The following special notations identify certain items: Example Description Top button Buttons are shown in bold print. Information appearing in the radio’s display is shown using SELF TEST the special display font. ASTRO XTS 1500 Model 1.5...
General Radio Operation Programmable Features The programmable controls on your radio can be programmed by a qualified technician to operate certain software-activated features. The features that can be assigned to these controls, and the page numbers where these features can be found, are listed below. Table 1: Programmable Features Feature Page...
If poor light conditions make the display difficult to read, turn on the radio’s backlight by pressing the Light button. The light will remain on for a preprogrammed time before it turns off automatically, or you can turn it off immediately by pressing the Light button again. ASTRO XTS 1500 Model 1.5...
General Radio Operation Status Symbols The top two rows in the display contain symbols indicating the radio’s status. Table 2: Status Symbols Symbol Indication Page Call Received. Blinks when an Individual Call is received. View Mode. View a list. Received Signal Strength Indication (RSSI). The received signal strength for the current site.
Invalid Key-Press pressed. Radio Self-Test when the radio fails the power- Short, Failed up self test. Low-Pitched when an unauthorized request Tone Reject is made. Time-Out Timer four seconds before time out. Warning ASTRO XTS 1500 Model 1.5...
Page 20
General Radio Operation Table 4: Alert Tones (Continued) You hear: Tone Name Heard: when the radio does not No ACK Received receive an acknowledgment. Time-Out Timer after time out. Timed Out when the PTT button is Talk Prohibit/ pressed, and transmissions PTT Inhibit are prevented.
Page 21
3-Position Rotary Switch. Group of Low Pitched Tones Short, High- when the battery is below the Pitched Tone Low-Battery Chirp preset threshold value. (Chirp) when a landline phone call is Ringing Phone Call Received received. ASTRO XTS 1500 Model 1.5...
Prior to using a new battery, charge it for a minimum of 16 hours to ensure optimum capacity and performance. For a list of Motorola approved batteries available for use with your XTS 1500 radio, see “Batteries” on page 44.
Page 23
Remove the Battery With the radio off, slide down the latches on the sides of the battery. Pull the top of the battery away from the radio. ASTRO XTS 1500 Model 1.5...
Page 24
General Radio Operation Smart Battery Condition This feature allows you to view the condition of your Smart Battery. Press the Smart Battery CAPACITY button. INIT 10/01 EST CHGS Note: If a Smart Battery is not SMART BATT powering your radio: DATA NOT AVAILABLE Press the Smart Battery button again to exit.
For information regarding other available antennas, see page 44. Attach the Antenna With the radio off, turn the antenna clockwise to attach Remove the Antenna With the radio off, turn the antenna counterclockwise to remove it. ASTRO XTS 1500 Model 1.5...
General Radio Operation Belt Clip Attach the Belt Clip Align the grooves of the belt clip with those of the battery. Press the belt clip downward until you clear a “click.” Remove the Belt Clip Use a flat-bladed screwdriver to press the belt clip tab away from the battery.
Insert the hooked end of the cover into the top of the connector. Press downward on the cover’s top to seat it into the slot. Press the cover’s lower tab below the connector until it snaps in place. ASTRO XTS 1500 Model 1.5...
Attach the Adapter With the Motorola side of the adapter facing out, snap the smaller end of the adapter into place in the shroud indent, below the On/Off Volume Control Knob.
If the radio continues to fail the power-up test, record the ERROR XX/YY code and contact a qualified service technician. Turn the Radio Off Turn the On/Off/Volume Control knob counterclockwise until it clicks. ASTRO XTS 1500 Model 1.5...
General Radio Operation Zones and Channels A zone is a grouping of channels. A channel is a group of radio characteristics, such as transmit/receive frequency pairs. Before you use your radio to receive or send messages, you should select the zone. Select a Zone If a control on your radio has FIRE...
Mode Select button.The buttons that are assigned for this feature are labeled in the following picture. Top Button Top Side Button Side Button 1 Side Button 2 ASTRO XTS 1500 Model 1.5...
General Radio Operation Receive / Transmit Radio users who switch from analog to digital radios often assume that the lack of static on a digital channel is an indication that the radio is not working properly. This is not the case. Digital technology quiets the transmission by removing the “noise”...
Release the Volume Set button. Adjust the Volume Control Knob if necessary. Press and hold the PTT button to transmit. LED lights RED while transmitting. Release the PTT button to receive (listen). ASTRO XTS 1500 Model 1.5...
General Radio Operation Use the Preprogrammed Monitor Button Turn the radio on and select the desired zone and channel. Press the Monitor button and listen for activity. (See the following Conventional Mode Operation.) Adjust the Volume Control knob if necessary. Press and hold the PTT button to transmit.
Press the Monitor button again, or the PTT button, to return to the original squelch setting. Note: If you try to transmit on a receive-only channel, you will hear an invalid tone until you release the PTT button. ASTRO XTS 1500 Model 1.5...
Defeat position. You can now hear any activity on the channel. The radio is muted if no activity is present. When this feature is active, the Carrier Squelch status indicator ( ) will be displayed. ASTRO XTS 1500 Model 1.5...
Common Radio Features Time-Out Timer The time-out timer turns off your radio’s transmitter. The timer is set for 60 seconds at the factory, but it can be programmed from 0 to 7.75 minutes (465 seconds) by a qualified radio technician. Hold down the PTT longer •...
If the selected channel does NO EMERGENCY not support emergency, the display shows NO EMERGENCY. Select a channel that does show EMERGENCY. Note: To exit emergency at any time, press and hold the Emergency button for about a second. ASTRO XTS 1500 Model 1.5...
Common Radio Features When you receive the ACK RECEIVED dispatcher’s • Four tones acknowledgment, you see • Alarm ends ACK RECEIVED, four tones sound, the alarm ends, and • Radio exits emergency the radio exits the emergency mode. If no acknowledgement is NO ACKNOWLDG received, you see NO ACKNOWLDG, the alarm ends,...
Page 41
• If the new channel is NOT programmed for Emergency, an invalid tone sounds until you exit the Emergency state or change to a channel programmed for emergency. ASTRO XTS 1500 Model 1.5...
Common Radio Features Scan The scan feature allows you to monitor traffic on different channels by scanning a preprogrammed list of channels. The list must be preprogrammed by a qualified technician. Turn Scan On and Off Place the Scan On/Off switch in the On or Off position.
Note: You cannot delete priority channels or the designated transmit channel. The radio continues scanning the remaining channels in the list. To resume scanning the deleted channel, change channels or turn scan off and then back on again. ASTRO XTS 1500 Model 1.5...
Common Radio Features Conventional Scan Only Make a Dynamic Priority Change While the radio is scanning, the dynamic priority change feature lets you temporarily change any channel in a scan list (except the priority- one channel) to the priority-two channel. The replaced priority-two channel becomes a non-priority channel.
20 seconds after the call indicators begin. Press and hold the PTT button to talk; release it to listen. Press the Call Response button again to hang up and return to the home display. ASTRO XTS 1500 Model 1.5...
Common Radio Features Private Calls (Trunking Only) These one-to-one calls between two radios are not heard by others in the current talkgroup. The calling radio automatically verifies that the receiving radio is active on the system and that it can display the caller’s ID.
PAGE RECEIVD LED blinks GREEN, the • Four repeating alert tones call-received symbol ( • Blinking GREEN LED blinks, and PAGE RECEIVED is displayed. Press and hold the PTT button to talk, release it to listen. ASTRO XTS 1500 Model 1.5...
Common Radio Features Repeater or Direct Operation Also known as TALKAROUND operation, DIRECT lets you bypass the repeater and connect directly to another radio. The transmit and receive frequencies are the same. REPEATER operation increases the radio’s range by connecting with other radios through a repeater.
Your radio’s ID FAILSOFT predetermined frequency. You hear a medium-pitched tone • Medium-pitched tone every 10 seconds. When the trunking system returns to normal operation, your radio automatically leaves failsoft operation and returns to trunked operation. ASTRO XTS 1500 Model 1.5...
Special Radio Features Out-of-Range If you go out of the range of the system, and can no longer lock onto a control channel: The display shows OUT OF RANGE Your radio’s ID OUT OF RANGE and the currently selected zone/ channel combination, and/or you AND/OR hear a low-pitched tone.
You hear a tone, and the • Tone display shows SCANING SITE while the radio scans SCANING SITE for a new site. The radio returns to the home display when it finds a new site. ASTRO XTS 1500 Model 1.5...
Avoid subjecting the radio to corrosives, solvents or spirits. • Do not disassemble the radio. • Keep the accessory-connector cover in place until ready to use the connector. Replace the cover immediately once the accessory has been disconnected. ASTRO XTS 1500 Model 1.5...
Helpful Tips Service Proper repair and maintenance procedures will assure efficient operation and long life for this product. A Motorola maintenance agreement will provide expert service to keep this and all other communication equipment in perfect operating condition. A nationwide service organization is provided by Motorola to support maintenance services.
Helpful Tips Charging the Battery Motorola batteries are designed specifically to be used with a Motorola charger and vice-versa. Charging in non-Motorola equipment may lead to battery damage and void the battery warranty. Motorola-authorized battery chargers may not charge batteries other than the ones listed on page 44.
Motorola fully endorses and encourages the recycling of NiCd batteries. In the U.S. and Canada, Motorola participates in the nationwide Rechargeable Battery Recycling Corporation (RBRC) program for NiCd battery collection and recycling. Many retailers and dealers participate in this program.
Accessories Accessories Motorola provides the following approved accessories to improve the productivity of your XTS 1500 portable two-way radio. For a list of Motorola-approved antennas, batteries, and other accessories, visit the following web site which lists approved accessories: http://www.motorola.com/governmentandenterprise/ Antennas NAD6563 VHF whip (136–174 MHz)
* Batteries include an over-discharge protection circuit (similar to those in Li-Ion batteries) to extend life of batteries by preventing excessive battery discharge during customer use. Motorola strongly recommends charging these batteries with Motorola-approved IMPRES desktop charges programmed with version 3.4 of the IMPRES desktop charger software.
CommPort with palm PTT NTN1625 CommPort ear mic with PTT for noise levels up to 100 dB (requires BDN6676 adapter) NTN1663 CommPort ear mic with ring PTT for noise levels up to 100 dB (requires BDN6676 adapter) ASTRO XTS 1500 Model 1.5...
Accessories NTN1736 CommPort ear mic with snap-on side PTT for noise levels up to 100 dB (requires BDN6676 adapter) Earpieces BDN6641 Ear mic, high noise level up to 105 dB, grey (must order BDN6671 interface module) BDN6664 Earpiece with standard earphone, beige BDN6665 Earpiece with extra-loud earphone (exceeds OSHA limits), beige...
Push-to-talk (PTT) and voice-activated (VOX) interface module (for use with BDN6641, BDN6677 and BDN6678) BDN6708 PTT interface module (for use with BDN6641, BDN6677 and BDN6678) Switches 0180300E83 Remote PTT body switch NTN7660 Tilt / Man down switch ASTRO XTS 1500 Model 1.5...
10 Wait for a response. 11 If you do not receive an immediate response, remain by the radio and repeat the transmission at intervals until you receive a response. Be prepared to follow any instructions given to you. ASTRO XTS 1500 Model 1.5...
