts Of Connecting Wires DISPLAY PWB-B1 MICOM REFLASH PWB-A5 CNP701A Bi703 MICOM EXTERNAL DEVICE CNS703 FFC701 CD PWB-D (CNP6) FFC705 FFC702 CNS801 1 2 3 4 5 6 1 2 3 4 5 6 7 8 9 10 11...
  • Page 47 XL-DK257N FROM MAIN PWB-A1 (Bi601) FROM MAIN PWB-A1 (CNP702) FFC705 CNS601 CNP5 CNP6 CNP3 VOLUME LED LIGHT-UP PWB-B3 CD PWB-D CNP1 CD PWB-D ANTENNA (CNP6) FFC301 FFC1 iPOD PWB-C 9 11 CNP702 CNP301 TUNER PACK CD PICK-UP UNIT FROM FFC102...

  • Page 48: Wiring Side Of Pwb

    XL-DK257N [5] Wiring Side Of PWB MAIN PWB-A1 10 9 8 7 6 5 4 3 2 1 D G S D G S 2 3 4 5 6 7 8 9 10 11 12 2 3 4 5 6 Lead-free solder indication Lead-free solder is used in the MAIN PWB.
  • Page 49 XL-DK257N VIDEO OUT SUBWOOFER 9 10 11 12 PRE-OUT 2 3 4 5 6 7 8 9 10 Figure 6-26: WIRING SIDE OF MAIN PWB (TOP VIEW) (2/2) 6 – 27...
  • Page 50 XL-DK257N MAIN PWB-A1 JP46 Figure 6-27: WIRING SIDE OF MAIN PWB (BOTTOM VIEW) (1/2) 6 – 28...
  • Page 51 XL-DK257N Lead-free solder indication Lead-free solder is used in the MAIN PWB. Refer to "Precautions for handling lead-free solder" for instructions and precautions. Figure 6-28: WIRING SIDE OF MAIN PWB (BOTTOM VIEW) (2/2) 6 – 29...
  • Page 52 XL-DK257N POWER PWB-A2 RL841 RELAY PT841 POWER TRANSFORMER (SUB) TF801 PT801 POWER TRANSFORMER (MAIN) B C E Lead-free solder indication Lead-free solder is used in the POWER PWB. Refer to "Precautions for handling lead-free solder" for instructions and precautions. Figure 6-29: WIRING SIDE OF POWER PWB (TOP VIEW)
  • Page 53 XL-DK257N -MEMO- 6 – 31...
  • Page 54 XL-DK257N AMPLIFIER PWB-A3 2 4 6 8 10 12 14 1618 20 22 1 3 5 7 9 11 13 15 1719 21 23 Lead-free solder indication Lead-free solder is used in the AMPLIFIER PWB. Refer to "Precautions for handling lead-free solder" for instructions and precautions.
  • Page 55 XL-DK257N AMPLIFIER PWB-A3 Lead-free solder indication Lead-free solder is used in the AMPLIFIER PWB. Refer to "Precautions for handling lead-free solder" for instructions and precautions. Figure 6-31: WIRING SIDE OF AMPLIFIER PWB (BOTTOM VIEW) 6 – 33...
  • Page 56 XL-DK257N HEADPHONE PWB-A4 AUDIO IN FOR HEADPHONE ONLY 3 2 1 MICOM REFLASH PWB-A5 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Lead-free solder indication Lead-free solder is used in the HEADPHONE and MICOM REFLASH PWB.
  • Page 57 XL-DK257N HEADPHONE PWB-A4 Lead-free solder indication Lead-free solder is used in the HEADPHONE PWB. Refer to "Precautions for handling lead-free solder" for instructions and precautions. Figure 6-33: WIRING SIDE OF HEADPHONE PWB (BOTTOM VIEW) 6 – 35...
  • Page 58 XL-DK257N FL701 DISPLAY PWB-B1 2 4 6 8 10 12 14 16 18 7 9 11 13 15 17 Figure 6-34: WIRING SIDE OF DISPLAY PWB AND VOLUME LED LIGHT-UP (TOP VIEW) (1/2) 6 – 36...
  • Page 59 XL-DK257N FL701 VOLUME LED LIGHT-UP PWB-B3 Lead-free solder indication Lead-free solder is used in the DISPLAY PWB and VOLUME LED LIGHT-UP. Refer to "Precautions for handling lead-free solder" for instructions and precautions. Figure 6-35: WIRING SIDE OF DISPLAY PWB AND VOLUME LED LIGHT-UP (TOP VIEW) (2/2)
  • Page 60 XL-DK257N DISPLAY PWB-B1 VOLUME LED LIGHT-UP PWB-B3 Figure 6-36: WIRING SIDE OF DISPLAY PWB AND VOLUME LED LIGHT-UP (BOTTOM VIEW) (1/2) 6 – 38...
  • Page 61 XL-DK257N Lead-free solder indication Lead-free solder is used in the DISPLAY PWB and VOLUME LED LIGHT-UP. Refer to "Precautions for handling lead-free solder" for instructions and precautions. Figure 6-37: WIRING SIDE OF DISPLAY PWB AND VOLUME LED LIGHT-UP (BOTTOM VIEW) (2/2)
  • Page 62 XL-DK257N SPEAKER PWB-B2 1 2 3 4 Lead-free solder indication Lead-free solder is used in the SPEAKER PWB. Refer to "Precautions for handling lead-free solder" for instructions and precautions. Figure 6-38: WIRING SIDE OF SPEAKER (TOP VIEW) 6 – 40...
  • Page 63 XL-DK257N SPEAKER PWB-B2 Lead-free solder indication Lead-free solder is used in the SPEAKER PWB. Refer to "Precautions for handling lead-free solder" for instructions and precautions. Figure 6-39: WIRING SIDE OF SPEAKER AND VOLUME LED LIGHT-UP PWB (BOTTOM VIEW) 6 – 41...
  • Page 64 XL-DK257N iPOD PWB-C R140 Q100 C113 R136 R134 R139 R133 IC101 R122 R138 R123 R135 C111 R132 C100 JP104 R110 D107 R113 R107 JP102 JP101 C112 C108 L101 C101 WIRE Lead-free solder indication Lead-free solder is used in the iPOD PWB.
  • Page 65 XL-DK257N iPOD PWB-C Figure 6-41: WIRING SIDE OF iPOD PWB (BOTTOM VIEW) 6 – 43...
  • Page 66 XL-DK257N CD PWB-D 6 8 10 12 14 16 5 7 9 11 13 15 Figure 6-42: WIRING SIDE OF CD PWB (TOP VIEW) (1/2) 6 – 44...
  • Page 67 XL-DK257N 6 8 10 5 7 9 12 14 16 1 13 15 Lead-free solder indication Lead-free solder is used in the CD PWB. Refer to "Precautions for handling lead-free solder" for instructions and precautions. Figure 6-43: WIRING SIDE OF CD PWB (TOP VIEW) (2/2)
  • Page 68 XL-DK257N CD PWB-D RA14 RA16 RA15 Lead-free solder indication Lead-free solder is used in the CD PWB. Refer to "Precautions for handling lead-free solder" for instructions and precautions. Figure 6-44: WIRING SIDE OF CD PWB (BOTTOM VIEW) (1/2) 6 – 46...
  • Page 69 XL-DK257N RA45 Figure 6-45: WIRING SIDE OF CD PWB (BOTTOM VIEW) (2/2) 6 – 47...

  • Page 70: Chapter 7. Flowchart

    XL-DK257N CHAPTER 7. FLOWCHART [1] Troubleshooting 1. When the CD does not function The CD section may not operate when the objective lens of the optical pickup is dirty. Clean the objective lens, and check the playback operation. When this section does not operate even after the above step is taken, check the following items.
  • Page 71 XL-DK257N (1) Focus-RF system check. Although a CD is inserted and the cover is closed, "NO DISC" is displayed. 1. Does the pickup move? Sled motor (M2A). 2. Does the focus (lens) move up and down ? Check the focus peripheral circuit.
  • Page 72 XL-DK257N (2) Tracking system check. Check the TE waveform at pin 6 on IC1. If the waveform shown in Figure 4 appears and soon after NO The tracking servo is not activated. DISC appears ? Check the peripheral circuits at pins 6, 7, 10, 98 and 100 on IC1, pins 17, 18, 35 and 36 on IC2 and FFC1.
  • Page 73 XL-DK257N (4) PLL system check. When a disc is loaded, start play operation. TMAX LPFO The RF waveform is normal, but the TOC data cannot be read. Check the TMAX waveform. (Figure 6) Figure 6 Check around Pins 72, 73, 74, 75, 76 and 78 on IC1.

  • Page 74: Chapter 8. Other

    XL-DK257N CHAPTER 8. OTHER [1] Function Table Of IC IC2 VHILA6261//-1: Focus/Tracking/Spin/Sled Driver (LA6261) Pin No. Terminal Name Function BTL Output pin (+) for focus coil. BTL Output pin (-) for focus coil. BTL Output pin (+) for spin motor.
  • Page 75 XL-DK257N IC2 VHILA6261//-1: Focus/Tracking/Spin/Sled Driver (LA6261) VOLTAGE CONTROL AMP DUFFER AMP DUFFER AMP For VREF For 1/2 VCC Refcronce voltage Bandgad Figure 8-1 BLOCK DIAGRAM OF IC 8 – 2...
  • Page 76 XL-DK257N IC1 VHITC94A70FG2: CD MP3 DECODER (1/4) Pin Description Figure 8-2 BLOCK DIAGRAM OF IC 8 – 3...
  • Page 77 XL-DK257N IC1 VHITC94A70FG2: CD MP3 DECODER (2/4) Pin Description Symbol Input / Output Description Default Remarks AVSS3 Grounding pin for 3.3V CD analog circuits. RFZi Input 3AI/F Input pin for RF ripple zero-cross signal. Input Connect to RFRP 0.033uF RFRP Output 3AI/F RF ripple signal output pin.
  • Page 78 XL-DK257N IC1 VHITC94A70FG2: CD MP3 DECODER (3/4) Pin Description Symbol Input / Output Description Default Remarks Input / Output Pio1 DSP general input/output port -1. Input Schmitt input CMOS PORT 3I/F Input / Output Pio2 DSP general input/output port -2.
  • Page 79 XL-DK257N IC1 VHITC94A70FG2: CD MP3 DECODER (4/4) Pin Description Symbol Input / Output Description Default Remarks AGCi Input 3AI/F RF signal AGC amplifier input pin. Input Output 3AI/F RF signal generation amplifier output pin. Output RVDD3 Power supply for 3.3V RF amplifier core circuit.
  • Page 80 XL-DK257N IC701 RH-IXA159AW00: System Microcomputer (1/5) NAME SOFT INPUT / FORM FUNCTION OUTLINE PULLUP OUTPUT PORT_TYPE NO USE OUTPUT CMOS INPUT / OUTPUT Fix "L" P96/ANEX1 NO USE OUTPUT CMOS INPUT / OUTPUT Fix "L" P95/ANEX0 VOL_DATA COMMUNICATION WITH OUTPUT...
  • Page 81 XL-DK257N IC701 RH-IXA159AW00: System Microcomputer (2/5) NAME SOFT INPUT / FORM FUNCTION OUTLINE PULLUP OUTPUT PORT_TYPE RDS CLK INPUT CMOS INPUT / OUTPUT RDS CLK (H MODEL) P74/TA2OUT IPOD_DETECT L:IPOD INSERT INPUT CMOS INPUT / OUTPUT H:W/O IPOD P73/CTS2/RTS2/TA1IN FLD RESET...
  • Page 82 XL-DK257N IC701 RH-IXA159AW00: System Microcomputer (3/5) NAME SOFT INPUT / FORM FUNCTION OUTLINE PULLUP OUTPUT PORT_TYPE HP_MUTE HEADPHONE MUTE CONTROL OUTPUT CMOS INPUT / OUTPUT L: ON H:OFF HP_SW HP DETECT SW INPUT CMOS INPUT / OUTPUT L: HP_Out H: HP_In...
  • Page 83 XL-DK257N IC701 RH-IXA159AW00: System Microcomputer (4/5) NAME SOFT INPUT / FORM FUNCTION OUTLINE PULLUP OUTPUT PORT_TYPE CD_BUS1 CD DSP INTERFACE BUS INPUT / LINE 1 INPUT / OUTPUT CMOS INPUT / OUTPUT OUTPUT EXCEPT CD FUNCTION SET TO "L" CD_BUS0...
  • Page 84 XL-DK257N IC701 RH-IXA159AW00 : System Microcomputer (5/5) NO USE P96/ANEX1 P10 80 FUNC_CD NO USE P95/ANEX0 P11 79 BOOT CONTROL VOL_DATA P12 78 CD RESET VOL_CLK P13 77 CD_BUS0 NO USE P92/TB2IN P14 76 CD_BUS1 NO USE P91/TB1IN P15/INT3 75...
  • Page 85 XL-DK257N IC851 VHIAN80T53/-1: MULTI REGULATOR (AN80T53) Terminal Name Function REG4 Output 5.1 V power supply with a minimum peak out current of 1200 mA. REG3 Output 13 V power supply with a minimum peak out current of 1350 mA. Connected to Power supplies.

  • Page 86: Fl Display

    XL-DK257N [2] FL Display FL701 VVKFD291217-1 GRID ASSIGNMENT MP3 WMA TOTAL col2 Dot2 col1 Dot1 2G 3G 4G 5G 6G 7G h j k (1G) (2G~11G) ANODE CONNECTION FOLD TITLE-1 TITLE-2 TOTAL TITLE-3 PTYI SLEEP DAILY MEMORY X-BASS Dot1 Col1...

  • Page 87: Parts Guide

    XL-DK257N PARTS GUIDE MICRO COMPONENT SYSTEM XL-DK257N MODEL XL-DK257N Micro Component System consisting of XL-DK257N (main unit) and CP-DK257N (speaker system). CONTENTS [1] INTEGRATED CIRCUITS [9] OTHER CIRCUITRY PARTS [2] TRANSISTORS [10] CABINET PARTS / CD MECHANISM PARTS [3] DIODES...
  • Page 88 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [1] INTEGRATED CIRCUITS CD MP3 Decorder VHITC94A70FG2 CD Driver VHILA6261//-1 Apple Authentication IC iC101 VHI341S2160-1 Audio Pro iC601 VHINJU7391/-1 Headphone Amplifier iC603 VHIBH3547F+-1 Pre Amplifier, AZ4558 iC604 VHIAZ4558CME1 System Microcomputer, IXA159AW...
  • Page 89 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [3] DIODES Silicon,1N4004S D807 VHD1N4004S/-1 Silicon,1N4004S D808 VHD1N4004S/-1 D809 VHD1N4004S/-1 Silicon,1N4004S Silicon,1N4004S D810 VHD1N4004S/-1 Silicon,1N4004S D811 VHD1N4004S/-1 Silicon,1N4004S D812 VHD1N4004S/-1 Silicon,1N4004S D813 VHD1N4004S/-1 Silicon,1N4004S D814 VHD1N4004S/-1 Silicon,1N4004S D815 VHD1N4004S/-1 Silicon,HSS4148 D851...
  • Page 90 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [7] CAPACITORS 0.015 µF,50V VCKYCY1HB153K 0.1 µF,16V VCKYCY1CB104K 100 µF,10V,Electrolytic VCEAZA1AW107M 0.1 µF,16V VCKYCY1CB104K 0.033 µF,50V VCKYCY1HB333K 0.033 µF,50V VCKYCY1HB333K VCKYCY1CB104K 0.1 µF,16V VCCCCY1HH471J 470pF(CH),50V 0.1 µF,16V VCKYCY1CB104K 470pF(CH),50V VCCCCY1HH471J 0.047 µF,50V VCKYCY1HB473K 0.047 µF,50V...
  • Page 91 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [7] CAPACITORS 0.0015 µF,50V C640 VCKYCY1HB152K 0.0015 µF,50V C641 VCKYCY1HB152K 0.001 µF,50V C642 VCKYCY1HB102K 0.001 µF,50V C643 VCKYCY1HB102K 0.001 µF,50V C644 VCKYCY1HB102K C645 VCKYCY1HB102K 0.001 µF,50V 10 µF,50V,Electrolytic C646 VCEAZA1HW106M 10 µF,50V,Electrolytic...
  • Page 92 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [7] CAPACITORS 4700 pF,250V, Ceramic C823 RC-KZ002LAWZZ 10 µF,50V,Electrolytic C852 VCEAZA1HW106M 4700µF,25V,Electrolytic C853 VCEAZW1EW478M 22 µF,25V,Electrolytic C854 VCEAZA1EW226M 22 µF,25V,Electrolytic C855 VCEAZA1EW226M 22 µF,25V,Electrolytic C856 VCEAZA1EW226M C857 VCEAZA1EW476M 47 µF,25V,Electrolytic 1 µF,16V...
  • Page 93 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [8] RESISTORS 0 ohms,Jumper,1.25x2mm,Green VRS-TV2AB000J 0 ohms,Jumper,0.8x1.55mm,Green J694 VRS-CY1JB000J VRS-CY1JB000J 0 ohms,Jumper,0.8x1.55mm,Green 0 ohms,Jumper,1.55x3.1mm,Green VRS-TQ2BB000J 0 ohms,Jumper,0.8x1.55mm,Green VRS-CY1JB000J 0 ohms,Jumper,1.55x3.1mm,Green VRS-TQ2BB000J 0 ohms,Jumper,1.25x2mm,Green VRS-CY1JB000J 0 ohms,Jumper,0.8x1.55mm,Green JP16 VRS-CY1JB000J 0 ohms,Jumper,0.8x1.55mm,Green JP19 VRS-CY1JB000J 0 ohms,Jumper,1.55x3.1mm,Green...
  • Page 94 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [8] RESISTORS 0 ohms,Jumper,0.8x1.55mm,Green R115 VRS-CY1JB000J 1 kohms,1/16W R118 VRS-CY1JB102J 1 kohms,1/16W R119 VRS-CY1JB102J 100 kohms,1/16W R120 VRS-CY1JB104J 100 kohms,1/16W R121 VRS-CY1JB104J 100 kohms,1/16W R122 VRS-CY1JB104D 100 kohms,1/16W R123 VRS-CY1JB104D 100 kohms,1/16W...
  • Page 95 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [8] RESISTORS 1 kohms,1/16W R727 VRS-CY1JB102J 1 kohms,1/6W R728 VRD-ST2CD102J R729 VRS-CY1JB271J 270 ohms,1/16W 270 ohms,1/6W R730 VRD-ST2CD271J 220 ohms,1/6W R731 VRD-ST2CD221J 220 ohms,1/6W R732 VRD-ST2CD221J 220 ohms,1/6W R733 VRD-ST2CD221J 220 ohms,1/6W...
  • Page 96 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [8] RESISTORS 0 ohms,Jumper,0.8x1.55mm,Green R920 VRS-CY1JB000J 5.6 kohms,1/16W R921 VRS-CY1JB562J 5.6 kohms,1/16W R922 VRS-CY1JB562J R923 VRS-CY1JB562J 5.6 kohms,1/16W 5.6 kohms,1/16W R924 VRS-CY1JB562J 5.6 kohms,1/16W R925 VRS-CY1JB562J 5.6 kohms,1/16W R926 VRS-CY1JB562J 10 kohms,1/16W...
  • Page 97 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [9] OTHER CIRCUITRY PARTS Socket,18 Pin CNP701B QCNCWZY18AWZZ CNP702 QCNCWZX10AWZZ Socket,10 Pin Connector, 2 Pin [Use in Volume LED Light-Up PWB-B3] CNP703 92LCONE2P53253 Connector, 10 Pin [Use in Amplifier PWB-A3] CNP703...
  • Page 98 XL-DK257N [10] CABINET PARTS / CD MECHANISM PARTS 601x4 605x2...
  • Page 99 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [10] CABINET PARTS / CD MECHANISM PARTS CCABA7119AW01 Front Panel Ass'y Front Panel (Not Replacement Item ) 201-1 ------------- Decoration, Volume Knob 201-2 HDECQA242AWSA Button, Function 201-3 JKNBZA245AWSA Button, Open/Close 201-4...
  • Page 100 XL-DK257N [11] SPEAKER BOX PARTS...
  • Page 101 XL-DK257N PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [11] SPEAKER BOX PARTS Wooden Box Ass'y GBOXSA207AW01 Net Frame Ass'y CWAKPA010AW05 Front Board GiTASA208AWSA Catching Holder LHLDZ8002AWSB Cushion, Leg PCUSGA020AWZZ Label, Specification TSPC-A965AWZZ Tweeter Ring HDECQA355AWSB Woofer Ring HDECQA354AWSB Screw, M3 x 14mm XEBY730P14000 Screw, M3.5 x 14mm...
  • Page 102 XL-DK257N [12] ACCESSORIES / PACKING PARTS PACKING METHOD (FOR U.S.A. ONLY) UNIT Front Speaker(L/R) Polyethylene Bag,Unit SSAKH0094AWZZ Polyethylene Bag,Speaker SSAKHA087AWZZ Packing,Add., Front Speaker,Top/Bottom SPAKAA187AWZZ Packing Add.,Unit,Top/Bottom Label,POP SPAKAA186AWZZ TLABZA652AWZZ Label,POP Bottom TLABZA713AWZZ Caution Label,iPod TLABZA725AWZZ Adaptor Accessories AM Loop Antenna...
  • Page 103 XL-DK257N...
  • Page 104 XL-DK257N COPYRIGHT 2008 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
