Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Canon MAXIFY GX5550 o cerca il tuo prodotto tra le migliori offerte di Stampanti GX5500 series Online Manual English...
Page 2: Table Of Contents
Contents Appendix............9 Symbols Used in This Document.
Page 3 Performing Maintenance Functions from Your Computer (Windows)....Opening the Maintenance Tool (Canon IJ Printer Assistant Tool)......141 Cleaning the Print Heads.
Page 4 Cleaning Paper Feed Rollers............155 Cleaning Inside the Printer (Bottom Plate Cleaning).
Page 5 Regulatory Information............. . 213 WEEE.
Page 6 Canon IJ Status Monitor Description........
Page 7 Network Key (Password) Unknown..........347 Printer Cannot Be Used After Replacing Wireless Router or Changed Router Settings.
Page 8 Errors and Messages........... . 422 When Error Occurred.
Page 9: Appendix
Appendix Online Manual Symbols Used in This Document Trademarks and Licenses...
Page 10: Symbols Used In This Document
Symbols Used in This Document Warning Instructions that, if ignored, could result in death, serious personal injury, or property damage caused by incorrect operation of the equipment. These must be observed for safe operation. Caution Instructions that, if ignored, could result in personal injury or property damage caused by incorrect operation of the equipment.
Page 11: Trademarks And Licenses
Trademarks and Licenses Trademarks Licenses...
Page 12: Trademarks
• App Store is a trademark of Apple Inc., registered in the U.S. and other countries. • Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A. and licensed to Canon Inc. • QR Code is a registered trademark of DENSO WAVE INCORPORATED in Japan and in other countries.
Page 13: Licenses
Licenses Copyright (c) 2003-2015 Apple Inc. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Page 14 "Object" form shall mean any form resulting from mechanical transformation or translation of a Source form, including but not limited to compiled object code, generated documentation, and conversions to other media types. "Work" shall mean the work of authorship, whether in Source or Object form, made available under the License, as indicated by a copyright notice that is included in or attached to the work (an example is provided in the Appendix below).
Page 15 3. You must retain, in the Source form of any Derivative Works that You distribute, all copyright, patent, trademark, and attribution notices from the Source form of the Work, excluding those notices that do not pertain to any part of the Derivative Works; and 4.
Page 16 such warranty or additional liability. END OF TERMS AND CONDITIONS ---- Part 1: CMU/UCD copyright notice: (BSD like) ----- Copyright 1989, 1991, 1992 by Carnegie Mellon University Derivative Work - 1996, 1998-2000 Copyright 1996, 1998-2000 The Regents of the University of California All Rights Reserved Permission to use, copy, modify and distribute this software and its documentation for any purpose and without fee is hereby granted, provided that the above copyright notice appears in all copies and that both...
Page 17 ---- Part 3: Cambridge Broadband Ltd. copyright notice (BSD) ----- Portions of this code are copyright (c) 2001-2003, Cambridge Broadband Ltd. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Page 18 SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. ---- Part 5: Sparta, Inc copyright notice (BSD) ----- Copyright (c) 2003-2012, Sparta, Inc All rights reserved.
Page 19 ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Page 20 OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL APPLE OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS;...
Page 21 The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software. THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.
Page 22 ---- Part 12: Arista Networks copyright notice (BSD) ---- Copyright (c) 2013, Arista Networks, Inc. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Page 23 * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. * Neither the name of VMware, Inc. nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.
Page 24 PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Page 25 Permission to use, copy, modify, and distribute this software for any purpose without fee is hereby granted, provided that this entire notice is included in all copies of any software which is or includes a copy or modification of this software. THIS SOFTWARE IS BEING PROVIDED "AS IS", WITHOUT ANY EXPRESS OR IMPLIED WARRANTY.
Page 26 David Turner, Robert Wilhelm, and Werner Lemberg Introduction ============ The FreeType Project is distributed in several archive packages; some of them may contain, in addition to the FreeType font engine, various tools and contributions which rely on, or relate to, the FreeType Project. This license applies to all files found in such packages, and which do not fall under their own explicit license.
Page 27 This license applies to all files distributed in the original FreeType Project, including all source code, binaries and documentation, unless otherwise stated in the file in its original, unmodified form as distributed in the original archive. If you are unsure whether or not a particular file is covered by this license, you must contact us to verify this.
Page 28 ----------- There are two mailing lists related to FreeType: o freetype@nongnu.org Discusses general use and applications of FreeType, as well as future and wanted additions to the library and distribution. If you are looking for support, start in this list if you haven't found anything to help you in the documentation.
Page 29 - Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. - Neither the name of ARM nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.
Page 30 ALTERNATIVELY, provided that this notice is retained in full, this product may be distributed under the terms of the GNU General Public License (GPL), in which case the provisions of the GPL apply INSTEAD OF those given above. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDER AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
Page 31 PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE FOUNDATION OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE...
Page 32 The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software. THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.
Page 33 THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
Page 34 THE SOFTWARE IS PROVIDED "AS IS" AND THE AUTHOR DISCLAIMS ALL WARRANTIES WITH REGARD TO THIS SOFTWARE INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS. IN NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY SPECIAL, DIRECT, INDIRECT, OR CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
Page 35 * Neither the name of Google Inc. nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS AS IS AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
Page 36 may be infringed by your derivative works or by other works in which the Apple Software may be incorporated. Unless you explicitly state otherwise, if you provide any ideas, suggestions, recommendations, bug fixes or enhancements to Apple in connection with this software ("Feedback"), you hereby grant to Apple a non-exclusive, fully paid-up, perpetual, irrevocable, worldwide license to make, use, reproduce, incorporate, modify, display, perform, sell, make or have made derivative works of, distribute (directly or indirectly) and sublicense, such Feedback in connection with Apple products...
Page 37 PCRE JUST-IN-TIME COMPILATION SUPPORT ------------------------------------- Written by: Zoltan Herczeg Email local part: hzmester Emain domain: freemail.hu Copyright(c) 2010-2012 Zoltan Herczeg All rights reserved. STACK-LESS JUST-IN-TIME COMPILER -------------------------------- Written by: Zoltan Herczeg Email local part: hzmester Emain domain: freemail.hu Copyright(c) 2009-2012 Zoltan Herczeg All rights reserved.
Page 38 LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Page 39: Main Components And Their Use
Main Components and Their Use Main Components Power Supply Loading Paper...
Page 40: Main Components
Main Components Front View Rear View Inside View Operation Panel...
Page 41: Front View
Front View A: Rear Tray Cover Open to load paper in the rear tray. B: Paper Support Extend to load paper in the rear tray. C: Operation Panel Use to change the settings of the printer or to operate it. Operation Panel D: Paper Output Tray Printed paper is ejected.
Page 42 G: Cassette 1 Load A4, B5, A5, Letter-sized or Executive plain paper into the cassette 1, and insert it into the printer. Use to change the settings of the printer or to operate it. Loading Plain Paper, and Delivery Slips in Cassette Loading Medicine Envelopes in Cassette H: Resizing Tab Use to load legal-size paper into the cassette.
Page 43: Rear View
Rear View A: Maintenance Cartridge Absorbs ink used for cleaning. Replacing the Maintenance Cartridge B: Maintenance Cover Remove when replacing the maintenance cartridge. C: Transport Unit Open when removing jammed paper. D: Rear Cover Detach when removing jammed paper. E: Power Cord Connector Plug in the supplied power cord.
Page 44: Inside View
Inside View A: Top Cover Open to refill ink tanks and to remove jammed paper. B: Print Head Holder The print head is pre-installed. C: Ink Tank Covers Open to refill ink tanks. D: Tank Caps Open to refill ink tanks. E: Ink Tanks The black ink tank is on the left, and the color ink tanks (cyan, magenta, and yellow) are on the right.
Page 45 I: Lower Limit Line Indicates the lower limit of the sufficient amount of ink to print. Refill the ink tank before the amount of ink is below this line.
Page 46: Operation Panel
Operation Panel A: ON lamp Lights after flashing when the power is turned on. B: ON button Turns the power on or off. Before turning on the power, make sure that the top cover is closed. Turning the Printer On and Off C: HOME button Used to display the HOME screen.
Page 47: Using Touch Screen
Using Touch Screen The HOME screen on the touch screen appears when the printer is turned on. Touch the HOME screen on the touch screen with your finger tip to select a menu to perform settings. HOME Screen Basic Operation of the touch screen HOME Screen The HOME screen consists of the two screens.
Page 48 Displays quick guides about such procedures as loading paper and troubleshooting and such information as estimated ink level and system information. If you set Notification settings to Enable, (NEW) is displayed when notification is sent to Canon. Notification settings Note • For details on how to change settings, refer to •...
Page 49 Basic Operation of the touch screen Touch the touch screen lightly with your finger tip or move your finger to access various functions or settings. Important • When operating the touch screen, make sure to avoid the followings, which may cause the printer to •...
Page 50 Drag While lightly touching the screen, move your finger up, down, left, or right. Use to view lists of items or move sliders. Entering Numbers, Letters, and Symbols...
Page 51: Entering Numbers, Letters, And Symbols
Entering Numbers, Letters, and Symbols In the printer, you can enter (or correct) the characters and numbers when the keyboard is displayed on the screen. The character is allocated to each key displayed on the screen. Tap the key to enter the character. After entry is completed, tap for determination.
Page 52 Move the cursor. To insert the character, move the cursor to the character on the right of the position where you want to insert the character. To delete the character, move the cursor to the character you want to delete. Note •...
Page 53: Power Supply
Power Supply Turning the Printer On and Off...
Page 54: Turning The Printer On And Off
Turning the Printer On and Off Checking that Power Is On Turning on the printer Turning off the printer Checking that Power Is On The ON lamp is lit when the printer is turned on. Even if the touch screen is off, if the ON lamp is lit, the printer is on. Note •...
Page 55 • You can set the printer to automatically turn on when a print operation is performed from a computer • connected by USB cable or wireless network. This feature is set to off by default. From the printer ECO settings From the computer For Windows: Managing the Printer Power...
Page 56 Important • When you unplug the power cord, press the ON button, then confirm that the ON lamp is off. • Unplugging the power cord while the ON lamp is lit or flashing may cause drying or clogging of the print head and print quality may be reduced.
Page 57: Loading Paper
Loading Paper Paper Sources Loading Photo Paper / Plain Paper in Rear Tray Loading Plain Paper, and Delivery Slips in Cassette Loading Envelopes, Medicine Envelopes, and Delivery Slips in Rear Tray Loading Medicine Envelopes in Cassette...
Page 58: Paper Sources
Paper Sources The printer has two paper sources for feeding paper, the rear tray and cassettes. With the plain paper loaded in a cassette, you can also load paper on the rear tray to make prints. Rear tray Cassette Rear tray You can load all supported paper such as photo paper and plain paper on the rear tray.
Page 59 Cassette You can load A4, B5, A5, Letter-sized or Executive plain paper in the cassette. Legal-sized paper can also be loaded into Cassette 2. Loading Plain Paper, and Delivery Slips in Cassette Loading Medicine Envelopes in Cassette Note • For details on paper that can be used in this printer: •...
Page 60: Loading Photo Paper / Plain Paper In Rear Tray
Loading Photo Paper / Plain Paper in Rear Tray You can load photo paper or plain paper. You can also load envelopes on the rear tray. Loading Envelopes, Medicine Envelopes, and Delivery Slips in Rear Tray 1. Prepare paper. Align the edges of paper. If paper is curled, flatten it. Note •...
Page 61 Note • Load long-length paper without pulling out the paper support. Depending on the weight of the • paper, the leading edge may rise and printing may be shifted. Make sure that the leading edge of the paper does not rise, such as by holding the part that protrudes from the rear tray. 3.
Page 62 Important • Always load paper in portrait orientation (D). Loading paper in landscape orientation (E) can • cause paper jams. 5. Slide right paper guide to align with both sides of paper stack. Do not slide the paper guides too hard against the paper. The paper may not be fed properly. The paper setting confirmation screen for the rear tray appears on the touch screen.
Page 63 Note • Do not load sheets of paper higher than the load limit mark (F). • 6. If page size and media type on touch screen match size and type of paper loaded in rear tray, select Yes. If not, select Change to change the settings in accordance with the size and type of the loaded paper. Note •...
Page 64 Note • There are various types of paper, such as paper with a special surface coating for printing photos at • optimal quality and paper suitable for documents. Each media type has specific preset settings (how ink is used and sprayed, distance from nozzles, etc.), that allow you to print to that type with optimal image quality.
Page 65: Loading Plain Paper, And Delivery Slips In Cassette
Loading Plain Paper, and Delivery Slips in Cassette You can load plain paper or delivery slips in the cassette. 1. Prepare paper. Align the edges of paper. If paper is curled, flatten it. Note • Align the edges of paper neatly before loading. Loading paper without aligning the edges may •...
Page 66 Important • Always load paper in portrait orientation (D). Loading paper in landscape orientation (E) can • cause paper jams. Note • Align the paper stack with the edge of the cassette as shown in the figure below. • If the paper stack is in contact with the protrusion (F), the paper may not be fed properly.
Page 67 • To load Legal-sized paper in Cassette 2, pull the resizing tab (J) forward to extend the cassette. • • To load paper sizes other than Legal, use the cassette in its condensed state. To condense the • cassette, pull the resizing tab (J) forward. 5.
Page 68 Note • Do not load sheets of paper higher than the load limit mark (G). • • Keep the paper stack height below the tabs (H) of the paper guides. • 6. Insert cassette into printer. Push the cassette into the printer until it stops.
Page 69 After inserting the cassette into the printer, the screen asking you to confirm settings of paper in cassette appears on the touch screen. Note • When paper larger than A4 is loaded, the cassette is extended and thus stops in a protruding •...
Page 70 Note • When loading a delivery slip, select Delivery Slip for media type. • • See • Check paper replacement when you want to hide the screen for confirming the setting of paper. 3. Pull out a paper output tray (I). Note •...
Page 71: Loading Envelopes, Medicine Envelopes, And Delivery Slips In Rear Tray
Loading Envelopes, Medicine Envelopes, and Delivery Slips in Rear Tray You can load envelopes on the rear tray. The address is automatically rotated and printed according to the envelope's direction by specifying with the printer driver properly. Important • Check the condition of the paper prior to loading. •...
Page 72 The figures above show a side view of the leading edge of the envelope. Important • The envelopes may jam in the printer if they are not flat or the edges are not aligned. Make sure • that no curl or puff exceeds 0.12 in. (3 mm). •...
Page 73 • Envelopes • Fold flap of the envelope and load the envelope in portrait orientation with the address side facing • Medicine envelopes • Load medicine envelopes vertically with the side that opens facing up. • Delivery slips • Load delivery slips vertically with print side facing up. 5.
Page 74 Note • Do not load paper higher than the load limit mark (D). • 6. If page size and media type on touch screen match size and type of paper loaded in rear tray, select Yes. If not, select Change to change the settings in accordance with the size and type of the loaded paper.
Page 75 Note • When loading a medicine envelope, select Medicine Envelope for media type. • • When loading a delivery slip, select Delivery Slip for media type. • 7. Pull out a paper output tray (E). Note • Depending on the paper used, ink on the printed surface of printed materials may come off or smudge •...
Page 76: Loading Medicine Envelopes In Cassette
Loading Medicine Envelopes in Cassette You can load Medicine Envelopes into the cassette. Important • Check the condition of the paper prior to loading. • Unsupported Media Types Handling Paper 1. Prepare paper. • Loosen the stiff portions of the corners. If paper is curled, hold the opposite corners and gently •...
Page 77 2. Pull out the cassette (A) from the printer. 3. Slide paper guides (B) in front and (C) on right to open guides. 4. Load paper stack in portrait orientation WITH PRINT SIDE FACING DOWN, and place it in center of cassette. Medicine envelopes How to load:...
Page 78 Load vertically with the side that opens facing the front. Note • Align the paper stack with the edge of the cassette as shown in the figure below. • If the paper stack is in contact with the protrusion (D), the paper may not be fed properly. 5.
Page 79 Note • Do not load sheets of paper higher than the load limit mark (E). • • Keep the paper stack height below the tabs (F) of the paper guides. • 6. Insert cassette into printer. Push the cassette into the printer until it stops. 7.
Page 80 Note • See • Check paper replacement when you want to hide the screen for confirming the setting of paper. 8. Pull out a paper output tray (G). Note • To prevent incorrect printing, this printer has a function that detects whether the settings for the paper •...
Page 81: Refilling Ink Tanks
Refilling Ink Tanks Refilling Ink Tanks Checking Ink Level...
Page 82: Refilling Ink Tanks
Refilling Ink Tanks When remaining ink cautions or errors occur, the message will appear on the touch screen to inform you of the error. In this state, the printer cannot print. Check the remaining ink level with the ink tank indicator on the front of the printer.
Page 83 Important • Do not touch tubes or other parts inside the printer. This can cause trouble with the printer. • 3. Open the ink tank cover (C) of the ink tank to be refilled. D: Yellow E: Magenta F: Cyan G: Black 4.
Page 84 Important • Carefully open the tank cap of the ink tank. Ink on the inside of the tank cap may spatter when opening it. 5. Hold the ink bottle upright and gently twist the bottle cap (I) to remove. Important •...
Page 85 Important • Make sure that each color of ink tanks is filled with corresponding color of ink bottles. • If ink is not injected into the ink tank, slowly remove and insert the ink bottle. • Make sure to refill the ink tank with ink up to the upper limit line (K) on the ink tank. •...
Page 86 10. Close the top cover. To close the top cover, hold it up once, then take it down gently. Note • If the error message appears on the touch screen after the top cover is closed, take appropriate • action. When Error Occurred Notes on ink bottles Important...
Page 87 • Ink may stain clothes or other belongings permanently. Washing may not remove ink stains. • Do not use ink bottles and ink contained therein except to refill tanks of printers specified by Canon. • Do not leave ink bottles in areas exposed to high temperature, such as near fire or a heater or in a car.
Page 88: Checking Ink Level
Checking Ink Level Check ink level with the ink tank indicator on the front of the printer. When ink reaches the upper limit line (A), ink is full. When ink is near the lower limit line (B), ink is running low. Refill the ink tank. Note •...
Page 89: Restrictions
Restrictions When connecting another device while a device (such as a computer) is already connected to the printer, connect it using the same connection method as the connected device. If you connect using a different connection method, the connection to the device in use will be disabled. However, you can use a Wi-Fi connection and Wireless Direct at the same time.
Page 90 When you connect a device and the printer using Wireless Direct, the connection information will be saved to Wi-Fi settings. The device may be connected to the printer automatically even after disconnecting it or connecting it to another wireless router. To prevent automatic connection to the printer in Wireless Direct mode, change the connection mode after using the printer, or set not to connect automatically in the Wi-Fi settings of the device.
Page 91: Detect Same Printer Name
Detect Same Printer Name When the printer is detected during setup, plural printers with the same name may appear on the results screen. Select a printer with checking the printer settings against those on detection result screen. • For Windows: •...
Page 92: Switching Printer's Connection To Network Or Devices
Switching Printer's Connection to Network or Devices Check the following items when connecting a newly added computer to the LAN environment to the printer, changing the connection method from USB to LAN, or changing the wireless LAN (Wi-Fi) connection method. 1.
Page 93 Refer to Setup Guide to setup. 3. Reconfiguration Method of Wi-Fi Connection • If you want to switch to Wireless Direct when using the printer with Wi-Fi connection: • Wireless Direct connection is available. Wireless Direct and Wi-Fi connection can be used together. But if you use IEEE802.1X/EAP (WPA/WPA2/WPA3 Enterprise), they can be not used together.
Page 94: Network Connection Tips (Windows/Macos)
Network Connection Tips (Windows/macOS) Detect Same Printer Name Switching Printer's Connection to Network or Devices...
Page 95 Detect Same Printer Name When the printer is detected during setup, plural printers with the same name may appear on the results screen. Select a printer with checking the printer settings against those on detection result screen. • For Windows: •...
Page 96 Switching Printer's Connection to Network or Devices Check the following items when connecting a newly added computer to the LAN environment to the printer, changing the connection method from USB to LAN, or changing the wireless LAN (Wi-Fi) connection method. 1.
Page 97 Refer to Setup Guide to setup. 3. Reconfiguration Method of Wi-Fi Connection • If you want to switch to Wireless Direct when using the printer with Wi-Fi connection: • Wireless Direct connection is available. Wireless Direct and Wi-Fi connection can be used together. But if you use IEEE802.1X/EAP (WPA/WPA2/WPA3 Enterprise), they can be not used together.
Page 98: Wi-Fi Connection Assistant (Windows)
Wi-Fi Connection Assistant (Windows) Wi-Fi Connection Assistant Starting Up Wi-Fi Connection Assistant Diagnosing and Repairing Network Settings Performing/Changing Network Settings List of Models Which Does Not Support Diagnosis and Repair Function List of Models Which Does Not Support IPv6 Configuration via USB Connection Important •...
Page 99: Wi-Fi Connection Assistant
Wi-Fi Connection Assistant Wi-Fi Connection Assistant allows you to diagnose or repair the network status, and to perform printer settings on network. Use Wi-Fi Connection Assistant for: • Searching printers on network and performing initial network setup for detected printers •...
Page 100: Starting Up Wi-Fi Connection Assistant
Connection Assistant. Note • In Windows 10, select Start > (All apps > ) > Canon Utilities > Wi-Fi Connection Assistant. • In Windows 7, click Start and select All Programs, Canon Utilities, Wi-Fi Connection Assistant, and then Wi-Fi Connection Assistant.
Page 101: Diagnosing And Repairing Network Settings
Diagnosing and Repairing Network Settings Wi-Fi Connection Assistant diagnoses and repairs computer settings or connection between the computer and printer when a problem (e.g. cannot print from a printer on the network) occurs. Important • Some models do not support diagnosis and repair function. •...
Page 102: Performing/Changing Network Settings
Performing/Changing Network Settings Canon Wi-Fi Connection Assistant Screen Performing Network Settings...
Page 103: Canon Wi-Fi Connection Assistant Screen
Items on Canon Wi-Fi Connection Assistant Screen Menus on Canon Wi-Fi Connection Assistant Screen Items on Canon Wi-Fi Connection Assistant Screen Toolbar Items on Canon Wi-Fi Connection Assistant Screen The screen below appears when you start up Wi-Fi Connection Assistant and select Printer Network Setup.
Page 104 Appears after performing network setup and clicking Set to close the window. • Requires Setup • Indicates the printer is required to perform Wi-Fi setup. Performing/Changing Wi-Fi Settings • Not Set • Indicates the printer cannot be used on network, or IPv6 is disabled. Specify an IP address or enable IPv6 on Network Settings..
Page 105 Selecting a printer from the printer list displays its current status and what to do next. Menus on Canon Wi-Fi Connection Assistant Screen This section describes menus on Canon Wi-Fi Connection Assistant screen. A: Printer Settings menu Printer Settings Menu...
Page 106 D: Help menu Help Menu Items on Canon Wi-Fi Connection Assistant Screen Toolbar This section describes items on Canon Wi-Fi Connection Assistant Screen toolbar. A: Perform wired or Wi-Fi setup. Note • This item has the same function as Network Settings... in the Printer Settings menu.
Page 107: Performing Network Settings
Performing Network Settings Performing/Changing Wired LAN Connection (Ethernet Cable) Settings Performing/Changing Wi-Fi Settings Assigning Printer Information...
Page 108: Performing/Changing Wired Lan Connection (Ethernet Cable) Settings
Performing/Changing Wired LAN Connection (Ethernet Cable) Settings Follow the procedure below to perform/change wired LAN settings. Note • For some models, you can perform network setup for a USB connected printer using Wi-Fi Connection Assistant. Select USB on Switch View under the View menu to display printers for which you can perform setup.
Page 109 7. Perform/change settings. You can switch the screen between IPv4 and IPv6. Click the tab to switch the protocol. • IPv4 settings • A: Use IPv4 address Always selected. (displayed in a gray out state) B: Get IP address automatically Select this option to use an IP address automatically assigned by a DHCP server.
Page 110 A: Use IPv6 address Select when you use the printer with IPv6 environment. B: Use Stateless Address: Select when you use an IP address assigned automatically. Use a router compatible with IPv6. Note • This setting item is not available depending on the printer you are using. C: Use Manual Address: Select this option if no DHCP server functionality is available in your setup where you use the printer, or you want to use a fixed IP address.
Page 111: Performing/Changing Wi-Fi Settings
Performing/Changing Wi-Fi Settings Follow the procedure below to perform/change Wi-Fi settings. Important • Enable Easy wireless connect (Cableless setup) before performing printer setup. (Not required if you change the IP address.) For details, search for "NR049" on your printer's online manual and see the page shown.
Page 112 Select Wi-Fi and click OK. 6. Enter password and click OK. The Network Settings screen appears. 7. Perform/change settings. You can switch the screen between IPv4 and IPv6. Click the tab to switch the protocol. • IPv4/IPv6 settings • A: Network Type: Select the Wi-Fi mode.
Page 113 The network name (SSID) for Wireless Direct appears while in Wireless Direct. C: Search... The Detected Wireless Routers screen is displayed to select a wireless router to connect to. For a wireless router already connected to the computer, Available is displayed on Communication Status.
Page 114 Enter the IP address, subnet mask, and default gateway. • IPv6 settings • Note • If you select a USB connected printer on step 4, you cannot perform IPv6 settings depending • on the printer you are using. For details, see List of Models Which Does Not Support IPv6 Configuration via USB Connection.
Page 115 D: Use DHCPv6: Select when you obtain an IP address using DHCPv6. Note • This setting item is not available depending on the printer you are using. 8. Click Set.
Page 116: Assigning Printer Information
Assigning Printer Information Follow the procedure below to assign/change printer location name or device name. The names appear on Device Name: and Location: on the Canon Wi-Fi Connection Assistant screen. Note • If USB is selected from the pulldown menu on the toolbar, this setting item is not available.
Page 117: List Of Models Which Does Not Support Diagnosis And Repair Function
List of Models Which Does Not Support Diagnosis and Repair Function The following models does not support "Diagnose and Repair" function of Wi-Fi Connection Assistant. • G4000 series • PRO-500 series • PRO-1000 series • MB2100 series • MB2700 series •...
Page 118: List Of Models Which Does Not Support Ipv6 Configuration Via Usb Connection
List of Models Which Does Not Support IPv6 Configuration via USB Connection For the following models, you can perform settings only for IPv4 using Wi-Fi Connection Assistant. (You cannot perform settings for IPv6.) • iB4100 series • MG3000 series • E470 series •...
Page 119 • TR9530 series • TS3300 series • E3300 series...
Page 120: Wi-Fi Connection Assistant (Macos)
Wi-Fi Connection Assistant (macOS) Wi-Fi Connection Assistant Starting Up Wi-Fi Connection Assistant Diagnosing and Repairing Network Settings List of Models Which Does Not Support Diagnosis and Repair Function Important • Some functions may not be available depending on your model and software version.
Page 121: Wi-Fi Connection Assistant
Wi-Fi Connection Assistant If anything is wrong with connection, Wi-Fi Connection Assistant diagnoses the settings of the printer and those of computer on which it is installed. In addition, Wi-Fi Connection Assistant restores the status of the printer and computer. Important •...
Page 122: Starting Up Wi-Fi Connection Assistant
Starting Up Wi-Fi Connection Assistant Start up Launchpad, select Canon Utilities, and then select Wi-Fi Connection Assistant. When you start up Wi-Fi Connection Assistant, the screen below appears. Enter the password specified for your computer and select Install Helper. Wi-Fi Connection Assistant starts diagnosis and repair of network.
Page 123: Diagnosing And Repairing Network Settings
Diagnosing and Repairing Network Settings Wi-Fi Connection Assistant diagnoses and repairs computer settings or connection between the computer and printer when a problem (e.g. cannot print from a printer on the network) occurs. Important • Some models do not support diagnosis and repair function. •...
Page 124: List Of Models Which Does Not Support Diagnosis And Repair Function
List of Models Which Does Not Support Diagnosis and Repair Function The following models does not support "Diagnose and Repair" function of Wi-Fi Connection Assistant. • G4000 series • PRO-500 series • PRO-1000 series • MB2100 series • MB2700 series •...
Page 125: Performing Maintenance Functions From The Printer
Performing Maintenance Functions from the Printer Maintenance Procedure Printing the Nozzle Check Pattern Examining the Nozzle Check Pattern Cleaning the Print Head Deep Print Head Cleaning Aligning the Print Head Aligning the Print Head Manually...
Page 126: Maintenance Procedure
Maintenance Procedure If print results are blurred, colors are not printed correctly, or print results are unsatisfactory (e.g. misaligned printed ruled lines), perform the maintenance procedure below. Important • Do not rinse or wipe the print head. This can cause trouble with the print head. •...
Page 127 • Be sure to check the remaining ink level before replacing ink in print head. • Perform Replace Ink in Print Head If the symptom still persists, the print head may be defective. Contact Canon to request a repair. When the Print Results Are Not Even such as the Ruled Lines Are Misaligned: Align the print head.
Page 128: Printing The Nozzle Check Pattern
Printing the Nozzle Check Pattern Print the nozzle check pattern to determine whether the ink ejects properly from the print head nozzle. Note • If the remaining ink level is low, the nozzle check pattern will not be printed correctly. •...
Page 129: Examining The Nozzle Check Pattern
Examining the Nozzle Check Pattern Examine the nozzle check pattern, and clean the print head if necessary. 1. Check if there are missing lines in the pattern C or horizontal streaks in the pattern D. A: No missing lines/No horizontal streaks B: Lines are missing/Horizontal streaks are present 2.
Page 130 For A (no missing lines or no horizontal streaks) in both the pattern C and pattern D: The cleaning is not required. Select All A, confirm the message, and then tap OK. The screen will return to the Maintenance screen. For B (lines are missing or horizontal streaks are present) in the pattern C or pattern D, or in both patterns: The cleaning is required.
Page 131: Cleaning The Print Head
Cleaning the Print Head Clean the print head if lines are missing or if horizontal streaks are present in the printed nozzle check pattern. Cleaning unclogs the nozzles and restores the print head condition. Cleaning the print head consumes ink, so clean the print head only when necessary. Important •...
Page 132 The pattern print confirmation screen will appear. 7. Select Yes. The nozzle check pattern will be printed. Examine the nozzle check pattern. Note • If the problem is not resolved after cleaning the print head twice, • clean the print head deeply.
Page 133: Deep Print Head Cleaning
Deep Print Head Cleaning If print quality does not improve by the standard cleaning of the print head, clean the print head deeply. Cleaning the print head deeply consumes more ink than the standard cleaning of the print head, so clean the print head deeply only when necessary.
Page 134 The pattern print confirmation screen will appear. 7. Select Yes. The nozzle check pattern will be printed. 8. When the completion message appears, tap OK. Examine the nozzle check pattern. If the problem is not resolved, turn off the power and clean the print head deeply again after 24 hours. Do not unplug the power cord when turning off the power.
Page 135: Aligning The Print Head
Aligning the Print Head If printed ruled lines are misaligned or print results are otherwise unsatisfactory, adjust the print head position. Note • If the remaining ink level is low, the print head alignment sheet will not be printed correctly. •...
Page 136 Note • If automatic print head alignment fails, an error message appears on the touch screen. • When Error Occurred 7. When the completion message appears, tap OK. Note • If the print results are still not satisfactory after adjusting the print head position as described above, •...
Page 137: Aligning The Print Head Manually
Aligning the Print Head Manually Try aligning the print head manually after automatic print head alignment if printing results are not as expected, as when printed ruled lines are misaligned. You need to prepare: two sheets of A4 or Letter-sized plain paper Check that printer is turned on.
Page 138 8. Check message and tap Next. The input screen for head position alignment values is displayed. 9. Examine first patterns and select A. In column A, find pattern in which stripes are least noticeable, and then select the number of that pattern. Note •...
Page 139 • If all patterns look different, choose the pattern in which horizontal stripes are least noticeable. • Subtle horizontal stripes Noticeable horizontal stripes 10. Repeat these steps until you have finished entering pattern numbers for columns B to N, and then tap OK. 11.
Page 140: Performing Maintenance Functions From Your Computer (Windows)
Performing Maintenance Functions from Your Computer (Windows) Opening the Maintenance Tool (Canon IJ Printer Assistant Tool) Cleaning the Print Heads Adjusting Print Head Position Automatically Adjusting Print Head Position Manually...
Page 141: Opening The Maintenance Tool (Canon Ij Printer Assistant Tool)
Canon IJ Printer Assistant Tool can be started in the following ways. • Click Maintenance and Preferences icon in the Maintenance tab of the printer driver. • From Windows Start menu, click (All apps, Apps, or All Programs ->) Canon Utilities -> IJ Printer Assistant Tool.
Page 142 Managing the Printer Power Reducing the Printer Noise Changing the Printer Operation Mode...
Page 143: Cleaning The Print Heads
Perform print head Cleaning if printing results are not satisfactory or if a specific color fails to print, even though there is enough ink. Cleaning 1. Open Canon IJ Printer Assistant Tool 2. Click Cleaning When the Print Head Cleaning dialog box opens, select the ink group for which Cleaning is to be performed.
Page 144 2. Click Deep Cleaning When the Deep Cleaning dialog box opens, select the ink group for which Deep Cleaning is to be performed. Click Initial Check Items to display the items you need to check before performing Deep Cleaning. 3. Perform Deep Cleaning Check that the printer is on and then click Start.
Page 145: Adjusting Print Head Position Automatically
• A pattern will be printed for head alignment. Do not open the top cover while printing is in progress. Print Head Alignment 1. Open Canon IJ Printer Assistant Tool 2. Click Print Head Alignment The Print Head Alignment dialog box opens.
Page 146: Adjusting Print Head Position Manually
• Printing is required for adjusting the position of the print head. Do not open the top cover while printing is in progress; otherwise, printing will stop. Print Head Alignment 1. Open Canon IJ Printer Assistant Tool 2. Check that the printer power is on, and then click Custom Settings The Custom Settings dialog box opens. Note •...
Page 147 7. Perform head alignment Click Start. Follow the instruction in the message. 8. Check printed pattern In each entry field, enter the number of the pattern with the least prominent streaks or stripes from among the printed patterns. You can also enter numbers into the entry fields automatically by clicking relevant pattern in the preview.
Page 148 10. Check printed patterns In each entry field, enter the number of the pattern with the least prominent stripes or streaks from among the printed patterns. You can also enter numbers into the entry fields automatically by clicking relevant pattern in the preview.
Page 149: Performing Maintenance Functions From Your Computer (Macos)
Performing Maintenance Functions from Your Computer (macOS) Opening Remote UI for Maintenance Cleaning the Print Heads Adjusting Print Head Position...
Page 150: Opening Remote Ui For Maintenance
Opening Remote UI for Maintenance You can perform maintenance of printer and change the settings from a Remote UI. The following is the procedure to open a Remote UI. 1. Open System Settings, and select Printers & Scanners 2. Select your model from the printer list, and click Options & Supplies... 3.
Page 151: Cleaning The Print Heads
Cleaning the Print Heads The print head Cleaning and Deep Cleaning functions allow you to clear up clogged print head nozzles. Perform print head Cleaning if printing results are not satisfactory or if a specific color fails to print, even though there is enough ink.
Page 152 • Is there ink remaining? 3. Perform Deep Cleaning Click Yes. Print head Deep Cleaning starts. 4. Complete Deep Cleaning Next, the message for Nozzle Check pattern printing is displayed. 5. Check the results To check whether the print quality has improved, click Yes. To cancel the check process, click No. Important •...
Page 153: Adjusting Print Head Position
Adjusting Print Head Position Any error in the print head installation position can cause color and line shifts. Adjusting the print head position improves print results. Print Head Alignment - Auto 1. Select Utilities from Remote UI 2. Click Print Head Alignment - Auto A message appears.
Page 154: Cleaning
Cleaning Cleaning Exterior Surfaces Cleaning Paper Feed Rollers Cleaning Inside the Printer (Bottom Plate Cleaning) Cleaning Cassette Pads...
Page 155: Cleaning Paper Feed Rollers
Cleaning Paper Feed Rollers If a paper feed roller is dirty or paper powder is attached to it, paper may not be fed properly. In this case, perform Roller Cleaning. Cleaning will cause wear on rollers, so perform this only when necessary. You need to prepare: three sheets of A4 or Letter-sized plain paper Check that printer is turned on.
Page 156 Do not touch the roller with your fingers. Paper feeding performance may be degraded. 3. Turn on the power, then clean the paper feed rollers again. If the problem is not resolved after cleaning, contact your nearest Canon service center to request a repair.
Page 157: Cleaning Inside The Printer (Bottom Plate Cleaning)
Cleaning Inside the Printer (Bottom Plate Cleaning) Remove stains from the inside of the printer. If the inside of the printer becomes dirty, printed paper may get dirty, so we recommend performing cleaning regularly. You need to prepare: a sheet of A4 or Letter-sized plain paper* * Be sure to use a new piece of paper.
Page 158 9. Pull out a paper output tray (A). 10. Tap OK. The paper cleans the inside of the printer as it feeds through the printer. Check the folded parts of the ejected paper. If they are smudged with ink, perform Bottom Plate Cleaning again.
Page 159 If the problem is not resolved after performing cleaning again, the protrusions inside the printer may be stained. Wipe off any ink from the protrusions using a cotton swab or the like. Important • Be sure to turn off the power and unplug the power cord before cleaning the printer. •...
Page 160: Replacing The Maintenance Cartridge
Replacing the Maintenance Cartridge Replacing the Maintenance Cartridge Checking Maintenance Cartridge Status on Touch Screen...
Page 161: Replacing The Maintenance Cartridge
Replacing the Maintenance Cartridge In case of cautions or errors concerning the maintenance cartridge, an error message will appear on the touch screen to inform you of the error. Take appropriate action as prompted by the message. When Error Occurred Important •...
Page 162 4. Pull out the maintenance cartridge. Hold the upper portion of the maintenance cartridge with your hands so that its bottom does not touch the floor or desk. Important • Be careful not to drop or place the removed maintenance cartridge on a desk or something. Dirt •...
Page 163 • Do not put your hands inside the printer, as ink may adhere to your hands. • 5. Insert the new maintenance cartridge straight until it stops. 6. Attach the maintenance cover. Align the tab on the back of the maintenance cover with the hole on the printer and close it. 7.
Page 165: Checking Maintenance Cartridge Status On Touch Screen
Checking Maintenance Cartridge Status on Touch Screen Check that printer is turned on. 2. Select (Hint) on HOME screen. Using Touch Screen The hint menu screen will appear. 3. Select Maintenance cart. info.. A symbol appears in the area A if there is any information about the used space of the maintenance cartridge.
Page 166: Changing Settings
Changing Settings Changing Printer Settings from Your Computer (Windows) Changing Printer Settings from Your Computer (macOS) Changing Settings from Operation Panel...
Page 167: Changing Printer Settings From Your Computer (Windows)
Changing Printer Settings from Your Computer (Windows) Changing the Print Options Managing the Printer Power Changing the Printer Operation Mode...
Page 168: Changing The Print Options
Changing the Print Options You can change the detailed printer driver settings for print data that is sent from an application software. Check this check box if part of the image data is cut off, the paper source during printing differs from the driver settings, or printing fails.
Page 169: Managing The Printer Power
Managing the Printer Power This function allows you to manage the printer power from the Canon IJ Printer Assistant Tool. Power Off The Power Off function turns off the printer. When you use this function, you will not be able to turn the printer on from the Canon IJ Printer Assistant Tool.
Page 170 Note • When the printer is turned off, the Canon IJ Status Monitor message varies depending on the Auto Power On setting. When the setting is Enable, "Printer is standing by" is displayed. When the setting is Disable,...
Page 171: Changing The Printer Operation Mode
Custom Settings in Canon IJ Printer Assistant Tool For functions related to print settings, go to Custom Settings in the Maintenance Tab. For other settings, go to Custom Settings in Canon IJ Printer Assistant Tool. Custom Settings in the Maintenance Tab 1.
Page 172 If necessary, switch between various modes of printer operation. 4. Apply the settings Click OK and when the confirmation message appears, click OK. The printer operates with the modified settings hereafter.
Page 173: Changing Printer Settings From Your Computer (Macos)
Changing Printer Settings from Your Computer (macOS) Managing the Printer Power Changing the Printer Operation Mode...
Page 174: Managing The Printer Power
Managing the Printer Power Printer power supply is operated from Remote UI. Power control settings Power control settings allow you to set Auto power off and Auto power on. Auto power off is the function wherein the printer automatically turns itself off, when data is not sent or the printer remains inactive for a certain period.
Page 175: Changing The Printer Operation Mode
Changing the Printer Operation Mode If necessary, switch between various modes of printer operation. 1. Check whether the printer is on and select Printer settings from Remote UI 2. If necessary, complete the following settings: Print settings - Prevent paper abrasion The printer can increase the gap between the print head and the paper during high-density printing to prevent paper abrasion.
Page 176: Changing Settings From Operation Panel
Changing Settings from Operation Panel Paper Settings Changing Settings from Operation Panel Setting Items on Operation Panel Security settings Print settings LAN settings Other printer settings Language selection Firmware update Administrator password settings User management settings Reset settings Feed settings Web service setup ECO settings Quiet setting...
Page 177: Changing Settings From Operation Panel
Changing Settings from Operation Panel This section describes the procedure to change the settings, taking the steps to specify prevent abrasion as an example. Check that printer is turned on. 2. Select (Setup) on the HOME screen. Using Touch Screen 3.
Page 178 For more on setting items on the operation panel: Setting Items on Operation Panel...
Page 179: Setting Items On Operation Panel
Setting Items on Operation Panel Note • The administrator password may be required to change the settings of some setting items. • Items for Printer Other printer settings Language selection Web service setup Quiet setting Items for Paper/Printing Print settings Feed settings Items for Maintenance/Management Security settings...
Page 180: Security Settings
Security Settings Select this setting item from Printer settings in (Setup). Important • The administrator password may be required to change the settings. • • Lockout settings • Set whether to lock password input for a period of time after multiple incorrect attempts. ◦...
Page 181: Print Settings
Print settings Select this setting item from Printer settings in (Setup). • Reduce ink volume • Adjust ink volume when ink on the printed surface of printed materials comes off or smudges when touched immediately after printing. Note • Ink volume can be set for each type of paper used. •...
Page 182 Note • This feature will be implemented with the following settings. • Plain paper Color printing Size is a template size or a user-defined size within the range of a template size * The feature may not be implemented even when the above settings are selected, depending on other setting details.
Page 183: Lan Settings
LAN settings Select this setting item from Printer settings in (Setup). Important • The administrator password may be required to change the settings. • Wi-Fi Wireless Direct Wired LAN To print the network settings, select Print details and select Yes. Printing Network Settings Important •...
Page 184 XXXXXXXXXXXXX XXXXXXXXXXXXX ("XX" represents alphanumeric characters.) • Enable/disable Wi-Fi • Enables/disables Wi-Fi. • Wi-Fi setup • Selects the setup method for Wi-Fi connection. ◦ Easy wireless connect ◦ Select if you specify the settings of the access point information to the printer directly from a device (e.g.
Page 185 IPv4 address XXX. XXX. XXX. XXX IPv4 subnet mask XXX. XXX. XXX. XXX IPv4 default gateway XXX. XXX. XXX. XXX IPv6 link-local address XXXX: XXXX: XXXX: XXXX: XXXX: XXXX: XXXX: XXXX MAC address (Wi-Fi) XX:XX:XX:XX:XX:XX Printer name XXXXXXXXXXXXXXX Bonjour service name XXXXXXXXXXXXX XXXXXXXXXXXXX XXXXXXXXXXXXX...
Page 186 Connection Enabled (connected)/Enabled (disconnected)/Disable IPv4 address XXX. XXX. XXX. XXX IPv4 subnet mask XXX. XXX. XXX. XXX IPv4 default gateway XXX. XXX. XXX. XXX IPv6 link-local address XXXX: XXXX: XXXX: XXXX: XXXX: XXXX: XXXX: XXXX MAC address (Wired LAN) XX:XX:XX:XX:XX:XX Printer name XXXXXXXXXXXXXXX Bonjour service name...
Page 187 Selecting Enable allows you to receive the WSD printing data faster. ◦ Timeout settings ◦ Specifies the timeout length. • Bonjour settings • Setting items when you use Bonjour. ◦ Enable/disable Bonjour ◦ Selecting Enable allows you to use Bonjour to perform the network settings. ◦...
Page 188 ◦ Enable/disable ◦ Enables/disables IEEE802.1X/EAP. ◦ Search for EAP router ◦ Searches switch/access point of IEEE802.1X/EAP and display it. ◦ Last authentication result ◦ Displays the latest authentication result of IEEE802.1X/EAP setting. • Easy wireless connect • When set to Auto start: ON, the device will automatically put into the standby mode for easy wireless connect.
Page 189: Other Printer Settings
Other printer settings Select this setting item from Printer settings in (Setup). Important • The administrator password may be required to change the settings. • • Date/time settings • Sets the current date and time. • Date display format • Selects the date display format.
Page 190 • Power control • Allows you to turn on/off the printer automatically to save electricity. In addition, you can specify the time and day to turn it on/off. ◦ Use auto power control ◦ Specifies the length of time to turn off the printer automatically when no operation is made or no printing data is sent to the printer.
Page 191 • Screen lock settings • Lock the screen to prevent the panel operation by someone other than the administrator. • External server connection • Set external server connections. • Notification settings • All notification screens are not displayed if you select OFF.
Page 192: Language Selection
Language selection Select this setting item from Printer settings in (Setup). Changes the language for the messages and menus on the touch screen. Important • The administrator password may be required to change the settings. • Japanese / English / German / French / Italian / Spanish / Portuguese / Dutch / Danish / Norwegian / Swedish / Finnish / Russian / Ukrainian / Polish / Czech / Slovene / Hungarian / Slovak / Croatian / Romanian / Bulgarian / Turkish / Greek / Estonian / Latvian / Lithuanian / Simplified Chinese / Korean / Traditional Chinese / Thai / Indonesian / Vietnamese...
Page 193: Firmware Update
Firmware update Select this setting item from Printer settings in (Setup). You can update the firmware of the printer, check the firmware version, or perform settings of a notification screen, a DNS server and a proxy server. Important • The administrator password may be required to change the settings. •...
Page 194: Administrator Password Settings
Administrator password settings The administrator password can be set or canceled. Important • The administrator password of the printer is set by default. It is set in the serial number of the printer • which consists of 9 characters (the first 4 characters are alphabet and the latter 5 characters are number) and is indicated on the seal on the device.
Page 195 9. Select Apply. 10. Enter the administrator password again. 11. Select Apply. The administrator password is available. Note • When the administrator password is canceled or the effective range of the administrator password • is set to Remote UI and other tools, the user management is disabled.
Page 196: User Management Settings
User management settings The administrator makes settings to manage users. Important • The administrator password may be required to change the settings. • Check that printer is turned on. 2. Select Setup on the HOME screen. Using Touch Screen The setup menu screen will appear. 3.
Page 197: Reset Settings
Reset settings Select this setting item from Printer settings in (Setup). You can set the settings back to the default. Important • The administrator password may be required to change the settings. • • Web service setup only • Sets the Web service settings back to the default. •...
Page 198: Feed Settings
Feed settings Select this setting item from (Setup). Note • By registering the paper size and the media type, the message can be displayed before printing starts • when the paper size or the media type of the loaded paper differs from the paper settings. Paper Settings •...
Page 199 • For AirPrint of iOS/iPadOS, paper may be printed based on the paper size set during paper loading. • It is recommended to set to ON when making prints using an AirPrint function.
Page 200: Web Service Setup
The following setting items are available. ◦ IJ Cloud Printing Center setup ◦ Registers/Deletes the printer to/from Canon Inkjet Cloud Printing Center and sets the history saving. ◦ Check Web service setup ◦ Make sure whether the printer is registered to Canon Inkjet Cloud Printing Center.
Page 201: Eco Settings
ECO settings This setting allows you to turn on/off the printer automatically to save electricity. Important • The administrator password may be required to change the settings. • Using Power Saving Function Using Power Saving Function Follow the procedure below to use power saving function. Check that printer is turned on.
Page 202 • Selecting Do not use power control disables all settings of the power control and scheduling. •...
Page 203: Quiet Setting
Quiet setting Enables this function on the printer if you want to reduce the operating noise, such as when printing at night. In addition, you can specify the time range to reduce the operating noise. Important • The administrator password may be required to change the settings. •...
Page 204 Specify End time in the same procedure, and tap OK. You can reduce the operating noise during the specified time. The confirmation screen is displayed and the icon appears as the Quiet setting menu icon. Important • Operating speed is reduced compared to when OFF is selected. •...
Page 205: System Information
System information Select this item from (Hint). • Current version • Displays the current firmware version. • Printer name • Displays the printer name currently specified. • Serial number • Displays the printer serial number. • Head information • Displays the serial number of the print head. •...
Page 206: Job Management
Job management Select this item from (Hint). Important • The administrator password may be required to change the settings. • • Display job history • Displays the job history of printing. • Print job history • Prints the job history of printing. •...
Page 207: Checking The Total Number Of Uses Of Printer
Checking the Total Number of Uses of Printer You can check the total number of printed pages by type of paper and output method. Check that printer is turned on. 2. Select (Hint) on HOME screen. Using Touch Screen The hint menu screen will appear. 3.
Page 208: Basic Information
Basic Information Safety Safety Precautions Regulatory Information WEEE Handling Precautions Canceling Print Jobs Legal Restrictions on Printing Printer Handling Precautions Transporting Your Printer When Repairing, Lending, or Disposing of the Printer Keeping Print Quality High Ink Tips Specifications Product Specifications Supported Paper Sizes and Weights Print Area Paper Load Limit...
Page 209: Safety
Safety Safety Precautions Regulatory Information WEEE...
Page 210: Safety Precautions
Safety Precautions Safety Precautions • This manual contains important notices and safety precautions about your printer. • Do not use the printer in ways other than described in the accompanying manuals, as this may result in fire, electric shock or other unexpected accidents. Safety standard marks and declarations are only valid for the supported voltages and frequencies in the applicable countries or regions.
Page 211 Moving parts Keep body parts away from moving parts. Keep body parts out of the motion path. • Ink bottles Keep out of reach of children. Do not drink ink. If ink is accidentally licked or swallowed, rinse out your mouth or drink one or two glasses of water and obtain medical advice immediately.
Page 212 General Notices Choosing a Location Refer to "Specifications" in the Online manual for details on operating environment. • Do not install the printer in a location that is unstable or subject to excessive vibration. • Do not install the printer in locations that get very hot (direct sunlight, or close to a heating source), very humid or dusty locations, or outdoors.
Page 213: Regulatory Information
FCC radio frequency (RF) Exposure Guidelines as this equipment has very low levels of RF energy. But it is desirable that it should be installed and operated keeping the radiator at least 20cm or more away from person's body. Canon U.S.A., Inc. One Canon Park Melville, New York 11747...
Page 214 Interference Do not use the printer around medical equipment or other electronic devices. Signals from the printer may interfere with the correct operation of these devices.
Page 215: Weee
EEE. Your cooperation in the correct disposal of this product will contribute to the effective usage of natural resources. For more information about the recycling of this product, please contact your local city office, waste authority, approved scheme or your household waste disposal service or visit www.canon- europe.com/sustainability/approach/.
Page 216 Nutzung natürlicher Ressourcen bei. Um weitere Informationen über die Wiederverwertung dieses Produkts zu erhalten, wenden Sie sich an Ihre Stadtverwaltung, den öffentlich-rechtlichen Entsorgungsträger, eine autorisierte Stelle für die Entsorgung von Elektro- und Elektronik-Altgeräten oder Ihr örtliches Entsorgungsunternehmen oder besuchen Sie www.canon-europe.com/weee, oder www.canon-europe.com/battery. Zusatzinformationen für Deutschland: Dieses Produkt kann durch Rückgabe an den Händler unter den in der Verordnung des Elektro- und...
Page 217 Voor verdere informatie over recycling van dit product kunt u contact opnemen met uw plaatselijke gemeente, afvaldienst, officiële dienst voor klein chemisch afval of afvalstortplaats, of kunt u terecht op www.canon- europe.com/weee, of www.canon-europe.com/battery.
Page 218 Si desea más información sobre el reciclado de este producto, póngase en contacto con su municipio, el servicio o el organismo encargado de la gestión de residuos domésticos o visite www.canon-europe.com/ weee, o www.canon-europe.com/battery.
Page 219 Solo per Unione Europea e SEE (Norvegia, Islanda e Liechtenstein) Questi simboli indicano che il prodotto non può essere smaltito con i rifiuti domestici, ai sensi della Direttiva RAEE (2012/19/UE), della Direttiva sulle Batterie (2006/66/CE) e/o delle leggi nazionali che attuano tali Direttive.
Page 220 Når du foretager korrekt bortskaffelse af produktet, bidrager du til effektiv brug af naturressourcerne. Kontakt din kommune, den lokale affaldsmyndighed, det lokale affaldsanlæg, eller besøg www.canon-europe.com/weee, eller www.canon-europe.com/battery for at få flere oplysninger om genbrug af dette produkt.
Page 221 Sähkö- ja elektroniikkalaiteromun virheellinen käsittely voi vahingoittaa ympäristöä ja ihmisten terveyttä, koska laitteet saattavat sisältää ympäristölle ja terveydelle haitallisia aineita. Tuotteen asianmukainen hävittäminen säästää myös luonnonvaroja. Jos haluat lisätietoja tämän tuotteen kierrätyksestä, ota yhteys kunnan jätehuoltoviranomaisiin tai käyttämääsi jätehuoltoyhtiöön tai käy osoitteessa www.canon- europe.com/weee, tai www.canon-europe.com/battery.
Page 222 Om du vill ha mer information om var du kan lämna in den här produkten, kontakta ditt lokala kommunkontor, berörd myndighet eller företag för avfallshantering eller se www.canon-europe.com/weee, eller www.canon- europe.com/battery.
Page 223 Państwa współpraca w zakresie właściwej utylizacji tego produktu przyczyni się do efektywnego wykorzystania zasobów naturalnych. W celu uzyskania informacji o sposobie recyklingu tego produktu prosimy o kontakt z właściwym urzędem miejskim lub zakładem gospodarki komunalnej bądź zapraszamy na stronę www.canon-europe.com/weee, lub www.canon-europe.com/battery.
Page 224 Täiendava teabe saamiseks elektri- ja elektroonikaseadmetest tekkinud jäätmete ning patarei- ja akujäätmete tagastamise ja ümbertöötlemise kohta võtke ühendust kohaliku omavalitsusega, asjakohase valitsusasutusega, asjakohase tootjavastutusorganisatsiooniga või olmejäätmete käitlejaga. Lisateavet leitate ka Interneti- leheküljelt www.canon-europe.com/weee või www.canon-europe.com/battery.
Page 225 įranga. Bendradarbiaudami ir teisingai utilizuodami šiuos gaminius, jūs padėsite efektyviai naudoti gamtinius išteklius. Daugiau informacijos apie gaminio perdirbimą jums gali suteikti vietinis biuras, atliekų tvarkymo bendrovė, sertifikuoti organai ar buitinių atliekų surinkimo įmonės. Taip pat siūloma apsilankyti interneto svetainėje www.canon- europe.com/weee, arba www.canon-europe.com/battery.
Page 226 Za več informacij o ponovni uporabi tega izdelka se obrnite na lokalen mestni urad, pristojno službo za odpadke, predstavnika pooblaščenega programa za obdelavo odpadkov ali na lokalno komunalo. Lahko pa tudi obiščete našo spletno stran www.canon-europe.com/weee, ali www.canon- europe.com/battery.
Page 227 Vaša suradnja u pravilnom zbrinjavanju ovog proizvoda pridonijet će djelotvornom iskorištavanju prirodnih resursa. Dodatne informacije o recikliranju ovog proizvoda zatražite od svog lokalnog gradskog ureda, službe za zbrinjavanje otpada, odobrenog programa ili komunalne službe za uklanjanje otpada ili pak na stranicama www.canon-europe.com/weee ili www.canon-europe.com/battery.
Page 228 EEE. Vaša saradnja na ispravnom odlaganju ovog proizvoda će doprineti efikasnom korišćenju prirodnih resursa. Više informacija o tome kako možete da reciklirate ovaj proizvod potražite od lokalnih gradskih vlasti, komunalne službe, odobrenog plana reciklaže ili servisa za odlaganje kućnog otpada, ili posetite stranicu www.canon-europe.com/weee, ili www.canon-europe.com/battery.
Page 229: Handling Precautions
Handling Precautions Canceling Print Jobs Legal Restrictions on Printing Printer Handling Precautions Transporting Your Printer When Repairing, Lending, or Disposing of the Printer Keeping Print Quality High Ink Tips...
Page 230: Legal Restrictions On Printing
Legal Restrictions on Printing Printing or modifying printed copies of the following may be punishable under law. This list is non-exhaustive. When in doubt, check with a local legal representative. • Paper money • • Money orders • • Certificates of deposit •...
Page 231: Printer Handling Precautions
Printer Handling Precautions Do not place any object on the top cover! Do not place any object on the top cover. It will fall into the rear tray when the top cover is opened and cause the printer to malfunction. Also, place the printer where objects will not fall on it.
Page 232: Transporting Your Printer
Transporting Your Printer When relocating the printer for changing your living place, make sure of the following. Important • You cannot take ink out of ink tanks. • • Check if the tank cap is completely inserted. • • Prepare for transporting the printer with the print head attached. This allows the printer to automatically •...
Page 233 4. Confirm the message, then select Yes. The mode is shifted to the transfer mode. When it is completed, the power is turned off automatically. 5. Check that ON lamp is off and unplug power cord. Important • Do not unplug the printer while the ON lamp is lit or flashing, as it may cause malfunction or •...
Page 235: When Repairing, Lending, Or Disposing Of The Printer
When Repairing, Lending, or Disposing of the Printer If you have entered personal data, passwords and/or other security settings on the printer, such information may be stored in the printer. To keep your personal information safe, please be sure to reset all printer settings when sending the printer for repair, lending or transferring the printer to another person, or disposing of the printer.
Page 236: Keeping Print Quality High
Keeping Print Quality High The key to printing with the optimal printing quality is to prevent the print head from drying or clogging. Always observe the following rules for optimal printing quality. Note • Depending on the type of paper, ink may blur if you trace the printed area with a highlight pen or •...
Page 237: Ink Tips
Therefore, the page yield of the initial bundled set of ink bottles is lower than that of the subsequent sets of bottles. To keep printer's performance, Canon printer performs cleaning automatically according to its condition. When the printer performs cleaning, a small amount of ink is consumed. In this case, all colors of ink may be consumed.
Page 238: Specifications
Specifications Product Specifications Supported Paper Sizes and Weights Print Area Paper Load Limit...
Page 239: Product Specifications
Product Specifications General Specifications Interface USB port: Hi-Speed USB * Network port: Wired LAN: 100BASE-TX / 10BASE-T Wi-Fi: IEEE802.11n / IEEE802.11g / IEEE802.11b / IEEE802.11a / IEEE802.11ac * A computer that complies with Hi-Speed USB standard is required. Since the Hi-Speed USB interface is fully upwardly compatible with USB 1.1, it can be used at USB 1.1.
Page 240 * With the Print Head installed. Network Specifications Communication protocol SNMP, HTTP, TCP/IP (IPv4/IPv6) Wired LAN Supported Standards: IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T) Transfer speed: 10 Mbps/100 Mbps (auto switching) Security: IEEE802.1X (EAP-TLS/EAP-TTLS/PEAP) Wi-Fi Supported Standards: IEEE802.11n / IEEE802.11g / IEEE802.11b / IEEE802.11a / IEEE802.11ac Frequency bandwidth: 2.4 GHz / 5 GHz * A frequency band that can be used varies depending on country or region.
Page 241 Catalina 10.15.7 - macOS Ventura 13 Other Supported OS iOS/iPadOS, Android, Chrome OS Some functions may not be available with the supported OS. Refer to the Canon web site for details. Information in this manual is subject to change without notice.
Page 242: Supported Paper Sizes And Weights
Supported Paper Sizes and Weights Page Sizes You can use the following page sizes. Note • Page sizes and media types the printer supports differ depending on the OS you are using. • Standard sizes: • Letter • • Legal •...
Page 243 • Yougata 1 • • Yougata 2 • • Yougata 3 • • Yougata 4 • • Yougata 6 • • Kakugata 3 • • Kakugata 4 • • Kakugata 5 • • Kakugata 6 • • Kakugata 7 • •...
Page 244: Paper Load Limit
• Page sizes and media types differ depending on the country or region where the paper is sold. For • details on page sizes and media types, access the Canon website. Paper Load Limits of Rear Tray and Cassette Genuine Canon Paper Paper for printing documents: Media Name <Model No.>...
Page 245 Double sided Matte Paper <MP-101D> Paper other than Genuine Canon Paper Common Name Rear Tray Cassette Plain Paper (including recycled paper)*1 Approx. 100 sheets (Legal, Approx. 250 sheets B-Oficio, M-Oficio, Foolscap, Legal(India): 10 sheets, B6 Half: 20 sheets) Thin Paper Approx.
Page 246: Supported Media Types
• details on page sizes and media types, access the Canon website. • Genuine Canon paper is not available in some countries or regions. Note that in the United States, • Canon paper is not sold by model number. Instead, purchase paper by name.
Page 247 Usable Media Types Other Than Genuine Canon paper • Plain Paper (including recycled paper) • • Thin Paper • • Thick Paper • • Envelopes • • Label Paper • • Glossy Label • • Medicine Envelopes • • Delivery Slips •...
Page 248: Unsupported Media Types
Unsupported Media Types Do not use the following types of paper. Using such paper will cause not only unsatisfactory results, but also the printer to jam or malfunction. • Folded, curled, or wrinkled paper • • Damp paper • • Paper thinner than a postcard, including plain paper or notepad paper cut to a small size (when printing •...
Page 249: Handling Paper
Handling Paper • For warnings on use of the non-printable side and operating environment, see each product's usage • information. • Problems may occur depending on the environment (a hot, humid environment or cold, dry • environment), paper handling method, and printer status used. If paper is warped after printing, remove paper from the paper output tray before printing on the next paper.
Page 250: Economy Mode
• ◦ Measurement images: ◦ Color printing: A4 color document ISO/IEC24712 ◦ Measurement method: ◦ Canon original ◦ Paper type: ◦ Plain paper (excludes thin paper and thick paper) ◦ Print driver setting: ◦ Setting to the default for plain paper (setting Quality to Economy).
Page 251: Printing
Printing Printing Photos and Documents Printing Hagaki and Envelopes...
Page 252: Printing Photos And Documents
Printing Photos and Documents Printing from Computer Printing from Smartphone/Tablet Using PIXMA/MAXIFY Cloud Link...
Page 253: Printing From Computer
Printing from Computer Printing from Application Software (Windows Printer Driver) Printing from Application Software (macOS AirPrint) Printing Using Canon Application Software Printing from Chrome OS...
Page 254: Printing From Application Software (Windows Printer Driver)
Printing from Application Software (Windows Printer Driver) Basic Printing Setup Basic Main Controls (Basic Settings Tab) Set Media Type, Quality, etc. (Media/Quality Tab) Set the Layout of Printed Documents (Page Setup Tab) Overview of the Printer Driver Updating the Driver...
Page 255: Basic Printing Setup
Basic Printing Setup In the Basic Settings tab, you can print in various ways according to your purpose. Check that printer is turned on 2. Open printer driver's setup screen 3. Select Profile (A) Select the print settings according to your purpose in Profiles on the Basic Settings tab. If you select a print setting, Paper Size and Media Type will change automatically.
Page 256 Note • For details about the paper information to be registered to the printer driver and on the printer, see the following: Paper Settings on the Printer Driver and the Printer (Media Type) Paper Settings on the Printer Driver and the Printer (Paper Size)
Page 257: Main Controls (Basic Settings Tab)
Main Controls (Basic Settings Tab) Basic Settings Tab Description Paper Settings on the Printer Driver and the Printer (Media Type) Paper Settings on the Printer Driver and the Printer (Paper Size)
Page 258: Basic Settings Tab Description
Basic Settings Tab Description The Basic Settings tab is for registering commonly used print settings. When you select a registered setting, the printer automatically switches to the preset items. • Profiles • Settings Preview • Preview before printing • Always print with current settings •...
Page 259 You can also change a printing profile and register it under a new name. You can delete the registered printing profile. Standard These are the factory settings. If Page Size, Orientation, and Copies were set from the application software, those settings have priority.
Page 260 Important • If you log on with a different user name, the settings that were set when this function was enabled are not reflected in the print settings. • If a setting was specified on the application software, it has priority. Page Size Selects a page size.
Page 261 Important • Depending on the media type and size, the Paper Source settings that can be selected may differ. Copies Specifies the number of copies you want to print. You can specify a value from 1 to 999. Important • When the application software that you used to create the document has the same function, specify the settings on the printer driver.
Page 262 Poster (1 x 2) to Poster (4 x 4) This function enables you to enlarge the image data and divide the enlarged data into several pages to be printed. You can also glue together these sheets of paper to create large printed matter, such as a poster.
Page 263 Name Enter the name for the printing profile you wish to save. Up to 255 characters can be entered. The name appears, with its associated icon, in the Profiles list on the Basic Settings tab. Options... Opens the Add to Profiles dialog box.
Page 264 Page Layout Printing dialog box This dialog box allows you to select the number of document pages to be placed on one sheet of paper, the page order, and whether a page border line is to be printed around each document page. The settings specified in this dialog box can be confirmed in the settings preview on the printer driver.
Page 265 Preview Icon Shows the settings made on the Booklet Printing dialog box. You can check what the document will look like when printed as a booklet. Margin for stapling Specifies which side of the booklet is to be stapled. Insert blank page Selects whether to print the document on one side or both sides of the booklet.
Page 266: Paper Settings On The Printer Driver And The Printer (Media Type)
Media Type in the printer driver the printer Canon Red Label Superior <WOP111> Plain Paper Plain paper Canon Océ Office Colour Paper <SAT213> Plain Paper Plain paper High Resolution Paper <HR-101N> High Resolution Paper High-Res Paper Canon genuine papers (Photo Printing) Paper information regis- Media name <Model No.>...
Page 267 Commercially available papers Paper information registered on the Media name Media Type in the printer driver printer Plain Paper (including recycled paper) Plain Paper Plain paper Thin Paper Thin Paper Thin Paper Thick Paper Thick Paper Thick Paper Envelopes Envelope Envelope Medicine Envelope Medicine Envelope...
Page 268: Paper Settings On The Printer Driver And The Printer (Paper Size)
Paper Settings on the Printer Driver and the Printer (Paper Size) When you use this printer, selecting a paper size that matches the print purpose will help you achieve the best print results. You can use the following paper sizes on this printer. Printer Paper Size in the printer driver Paper information registered on the printer Letter 8.5"x11"...
Page 269 Yougata 1 4.72"x6.93" Yougata 1 Yougata 2 4.49"x6.38" Yougata 2 Yougata 3 3.86"x5.83" Yougata 3 Envelope DL Envelope DL Nagagata 3 4.72"x9.25" Nagagata 3 Nagagata 4 3.54"x8.07" Nagagata 4 Yougata 4 4.13"x9.25" Yougata 4 Yougata 6 3.86"x7.48" Yougata 6 Kakugata 3 8.50"x10.91" Kakugata 3 Kakugata 4 7.76"x10.51"...
Page 270: Printing On Postcards
Printing on Postcards Load postcard on the printer 2. Open the printer driver setup window 3. Select commonly used settings Display the Basic Settings tab, and for Profiles, select Standard. 4. Select the paper size For Printer Paper Size, select Hagaki 100x148mm or Hagaki 2 200x148mm. Important •...
Page 271: Setting Up Envelope Printing
To hide the guide messages, check the Do not show this message again check box. To show the guide again, click the View Printer Status button on the Maintenance tab, and start the Canon IJ Status Monitor. Then click Envelope Printing from Display Guide Message of the Option menu to enable the setting.
Page 272: Registering A Frequently Used Printing Profile
Registering a Frequently Used Printing Profile You can register the frequently used printing profile to Profiles on the Basic Settings tab. Unnecessary printing profiles can be deleted at any time. Registering a Printing Profile 1. Open the printer driver setup window 2.
Page 273 4. Save the settings Enter a name for the print settings to register in the Name field. If necessary, click Options..., set the items, and then click OK. In the Add to Profiles dialog box, click OK to save the print settings and return to the Basic Settings tab.
Page 274: Set Media Type, Quality, Etc. (Media/Quality Tab)
Set Media Type, Quality, etc. (Media/Quality Tab) Media/Quality Tab Description Adjust Colors Specifying Color Correction Optimal Photo Printing of Image Data Adjusting Colors with the Printer Driver Printing with ICC Profiles...
Page 275: Media/Quality Tab Description
Media/Quality Tab Description The Media/Quality tab allows you to create a basic print setup in accordance with the media type.You can also adjust the print quality and color tones. • Settings Preview • Media Type • Paper Source • Quality •...
Page 276 Automatically Select Based on the paper settings in the printer driver and the paper information registered on the printer, the printer automatically determines the paper source and feeds paper. Rear Tray/Cassette 1/Cassette 2 Paper is always supplied from the selected paper source. Important •...
Page 277 Grayscale Printing This function converts the data to monochrome data when printing your document. Check this check box to print a color document in monochrome. Preview before printing Shows what the print result will look like before you actually print the data. Check this check box to display a preview before printing.
Page 278 Allows you to select Driver Matching, ICM, or None to match the purpose of the print operation. Driver Matching With Canon Digital Photo Color, you can print sRGB data with color tints that most people prefer. Adjusts the colors by using an ICC profile when printing.
Page 279: Set The Layout Of Printed Documents (Page Setup Tab)
Set the Layout of Printed Documents (Page Setup Tab) Page Setup Tab Description Setting the Number of Copies and Printing Order...
Page 280: Page Setup Tab Description
Page Setup Tab Description The Page Setup tab allows you to determine how a document is to be arranged on the paper. Also, this tab allows you to set the number of copies and the order of printing. If the application which created the document has a similar function, set them with the application.
Page 281 Page Size Selects a page size. Ensure that you select the same page size as you selected within the application. If you select Custom..., the Custom Paper Size dialog box opens and allows you to specify any vertical and horizontal dimensions for the paper size. Printer Paper Size Selects the size of paper actually loaded into the printer.
Page 282 To rotate the document 90 degrees to the left when printing, select the Rotate 90 degrees left when orientation is [Landscape] check box. Rotate 180 degrees Prints the document by rotating it 180 degrees against the paper feed direction. The width of print area and the amount of extension that are configured in other application software will be reversed vertically and horizontally.
Page 283 Print Options... Opens the Print Options dialog box. Changes detailed printer driver settings for print data that is sent from applications. Stamp/Background... Opens the Stamp/Background dialog box. The Stamp function allows you to print a stamp text or a bitmap over or behind document data. It also allows you to print date, time and user name.
Page 284 Print "Cut/Paste" in margins Specifies whether to print the words "Cut" and "Paste" in the margins. These words serve as guidelines for pasting together the pages into a poster. Check this check box to print the words. Note • Depending on the environment of the printer driver you are using, this function may not be available.
Page 285 In this case, check this function. Important • When this function is enabled, normally the paper feeding method cannot be changed from the Canon IJ Preview. Ungroup Papers Sets the display method of Media Type, Page Size, and Printer Paper Size.
Page 286 Do not allow application software to compress print data Compression of the application software print data is prohibited. If the print result has missing image data or unintended colors, selecting this check box may improve the condition. Important • Uncheck this check box under normal circumstances. Print after creating print data by page The print data is created in page units, and printing starts after the processing of one page of print data is complete.
Page 287 Stamp/Background dialog box Depending on the environment, Stamp and Background may not be available. The Stamp/Background dialog box allows you to print a stamp and/or background over or behind the document pages. In addition to the pre-registered ones, you can register and use your original stamp or background.
Page 288 Stamp Type Specifies the stamp type. Select Text to create a stamp with characters. Select Bitmap to create with a bitmap file. Select Date/Time/User Name to display the creation date/time and user name of the printed document. The setting items in the Stamp tab change depending on the selected type. •...
Page 289 Transparent white area Specifies whether to make white-filled areas of the bitmap transparent. Check this check box to make white-filled areas of the bitmap transparent. Note • Click Defaults to set Stamp Type to text, Stamp Text to blank, TrueType Font to Arial, Style to Regular, Size to 36 points, Outline unchecked, and Color to gray with the RGB values (192, 192, 192).
Page 290 Delete Deletes an unnecessary stamp. Specify the title of an unnecessary stamp from the Stamps list, and click this button. Background Tab The Background tab allows you to select a bitmap file (.bmp) to be used as a background or determine how to print the selected background.
Page 291 Delete Deletes an unnecessary background. Specify the title of an unnecessary background from the Backgrounds list, and then click this button.
Page 292: Setting The Number Of Copies And Printing Order
Setting the Number of Copies and Printing Order You can also set the number of copies on the Basic Settings tab. 1. Open the printer driver setup window 2. Specify the number of copies to be printed For Copies on the Page Setup tab, specify the number of copies to be printed. 3.
Page 293 Important • When the application software that you used to create the document has the same function, specify the settings on the printer driver. However, if the print results are not acceptable, specify the function settings on the application software. When you specify the number of copies and the printing order with both the application software and this printer driver, the number of copies may be multiplied numbers of the two settings or the specified printing order may not be enabled.
Page 294: Page Layout Printing
Page Layout Printing The page layout printing function allows you to print more than one page image on a single sheet of paper. 1. Open the printer driver setup window 2. Set page layout printing Select a page layout number from 1 on 1 to 16 on 1 from the Page Layout list on the Page Setup tab. The current settings are displayed in the settings preview on the left side of the printer driver.
Page 295: Duplex Printing
Duplex Printing You can also set duplex printing in the Basic Settings tab. Performing Automatic Duplex Printing You can perform the duplex printing without having to turn over the paper. 1. Open the printer driver setup window 2. Set automatic duplex printing Select 2-sided Printing for 1-sided/2-sided/Booklet Printing on the Page Setup tab.
Page 296 Select 2-sided Printing from 1-sided/2-sided/Booklet Printing on the Page Setup tab. Uncheck the Automatic check box. 3. Select the layout Select the layout you want to use from the Page Layout list. 4. Specify the side to be stapled The best Binding Location is selected automatically from the Orientation and Page Layout settings. To change the setting, select another stapling side from the Binding Location list.
Page 297: Overview Of The Printer Driver
Overview of the Printer Driver Canon IJ Printer Driver Opening Printer Driver's Setup Screen Canon IJ Status Monitor Instructions for Use (Printer Driver)
Page 298: Canon Ij Printer Driver
Canon IJ Printer Driver The Canon IJ printer driver (simply called printer driver below) is software that you install onto your computer so that it can communicate with the printer. The printer driver converts the print data created by your application software into data that your printer can understand, and sends the converted data to the printer.
Page 299: Opening Printer Driver's Setup Screen
Opening Printer Driver's Setup Screen You can display the printer driver's setup screen from your application software or by clicking the printer icon. Displaying the Printer Driver's Setup Screen from Your Application Software Perform this procedure to set up the print settings during printing. 1.
Page 300: Canon Ij Status Monitor
When Errors Occur The Canon IJ Status Monitor is automatically displayed if an error occurs (e.g., if the printer runs out of paper or if the ink is low). In such cases, take the appropriate action as described.
Page 301: Instructions For Use (Printer Driver)
Instructions for Use (Printer Driver) This printer driver is subject to the following restrictions. Keep the following points in mind when using the printer driver. Restrictions on the Printer Driver • With some applications, the Copies setting in the Page Setup tab of the printer driver may not be enabled.
Page 302 1. Open Word's Print dialog box. 2. Open the printer driver setup window, and on the Page Setup tab, set Page Size to the same paper size that you specified in Word. 3. Set Booklet Printing in Page Layout or 1-sided/2-sided/Booklet Printing according to your requirements.
Page 303: Maintenance Tab Description
Canon IJ Printer Assistant Tool or check the status of the printer. Maintenance and Preferences Canon IJ Printer Assistant Tool is started. You can perform printer maintenance or change the settings of the printer. Custom Settings Opens the Custom Settings dialog box.
Page 304 About Opens the About dialog box. The version of the printer driver, plus a copyright notice, can be checked. In addition, the language to be used can be switched. Custom Settings dialog box When you click Custom Settings, the Custom Settings dialog box is displayed. If necessary, switch between various modes of printer operation.
Page 305 Allow Google Analytics to send information To stop sending information, uncheck this check box. The check box appears only if a user with administrator privileges is logged on. If information is not provided, the check box will not appear.
Page 306: Canon Ij Status Monitor Description
Canon IJ Status Monitor Description The Canon IJ Status Monitor displays the printer status and the printing progress. The printer status is shown by the icons and messages in the status monitor. Features of the Canon IJ Status Monitor The Canon IJ Status Monitor has the following functions: Onscreen display of printer status The status monitor displays the printer status in real-time.
Page 307 (the disclosure triangle) to display a pictorial representation of the estimated usage amount in the maintenance cartridge. Option Menu If a printer message appears, select Enable Status Monitor to start the Canon IJ Status Monitor. Select Enable Status Monitor to use the following commands: Always Display Current Job Displays the Canon IJ Status Monitor whenever a document is being printed.
Page 308 Display Warning Automatically When a Low Ink Warning Occurs Starts the Canon IJ Status Monitor window as a pop-up, and displays it in front of the other windows when a low ink warning occurs. When a Maintenance Cartridge Warning Occurs When a maintenance cartridge remaining space warning occurs, the Canon IJ status monitor starts automatically and appears in front of all other windows.
Page 309: Updating The Driver
1. Start the uninstaller Select Control Panel -> Programs -> Programs and Features. From the program list, select "Canon XXX Printer Driver" (where "XXX" is your model name) and then click Uninstall. The confirmation window for uninstalling the model appears.
Page 310 2. Perform the uninstaller Click Start. When the confirmation message appears, click Yes. When all the files have been deleted, click Complete. The deletion of the Driver is complete.
Page 311: Printing From Application Software (Macos Airprint)
Printing from Application Software (macOS AirPrint) Printing Basic Printing on Postcards Adding Printer How to Open Printer Settings Screen Displaying the Printing Status Screen Deleting the Undesired Print Job Removing Printer That Is No Longer Required from List of Printers...
Page 312: Printing
Printing This printer is compatible with the macOS standard printing system (AirPrint). You can start printing right away after connecting this printer to your Mac without installing any special software. Checking Your Environment First, check your environment. • AirPrint Operation Environment •...
Page 313 6. Check print settings Set items such as Paper Size to the appropriate size, as well as Media Type from Media & Quality. Set Double-sided to Off if you are not printing on both sides of the paper.
Page 314 Important • An error may occur if the paper size set in the print dialog is different from the paper size registered on the printer. Select the correct items on the print dialog and the printer that correspond to the paper being printed. •...
Page 315 Load the envelope in vertically with the address side facing up so that the folded flap of the envelope will be faced down on the right side.
Page 316: Printing On Postcards
Printing on Postcards This section describes the procedure for printing on postcards. Load postcards in printer 2. Select paper size and paper type from the printer Register Hagaki for paper size from the printer operation panel. Also, register Ink Jet Hagaki, Hagaki K, or Hagaki for paper type, according to your purpose. When you print on the address side, register Hagaki.
Page 317: Adding Printer
Adding Printer This section describes the procedure for adding a printer to your Mac. To re-add a printer that was deleted, open System Settings -> Printers & Scanners, click Add Printer, Scanner or Fax..., and then perform the procedure described below. If your printer is connected via USB, and you connect the USB cable to a Mac, the printer is automatically added.
Page 318: How To Open Printer Settings Screen
How to Open Printer Settings Screen The settings screen of the printer can be displayed from your application software. Opening the Page Setup Dialog Use this procedure to set the page (paper) settings before printing. 1. Select Page Setup... from the File menu of the application software The Page Setup dialog opens.
Page 319: Displaying The Printing Status Screen
Displaying the Printing Status Screen Check the print progress according to the following procedure: 1. Launch the printing status screen • If the print data has been sent to the printer • The printing status screen opens automatically. To display the printing status screen, click the printer icon displayed on the Dock.
Page 320: Deleting The Undesired Print Job
Deleting the Undesired Print Job If the printer does not start printing, canceled or failed print job data may be remaining. Delete unnecessary print jobs from the print status check screen. 1. Open System Settings, and select Printers & Scanners 2.
Page 321: Removing Printer That Is No Longer Required From List Of Printers
Removing Printer That Is No Longer Required from List of Printers The printer that is no longer in use can be removed from the list of printers. Before removing the printer, remove the cable connecting the printer and PC. You cannot remove the printer if you are not logged on as the administrator. For information about an administrative user, see Users &...
Page 322: Printing Using Canon Application Software
Printing Using Canon Application Software Easy-PhotoPrint Editor Guide...
Page 323: Printing From Smartphone/Tablet
Printing from Smartphone/Tablet Printing from iPhone/iPad/iPod touch (iOS) Printing from Smartphone/Tablet (Android)
Page 324: Printing Hagaki And Envelopes
Printing Hagaki and Envelopes For Windows Printing on Postcards Setting Up Envelope Printing For macOS Printing on Postcards...
Page 325 Printing on Postcards Load postcard on the printer 2. Open the printer driver setup window 3. Select commonly used settings Display the Basic Settings tab, and for Profiles, select Standard. 4. Select the paper size For Printer Paper Size, select Hagaki 100x148mm or Hagaki 2 200x148mm. Important •...
Page 326 Printing on Postcards This section describes the procedure for printing on postcards. Load postcards in printer 2. Select paper size and paper type from the printer Register Hagaki for paper size from the printer operation panel. Also, register Ink Jet Hagaki, Hagaki K, or Hagaki for paper type, according to your purpose. When you print on the address side, register Hagaki.
Page 327 To hide the guide messages, check the Do not show this message again check box. To show the guide again, click the View Printer Status button on the Maintenance tab, and start the Canon IJ Status Monitor. Then click Envelope Printing from Display Guide Message of the Option menu to enable the setting.
Page 328: Paper Settings
Paper Settings By registering the paper size and the media type, the message is displayed before printing starts when the paper size or the media type of the loaded paper differs from the paper settings. After loading paper • When you loading paper in the rear tray •...
Page 329 • When you insert the cassette • The screen to register the cassette paper information is displayed. If the page size on the touch screen matches the size of the paper loaded in the cassette, select Yes. If not, select Change to change the setting in accordance with the size of the loaded paper. Note •...
Page 330 When you start printing, a message is displayed. Check the message and select Next, and then choose one of the following. Print with the loaded paper. Select if you want to print on the paper loaded without changing the paper settings. For example, when the paper setting for printing is A5 and the paper information registered to the printer is A4, the printer starts printing on the paper loaded in the rear tray or in the cassette without changing the paper size setting for printing.
Page 331: Frequently Asked Questions
Frequently Asked Questions Top 6 Network Connection Setup Guide > List of Support Codes for Printer Errors > Network Communication Problems > Ink Does Not Come Out > Connecting with Wireless Direct > Printer Does Not Print Search by Category Error List of Support Codes for Printer Errors When Error Occurred...
Page 332 Printing What to Do When Paper Is Jammed Printer Does Not Print Resolving Print Quality Problems Blurry or Fuzzy Inaccurate or Bleeding Colors Lines Are Misaligned/Distorted Security / Other Set Up/Manage Security Searching Printer by IP Address or Host Name During Setup Failed to MP Drivers (Printer Driver) Installation (Windows) Updating MP Drivers (Printer Driver) in Network Environment (Windows) Perform Replace Ink in Print Head...
Page 333 Cannot Print Using AirPrint Printing (Copying) Stops Printer Does Not Pick Up or Feed the Paper/"No Paper" Error Automatic 2-sided Printing Problems Paper Does Not Feed from Paper Source Specified in Printer Driver (Windows) Printed Barcodes Are Not Recognized The Print Position Shifts Security / Other Printer Does Not Turn On Maintenance...
Page 334: Network Faq
Network FAQ Here are frequently asked questions on network. Select a connection method you are using, or you want to use. Wi-Fi Wireless Direct Wired LAN Wi-Fi Cannot Find Printer Cannot Find Printer on Network (Windows/macOS) Cannot Proceed Beyond Printer Connection Screen (Cannot Find Printer Connected via USB) Searching Printer by IP Address or Host Name During Setup Detect Same Printer Name Switching Printer's Connection to Network or Devices...
Page 335 Setting Up Using Smartphone/Tablet Cannot Print (Scan) from Smartphone/Tablet Downloading Canon PRINT Problems while Using Printer Message Appears on Computer During Setup Cannot Find Printer on Network (Windows/macOS) Wireless Direct Cannot Print or Connect Solve Network Troubles with The Printer's Diagnostic Functions...
Page 336 Printing Network Settings Checking Status Code Problems while Using Printer Message Appears on Computer During Setup Cannot Find Printer on Network (Windows/macOS)
Page 337: Network Communication Problems
Network Communication Problems Cannot Find Printer on Network (Windows/macOS) Wireless Router Problems Printer Settings/Smartphone/Tablet Troubles for Network...
Page 338: Cannot Find Printer On Network (Windows/Macos)
Cannot Find Printer on Network (Windows/macOS) Cannot Find Printer on Network Cannot Proceed Beyond Printer Connection Screen (Cannot Find Printer Connected via USB) Searching Printer by IP Address or Host Name During Setup...
Page 339: Cannot Find Printer On Network
Set Up Important • When you forget the administrator password of the printer, contact your nearest Canon service center. In Other Cases Than Above: If the printer suddenly stops working, even though you have not changed the settings of the device or network to which it is connected, or if you cannot find the printer during the setup process, check and solve the problem, using Wi-Fi Connection Assistant.
Page 340 Proceed once the network device such as router is ready for use. 2. Check if printer is turned on. If printer is not turned on, turn on the power. If the printer is on, turn it off and on again. Proceed once you complete checking the power status above.
Page 341 icon is displayed. icon indicates that the wireless router and the printer are not connected. Check the setting of printer. Reconsider the location of the wireless router and the printer in the next check. icon is displayed. "Easy wireless connect" is waiting for setup. Connect a device to the printer with the application on computer, smartphone or tablet.
Page 342 Make sure security software's firewall is off. Check 1 If your security software's firewall is on, a message may appear warning you that Canon software is attempting to access the network. If this warning message appears, set security software to always allow access.
Page 343 If your network name (SSID) contains characters other than single-byte alphanumeric characters, the connection is not established properly. Change the network (SSID) to use only single-byte alphanumeric characters. Solve network troubles with the printer's diagnostic functions. Check 3 See below. Solve Network Troubles with The Printer's Diagnostic Functions Related Topics Network Communication Problems...
Page 344: Cannot Proceed Beyond Printer Connection Screen (Cannot Find Printer Connected Via Usb)
Cannot Proceed Beyond Printer Connection Screen (Cannot Find Printer Connected via USB) If you cannot proceed beyond the Printer Connection screen, check the following. Make sure USB cable is securely plugged in to printer and computer. Check 1 Connect the printer and the computer using a USB cable as the illustration below. The USB port is located at the back of the printer.
Page 345 Important • When installing the MP Drivers (Printer Driver), make sure you select the correct printer name. • • For Windows: • To restart your computer, choose Restart instead of Shut down.
Page 346: Wireless Router Problems
Wireless Router Problems Network Key (Password) Unknown Checking Wireless Router SSID/Key Printer Cannot Be Used After Replacing Wireless Router or Changed Router Settings WPS (Router Button) Connection Privacy Separator/SSID Separator/Network Separation Function...
Page 347: Network Key (Password) Unknown
Network Key (Password) Unknown Diagnose and repair the network connections using Wi-Fi Connection Assistant. Download Wi-Fi Connection Assistant from the below page, and install it on your computer. Checking Printer Connection Status Using Wi-Fi Connection Assistant Refer to below in regard to starting up Wi-Fi Connection Assistant. •...
Page 348 Enter the Wi-Fi password configured on the wireless router. Either TKIP (basic encryption) or AES (secure encryption) is selected automatically as the dynamic encryption method. For details, see If WPA/WPA2/WPA3 Details Screen Appears. Note • This printer supports the following. WPA-PSK (WPA-Personal) WPA2-PSK (WPA2-Personal) WPA3-SAE (WPA3-Personal)
Page 349: Printer Cannot Be Used After Replacing Wireless Router Or Changed Router Settings
Printer Cannot Be Used After Replacing Wireless Router or Changed Router Settings When wireless router is replaced or router settings are changed, the network settings of your computer, smartphone/tablet or printer must be reconfigured according to the new wireless router. Check if your computer or smartphone/tablet can be connected to Internet Check 1 through the new wireless router.
Page 350 For more on setting up a wireless router, see the instruction manual provided with the wireless router or contact its manufacturer. Make sure the computer and the wireless router can communicate with each other under this setting. If filtering MAC addresses or IP addresses at wireless router, check Check 2 that MAC addresses or IP addresses for computer, network device, and printer are registered.
Page 351: Printer Settings/Smartphone/Tablet Troubles For Network
Printer Settings/Smartphone/Tablet Troubles for Network Solve Network Troubles with The Printer's Diagnostic Functions Checking Network Information of Printer Checking Status Code Printing Network Settings Restoring Printer's LAN Settings to Defaults Default Network Settings Connecting with Wireless Direct...
Page 352: Solve Network Troubles With The Printer's Diagnostic Functions
Solve Network Troubles with The Printer's Diagnostic Functions • If the printer and wireless router are connected or the printer and computer are connected by USB cable • but you cannot print: Change to Offline (Windows) • In other cases than above: •...
Page 353 Check that security software's firewall is off. Check 1 A message may appear warning you that Canon software is attempting to access the network. If this warning message appears, set the security software to always allow access. Quit the security software and make sure that the printer is recognized and ready to use. If so, the cause is the firewall setting.
Page 354 Are MP Drivers (Printer Driver) installed? (Windows) Check 4 If you are using Windows and MP Drivers (Printer Driver) are not installed, install it. Set Up The printer's Wi-Fi setting is disabled. (You can also check if the Wi-Fi icon does not appear on the printer's screen.) Enable the Wi-Fi setting in the printer's settings screen.
Page 355 Check status of printer and network device (e.g. wireless router) and Check 1 your computer/smartphone/tablet. Communication with a wireless router must be tuned to either the 2.4 GHz or 5 GHz frequency band. The network name (SSID) of the 2.4 GHz frequency band and the network name (SSID) of the 5 GHz frequency band cannot be used in combination.
Page 356 If problem occurs only when wireless router is in energy-saving Check 6 mode, turn off energy-saving mode of wireless router. If the problem seems to occur suddenly, it may be resolved by updating the wireless router firmware (e.g. update interval of a key, problems of DHCP update interval, etc.). For details, refer to the wireless router's instruction manual.
Page 357 The noise level is high and does not differ from the signal level due to various devices other than the printer. • If devices (microwave oven, external hard disk drive, and other USB 3.0 devices) that emit radio waves of the same frequency bandwidth as a wireless router is nearby, it may cause interference. Place the printer and the wireless router as far away from interference sources as possible.
Page 358 For macOS: Starting Up Wi-Fi Connection Assistant Cannot Communicate with Printer while It Is in Wireless Direct Check the following items Check power status of printer and other devices (e.g. computer/smartphone/ Check 1 tablet). Turn on the printer or devices. If the power is already turned on, cycle the power switch.
Page 359 To check the password specified for the printer, display it using the operation panel of the printer or print out the network settings information of the printer. • Display on the operation panel of the printer. • LAN settings • Print the network settings. •...
Page 360: Checking Network Information Of Printer
Printing Network Settings For Windows, you can check the network setting information on the computer screen. Canon Wi-Fi Connection Assistant Screen Checking Computer IP Address or MAC Address To check the IP Address or MAC Address of your computer, follow the instructions below.
Page 361 3. Click Details to check the IP Address. The IP Address of your computer appears. To check the MAC Address, click Hardware. Checking Communication Between the Computer, the Printer, and the wireless router Perform a ping test to check if communication is taking place. •...
Page 362 Checking Network Setting Information To check the printer's network settings information, display it using the operation panel of the printer or print it out. Display on the operation panel. LAN settings Print the network settings. Printing Network Settings...
Page 363: Printing Network Settings
Printing Network Settings Use the operation panel to print the printer's current network settings. Important • The network settings printout contains important information about your network. Handle it with care. • 1. Check that printer is turned on. Load five or more sheets of A4 or Letter-sized plain paper. 3.
Page 364 Network Diagnostics Network diagnostics – Diagnostic Result Diagnostic result XXXXXXXX Result Codes Result codes XXXXXXXX Result Code Details Result code details Solve Network Troubles with The Printer's Diagnostic Functions to check details on the diagnostic result and re- sult codes. Wireless LAN Wireless LAN Enable/Disable...
Page 365 3-2-20 Stateless Address2 Stateless address 2 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-2-21 Stateless Prefix Stateless prefix length Length2 3-2-22 Stateless Address3 Stateless address 3 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-2-23 Stateless Prefix Stateless prefix length Length3 3-2-24 Stateless Address4 Stateless address 4 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-2-25 Stateless Prefix Stateless prefix length Length4 3-2-26...
Page 366 3-3-8 TCP/IPv4 TCP/IPv4 Enable 3-3-9 IP Address IP address XXX.XXX.XXX.XXX 3-3-10 Subnet Mask Subnet mask XXX.XXX.XXX.XXX 3-3-11 Default Gateway Default gateway XXX.XXX.XXX.XXX 3-3-12 TCP/IPv6 TCP/IPv6 Enable/Disable 3-3-13 Link Local Address Link local address XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-3-14 Link Local Prefix Link local prefix length Length 3-3-15 IPsec...
Page 367 XXXX:XXXX:XXXX:XXXX 4-13 Stateless Prefix Stateless prefix length Length2 4-14 Stateless Address3 Stateless address 3 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 4-15 Stateless Prefix Stateless prefix length Length3 4-16 Stateless Address4 Stateless address 4 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 4-17 Stateless Prefix Stateless prefix length Length4 4-18 Default Gateway1 Default gateway 1 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX...
Page 368 5-11 LLMNR LLMNR setting Enable/Disable 5-12 SNMP SNMP setting Enable/Disable 5-14 DNS Server Obtain DNS server ad- Auto/Manual dress automatically 5-15 Primary Server Primary server address XXX.XXX.XXX.XXX 5-16 Secondary Server Secondary server ad- XXX.XXX.XXX.XXX dress 5-17 Proxy Server Proxy server setting Enable/Disable 5-18 Proxy Address...
Page 369 Prohibit use of USB Prohibit use of USB de- Enable/Disable connection vice Prohibit use of external Prohibit use as USB Enable/Disable USB devices storage device Network Network function – 9-3-1 Communication policy Communication opera- – tional policy Always verify signa- Always verify signa- Enable/Disable tures for SMB/WebDAV...
Page 370 Restrict SNMP port Restrict SNMP port Enable/Disable Authentication Authentication function – 9-4-1 Authentication policy Authentication opera- – tional policy Prohibit guest users Prohibit guest users Enable/Disable from using the printer from using the device Force auto logout Force auto logout Enable/Disable Logout period Time Until Logout...
Page 371 Require use of at least Force use of at least 1 Enable/Disable 1 number digit Require use of at least Force use of at least 1 Enable/Disable 1 symbol symbol 9-4-4 Lockout policy Lockout Policy – Enable lockout Enable lockout Enable/Disable Lockout threshold Lockout Threshold...
Page 372 9-7-3 Storage Storage policy – Force complete dele- Force complete dele- Enable/Disable tion of data tion of data ("XX" represents alphanumeric characters.)
Page 373: Restoring Printer's Lan Settings To Defaults
Restoring Printer's LAN Settings to Defaults Important • Initialization erases all network settings on the printer, making printing operation from a computer over • a network impossible. To use the printer over a network again after restoring it to the factory defaults, refer to Setup Guide and redo setup.
Page 374: Default Network Settings
Set printer name* XXXXXXXXXXXXXXX Enable/disable IPv6 Enable Enable/disable WSD Enable Timeout settings (WSD) 15 minutes Enable/disable Bonjour Enable Bonjour service name* Canon ModelName LPR protocol settings Enable RAW protocol Enable LLMNR Enable Wi-Fi DRX settings Enable Wired LAN DRX settings Enable ("XX"...
Page 375 Network name (SSID) DIRECT-abXX-ModelName *1 *2 Password YYYYYYYYYY *3 Wi-Fi security WPA2-PSK (AES) Connection request confirmation Displayed 2.4GHz/5GHz Switch 2.4GHz *1 Default value depends on printer. To check value, use operation panel. *2 "ab" is specified at random and "XX" represents last two digits of printer's MAC address. (The value is specified when the printer is turned on for the first time.) *3 The password is specified automatically when the printer is turned on for the first time.
Page 376: Connecting With Wireless Direct
Connecting with Wireless Direct You can connect devices (e.g. computer, smartphone, or tablet) to the printer by two methods below. • Wireless connection (connecting devices via a wireless router) • • Direct wireless connection (connecting devices directly without a wireless router) •...
Page 377 Note • If User management settings is enabled, the user selection screen is displayed before the • HOME screen is displayed. 3. Select Printer settings. 4. Select LAN settings. 5. Select Wireless Direct. 6. Select Connect to smartphone. 7. Select iPhone/iPad to connect with an iPhone/iPad, Android device to connect with an Android device, and Others to connect with other device.
Page 378 • If the QR code cannot be read, select (Back) in the screen displayed QR code and connect the printer from Connect to smartphone > Others. • Others • 1. Select Next. Network name (SSID) and Password are displayed. Note •...
Page 379 Note • If User management settings is enabled, the user selection screen is displayed before the • HOME screen is displayed. 3. Select LAN settings. 4. Select Wireless Direct. Note • To change the Wireless Direct settings, you need to enable Wireless Direct in advance. •...
Page 380 3. Enter the new password (10 characters). Change using the keyboard that appears. 4. When you have finished making changes, select OK. ◦ To set automatically ◦ 1. Select Auto update. 2. Select Yes. You can check the updated setting. Note •...
Page 381: Problems While Printing (Scanning) From Smartphone/Tablet
Problems While Printing (Scanning) from Smartphone/Tablet Cannot Print (Scan) from Smartphone/Tablet...
Page 382: Cannot Print (Scan) From Smartphone/Tablet
Cannot Print (Scan) from Smartphone/Tablet If you cannot Print (Scan) from your smartphone/tablet, it is possible that your smartphone/tablet cannot communicate with the printer. Check the cause of your problem according to the connection method. Cannot Communicate with Printer via Wi-Fi Cannot Connect to Printer through Wireless Direct Note •...
Page 383 To check the current network settings of the printer, print out the network settings information or use the operation panel to display it. ◦ Display on the operation panel of the printer. ◦ LAN settings ◦ Print the network settings. ◦...
Page 384 Note • If the web page cannot be printed using an Android device, it may be possible to print it by changing • Wireless Direct connection. Connecting with Wireless Direct Cannot Communicate with Printer while It Is in Wireless Direct If your smartphone/tablet cannot communicate with the printer in the Wireless Direct, check the following.
Page 385 LAN settings • Print the network settings. • Printing Network Settings Check that printer is not placed too far away from device. Check 6 If the distance between the printer and the device is too far, wireless communication becomes poor. Place the printer and the device close to each other.
Page 386: Printing Problems
Printing Problems Printer Does Not Print Printer Does Not Pick Up or Feed the Paper/"No Paper" Error Resolving Print Quality Problems Change to Offline (Windows) No Ink Level Appears in Canon IJ Status Monitor (Windows)
Page 387: Printer Does Not Print
Printer Does Not Print Make sure printer is turned on. Check 1 If not, make sure the printer is securely plugged in and press ON button to turn on. The ON lamp flashes while the printer is initializing. Wait until the ON lamp stops flashing and remains lit. Note •...
Page 388 • For Windows: • Make sure "Canon XXX series" (where "XXX" is your printer's name) is selected in the Print dialog box. Note • If multiple printers are registered to your computer, set your printer as Let Windows manage my •...
Page 389 If the printer does not start printing after a certain period of time, select On for Prevention of Print Data Loss on the Print Options dialog box. For details, refer to Page Setup Tab Description. Important • Selecting On for Prevention of Print Data Loss may reduce print quality. •...
Page 390: Printer Does Not Pick Up Or Feed The Paper/"No Paper" Error
Printer Does Not Pick Up or Feed the Paper/"No Paper" Error Check the printer is placed on the right spot. Check 1 Place the printer on a flat table or similar platform. Make sure paper is loaded in the specified rear tray or cassette. Check 2 Loading Paper When loading paper, consider the following.
Page 391 If a foreign object is inside the rear tray, remove it according to the following procedure. 1. Turn off the power of the printer and disconnect the power plug from the outlet. 2. Fold one A4 sheet in half and insert it horizontally into the rear tray. Insert the paper so that your hand does not directly touch the part in the center of the rear tray when removing the foreign object.
Page 392 Check 10 Rear View for the positions of the transport unit. If the measures above do not solve the problem, contact your nearest Canon service center to request a repair. Important • Do not tilt the printer when moving it since the ink may leak out.
Page 393: Resolving Print Quality Problems
Resolving Print Quality Problems If the print results are unsatisfactory due to white streaks, misaligned/distorted lines, or uneven colors, check the paper and print quality settings first. Make sure that Print target for plain paper is set to Text and photos. Check 1 Select (Setup) on HOME screen >...
Page 394 Ink Does Not Come Blurry or Fuzzy Inaccurate or Streaks Bleeding Colors Printed in Black and Lines Are Paper Is Smudged/ Ink Blots/Paper Curl White Misaligned/Distorted Printed Surface Is Scratched...
Page 395 Vertical Line Next to Images Incomplete/ Lines Incomplete or Back of Paper Is Image Cannot Complete Missing (Windows) Smudged Printing Uneven Colors Streaked Colors Printed Barcodes The Print Position Are Not Recognized Shifts Note • Depending on the specifications of the printer you are using, some of the features described •...
Page 396: Ink Does Not Come Out/Blurry Or Fuzzy/Inaccurate Or Bleeding Colors/Streaks
Ink Does Not Come Out/Blurry or Fuzzy/Inaccurate or Bleeding Colors/Streaks Ink Does Not Come Out Blurry or Fuzzy Inaccurate or Bleeding Streaks Colors Note • If printouts are blank, black does not print, is faint, or has a blue or red tint, refer to this web page. •...
Page 397 Clean the print head deeply. Step 4 After cleaning the print head deeply, print the nozzle check pattern and check the result. • From the printer • Deep Print Head Cleaning If it does not improve, turn off the printer, wait for more than 24 hours without unplugging the power supply, and go to the next step. Clean the print head deeply again.
Page 398: Printed In Black And White
Printed in Black and White If the ink used by the printer is set to Black only, printouts from a computer etc. will be printed in black and white. To print in color, select (Setup) on HOME screen > Printer settings > Other printer settings, and set Force ink tank selection to All ink tanks.
Page 399: Lines Are Misaligned/Distorted
Lines Are Misaligned/Distorted Note • For the case of misaligned or distortion, refer to this web page. • Check paper and print quality settings. Check 1 Resolving Print Quality Problems Perform print head alignment. Check 2 If printed lines are misaligned/distorted or print results are otherwise unsatisfactory, adjust the print head position.
Page 400: Paper Is Smudged/Printed Surface Is Scratched/Ink Blots/Paper Curl
Make sure you are using the right paper for what you are printing. To print data with high color saturation such as photographs or images with dark colors, we recommend that you use Photo Paper Plus Glossy II or other Canon specialty paper. Supported Media Types Correct curl before loading paper.
Page 401 1. Roll up paper in opposite direction to paper curl as shown below. 2. Check that paper is now flat. We recommend printing curl-corrected paper one sheet at a time. Note • Depending on paper type, the paper may smudge or may not feed properly even if it is not curled inward. •...
Page 402 Adjust the amount of ink. Check 5 Depending on paper type, if you touch the printed surface right after printing, the printing may be scratched or ink may adhere to the object you touched. In that case, reduce the amount of ink. Print settings Select (Setup) on HOME screen >...
Page 403 Note • If you specify the administrator password, enter the password. 3. Select Printer settings. 4. Select Ink drying wait time. • For macOS: • Set the waiting time using Remote UI. Opening Remote UI for Maintenance...
Page 404: Vertical Line Next To Image
Vertical Line Next to Image Is loaded paper size correct? Check If the loaded paper is larger than the size you specified, vertical lines (A) may appear in the left margin or the both margins. Set the paper size to match the loaded paper. Resolving Print Quality Problems Note •...
Page 405: Images Incomplete/Cannot Complete Printing
Images Incomplete/Cannot Complete Printing If the printing of photos, images, stops in the middle of printing and cannot be printed to the end, check the following items. Select setting not to compress printing data (Windows). Check 1 If you select the setting not to compress the printing data with an application software you are using, the printing result may be improved.
Page 406: Lines Incomplete Or Missing (Windows)
Lines Incomplete or Missing (Windows) Are you using Page Layout Printing or Binding Margin function? Check 1 When the Page Layout Printing or Binding margin function is in use, thin lines may not be printed. Try thickening the lines in the document. Are you trying to print a large data file? (Windows) Check 2 If you are trying to print a large data file, printing may not be performed properly due to missing print data.
Page 407: Back Of Paper Is Smudged
Back of Paper Is Smudged Check paper and print quality settings. Check 1 Resolving Print Quality Problems Perform bottom plate cleaning to clean inside of printer. Check 2 Cleaning Inside the Printer (Bottom Plate Cleaning) Note • During 2-sided printing, or too much printing, ink may stain the inside of the printer. •...
Page 408: Uneven Or Streaked Colors
Uneven or Streaked Colors Increase print quality and try printing again. Check 1 Increasing the print quality using operation panel of the printer or from computer may improve the print result. Perform print head alignment. Check 2 Aligning the Print Head Note •...
Page 409: Change To Offline (Windows)
2. Click the name of printer you want to configure. 3. Click Printing preferences. Printing preferences window opens. 4. Click Maintenance sheet. 5. Click View Printer Status. The Canon IJ Status Monitor window is displayed. 6. Click Display Print Queue of the Canon IJ Status Monitor window.
Page 410 The Print Queue window is displayed. 7. Click Printer menu in the window displayed. Make sure Use Printer Offline is not selected. If it is selected, click Use Printer Offline to deselect it. Confirm that the offline mode has been disabled. If the printer is still offline, proceed to the next step. For Windows 10: 1.
Page 411: Mechanical Problems
Mechanical Problems Printer Does Not Turn On Printer Turns Off Unexpectedly or Repeatedly USB Connection Problems Switching Printer's Connection to Network or Devices Wrong Language Appears in LCD...
Page 412: Printer Does Not Turn On
Check 2 Unplug printer, leave it for at least 2 minutes, and then plug it back in and turn Check 3 on again. If this does not solve the problem, contact your nearest Canon service center to request a repair.
Page 413: Printer Turns Off Unexpectedly Or Repeatedly
Printer Turns Off Unexpectedly or Repeatedly If printer is set to turn off automatically after a certain time, disable this setting. Check If you have set the printer to turn off automatically after a specified time, the power will shut off by itself once that time has elapsed.
Page 414: Usb Connection Problems
USB Connection Problems If the printer connected to the computer via USB is not recognized, check the following items. USB Connection Not Recognized The following problems may occur even though the USB connection is recognized. • Printing (scanning) is slow. •...
Page 415 Check that Enable bidirectional support is selected in Ports sheet of Check 3 Printer properties dialog box (Windows). If not, select it to enable bidirectional support. Opening Printer Driver's Setup Screen Initialize the printer settings. Check 4 Select (Setup) on HOME screen > Printer settings > Reset settings > Reset all. Reset settings After initializing the printer settings, redo setup.
Page 416: Wrong Language Appears In Lcd
Wrong Language Appears in LCD Follow the instructions below to select your language. 1. Select (HOME) button. 2. Select (Setup). Using Touch Screen Note • If User management settings is enabled, the user selection screen is displayed before the • HOME screen is displayed.
Page 417: Installation And Download Problems
Installation and Download Problems Failed to MP Drivers (Printer Driver) Installation (Windows) Cannot Proceed Beyond Printer Connection Screen (Cannot Find Printer Connected via USB) Updating MP Drivers (Printer Driver) in Network Environment (Windows) Disable Function to Send Usage Information of Printer...
Page 418: Failed To Mp Drivers (Printer Driver) Installation (Windows)
Select Settings > Apps. For Windows 8.1 / Windows 7: Select Control Panel > Programs and Features. 2. Check if there is "Canon XXX series Driver" or "Canon XXX series Printer Driver" you want to install in list. "XXX" is the model name.
Page 419 Cannot Proceed Beyond Printer Connection Screen (Cannot Find Printer Connected via USB) If you cannot proceed beyond the Printer Connection screen, check the following. Make sure USB cable is securely plugged in to printer and computer. Check 1 Connect the printer and the computer using a USB cable as the illustration below. The USB port is located at the back of the printer.
Page 420 Important • When installing the MP Drivers (Printer Driver), make sure you select the correct printer name. • • For Windows: • To restart your computer, choose Restart instead of Shut down.
Page 421: Updating Mp Drivers (Printer Driver) In Network Environment (Windows)
Download the latest MP Drivers (Printer Driver) in advance. Download the latest MP Drivers (Printer Driver) for your model on the download page of the Canon website. After the download is completed, overwrite and install the new version of the MP Drivers (Printer Driver) according to the specified installation procedure.
Page 422: Errors And Messages
Errors and Messages When Error Occurred Message Is Displayed...
Page 423: When Error Occurred
When Error Occurred If an error occurs while printing, for example, if the paper runs out or jams, a troubleshooting message is displayed automatically. For some errors, a support code (error number) is also displayed. Take the appropriate action described in the message. When a Support Code and a Message are displayed on the Computer Screen (Windows):...
Page 424 When a Support Code and a Message are displayed on the Printer's Touch Screen: For details on how to resolve errors with Support Codes, see List of Support Codes for Printer Errors. For details on how to resolve errors without Support Codes, see Message Is Displayed.
Page 425: Message Is Displayed
Message Is Displayed This section describes some of the messages. If a message is displayed on the printer's touch screen, see below. Message Is Displayed on Printer's Touch Screen If a message is displayed on the computer, see below. Error Regarding Automatic 2-sided Printing Is Displayed Error Regarding Power Cord Being Unplugged Is Displayed (Windows) Writing Error/Output Error/Communication Error (Windows) Other Error Messages (Windows)
Page 426 If you are using a USB cable, make sure it is securely connected to both the printer and the computer. When the USB cable is securely plugged in, check the following: • If you are using a relay device such as a USB hub, disconnect it, connect the printer directly to the computer, and retry the printing.
Page 427 Refer to Updating the Driver to uninstall unnecessary drivers and install the latest drivers. • "Could not print Application name - File name" • Try printing again once the current job is complete.
Page 428: Repairing Your Printer
Repairing Your Printer This section describes how to transport the printer for repairing it. Important • You cannot take ink out of ink tanks. • • Make sure the tank caps of ink tanks are closed securely. If the tank caps are open, close the tank caps •...
Page 429 If the power is on, press the ON button to turn off the printer. Turning the Printer On and Off Important • Do not unplug the printer while the ON lamp is lit or flashing. It may cause malfunction or damage to the printer, making the printer unable to print.
Page 430 5. To close the top cover, hold it up once, then take it down gently. Go to Packing Printer. Packing Printer 1. Retract paper output tray. 2. Retract paper support, and then close it. 3. Unplug cable and power cord. 4.
Page 431 6. Pack printer in box. Attach the protective material to the printer to pack it securely in the box. Important • Carry the printer as shown in the illustration below. If you hold the cassette when carrying, the • cassette may come off from the printer.
Page 432 When Error Occurred If an error occurs while printing, for example, if the paper runs out or jams, a troubleshooting message is displayed automatically. For some errors, a support code (error number) is also displayed. Take the appropriate action described in the message. When a Support Code and a Message are displayed on the Computer Screen (Windows):...
Page 433 When a Support Code and a Message are displayed on the Printer's Touch Screen: For details on how to resolve errors with Support Codes, see List of Support Codes for Printer Errors. For details on how to resolve errors without Support Codes, see Message Is Displayed.
Page 434: List Of Support Codes For Printer Errors
List of Support Codes for Printer Errors Support codes are displayed on the printer's touch screen and your computer screen when errors occur. A "support code" is an error number, and is displayed along with an error message. When an error occurs, check the support code and take the appropriate action in response. Support Codes Displayed on Printer's Touch Screen and Computer Screen •...
Page 435 • 7000 to 7ZZZ • 7500 7600 7700 7800 • A000 to ZZZZ • B506 B508 B509 C000 C100 C101 Note • If no support code is displayed but the paper is not fed or output normally, see What to Do If Paper Is Not Fed/Output Normally.
Page 436: What To Do When Paper Is Jammed
What to Do When Paper Is Jammed If a paper jam occurs during printing (support code 1300/1303/1304/1313 is displayed), follow the procedure below. Note • If the paper is not jammed (no support code displayed) but the paper is not fed or output normally, see What to Do If Paper Is Not Fed/Output Normally.
Page 437 Retract the paper output tray, and then check if the jammed paper is visible in the feed slot of the cassette. Removing Jammed Paper through Feed Slot of Cassette If the jammed paper is not visible in the paper output slot or the feed slot. Check 6 Removing Jammed Paper inside Printer Removing Jammed Paper through Paper Output Slot...
Page 438 If the measures above do not solve the problem, a bit of paper may remain in the printer. See Removing Jammed Paper inside Printer. Removing Jammed Paper through Feed Slot of Rear Tray 1. Hold jammed paper firmly with both hands and pull it out slowly. Slowly pull out the paper so as not to tear it.
Page 439 Removing Jammed Paper through Feed Slot of Cassette 1. Hold jammed paper firmly with both hands and pull it out slowly. Slowly pull out the paper so as not to tear it. Note • If the paper cannot be pulled out or is torn, detach the rear cover and remove the jammed paper •...
Page 440: Removing Jammed Paper Inside Printer
Removing Jammed Paper inside Printer 1. Press printer's Stop button. 2. Turn off printer and unplug it. 3. Open top cover. Important • Do not touch the clear film (A), white belt (B), or tubes (C). • If you soil or scratch this part by touching it with paper or your hand, it could damage the printer. 4.
Page 441 5. Hold jammed paper firmly with both hands. If the paper is rolled up, pull it out and grasp the edges of the paper.
Page 442 6. Slowly pull out jammed paper so as not to tear it. Pull out the paper at an angle of about 45 degrees. 7. Make sure all jammed paper is removed. If the paper tears when you pull out it, a bit of paper may remain in the printer. Check the following and remove any remaining paper.
Page 443 Note • If you are unable to remove the jammed paper, detach the rear cover and remove the jammed • paper from the rear side. Removing Jammed Paper from Rear Side 8. Close top cover. To close the top cover, lift it up slightly and then lower it gently. 9.
Page 444 Loading Photo Paper / Plain Paper in Rear Tray Loading Envelopes / Medicine Envelopes / Delivery Slips in Rear Tray Loading Plain Paper / Delivery Slips in Cassette Loading Medicine Envelopes in Cassette Note • Make sure you are using suitable paper and loading it correctly. •...
Page 445: Removing Jammed Paper From Rear Side
Removing Jammed Paper from Rear Side 1. Press printer's Stop button. 2. Turn off printer and unplug it. 3. Retract rear tray and paper output tray. 4. Turn printer so that rear side of printer faces toward you. Important • When changing the orientation of the printer, do not turn the printer upside down or tilt it. The ink may leak out.
Page 446 6. Hold jammed paper firmly with both hands and pull it out slowly. If the paper is rolled up, pull it out and grasp the edges of the paper. Note • Do not touch the inner parts of the printer. If you are unable to remove the jammed paper, follow the steps below to detach the transport unit and then remove the paper.
Page 447 2. Slowly pull out jammed paper. Note • Do not touch the inner parts of the printer. 3. Make sure all jammed paper is removed. 4. If parts (A) are raised, tip them toward you. Important • If you replace the transport unit without lowering parts (A) toward you, it could damage the printer.
Page 448 5. Replace transport unit. Insert the transport unit until it reaches the back of the printer. 7. Attach rear cover.
Page 449 • If 1300 error recurs, check the feed slot of the rear tray again. If a foreign object is in the rear tray, refer to in What to Do If Paper Is Not Fed/Output Normally and take appropriate action. Check 1 If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
Page 450 Important • Do not tilt the printer when moving it since the ink may leak out. • When transporting the printer for repairing it, see Repairing Your Printer.
Page 451 1000 Cause Possible causes include the following. • There is no paper in the rear tray. • Paper is not loaded in the rear tray properly. • There are any foreign objects in the rear tray. What to Do • After loading the paper in the rear tray correctly, follow the messages displayed on the printer's touch •...
Page 452 1007 Cause Possible causes include the following. • There is no paper in the cassette 1. • Paper is not loaded in the cassette 1 properly. What to Do After loading the paper in the cassette 1 correctly, follow the messages displayed on the printer's touch screen.
Page 453 1008 Cause Possible causes include the following. • There is no paper in the cassette 2. • Paper is not loaded in the cassette 2 properly. What to Do After loading the paper in the cassette 2 correctly, follow the messages displayed on the printer's touch screen.
Page 454 1200 Cause Top cover is open. What to Do Close the top cover and wait for a while. Always close the top cover after opening it for ink refilling or any other reason.
Page 455 What to Do Turn off the printer and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair. Important • Do not tilt the printer when moving it since the ink may leak out.
Page 456 1496 Cause The maintenance cartridge may not be installed properly or may not be compatible with this printer. What to Do Remove the maintenance cartridge, and then reinstall it correctly. Refer to Replacing the Maintenance Cartridge for details on removing and installing the maintenance cartridge.
Page 457: Shipping Tape Etc. Are Still Attached (15A3)
Shipping Tape etc. Are Still Attached (15A3) Cause Tape for securing print head holder during transportation may still be attached. What to Do Open the top cover and make sure the tape for securing the print head holder during transportation has been removed.
Page 458 1723 Cause The maintenance cartridge is not installed. What to Do Install the maintenance cartridge. Refer to Replacing the Maintenance Cartridge for details on installing the maintenance cartridge.
Page 459 1724 Cause The currently installed maintenance cartridge cannot be used. This printer cannot use maintenance cartridges that have been installed in other printers. What to Do Replace with a new maintenance cartridge. Replacing the Maintenance Cartridge...
Page 460 1725 Cause The maintenance cartridge may not be installed properly or may not be compatible with this printer. What to Do Remove the maintenance cartridge, and then reinstall it correctly. Refer to Replacing the Maintenance Cartridge for details on removing and installing the maintenance cartridge.
Page 461 1726 Cause The maintenance cartridge is full. What to Do Replace the maintenance cartridge. Replacing the Maintenance Cartridge The condition of the maintenance cartridge when this error is displayed will depend on where and how the printer is used. When this message is displayed, you must replace the maintenance cartridge.
Page 462 1727 Cause The maintenance cartridge is almost full. What to Do The printer will not be able to print with a full maintenance cartridge. Tap the printer's OK button to cancel the error and then prepare a new maintenance cartridge. For details on the maintenance cartridge, see Replacing the Maintenance Cartridge.
Page 463: Cassette Is Not Installed (1876)
Cassette Is Not Installed (1876) Cause Possible causes include the following. • The cassette 1 is not installed. • The cassette 1 is not pushed all the way into the printer. What to Do After loading the paper in the cassette 1 and installing the cassette in the printer, follow the messages displayed on the printer's touch screen.
Page 464 2113 Cause An incompatible print setting combination has been specified for paper loaded in the rear tray, cassette 1 or cassette 2. Note • To disable notifications for this error, disable the function to detect paper setting mismatch. What to Do To specify the appropriate print settings for the paper loaded in the printer and retry printing, follow the steps below.
Page 465 • When using paper from the cassette: • 4. Check paper information (paper size and media type). The paper information is used to specify the print settings in step 5. • When using paper from the rear tray: • Check the paper information (paper size and media type) and select Yes.
Page 466 • When using paper from the cassette: • Check the paper information (paper size and media type) and select Yes. 5. Redo printing. Note • For the proper combination of paper size and media type, see below. • Paper Settings on the Printer Driver and the Printer (Paper Size) Paper Settings on the Printer Driver and the Printer (Media Type) Other Measures Load paper specified in print settings...
Page 467 2. Select Replace the paper and print. 3. Load paper specified in print settings into rear tray / cassette. • When changing the paper in the rear tray: • • When changing the paper in the cassette: •...
Page 468 4. Check paper information (paper size and media type). • When the paper in the rear tray is changed: • Confirm that the paper information displayed matches the print settings, and then select Yes. • When the paper in the cassette is changed: •...
Page 469 2. Select Print with the loaded paper.. Note • Depending on your printer's settings, Print with the loaded paper. may not be displayed. Disable notifications for 2113 error To disable the function to detect paper setting mismatch, follow the steps below. 1.
Page 470 3. Select Detect paper setting mismatch. 4. Select Disable.
Page 471 2114 Cause An incompatible print setting combination has been specified for the paper loaded in the rear tray. Note • To disable notifications for this error, disable the function to detect paper setting mismatch. What to Do To specify the appropriate print settings for the paper loaded in the rear tray and retry printing, follow the steps below.
Page 472 4. Check paper information (paper size and media type). The paper information is used to specify the print settings in step 5. Check the paper information (paper size and media type) and select Yes. 5. Redo printing. Note • For the proper combination of paper size and media type, see below. •...
Page 473 Other Measures Load paper specified in print settings To replace the paper in the rear tray with paper suitable for the print settings and continue printing, follow the steps below. 1. Check print settings, and select Next. 2. Select Replace the paper and print. 3.
Page 474 4. Check paper information (paper size and media type). Confirm that the paper information displayed matches the print settings, and then select Yes. Print without changing paper and print settings For example, to continue printing with a mismatch between the paper loaded in the rear tray and the paper information registered in the printer, follow the steps below.
Page 475 2. Select Print with the loaded paper.. Note • Depending on your printer's settings, Print with the loaded paper. may not be displayed. Disable notifications for 2114 error To disable the function to detect paper setting mismatch, follow the steps below. 1.
Page 476 3. Select Detect paper setting mismatch. 4. Select Disable.
Page 477 An internal part will need replacing soon. What to Do Select OK on the printer's touch screen to cancel the error. You cannot replace the internal parts of the printer yourself. Contact your nearest Canon service center to request a repair as soon as possible. Important •...
Page 478 3252 Cause The maintenance cartridge is almost full. What to Do The printer will not be able to print with a full maintenance cartridge. Tap the printer's OK button to clear the error message.
Page 479 4103 Cause Cannot perform printing with current print settings. What to Do Press the printer's Stop button to cancel printing. Change the print settings specified when printing and retry printing. Important • B6 Half size paper does not support 2-sided printing.
Page 480 If you soil or scratch this part by touching it with paper or your hand, it could damage the printer. Turn the printer back on. If this does not solve the problem, contact your nearest Canon service center to request a repair. Important •...
Page 481 2. Wait about 10 minutes and then plug in printer again and turn it back on. 3. Perform Replace Ink in Print Head. Perform Replace Ink in Print Head If the error recurs after taking the above actions, contact your nearest Canon service center to request a repair. Important •...
Page 482 Turn off the printer and unplug it. Plug in the printer again and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair. Important • Do not tilt the printer when moving it since the ink may leak out.
Page 483 Message Is Displayed This section describes some of the messages. If a message is displayed on the printer's touch screen, see below. Message Is Displayed on Printer's Touch Screen If a message is displayed on the computer, see below. Error Regarding Automatic 2-sided Printing Is Displayed Error Regarding Power Cord Being Unplugged Is Displayed (Windows) Writing Error/Output Error/Communication Error (Windows) Other Error Messages (Windows)
Page 484 If you are using a USB cable, make sure it is securely connected to both the printer and the computer. When the USB cable is securely plugged in, check the following: • If you are using a relay device such as a USB hub, disconnect it, connect the printer directly to the computer, and retry the printing.
Page 485 Refer to Updating the Driver to uninstall unnecessary drivers and install the latest drivers. • "Could not print Application name - File name" • Try printing again once the current job is complete.
