MAINTENANCE SPECIFICATIONS |
Maintenance
Cleaning the Cabinet
¢ Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution containing
alcohol, spirits, ammonia or abrasives.
Cleaning Discs
¢ When a disc becomes dirty, clean it with a cleaning
cloth. Wipe the disc from the center out.
¢ Do not use solvents such as benzine, thinner,
commercially available cleaners, or antistatic spray
intended for analog records.
Cleaning the CD lens
After prolonged usage, dirt or dust may accumulate at the
CD Jens. To ensure good playback quality, clean the CD
lens with Philips CD Lens Cleaner or any commercially
available, Follow the instructions supplied with the Lens
Cleaner.
Cleaning the Heads and the Tape Paths
© To ensure good recording and playback quality, clean
the heads, the capstan|s), and pressure roller{s} after
every 50 hours of tape operation,
e Use a cotton swab slightly moistened with cleaning
fluid or alcohol.
e You can also clean the heads by playing a cleaning
tape through once.
Demagnetizing the heads
e Use a demagnetizing tape available at your dealer.
ee ee ee ee —_ oe ee
Specifications
AMPLIFIER
Output power
FW316C
WIUSIG: POWGE i inisiceterrt ee hnee soimeeets 2x10W
FW339C
MUSIC FOWED 2.520242 deer csareleswannt 2x50 W
Signal-to-noise ratio.................. > 75 dBA (IEC)
Frequency response ............. 60 — 16,000Hz, +3dB
Input sensitivity
AIDE hee ie ed pe eee seein acta 500 mV
Output
Speakers (FW316C} 0.2... eee eee 230
Speakers (FW339C) 0... cece cece eee 26Q
Headphones..............2.000005 32 Q- 1000 2
(1)$168
CD PLAYER
Number of programmable tracks ................. 40
Frequency range ............eeeeen ees 40 - 20000 Hz
Signal-to-noise ratio..... 0.2... cee eee eee > 80 dBA
Channel separation ................. = 60 dB (1 kHz)
Total harmonic distortion ..............000. < 0.003%
TUNER
FM wave range...........ee cece eee 87.5— 108 MHz
MW wave range.................08- 931 — 1602 kHz
LW wave range..... 0... cece eee e eee 153 — 279 kHz
Tuning Grid 0.0... 2. cece ee eee eee eee 9 kHz
Number OF Dre@Sets: 00:06 ivevagucaeiess sovee-c's 40
ANlenna: TM ss Secs geeessadsoreeeias 75 Q wire
BVI GAs scat aecncte esau ts Loop antenna
i —
an ee ees
TAPE DECK
Frequency range |
Normal tape (type l) ........... 80 — 12500 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type l) 2.0.2.0... eee ee eee > 48 dBA
Wow and flutter... 0... 0... cece eee ceues 20.4% JIS
SPEAKERS (FW316C)
SYVSIEM sew cawdnneeav stadt Double port bass reflex
IMIDEGANCE: carers tae ax aaa Gawain eee eae eae 32
Woofer ...... saciid tial Sod Gece Bla Leer 1x4
Dimensions (wxhxd).......... 210 x 310 x 180 (mm)
WEIGH ice nea sats ea tutayoiaceesateruees 2.3 kg
SPEAKERS (FW339C)
System ........ cece eee 2 way; Double port bass reflex
IMPSGANCE -s.0 eSwaleiacwese le noadney waeewtcs BQ
WOKE etic cn caviee cere tevecesee ws 1x55"
AWCBION jccieisant cwadaaeieeeee ac 1x 2.5" Polydome
Dimensions (wxhxd).......... 210 x 310 x 230 (mm)
WIN 425 2a. cee abemtgeudeas eae nuees 2.9 kg
GENERAL INFORMATION
Matertal/finish .......... 20. cee en eens Polystyrene
AG POWER 3 cieiteaxewaes eenwe tess 220 - 230 V / 50 Hz
Power Consumption
PCUIVG soci ao iret hiary win is Sean oe awtemauia aa: 44
S15) 11 2) Re s14W
Dimensions (wxhxd).......... 265 x 310 x 330 (mm)
Weight (without speakers)............22..008 5.9 kg
Subject to modification
