OWNER'S MANUAL
MOTORCYCLE
XTZ07AR (Ténéré 700)
Read this manual carefully
before operating this vehicle.
BVW-28199-70
For your safety - pre-operation checks
1
2
3
4
5
6
7
8
9
10
11
12

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha XTZ07AR 2024

  • Page 1: Table Of Contents

    Read this manual carefully before operating this vehicle. Location of important labels OWNER’S MANUAL Safety information Description Special features Instrument and control functions For your safety – pre-operation checks Operation and important riding points Periodic maintenance and adjustment Motorcycle care and storage MOTORCYCLE Specifications XTZ07AR (Ténéré...
  • Page 2 EAU46094 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.
  • Page 4 Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10202 XTZ07AR OWNER’S MANUAL ©2024 by Yamaha Motor Co., Ltd. 1st edition, June 2023 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.
  • Page 6 Table of contents Location of important labels... 1-1 Catalytic converter ......5-18 Removing and installing the Seats ..........5-19 cowling ........8-10 Safety information......2-1 Adjusting the headlight beams ..5-20 Checking the spark plugs..... 8-10 Adjusting the front fork ....5-20 Canister ........8-11 Description ........
  • Page 7 Table of contents Checking and lubricating the Maintenance record...... 11-7 brake and shift pedals ....8-27 YAMAHA MOTOR CANADA LTD. Checking and lubricating the MOTORCYCLE WARRANTY brake and clutch levers....8-28 GUIDE ........11-9 Checking and lubricating the sidestand ........8-29 Index ..........12-1 Lubricating the rear suspension..8-29...
  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer. 4,5,6,7,8,9,10...
  • Page 9 Location of important labels WARNING NOTICE BEFORE YOU OPERATE THIS VEHICLE, READ THE OWNER’S MANUAL AND ALL LABELS. ALWAYS WEAR AN APPROVED MOTORCYCLE 8ET-2815K-01 HELMET, eye protection, and protective clothing. 1TP-2118K-A2 STORAGE ORDER AVERTISSEMENT BAND TOOL KIT LIRE LE MANUEL DU PROPRIETAIRE AINSI QUE TOUTES POUCH LES ETIQUETTES AVANT D’UTILISER CE VEHICULE.
  • Page 10 Location of important labels TIRE INFORMATION INFORMATION SUR LES PNEUS Cold tire normal pressure should be set La pression des pneus à froid doit normalement as follows. être réglée comme suit. FRONT : 220 kPa, {2.20 kgf/cm²}, 32 psi AVANT : 220 kPa, {2.20 kgf/cm }, 32 psi REAR : 250 kPa, {2.50 kgf/cm²}, 36 psi...
  • Page 11 Location of important labels ATTENTION CAN ICES-002 / NMB-002 8ET-2815K-11 8KM-82377-12...
  • Page 12: Safety Information

    Safety information  Never operate a motorcycle with- pears to be very effective in reduc- EAU1031C out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 13 Safety information  Many accidents involve inexperi-  Wear a face shield or goggles. • Always signal before turning or enced operators. In fact, many op- changing lanes. Make sure that Wind in your unprotected eyes erators who have been involved in other motorists can see you.
  • Page 14 Safety information Carbon Monoxide is a colorless, odor- Loading close to the center of the vehicle less, tasteless gas which may be pres- Adding accessories or cargo to your as possible and make sure to dis- ent even if you do not see or smell any motorcycle can adversely affect stabil- tribute the weight as evenly as engine exhaust.
  • Page 15 Yamaha accessories, which are avail- characteristics can put you and others • Bulky or large accessories may able only from a Yamaha dealer, have at greater risk of serious injury or seriously affect the stability of been designed, tested, and approved death.
  • Page 16 Safety information  Secure the motorcycle with tie- Aftermarket Tires and Rims The tires and rims that came with your downs or suitable straps that are motorcycle were designed to match attached to solid parts of the mo- the performance capabilities and to torcycle, such as the frame or up- provide the best combination of han- per front fork triple clamp (and not,...
  • Page 17: Description

    Description EAU10411 Left view 1. Rebound damping force adjusting screw (page 5-20) 9. Engine oil filter cartridge (page 8-12) 2. Coolant reservoir (page 8-15) 10.Compression damping force adjusting screw (page 5-20) 3. Canister (page 8-11) 4. Seat lock (page 5-19) 5.
  • Page 18: Right View

    Description EAU10421 Right view 1. Main fuse (page 8-32) 2. Fuse box (page 8-32) 3. Battery (page 8-31) 4. Fuel tank cap (page 5-16) 5. Brake pedal (page 5-15) 6. Rear brake fluid reservoir (page 8-23)
  • Page 19: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 5-14) 9. Throttle grip (page 8-18) 2. Left handlebar switches (page 5-2) 10.Main switch/steering lock (page 5-1) 3. “ABS ON” button (page 5-4) 4. Multi-function meter unit (page 5-5) 5. USB jack (page 5-26) 6.
  • Page 20: Main Display Screen

    Description EAUM4620 Main display screen Explorer Explorer Street Street 9 9 10 9 9 10 1. Smartphone connectivity indicator “ ” (page 5-7) 10.Unread message indicator “ ” (page 5-9) 2. Smartphone battery level indicator “ ” (page 5-7) 11.Engine trouble warning indicator “ ”...
  • Page 21: Special Features

    Bluetooth radio waves or other electro- are momentarily adjusted to allow the wireless technology and the Yamaha magnetic noise. upshift to occur. Motorcycle Connect smartphone app.  At facilities nearby that are...
  • Page 22  If more than one phone has been 4. When pairing is complete, the Smartphone connectivity indica- registered in the CCU, then the Yamaha Motorcycle Connect may not tor and Smartphone battery level first phone within reach will be work on all smartphone models and indicator will come on.
  • Page 23: Compliance With Industry Canada

    Special features Please be advised that due to the Please carefully select the installa- EAUA1230 Compliance with Industry unique function supplied by this prod- tion position and make sure that Canada uct, the device is intended for use with the final output power does not our interactive entertainment software exceed the limit set force in rele- Communication control unit...
  • Page 24: Instrument And Control Functions

    Instrument and control functions  The headlight will stay on until the To lock the steering EAU10462 Main switch/steering lock key is turned to “OFF”, even if the engine stalls. EAU10664 All electrical systems are off. The key can be removed. EWA10062 WARNING LOCK...
  • Page 25: Handlebar Switches

    Instrument and control functions To unlock the steering Right EAU66059 Handlebar switches Left 1. Stop/Run/Start switch “ ” 1. Push. 2. Wheel switch “ ” 2. Turn. 1. Pass switch “ ” Push the key in and turn it to “OFF”. 2.
  • Page 26 Instrument and control functions EAU66030 ECA10062 Horn switch “ ” NOTICE When the dimmer switch is set Press this switch to sound the horn. Do not use the hazard lights for an to “ ”, the passing switch has no ef- extended length of time with the en- fect.
  • Page 27: Indicator Lights And Warning Lights

    Indicator lights and warning when the vehicle power is turned on, or This button reactivates the anti-lock lights if the light remains on, have a Yamaha brake system (ABS) if it has already dealer check the vehicle. been turned off.
  • Page 28: Main Display Screen

     The display units can be switched between kilometers/miles and cel- If all the fuel meter display segments cius/farenheit. (See page 5-13.) flash repeatedly, have a Yamaha deal- er inspect the vehicle.
  • Page 29 When the vehicle is turned on, this light theme. should come on for a few seconds and  If all the coolant temperature me- then go off. Otherwise, have a Yamaha Oil pressure warning indicator “ ” ter display segments flash repeat- dealer check the vehicle.
  • Page 30 If it does not flash when the vehicle  Icon off: No smartphone connect- the menu system. (See page 5-11.) power is turned on, have a Yamaha ABS status Indicated on display dealer inspect the vehicle.
  • Page 31 Instrument and control functions Missed call indicator “ ” The missed call indicator comes on when connected smartphone misses a call. It will remain on until the vehicle power is turned off or until “Cancel Notification” is selected in the “Telephone”...
  • Page 32 Instrument and control functions If the above indicators go off, the The information display items are: To reset information display items: incoming message indicator will “ODO”: odometer If a displayed item can be reset, short be displayed for the remaining “COOLANT”: coolant temperature pressing the wheel switch “...
  • Page 33 Instrument and control functions Air temperature “AIR”: to confirm and the next digit will flash. The air temperature is displayed from Repeat this until the third digit is con- If traveling at speeds under 10 km/h (6 –9 °C (16 °F) to 50 °C (122 °F) in 1 °C firmed and the tripmeter is set.
  • Page 34: Menu System

    Instrument and control functions  Short press wheel EAUA0931 Change between display Menu system “Themes” themes. (See page 5-12.) switch “ ” to highlight/de-high- Telephone notification set- light a selected item. “Telephone” tings. (See page 5-12.)  While an item is highlighted, long ...
  • Page 35 Instrument and control functions “Themes” This module allows you to clear all stored call notifications. When “Cancel  When one of the ABS items is set, Notification” is selected, the incom- the display will return to the main ing/missed call icon will disappear screen instead of the previous from the main screen.
  • Page 36 Instrument and control functions “Unit” “Brightness” Change measurement “Unit” units. (See page 5-13.) Adjust display brightness. “Brightness” (See page 5-13.) Set clock. (See page “Clock” 5-13.) Reset system settings. “All Reset” (See page 5-14.) “Maintenance” This module allows you to adjust the This module allows you to change the measurement units.
  • Page 37: Clutch Lever

    Instrument and control functions EAU12823 EAU12876 Clutch lever Shift pedal This module allows you to set the 12- hour clock. The hours and minutes are 1. Clutch lever 1. Shift pedal set individually. To disengage the drivetrain from the The shift pedal is located on the left engine, such as when shifting gears, side of the motorcycle.
  • Page 38: Brake Lever

    Instrument and control functions EAU26827 EAU12944 EAU90662 Brake lever Brake pedal The brake lever is located on the right The anti-lock brake system (ABS) acts side of the handlebar. To apply the on the front and rear brakes indepen- front brake, pull the lever toward the dently.
  • Page 39: Fuel Tank Cap

    Instrument and control functions  The ABS performs a self-check EAUM1795 Fuel tank cap when you first start off. During this time a clicking noise from the hy- draulic unit may be audible, and if the brake lever or brake pedal is applied a vibration can be felt, but this is not a malfunction.
  • Page 40: Fuel

    Instrument and control functions EAU13222 Fuel The fuel tank cap cannot be installed Make sure there is sufficient gasoline in unless the key is in the lock. In addi- the tank. tion, the key cannot be removed if the EWA10882 WARNING cap is not properly installed and locked.
  • Page 41: Catalytic Converter

    EWA10863 EAU86100 WARNING Use only unleaded gasoline. The use Your Yamaha engine was designed to The exhaust system is hot after op- of leaded gasoline will cause severe use regular unleaded gasoline. Con- eration. To prevent a fire hazard or...
  • Page 42: Seats

    Instrument and control functions To install the passenger seat EAUM4110 Seats 1. Insert the projection on the front of the passenger seat into the seat Passenger seat holder as shown, and then push the rear of the seat down to lock it To remove the passenger seat in place.
  • Page 43: Adjusting The Headlight Beams

    If headlights require adjustment, con- ECA10102 sult a Yamaha dealer. NOTICE To avoid damaging the mechanism, do not attempt to turn beyond the 1. Projection maximum or minimum settings.
  • Page 44 Instrument and control functions tions, however such adjustments are ineffective and may damage the suspension. Compression damping force 1. Remove the rubber cap by pulling it out of the front fork leg. 1. Rebound damping force adjusting screw 1. Compression damping force adjusting screw Rebound damping setting: Compression damping setting:...
  • Page 45: Front Fork Bleeding

    Instrument and control functions tions, however such adjustments EAU14796 Front fork bleeding are ineffective and may damage When riding in extremely rough condi- the suspension. tions, the air temperature and pressure in the front fork will rise and harden the suspension.
  • Page 46: Adjusting The Shock Absorber Assembly

    Instrument and control functions tions, however such adjustments EAUM4121 Adjusting the shock absorber are ineffective and may damage assembly the suspension. This shock absorber assembly is equipped with a spring preload adjust- Rebound damping force er and rebound and compression Turn the adjuster in direction (a) to in- damping force adjusters.
  • Page 47 Instrument and control functions To set the compression damping Rebound damping setting: force, turn the adjuster in direction (a) Unit for adjustment:  When turning the damping force until it stops, and then count the clicks Click adjuster in direction (a), the 0 click Minimum (soft): in direction (b).
  • Page 48: Luggage Strap Holders

    1. Loosen the bolts on each side of sembly yourself. Take the shock the front fender. absorber assembly to a Yamaha dealer for any service. 1. Luggage strap holder Use the indicated strap points to se- cure luggage ties to the vehicle.
  • Page 49: Dc Power Outlets

    3. Turn the accessory off. 4. If the USB jack overheats or mal- functions, the indicator light will go To prevent battery drain, do not use off. If this occurs, have a Yamaha accessories with the engine off. dealer check the vehicle. 5-26...
  • Page 50: Sidestand

    EAU15306 EAU57952 Sidestand Ignition circuit cut-off system Yamaha dealer repair it if it does not The sidestand is located on the left This system prevents in-gear engine function properly. side of the frame. Raise the sidestand...
  • Page 51 The neutral switch may not be working. 6. Move the sidestand up. The motorcycle should not be ridden until 7. Pull the clutch lever. checked by a Yamaha dealer. 8. Shift transmission into gear. 9. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.
  • Page 52: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 8-15 Coolant • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary. 8-22, 8-23 •...
  • Page 53 • Make sure that operation is smooth. • Check throttle grip free play. 8-18, 8-27 Throttle grip • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 8-27 •...
  • Page 54 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 5-27 • If system is not working correctly, have Yamaha dealer check vehicle.
  • Page 55: Operation And Important Riding Points

    ECA10311 NOTICE there is a control or function you do not between 0 and 1600 km (1000 mi). For understand, ask your Yamaha dealer. this reason, you should read the fol-  Keep the engine speed out of EWA10272 lowing material carefully.
  • Page 56: Starting The Engine

    Yamaha dealer check the vehicle. tion. Turn the vehicle power off To start the engine 3. Shift the transmission into the and then back on again to cancel 1.
  • Page 57: Shifting

    Operation and important riding points 3. Open the throttle gradually, and at EAU16675 ECA10262 Shifting NOTICE the same time, release the clutch  When shifting, press the shift lever slowly. pedal firmly until you feel the 4. At the recommended shift points gear shift is complete.
  • Page 58: Parking

    Operation and important riding points 3. When the motorcycle reaches 25 accident and injury. It could also EAU17214 Parking km/h (16 mph), the engine is about cause engine or drive train dam- When parking, stop the engine, and to stall or runs roughly, pull the age.
  • Page 59: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.
  • Page 60: Tool Kit

    Tool kit If you do not have the tools or experi- ence required for a particular job, have your Yamaha dealer perform it for you. 1. Tool kit 2. Storage pouch The tool kit is in the location shown. Al-...
  • Page 61: Periodic Maintenance Chart For The Emission Control System

     From 37000 km (24000 mi) or 36 months, repeat the maintenance intervals starting from 13000 km (8000 mi) or 12 months.  Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the ser- vice.
  • Page 62 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 1000 km 7000 km 13000 km 19000 km 25000 km 31000 km ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) (20000 mi) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 63: General Maintenance And Lubrication Chart

    30 months 1 month • Perform dynamic inspection us- Diagnostic system √ √ √ √ √ √ ing Yamaha diagnostic tool. check • Check the error codes. Air filter element • Replace. Every 19000 km (12000 mi) √ √ √ √...
  • Page 64 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 1000 km 7000 km 13000 km 19000 km 25000 km 31000 km ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) (20000 mi) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 65 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 1000 km 7000 km 13000 km 19000 km 25000 km 31000 km ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) (20000 mi) 1 month 6 months 12 months 18 months 24 months 30 months Brake pedal pivot...
  • Page 66 Every 3 years Front and rear √ √ √ √ √ √ 28 * • Check operation. brake switches • Apply Yamaha cable lubricant or √ √ √ √ √ √ 29 * Control cables other suitable cable lubricant thoroughly.
  • Page 67 Periodic maintenance and adjustment • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid. • Replace the brake hoses every four years or sooner if cracked or damaged.
  • Page 68: Removing And Installing The Cowling

    The cowling shown needs to be re- checked periodically, preferably by a moved to perform some of the mainte- Yamaha dealer. Since heat and depos- nance jobs described in this chapter. its will cause any spark plug to slowly Refer to this section each time the...
  • Page 69: Canister

    Periodic maintenance and adjustment EAU36113 Specified spark plug: Canister NGK/LMAR8A-9 If a torque wrench is not available when installing a spark plug, a good Before installing a spark plug, the estimate of the correct torque is 1/4– spark plug gap should be measured 1/2 turn past finger tight.
  • Page 70: Engine Oil And Oil Filter Cartridge

    Periodic maintenance and adjustment EAUM4152 Engine oil and oil filter car- tridge The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter car- tridge replaced at the intervals speci- fied in the periodic maintenance chart.
  • Page 71 Periodic maintenance and adjustment An oil filter wrench is available at a Yamaha dealer. 7. Apply a thin coat of clean engine oil to the O-ring of the new oil filter cartridge. 1. Engine oil drain bolt 1. Torque wrench 2.
  • Page 72 2.30 L (2.43 US qt, 2.02 Imp.qt) is correct, immediately turn the en- With oil filter removal: gine off and have a Yamaha dealer 2.60 L (2.75 US qt, 2.29 Imp.qt) check the vehicle. 15. Turn the engine off, wait a few...
  • Page 73: Why Yamalube

    Thus, 3. Minimum level mark Yamalube mineral, semisynthetic and If genuine Yamaha coolant is not avail- synthetic oils have their own distinct 3. If the coolant is at or below the able, use an ethylene glycol antifreeze characters and value.
  • Page 74: Replacing The Air Filter Element And Cleaning The Check Hose

    Have a maintenance chart. Replace the air fil- Yamaha dealer change the coolant. ter element more frequently if you often WARNING! Never attempt to remove ride in the rain or dusty areas. In addi-...
  • Page 75 Periodic maintenance and adjustment seated in the air filter case. The ECA21220 NOTICE engine should never be operat-  The air filter element must be ed without the air filter element replaced at the intervals speci- installed, otherwise the pis- fied in the periodic maintenance ton(s) and/or cylinder(s) may become...
  • Page 76: Checking The Throttle Grip Free Play

    3.0–5.0 mm (0.12–0.20 in) proper tire pressure may cause se- Periodically check the throttle grip free vere injury or death from loss of play and, if necessary, have a Yamaha control.  The tire air pressure must be dealer adjust it.
  • Page 77 “broken Never overload your vehicle. Opera- wall is cracked, have a Yamaha dealer in” for it to develop its optimal tion of an overloaded vehicle could replace the tire immediately.
  • Page 78: Spoke Wheels

    Yamaha the vehicle may be different, which dealer. Do not attempt to repair or could lead to an accident.
  • Page 79: Checking The Brake Lever Free Play

    2. Loosen the locknut at the crank- case. 1. No brake lever free play There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system. EWA14212 WARNING 1. Locknut A soft or spongy feeling in the brake 2.
  • Page 80: Brake Light Switches

    EAU36505 EAU22393 Brake light switches Checking the front and rear peared, have a Yamaha dealer replace The brake light should come on just brake pads the brake pads as a set. before braking takes effect. The brake...
  • Page 81: Checking The Brake Fluid Level

    Periodic maintenance and adjustment  Use only the specified brake flu- Rear brake EAU40262 Checking the brake fluid level id; otherwise, the rubber seals Before riding, check that the brake fluid may deteriorate, causing leak- is above the minimum level mark. age.
  • Page 82: Changing The Brake Fluid

    EAU22734 EAU22762 Changing the brake fluid Drive chain slack Yamaha dealer check the cause before Have a Yamaha dealer change the The drive chain slack should be further riding. brake fluid every 2 years. In addition,...
  • Page 83 Periodic maintenance and adjustment EAU74260 To adjust the drive chain slack Consult a Yamaha dealer before ad- justing the drive chain slack. 1. Loosen the axle nut and the lock- nut on each side of the swingarm. 1. Drive chain guide 1.
  • Page 84: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment 3. Tighten the axle nut, then the lock- cants for the drive chain, as they EAU23027 Cleaning and lubricating the nuts to their specified torques. may contain substances that drive chain could damage O-rings. The drive chain must be cleaned and Tightening torques: [ECA11112] Axle nut:...
  • Page 85: Checking And Lubricating The Cables

    Yamaha dealer at the intervals bricated if necessary. cated if necessary. If a cable is specified in the periodic maintenance...
  • Page 86: Checking And Lubricating The Brake And Clutch Levers

    Periodic maintenance and adjustment EAU23144 Recommended lubricant: Recommended lubricants: Checking and lubricating the Lithium-soap-based grease Brake lever: brake and clutch levers Silicone grease The operation of the brake and clutch Clutch lever: Lithium-soap-based grease levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.
  • Page 87: Checking And Lubricating The Sidestand

    The swingarm pivots must be lubricat- be checked before each ride, and the sion must be lubricated by a Yamaha ed by a Yamaha dealer at the intervals sidestand pivot and metal-to-metal dealer at the intervals specified in the specified in the periodic maintenance...
  • Page 88: Checking The Front Fork

    [EWA10752] tion. WARNING! To avoid injury, 2. Hold the lower ends of the front have a Yamaha dealer check or re- securely support the vehicle so fork legs and try to move them for- pair it.
  • Page 89: Checking The Wheel Bearings

    EWA10761 WARNING To charge the battery  Electrolyte is poisonous and Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to furic acid, which causes severe have discharged. Keep in mind that the...
  • Page 90: Replacing The Fuses

    Periodic maintenance and adjustment battery tends to discharge more quick- nect the positive lead before EAU59876 Replacing the fuses ly if the vehicle is equipped with op- connecting the negative lead. The main fuse and the fuse boxes, tional electrical accessories. [ECA16842] which contain the fuses for the individ- ECA16522...
  • Page 91 Periodic maintenance and adjustment avoid causing extensive dam- 4. If the fuse immediately blows age to the electrical system and again, have a Yamaha dealer possibly a fire. check the electrical system. [EWA15132] Specified fuses: Main fuse: 30.0 A Auxiliary fuse: 2.0 A...
  • Page 92: Vehicle Lights

    EAUM4210 Vehicle lights License plate light Supporting the motorcycle If the license plate light does not come on, have a Yamaha dealer check the electrical circuit or replace the bulb. 1. Headlight 1. Motorcycle jack 2. Auxiliary light Since this model is not equipped with a...
  • Page 93: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.
  • Page 94: Troubleshooting Chart

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 95 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.
  • Page 96: Motorcycle Care And Storage

    Be performance and extend the useful life sure to wash the underside and sure to consult a Yamaha dealer for of many components. Washing, clean- chassis parts after riding in such ing, and polishing will also give you a advice on what products to use be- areas.
  • Page 97 Motorcycle care and storage detergent applications such as 4. Pre-soak stubborn stains like in- been exposed to salt. Warm wa- those available in coin-operated sects or bird droppings with a wet ter will increase salt’s corrosive car washers. towel for a few minutes. properties.
  • Page 98 Motorcycle care and storage  If necessary, clean the brake 3. Use a chrome polish to shine 8. When finished cleaning, start the chrome, aluminum, and stainless engine and let it idle for several discs and pads with brake steel parts. Often the thermally in- minutes to help dry any remaining cleaner or acetone.
  • Page 99: Storage

    Motorcycle care and storage 1. Make all necessary repairs and b. Pour a teaspoonful of engine EAU83472 Storage perform any outstanding mainte- oil into the spark plug bore. Always store the vehicle in a cool, dry nance. c. Install the spark plug cap onto place.
  • Page 100 Motorcycle care and storage wheels a little once a month in or- der to prevent the tires from be- coming degraded in one spot. 9. Cover the muffler outlet with a plastic bag to prevent moisture from entering it. 10. Remove the battery and fully charge it, or attach a maintenance charger to keep the battery opti- mally charged.
  • Page 101: Specifications

    Specifications Dimensions: Coolant quantity: Starting system: Electric starter Overall length: Coolant reservoir (up to the maximum level Engine oil: 2370 mm (93.3 in) mark): Overall width: Recommended brand: 0.25 L (0.26 US qt, 0.22 Imp.qt) 905 mm (35.6 in) Radiator (including all routes): Overall height: 1.60 L (1.69 US qt, 1.41 Imp.qt) 1455 mm (57.3 in)
  • Page 102 Specifications Front tire: Battery: Type: Model: With tube YTZ7S Size: Voltage, capacity: 90/90-21 M/C 54V M+S A 12 V, 6.0 Ah (10 HR) Manufacturer/model: Bulb wattage: PIRELLI/SCORPION RALLY STR Headlight: Rear tire: Type: Brake/tail light: With tube Size: Front turn signal/position light: 150/70 R18 M/C 70V M+S Manufacturer/model: Rear turn signal light:...
  • Page 103: Consumer Information

    Vehicle identification number ed when registering the vehicle with the authorities in your area and when EAU26442 Engine serial number ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number ENGINE SERIAL NUMBER: The vehicle identification number is 1.
  • Page 104 This label shows specifica- mation will be needed when ordering key. tions related to exhaust emissions as spare parts from a Yamaha dealer. required by federal law, state law and Environment Canada. 11-2...
  • Page 105: Diagnostic Connector

    Consumer information EAU69910 Diagnostic connector 1. Diagnostic connector The diagnostic connector is located as shown. 11-3...
  • Page 106: Use Of Your Vehicle Data

    (3) other data showing the status of the vehicle such as diagnostic trouble code (DTC). The collected data will be uploaded to server at Yamaha Motor Co., Ltd. by attaching a special Yamaha diagnostic tool to the vehicle, only when maintenance checks or service procedures are performed.
  • Page 107 Consumer information How to contact us? Any questions or complaints regarding the processing of your vehicle data can be submitted in writing to: Yamaha Motor Canada Ltd. Attn: Privacy Officer 480 Gordon Baker Road, Toronto, Ontario, M2H 3B4 The SOLE PURPOSE of above provided contact information is TO RESPOND DATA PROCESSING INQUIRY AND OTHER KINDS OF INQUIRIES WILL NOT BE RESPONDED.
  • Page 108: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immedi- ately inform Transport Canada in addition to notifying Yamaha Motor Canada Ltd, Canada. If Transport Canada receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 109: Maintenance Record

    Consumer information EAU26643 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 110 Consumer information Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 55000 km (36000 mi) or 54 months 61000 km (40000 mi) or 60 months 11-8...
  • Page 111: Yamaha Motor Canada Ltd

    In this warranty, the term ‘MOTORCYCLE’ shall refer to a new or YZ, with the exception of WR25R, WR25X, YZ65 and YZ85 change of registration is sent to YAMAHA at the time of such motorcycle manufactured by YAMAHA MOTOR COMPANY, LTD.
  • Page 112 CUSTOMER at the time of DELIVERY. fitness for a particular purpose on the part of YAMAHA, and any other obligation or liability on behalf of YAMAHA, and the above...
  • Page 113: Index

    Index Display, main screen......5-5 Luggage strap holders......5-25 Drive chain, cleaning and lubricating ... 8-26 ABS............5-15 Drive chain slack ........8-24 ABS OFF indicator light......5-4 Main switch/steering lock....... 5-1 ABS ON button........5-4 Maintenance and lubrication, periodic ... 8-5 ABS warning light ........
  • Page 114 Index Supporting the motorcycle ....8-34 Swingarm pivots, lubricating ....8-29 Throttle grip and cable, checking and lubricating...........8-27 Throttle grip free play, checking ...8-18 Tires ............8-18 Tool kit ............8-2 Troubleshooting ........8-35 Troubleshooting chart......8-36 Turn signal switch ........5-3 Use, your vehicle data ......11-4 Valve clearance........8-18 Vehicle Emission Control Information label ............11-2...
  • Page 115 Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products. They’re formulated and approved by the toughest judges we know: the Yamaha engineering teams that know your Yamaha from the inside out.
  • Page 116 PRINTED IN JAPAN 2023.08-0.3×1 CR (E)
