Pioneer TX-1320Z Operating Instructions Manual

Operating
Instructions
FM/AM DIGITAL SYNTHESIZER TUNER
T ——s
WM PIONEER Fwam oiral eyNTHesizen TUNER TX-1S02
=| Jk J
STEREO AMPLIFIER
be 520
WPIONEER onrrrec wounummnenscrmns Anacraan
Thank you for buying this PLONEER product. \
Please read through these operating instructions so you
5-BAND SPECTRUM ANALYZER
will know how to operate your model properly. After you
have finished reading the instructions, put them away in
a safe place for future reference.
In some countries or regions, the shape of the power plug
and power outlet may sometimes differ from that shown
in the explanatory drawings. However, the method of
connecting and operating the unit is the same.
WARNING: To preveENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT NOTICE
[For U.S. and Canadian models]
The serial number for this equipment is located on the rear panel. Please
write this serial number on your enclosed warranty card and keep it in
a secure area. This is for your security.
{For Canadian model]
CAUTION: to prevent ELECTRIC SHOCK DO NOT USE
THIS (POLARIZED) PLUG WITH AN EXTENSION CORD. RECEPTACLE
OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED
TO PREVENT BLADE EXPOSURE.
ATTENTION: pour prevenir LES CHOCS ELECTRIQUES
NE PAS UTILISER CETTE FICHE POLARISEE AVEC UN
PROLONGATEUR UNE PRISE DE COURANT OU UNE AUTRE SORTIE
DE COURANT, SAUF SI LES LAMES PEUVENT ETRE INSEREES A
FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT.
@Q PIONEER' 4
° o aa tad re) °
(—l-l-I-[-
HIGH POWER REMOTE SYSTEM
i
Illustration is U.S., Canadian models.
LINE VOLTAGE SELECTOR SWITCHES
Only multi-voltage models are provided with these switches. U.S. and
Canadian models are not provided with these switches.
Mains voltages in Saudi Arabia are 127 V and 220 V only. Never use
this model with 110 V setting in Saudi Arabia.
The line voltage selector switches are on the rear panel. Before your
model is shipped from the factory, these switches are set to the power
requirements of the destination. Check that ther are set properly before
plugging the power cord into the AC wall socket. If the voltage is not
properly set or if you move to an area where the voltage requirements
differ, adjust the selector switches as follows.
1. Use a medium-size screwdriver.
2. Insert the screwdriver into the groove on the voltage selector, and
adjust so that the tip of the arrow points to the voltage value of your
area.
Set the voltage selector ee eT ae
for the voltage in your
area.
120V-127V
1 27V— im 220V-240V
ee
Medium-size
screwdriver
