Summary of Contents for AEG LTR6G6141C
- Page 1 MANUEL Lave-linge NOTICE D’UTILISATION Tous nos Tutos vidéo Darty.com Tous nos magasins Communauté SAV Darty...
- Page 2 EN User Manual | Washing Machine LTR6G6141C...
-
Page 3: Table Of Contents
FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 4: Safety Information
SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 5 1.2 General Safety • This appliance is for washing domestic-type, machine- washable laundry only. • This appliance is designed for single household domestic use in an indoor environment. • This appliance may be used in, offices, hotel guest rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels.
-
Page 6: Safety Instructions
2. SAFETY INSTRUCTIONS 2.1 Installation • WARNING: This appliance is designed to be installed / connected to a grounding connection in the building. • Always use a correctly installed The installation must comply with shockproof socket. relevant national regulations. • Make sure that the parameters on the rating plate are compatible with the •... -
Page 7: Product Description
• Make sure that there is access to the tap valves, filters and aquastops, printed after the installation. circuit boards, electronic displays, pressure switches, thermostats and 2.4 Use sensors, software and firmware including reset software, door, door hinge and seals, other seals, door locking assembly, WARNING! plastic peripherals such as detergent Risk of injury, electric shock, fire, burns... - Page 8 3.2 Appliance overview 10 11 Control panel Drain hose Mains cable Lid handle Transit bolts Drain pump filter Hose support Lever to move the appliance Rating plate Feet for levelling the appliance Inlet hose Information for register product. The rating plate reports the model name The info label reports the model name (A), (A) , product number (B), electrical ratings (C) product number (B ) and serial number (C).
-
Page 9: Technical Data
4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,3 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles and moisture ensured IPX4 by the protective cover, except where the low voltage equipment has no protection against moisture... - Page 10 We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.
- Page 11 5.3 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension.
-
Page 12: Control Panel
6. CONTROL PANEL 6.1 Control panel description 12 11 Taches/Prélavage skipping touch button Marche/Arrêt push button Programme dial • Taches option Display • Prélavage option Départ Différé touch button Anti-allergie touch button Gain de Temps touch button Lessive liquide touch button Rinçage skipping touch button Essorage reduction touch button •... - Page 13 The indicator flashes during the laundry load estimation. Maximum laundry indicator. It flashes when the laundry load exceeds the maximum de‐ clared load of the selected programme. Lid locked indicator. Delay start indicator. The digital indicator can show: • Programme duration (e. g. •...
-
Page 14: Programme Chart
7. PROGRAMME CHART Washing programmes Programme Default Reference Maximum Programme description tempera‐ spin speed load ture Spin speed Tempera‐ range ture range White cotton and fast-coloured cotton. Normally soiled items. The energy consump‐ 1400 rpm Eco 40-60 6 kg tion decreases and the time of the washing 40 °C 1400-400 rpm programme is extended, ensuring good wash‐... - Page 15 Programme Default Reference Maximum Programme description tempera‐ spin speed load ture Spin speed Tempera‐ range ture range Do not us fabric softener and make sure there is no softener residue in the detergent dispens‐ Outdoor clothing, technical, sport fabrics, waterproof and breathable jackets, shell jackets with a removable fleece or inner in‐...
- Page 16 Programme Default Reference Maximum Programme description tempera‐ spin speed load ture Spin speed Tempera‐ range ture range All fabrics, except woollens and delicate 1400 rpm fabrics. To spin the laundry and to drain the 1400 rpm - 400 6 kg Essorage/ water in the drum.
- Page 17 OPTIONS Anti-allergie ■ ■ ■ ■ ■ Gain de Temps Départ Différé ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Lessive liquide ■ ■ ■ ■ ■ ■ ■ ■ Douceur Plus ■ ■ ■ ■ ■ This option is not available with temperature lower than 40 °C. If you set the shortest duration, we recommend that you decrease the load size.
-
Page 18: Options
7.1 Woolmark Wool Care - Green The wool wash cycle of this machine has been approved by The Woolmark Company for the washing of wool gar‐ ments labelled as «hand wash» provided that the prod‐ ucts are washed according to the instructions on the gar‐ ment label and those issued by the manufacturer of this washing machine. - Page 19 The intermediate and the final spinning The corresponding indicator above the phases are suppressed and the touch button illuminates. programme ends with water in the drum. 8.6 Rinçage This helps to reduce creasing. The display shows the indicator . The lid With this button you can select one of the stays locked.
-
Page 20: Settings
residues and pollens/allergenic items, making Touch the button repeatedly to set the it suitable for delicate and sensitive skins. required delay. The time increases by steps of 30 minutes up to 90' and from 2 hours up 8.9 Lessive liquide to 20 h. -
Page 21: Before First Use
9.5 Operating Hours Counter 9.6 Factory Reset It is possible to visualise the total operating This function allows to restore the factory time of the appliance in hours, starting from default options. To activate this option follow the first switching on. This value will count steps below: operating time of the cycles (does not include 1. -
Page 22: Daily Use
11. DAILY USE 11.1 Activating the appliance 2. Put the detergent and the fabric conditioner into the proper compartments. 1. Connect the mains plug to the mains socket. 2. Open the water tap. Always follow the instructions that you 3. Press button Marche/Arrêt to activate the find on the packaging of the detergent appliance. - Page 23 11.4 Liquid or powder detergent CLICK CLICK • Position A for powder detergent (factory setting). • Position B for liquid detergent. In case a selection is not possible , no indicator comes on and an acoustic signal sounds. When you use the liquid detergent: 11.6 Starting a programme without •...
- Page 24 11.7 Cycle time recalculation 11.11 Cancelling a running programme 1. Press button Marche/Arrêt to cancel the programme and to deactivate the After approximately 15 minutes from the appliance. start of the programme: 2. Press button Marche/Arrêt again to • The appliance adjusts automatically activate the appliance.
-
Page 25: Hints And Tips
11.13 Opening the Lid when the 1. Press button Marche/Arrêt to deactivate programme operates the appliance. After five minutes from the end of the programme, the energy saving function CAUTION! automatically deactivates the appliance. If the temperature and level of the water in the drum are too high, the indicator stays on and you cannot open When you activate the appliance again,... - Page 26 • Follow the washing instructions on the laundry care labels. • Do not wash white and coloured items together. • Some coloured items can discolour with the first wash. We recommend that you wash them separately for the first couple of times.
-
Page 27: Care And Cleaning
– there is large amounts of foam during • With adequate pre-treatment, stains and washing. limited soiling can be removed; the • When using detergent tabs or pods, laundry can then be washed at a lower always put them inside the drum, not in temperature. - Page 28 13.2 Removing foreign objects Always follow the instructions that you find on the packaging of the product. Make sure that pockets are empty and all loose elements are tied up before 13.5 Maintenance wash running your cycle. Refer to "The laundry load"...
- Page 29 13.8 Cleaning the detergent dispenser 13.9 Cleaning the drain filter WARNING! Regularly check the drain pump filter and • Disconnect the mains plug from the make sure that it is clean. mains socket. Clean the drain pump if: • Do not remove the filter while the appliance operates.
-
Page 30: Troubleshooting
13.10 Cleaning the inlet hose and the valve filter 13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, carry 2. Close the water tap. out the same procedure, described in 3. - Page 31 14.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Départ/ Pause button may flash continuously: Problem Possible solution...
- Page 32 Problem Possible solution • Make sure that the mains plug is connected to the mains socket. • Make sure that the appliance lid and drum door are closed. • Make sure that there is no damaged fuse in the fuse box. The programme does not •...
-
Page 33: Consumption Values
After the check, activate the appliance. The programme continues from the point of interruption. If the problem occurs again, contact the Authorised Service Centre. The necessary data for the service centre are on the rating plate. 15. CONSUMPTION VALUES 15.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label. - Page 34 15.3 According to Commission Regulation Eu 2019/2023 Eco 40-60 pro‐ rpm 1) Litres hh:mm °C gramme Full load 0.850 47.0 3:17 53.00 1351 Half load 0.405 37.0 2:35 53.00 1351 Quarter load 0.200 29.0 2:35 54.00 1351 Maximum spin speed. Power consumption in different modes Off (W) Stand-by (W)
-
Page 35: Quick Guide
16. QUICK GUIDE 16.1 Daily use Connect the mains plug to the mains socket. 2. Set the desired options (1) by means of the corresponding touch buttons. To start Open the water tap. the programme, touch the Départ/Pause Load the laundry. (2) button. -
Page 36: Environmental Concerns
Programmes Load Product description 3 kg Synthetic items or mixed fabric items. Synthétiques 2 kg Delicate fabrics such as acrylics, viscose, polyester items. Délicats 1,5 kg Machine washable wool, hand washable wool and delicates. Laine/Soie 3 kg Cotton and synthetic lightly soiled items or once worn items. 20 min. - Page 37 135970290-A-032023...
