Philips LCU7720/00 Installation Instructions

Coded Mains
Transformer LL
LCU7720/00
Installation Instructions
Instructions d'installation
Instrucciones de instalación
120 mm (4.7 in)
L1
in
out
1 2
transmitter
139 mm (5.5 in) max
4422 107 05486 17 December 2018
Istruzioni per l'installazione
Installatie-instructies
7 mm (0.3 in) 4x
L2
in
out
108 mm (4.3 in) max
max
≤90%
60° C
IP00
min
-20° C
Installationsanweisungen
インストール手順
1
Input from Transmitter
490V square wave
L1
in out
Line 1 in/out
kg
3.1 kg
安装指示书
‫إرشادات التركيب‬
Transmitter
0.8...2.0 mm
Torque: 4 Kgf.cm
L2
in out
1 2
transmitter
L1 in/out, L2 in/out
10...25 mm
Torque: 20.7 Kgf.cm
2x 32 A max
Line 2 in/out
www.philips.com/lighting
(AWG 18...14)
2
7.5 ±0.5 mm
(0.3 ±0.02 in)
use copper
conductors
only rated
75 ˚C min
(AWG 8...4)
2
13 ±0.5 mm
(0.5 ±0.02 in)
use copper
conductors
only rated
105 ˚C min
