- Page 1 Product User Manual 6 inch Control Panel 6”Smart Multi-functional Control Panel(in-wall)
-
Page 2: Table Of Contents
TABLE OF CONTENTS Chapter 1 Product presentations............3 1.1 Appearance.................3 Chapter 2 Product Specifications............4 PX30 Quad core Cortex-A35............4 Chapter 3 Ports and Specifications............5 3.1 Interface and ports.............. 5-6 3.2 Specifications................7 Chapter 4 Installation instructions.............8 4.1 Installation drawings............... 9 4.2 Wires connection drawing..........11 Chapter 5 Operation guideline............12 5.1 Safety Notes*****..............11 5.2 Operation guideline.............. -
Page 3: Chapter 1 Product Presentations
Chapter 1 Product presentation 1.1 Appearance 1.2 Main Features ● Fit Asian 86mm*86mm wall boxes, simple inwall installation. ● 6-inchHDLCD,IPS,multitouchscreen,quadruple microphone with noise reduction, Auto light sensor, built in 1W speaker. ● ZigBee gateway function, APP remote control. ● Control the lights, curtains, air conditioners, and all other Smart Home devices. -
Page 4: Chapter 2 Product Specifications
Chapter 2 Product Specifications... -
Page 5: Chapter 3 Ports And Specifications
Chapter 3 Ports and Specifications 3.1 Interface and ports... -
Page 7: Specifications
3.2 Specifications... -
Page 8: Chapter 4 Installation Instructions
Chapter 4 Installation instructions ● Turn off the main power in the electricity box and confirm the fire wire is not alive with a test pencil. ● Remove the base of the smart panel and install it in the wall box (as shown in the pictures following). -
Page 9: Installation Drawings
4.1 Installation drawings... -
Page 10: Wires Connection Drawing
Note: Make sure the circuit power were cut off before wire connections! Circuit breaker used as disconnected device shall be incorporated in the electrical installation of the building. Depth of the wall box should be more than 50mm. 4.2 Wires connection drawing... -
Page 11: Safety Notes
Chapter 5 Operation guideline 5.1 Safety Notes***** ●The product must be installed by professional electricians. ● Turn off the main power in the electricity box and confirm the live wire is... -
Page 12: Chapter 5 Operation Guideline
5.2 Operation guideline *This operation guideline is based on Unihoms ZigBee, Unihoms App,Unihoms cloud platform and Smatek S8E firmware. If any other platforms or firmware, please follow their operation guidelines. (1) The product will be turned on once you connect it to the power supply. - Page 13 (2) There are two options in the network settings. You can select wireless connection or wired connection. There will be a QR code showing on the screen after the network connection is done.
- Page 14 App home page, and then select the “ ”at top right corner in the App page. (3) Scan the QR code on the screen of the product to add it into the Unihoms App. You will find an S8E panel icon in your App.
- Page 15 G et into the product interface in the Unihoms App, you will （ ） see the gateway and switch icons like and .Click the switch icon to control 2 local switches (load of each switch for lamps should be no more than 200W.). It means the switch is off when the icon is in grey, and the switch is on when it is in orange.
- Page 16 LED indication light flickering which means it is in the set-up mode.) You will see the following pictures in the Unihoms App when you are adding sub devices to the gateway. Make sure the sub devices are in the set-up mode and the LED...
- Page 17 (6) Click the finish button on the App after you add the sub device successfully. For example (3 gang switch) as the following.
- Page 18 (7) You could change the name of the sub devices after they are added to the gateway successfully. (9) You could change the device type by getting into the device interface in the App. It means the switch is off when it is in grey, and the switch is on when it is in green.
- Page 19 (10) To create scenes,enter Unihoms smart App-Scene- Tap- to-Run (not Automation) - create scenes - Launch Tap-to-Run-Then -Runthedeviceandconfiguredifferent devices work at the same time as a scene. And you can rename your scenes. Swipe down and click sync to have your devices and scenes sync to panel, now one tap on panel, whole home automation.
- Page 20 If there is any questions when you add some other sub devices or scenes, please contact us for support.
