IMPORTANT SAFETY INSTRUCTIONS
WARNING:
not followed precisely, fire or explosion may result causing property
damage, personal injury or loss of life.
READ AND SAVE THESE INSTRUCTIONS
others are very important.
We have provided many important safety messages throughout this manual and
on the appliance.
Read all the instructions before using the appliance and always obey all safety
messages.

Table of Contents

If the instructions contained in this manual are
- Your safety and the safety of
9
9
10
10
11
12
12
13
13
20
27
28
33
37
37
37
38
43
3

Advertisement

Table of Contents
loading

Related Manuals for Smeg SOPU3302TPX

Summary of Contents for Smeg SOPU3302TPX

  • Page 1: Table Of Contents

    Table of Contents 1 Description 1.1 General Description 1.2 Control panel 1.3 Other parts 1.4 Available accessories 2 Use 2.1 First use 2.2 Use of accessories 2.3 Using the oven 2.4 Using the temperature probe 2.5 Cooking tips 2.6 Special features 2.7 Settings 3 Cleaning and maintenance 3.1 Surface cleaning...
  • Page 2 Important Safety Instructions RECOGNIZE SAFETY INFORMATION This is a safety alert symbol. This symbol alerts you to potential hazards that can result in severe personal injury or loss of life. UNDERSTAND SIGNAL WORDS A signal word - DANGER, WARNING or CAUTION - is used with the safety alert symbol.
  • Page 3 Important Safety Instructions WARNING To reduce the risk of fire, electrical shock, personal injury, or damage when using the appliance, follow basic safety precautions, including the following: WARNING: • Read all instructions. • • Proper installation is your responsibility. A) A child or adult can tip the range and be Have a qualified technician install and killed.
  • Page 4 Important Safety Instructions • WEAR PROPER APPAREL: Loose-fitting or • ELECTRICAL GROUNDING IS hanging garments should never be worn REQUIRED. It is the customer’s while using the appliance. responsibility: • For safety reasons and to avoid damage 1. To contact a qualified electrician. to your appliance, never sit, stand or 2.
  • Page 5 Important Safety Instructions • Prevent aluminum foil from contacting the • ONLY QUALIFIED SERVICE heating elements. PERSONNEL SHOULD PERFORM REPAIRS. Service personnel must • Do not place pans or trays directly on disconnect the power supply before the bottom of the oven cavity. servicing this unit.
  • Page 6 Important Safety Instructions To save energy • The light sources contained in the product are suitable for use in ambient • Unless otherwise indicated on the temperatures of ≥572°F (300°C) and package, defrost frozen foods before intended for use in high temperature placing them in the oven.

  • Page 7: Description

    Description 1 Description 1.1 General Description 1 Control panel 2 Oven light 3 Temperature probe socket 4 Door gasket 5 Fan 6 Rack/tray support frames 7 Door Frame shelf...

  • Page 8: Control Panel

    Description 1.2 Control panel 1 Function knob 1.3 Other parts This knob can be used to: Positioning shelves • select a function The appliance has shelves for positioning • start or stop a function trays and racks at various heights. The position heights go from the bottom 2 Digital programmer upwards (see 1.1 General Description).

  • Page 9: Available Accessories

    Description Oven lighting Protective cover The internal lighting for the appliance turns • when the door is opened • when the temperature knob is turned to the right • when any function is selected, except for functions. Used to cover and protect the temperature When the door is open, you probe socket when the temperature probe cannot turn off the internal lighting.

  • Page 10: Use

    2 Use Improper use Risk of damage to enameled Warnings surfaces High temperature inside the oven • Do not cover the bottom of the oven with while in use sheets of aluminum or tin foil. Burn hazard • If you wish to use parchment paper, place it so that it will not interfere with •...

  • Page 11: Use Of Accessories

    2.2 Use of accessories 2.3 Using the oven Racks Display Racks and trays must be inserted into the side guides until they stop. • The mechanical safety locks that prevent accidental removal of the racks must face downward and towards the rear of the oven.
  • Page 12 2. Press the temperature knob to confirm the Switching on the oven hour. To exit immediately from a function The segments that refer to the hour remain lit that is in progress, turn the functions steadily while those of the minutes flash. knob to the left.
  • Page 13 3. Press the functions knob to start the Cooking stage function (the text turns off). 1. Open the door. 2. Place the food to be cooked in the oven. When the door is opened, the 3. Close the door. function in progress is stopped. 4.
  • Page 14 Modifying the temperature during 2. Turn the temperature knob to the right or cooking left to select the required duration of the minute minder (e.g. 15 minutes). To change the temperature during cooking: 1. Press the temperature knob. The degrees symbol flashes.
  • Page 15 Timed cooking 3. Press the temperature knob or wait for a few moments to confirm the required Timed cooking is the function cooking time. which allows a cooking operation The text remains lit to be started and then ended after a specific length of time set by the with a steady light and user.
  • Page 16 1. Open the door. Preheating stage 2. Place the food to be cooked in the oven. The time required for preheating is 3. Close the door. included in the set cooking time. 4. Turn the temperature knob to the right from time to time to turn the oven light on Timed cooking is preceded by a preheating and check how the food is cooking.
  • Page 17 Cooking delayed Delayed cooking is the function that allows the user to start timed cooking later that the current time, after which the appliance will switch off automatically. The appliance does not preheat when the delayed cooking function is used. It is not possible to set delayed cooking times for more than 12 1.

  • Page 18: Using The Temperature Probe

    Countdown phase 2.4 Using the temperature probe During the delay time countdown: The temperature probe is very hot • the display goes into dimmed mode and Burn hazard indicates the time remaining before timed cooking starts • Do not touch the rod or the tip of the temperature probe after it has been •...
  • Page 19 Positioning the temperature probe Improper use 1. Place the food on a tray. Risk of damage to temperature probe 2. Insert the tip of the probe into the food before placing it in the oven. • Do not pull the cord to remove the temperature probe from the socket or from the food.
  • Page 20 Cooking settings when using the 3. Turn the temperature knob to the right or temperature probe left to select the required temperature (e.g. 400°F). Settings can only be made if the temperature probe connector is inserted correctly into the socket inside the oven.
  • Page 21 7. Press the temperature knob. 9. Press the temperature knob to confirm the target temperature. The display shows: The display shows: • the set cooking temperature, in the center • the symbol on steadily • the target temperature, at the top right •...
  • Page 22 Cooking using the temperature probe End of cooking with the temperature probe 10. Press the functions knob to start cooking. Improper use 11. During cooking, press the temperature Risk of injury knob to display the actual temperature inside the food. •...
  • Page 23 Functions list The heat coming from the broiler element gives perfect broiling results above all for thin and medium thickness meat and, in As the heat comes from above and below combination with the rotisserie (where at the same time, this system is particularly fitted), gives the food an even browning at suitable for certain types of food.
  • Page 24 Cooking information chart Weight Temp. Food Function Shelf Time (min.) (°F) (lbs.) Focaccia bread Turbo 25/30 Bread 6 x 0.3 Bake 38/42 Pizza 1.5/2.5 Conv. Bake 10/15 Pizza (frozen) Conv. Bake Quiche Bake 40/45 Grilled vegetables Broil + 5 2 Tenderloin (med-rare) Turbo 52/55...

  • Page 25: Cooking Tips

    2.5 Cooking tips • The temperature and baking duration depend on the quality and consistency General tips of the dough. • Use a convection function to achieve • To check whether the cake is baked uniform cooking at several levels. through, stick a toothpick into its highest point at the end of the baking time.

  • Page 26: Special Features

    2.6 Special features Minute minder The minute minder only warns the user that the set number of minutes has passed. 1. Press the temperature knob. symbol flashes. It is not possible to set minute minders for more than 12 hours. To cancel a minute minder, set the values to 0.
  • Page 27 1. Open the door. 6. Turn the temperature knob to the right or left to select the required defrost 2. Place the food in the oven and close the duration. door. 7. Press the temperature knob to confirm the 3. Press the functions knob. required defrost duration.
  • Page 28 4. Turn the functions knob to the right or left to select This function is particularly suitable for proving dough. If the oven has been used a short time ago for cooking, we recommend that you let the appliance cool down before activating the function.
  • Page 29 When finished, a sound is emitted. The text • the fan is deactivated • the buzzers are deactivated flashes and appears on the display. After having activated the Sabbath mode, parameters cannot be modified. To use the Sabbath function: 1. Open the door. 2.
  • Page 30 3. Press the temperature knob to confirm the 7. Wait a few moments until required cooking time. flashes. 4. Press the functions knob to start the 8. Press the functions knob to start the function. function. Turn the functions knob to the left at any time to exit from the function.

  • Page 31: Settings

    2.7 Settings To access the settings menu: During normal operation, the 1. From the clock screen, turn the controls lock is indicated by the temperature knob to the right. symbol lighting up. The oven light switches on. 2. Keep the temperature knob pressed for a If there is a power outage, the few seconds.
  • Page 32 1. After having accessed the settings menu Temperature format (and having left the controls lock setting Allows you to set the temperature ), press the temperature knob scale to degrees Fahrenheit to select the Showroom setting. or degrees Celsius 1. After accessing the settings menu, press the temperature knob to select the Temperature format.
  • Page 33 Time format Keep warm This setting allows you to enable or This setting allows the appliance to disable the clock display in a 12 keep cooked food warm (at low or 24 hour format. temperatures) after timed cooking finishes (if it is has not been 1.
  • Page 34 3. Press the temperature knob to confirm 1. After accessing the settings menu, press the temperature knob to select Eco logic. and move to the next setting. To use the appliance normally, set this function to Eco light For greater energy savings, the lights inside the oven are automatically switched off 2.

  • Page 35: Cleaning And Maintenance

    Cleaning and Maintenance 3 Cleaning and maintenance Food stains or residues Do not use steel wool or sharp scrapers: Warnings they will damage the surface. Use ordinary, non-abrasive products, with Improper use the aid of wooden or plastic tools if Risk of damage to surfaces necessary.

  • Page 36: Cleaning Inside The Oven

    Cleaning and Maintenance 2. Grasp the door on both sides with both Cleaning the door glazing hands. Lift it, forming an angle of about We recommend always keeping the glass 30°, and remove it. doors thoroughly clean. Use paper towels. If there are tough to clean spots, use a damp sponge and regular detergent.
  • Page 37 Cleaning and Maintenance 1. Move the door lock lever to the right as Manual door lock lever deactivation far as it will go. Improper use Burn hazard • The following should always be carried out with the appliance cold and switched off.
  • Page 38 Cleaning and Maintenance Removal of the frame supports for racks/ trays Self-Clean is an automatic high- Removing the guide frames makes it easier temperature cleaning procedure that to clean the sides of the oven. dissolves grime. Thanks to this process, it is possible to clean the inside of the oven very To remove the guide frames: easily.
  • Page 39 Cleaning and Maintenance Preliminary operations 2. Turn the functions knob to the right or left to select Before starting the Self-Clean function: • Clean the internal glass panel following the usual cleaning instructions. • Remove any food or spill residues from the inside of the oven.
  • Page 40 Cleaning and Maintenance End of the Self-Clean cycle The text flashes while A sound is emitted when the Self-Clean remains lit with a steady light. cycle ends. The text flashes and Self-Clean cycle appears on the display. 6. Press the functions knob to start the function.

  • Page 41: Extraordinary Maintenance

    Cleaning and Maintenance 3.4 Extraordinary maintenance 4. Loosen and remove the light bulb. Replacing the oven light Live parts Danger of shock • Switch off the electrical supply to the appliance. 1. Remove all accessories inside the oven. 2. Remove the frame supports for racks/ Do not touch the halogen bulb with your fingers;...
  • Page 42 PAGE INTENTIONALLY LEFT BLANK...
