- Page 1 P3AG-4812-13ENZ0 Fujitsu Storage ETERNUS AB series All-Flash Arrays, ETERNUS HB series Hybrid Arrays Site Planning Guide Requirements for transportation/installation...
-
Page 2: Table Of Contents
Circuit Protectors ................................44 Input Power Supply Lines ...............................48 2. Rack Installation Specifications ........50 Rack Installation Requirements ...................... 50 Placement in the Rack ..............................50 Cable Connection ................................51 Installable Racks ........................... 53 Fujitsu Racks ..................................53 Non-Fujitsu Racks ................................54 Site Planning Guide... - Page 3 List of Figures Figure 1 2.5" Type Controller Shelf Dimensions (ETERNUS AB2100, AB5100, ETERNUS HB1200/HB2200, HB5100) ........................ 24 Figure 2 2.5" Type Controller Shelf Dimensions (ETERNUS AB3100, AB6100)............ 24 Figure 3 3.5" Type Controller Shelf Dimensions (ETERNUS HB1100/HB2100) ............ 25 Figure 4 3.5"...
- Page 4 List of Tables Table 1 Installation Specifications (ETERNUS AB2100/AB3100) ................8 Table 2 Sound Level of the Drive Shelf..........................10 Table 3 Efficiency and Power Factor of the Power Supply Unit ................10 Table 4 Installation Specifications (ETERNUS AB5100/AB6100) ................10 Table 5 Sound Level of the Drive Shelf..........................
- Page 5 Preface Fujitsu would like to thank you for purchasing the Fujitsu Storage ETERNUS AB2100/AB3100, ETER- NUS AB5100/AB6100 All-Flash Arrays and the ETERNUS HB1100/HB1200/HB2100/HB2200/HB2300, ETERNUS HB5100/HB5200 Hybrid Arrays (hereinafter referred to as ETERNUS AB/HB). The ETERNUS AB/HB is designed to be connected to Fujitsu servers (Fujitsu SPARC Servers, PRIMEQUEST, PRIMERGY, and other servers) or non-Fujitsu servers.
- Page 6 Preface Trademarks Third-party trademark information related to this product is available at: https://www.fujitsu.com/global/products/computing/storage/eternus/trademarks.html About This Manual Intended Audience This manual is intended for managers of facilities where the ETERNUS AB/HB is installed. Related Information and Documents The latest information for your model is available at: https://www.fujitsu.com/global/support/products/computing/storage/manuals-list.html...
- Page 7 Preface Warning Signs Warning signs are shown throughout this manual in order to prevent injury to the user and/or mate- rial damage. These signs are composed of a symbol and a message describing the recommended level of caution. The following explains the symbol, its level of caution, and its meaning as used in this manual.
-
Page 8: Eternus Ab/Hb Installation
ETERNUS AB/HB Installation This chapter provides the installation specification of the ETERNUS AB/HB. Installation Specifications • ETERNUS AB series All-Flash Arrays "ETERNUS AB2100/AB3100" (page 8) "ETERNUS AB5100/AB6100" (page 10) • ETERNUS HB series Hybrid Arrays "ETERNUS HB1100/HB1200" (page 13) "ETERNUS HB2100/HB2200" (page 15) "ETERNUS HB2300"... - Page 9 ETERNUS AB/HB Installation Installation Specifications Item ETERNUS AB2100 ETERNUS AB3100 Maximum Controller 2.5" type AC100 – 120V 659 W (665 VA) power shelf AC200 – 240V 659 W (665 VA) 953 W (964 VA) consumption Drive shelf DE224C AC100 – 120V 375 W (379 VA) (*2) 2.5"...
-
Page 10: Eternus Ab5100/Ab6100
ETERNUS AB/HB Installation Installation Specifications A 2U power distribution unit is composed of two 1U power distribution units. These values are for each shelf when 24 drives are installed. The value in the parentheses for the controller shelf and drive shelves includes the mass of the rack rail kit. These values are for the maximum load when all the available options are installed in an ETERNUS AB/HB. - Page 11 ETERNUS AB/HB Installation Installation Specifications Item ETERNUS AB5100 ETERNUS AB6100 Maximum 2.5" type controller shelf 23.5 kg (27.5 kg) 27.4 kg (31.4 kg) weight (*2) DE224C 2.5" type drive shelf 22.9 kg (26.9 kg) 22.9 kg (26.9 kg) (*3) DE212C 3.5" type drive shelf 27.6 kg (31.6 kg) DE460C 60-drive type drive shelf 106.4 kg (110.4 kg)
-
Page 12: Table 5 Sound Level Of The Drive Shelf
ETERNUS AB/HB Installation Installation Specifications Item ETERNUS AB5100 ETERNUS AB6100 Environmental Temperature Operating 5 – 40 °C (*5) 10 – 35 °C (*6) conditions Not operating -40 – 70 °C During shipment -40 – 70 °C Temperature gradient 15 °C/Hr or less Humidity Operating 8 –... -
Page 13: Eternus Hb1100/Hb1200
ETERNUS AB/HB Installation Installation Specifications ETERNUS HB1100/HB1200 Each installation specification is shown below. • Installation specifications: Table 7 • Sound level of the drive shelf: Table 8 • Efficiency and the power factor of the power supply unit: Table 9 Table 7 Installation Specifications (ETERNUS HB1100/HB1200) Item... -
Page 14: Table 8 Sound Level Of The Drive Shelf
ETERNUS AB/HB Installation Installation Specifications Item ETERNUS HB1100 ETERNUS HB1200 Maximum Controller shelf amount of Drive shelf exhaust air Environmental Temperature Operating 5 – 45 °C (*5) 5 – 40 °C (*6) conditions Not operating -40 – 70 °C During shipment -40 –... -
Page 15: Eternus Hb2100/Hb2200
ETERNUS AB/HB Installation Installation Specifications Table 9 Efficiency and Power Factor of the Power Supply Unit Component name Efficiency Power factor 80PLUS® Output Shelf 20 % (*1) 50 % (*1) 100 % (*1) 50 % (*1) ETERNUS HB1100 Platinum 91.8 % 94.2 % 92.7 % 0.980... - Page 16 ETERNUS AB/HB Installation Installation Specifications Item ETERNUS HB2100 ETERNUS HB2200 Maximum Controller 3.5" type AC100 – 120V 565 W (568 VA) power shelf AC200 – 240V 565 W (568 VA) consumption 2.5" type AC100 – 120V 674 W (674 VA) (*2) AC200 –...
-
Page 17: Table 11 Sound Level Of The Drive Shelf
ETERNUS AB/HB Installation Installation Specifications Item ETERNUS HB2100 ETERNUS HB2200 Environmental Temperature Operating 5 – 45 °C (*5) 5 – 40 °C (*6) conditions Not operating -40 – 70 °C During shipment -40 – 70 °C Temperature gradient 15 °C/Hr or less Humidity Operating 8 –... -
Page 18: Eternus Hb2300
ETERNUS AB/HB Installation Installation Specifications Indicates the rated load against the rated output of the PSU. ETERNUS HB2300 Each installation specification is shown below. • Installation specifications: Table 13 • Sound level of the drive shelf: Table 14 • Efficiency and the power factor of the power supply unit: Table 15 Table 13 Installation Specifications (ETERNUS HB2300) - Page 19 ETERNUS AB/HB Installation Installation Specifications Item ETERNUS HB2300 Maximum Controller 3.5" type AC100 – 120V heat shelf AC200 – 240V 5,533 kJ/h generation Drive shelf DE212C AC100 – 120V (*2) 3.5" type AC200 – 240V 1,237 kJ/h DE224C AC100 – 120V 2.5"...
-
Page 20: Eternus Hb5100/Hb5200
ETERNUS AB/HB Installation Installation Specifications Table 14 Sound Level of the Drive Shelf DE212C DE224C DE460C Sound pressure level 64 dBA 51 dBA 72 dBA Sound power level 6.4 B 6.7 B 7.2 B Table 15 Efficiency and Power Factor of the Power Supply Unit Component name Efficiency Power factor... - Page 21 ETERNUS AB/HB Installation Installation Specifications Item ETERNUS HB5100 ETERNUS HB5200 Maximum Controller 3.5" type AC100 – 120V power shelf AC200 – 240V 1,777 W (1,793 VA) consumption 2.5" type AC100 – 120V 694 W (701 VA) (*2) AC200 – 240V 694 W (701 VA) Drive shelf DE224C...
-
Page 22: 19-Inch Racks
ETERNUS AB/HB Installation Installation Specifications Item ETERNUS HB5100 ETERNUS HB5200 Noise Sound pressure level 51 dBA 72 dBA emission (*6) Sound power level 6.7 B 7.2 B A power distribution unit is composed of two 1U power distribution units. These values are for each shelf when 24 drives are installed in a 2.5" type shelf, 12 drives are installed in a 3.5"... -
Page 23: Table 20 19-Inch Wide Rack Installation Specifications
ETERNUS AB/HB Installation Installation Specifications Table 20 19-inch Wide Rack Installation Specifications Specification Item Base rack Expansion rack Dimensions (W D H) 800 1,200 2,000 mm 800 1,432 2,000 mm (including anti-tipping stabilizer) Maximum weight 155 kg 125 kg Service area (including a space for... -
Page 24: Eternus Ab/Hb Dimensions
ETERNUS AB/HB Installation ETERNUS AB/HB Dimensions ETERNUS AB/HB Dimensions ■ Controller Shelf Dimensions The following diagrams show the dimensions of a controller shelf. The dimensions are approximations and do not include protruding parts. ● 2.5" Type Controller Shelf Figure 1 2.5"... -
Page 25: Figure 1 2.5" Type Controller Shelf Dimensions
ETERNUS AB/HB Installation ETERNUS AB/HB Dimensions ● 3.5" Type Controller Shelf Figure 3 3.5" Type Controller Shelf Dimensions (ETERNUS HB1100/HB2100) 447 mm (without the flanges) 505 mm 87 mm 480 mm (with the flanges) ● 3.5" Type 4U Controller Shelf Figure 4 3.5"... -
Page 26: Figure 5 3.5" Type 4U Controller Shelf Dimensions (Eternus Hb5200)
ETERNUS AB/HB Installation ETERNUS AB/HB Dimensions Figure 5 3.5" Type 4U Controller Shelf Dimensions (ETERNUS HB5200) 449 mm (without the flanges) 922 mm 176 mm 482 mm (with the flanges) ■ Drive Shelf Dimensions The diagrams below show the dimensions of a drive shelf. The dimensions are approximations and do not include protruding parts. -
Page 27: Figure 7 De212C 3.5" Type Drive Shelf Dimensions
ETERNUS AB/HB Installation ETERNUS AB/HB Dimensions ● DE212C 3.5" Type Drive Shelf Figure 7 DE212C 3.5" Type Drive Shelf Dimensions 447 mm (without the flanges) 505 mm 87 mm 480 mm (with the flanges) ● DE460C 60-Drive Type Drive Shelf Figure 8 DE460C 60-Drive Type Drive Shelf Dimensions 449 mm (without the flanges) -
Page 28: Rack Dimensions
ETERNUS AB/HB Installation Rack Dimensions Rack Dimensions The following diagrams show the dimensions of a 19-inch rack and an anti-tipping stabilizer. The dimensions are approximations and do not include protruding parts. For specification information that is required for securing a rack, refer to Figure 16 under "Installation... -
Page 29: Figure 10 19-Inch Rack Internal Dimensions (Horizontal Cross Section)
ETERNUS AB/HB Installation Rack Dimensions Figure 10 19-inch Rack Internal Dimensions (Horizontal Cross Section) 69.8 919.4 60.8 88.5 Leveling feet Caster 88.5 163.2 732.6 154.2 Site Planning Guide... -
Page 30: Figure 11 19-Inch Wide Rack Dimensions
ETERNUS AB/HB Installation Rack Dimensions Figure 11 19-inch Wide Rack Dimensions 800 mm 1,200 mm Front Side Rear Bottom Site Planning Guide... -
Page 31: Figure 12 19-Inch Wide Rack Internal Dimensions (Horizontal Cross Section)
ETERNUS AB/HB Installation Rack Dimensions Figure 12 19-inch Wide Rack Internal Dimensions (Horizontal Cross Section) (*1) (*1) (761) 465 r 1.6 450.5 (435) (*2) (*3) 740 r 2 (346) (*1) 1,186 (*1) Holes for fixing the storage system to the rack (size: 9.5mm square hole, universal pitch) Pitch of holes for fixing the storage system to the rack Inside the rack Figure 13 Anti-Tipping Stabilizer Dimensions... -
Page 32: Compliance Standards
ETERNUS AB/HB Installation Compliance Standards Compliance Standards ● About Compliance Standards • Product safety EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005, 2nd Edition + A1:2009 + A2:2013 ANSI/UL 60950-1:2014 CAN/CSA-C22.2 No 60950-1-07, + A1:2011 + A2:2014 EN 62368-1:2014 + A11:2017 IEC 62368-1:2014 IANSI/UL 62368-1, 2nd Edition... -
Page 33: Package Size
ETERNUS AB/HB Installation Package Size Package Size The ETERNUS AB/HB is shipped in cardboard boxes or in a rack. These boxes may not fit through some doorways or elevators. To make sure that the ETERNUS AB/HB can be moved to the installa- tion site, carefully check the transport route information. -
Page 34: Installation Area
Installation Area This section explains the installation areas and the service areas that are required for an ETERNUS AB/HB that is installed in a Fujitsu 19-inch rack. Secure service areas in the front and rear of the 19-inch rack. Figure 14 Installation Area and Service Area (When the Lifter Is Not Used) -
Page 35: Figure 15 Installation Area And Service Area (When The Lifter Is Used)
ETERNUS AB/HB Installation Installation Area When 4U controller shelves or DE460C drive shelves (60-drive) are installed in a rack or being main- tained, temporary space is required to use the lifter around the rack. Figure 15 Installation Area and Service Area (When the Lifter Is Used) Rear 850 mm or more service area... -
Page 36: Installation Environment
ETERNUS AB/HB Installation Installation Environment Installation Environment Sufficient consideration of the installation environment should be taken to ensure proper use of the ETERNUS AB/HB. Using the ETERNUS AB/HB in an environment that does not satisfy the installation environment requirements may cause a failure to occur with the ETERNUS AB/HB. Air Conditioning It is important to consider the flows of cooling air (intake air and exhaust air) for the installation loca- tion of the ETERNUS AB/HB. -
Page 37: Installation Methods
ETERNUS AB/HB Installation Installation Environment Installation Methods • Perform one of the following rack installation methods to ensure the safe use of an ETERNUS AB/ HB that is installed in a rack: To secure a rack, use a rack without stabilizers and secure it to the building with the leveling feet. -
Page 38: Load Bearing Capacity For Floors
ETERNUS AB/HB Installation Installation Environment Figure 17 Floor Dimensions of the Rack (of 19-inch Wide Racks) 53.2 mm 1,093.6 mm (leveling feet) 146.6 906.8 mm (caster) Front Rear 1,200 mm Caster Leveling feet Cable slot Load Bearing Capacity for Floors Make sure that the following relationship between the load bearing capacity of the floor and the weight of the ETERNUS AB/HB is maintained. -
Page 39: Outlet/Socket Specifications
ETERNUS AB/HB Installation Outlet/Socket Specifications Outlet/Socket Specifications This section explains the power connection specifications of the ETERNUS AB/HB storage systems. ■ Power Supply Units The ETERNUS AB/HB has multiple power supply units in each of its shelf. Using the same power requirements for all the power supply units is recommended so that the power requirements (use of power distribution units and input voltage) do not vary in the ETERNUS AB/HB. -
Page 40: Specifications For Optional Power Supply Products
ETERNUS AB/HB Installation Outlet/Socket Specifications Specifications for Optional Power Supply Products This section explains the specifications of optional power cords and power related optional prod- ucts for the ETERNUS AB/HB. When using power distribution units, take the number of outlets required to connect each shelf into consideration to select the most appropriate power distribution units. -
Page 41: Table 26 Specifications For Ac100V Power Cords (Iec60320 C13 - Nema 5-15P)
ETERNUS AB/HB Installation Outlet/Socket Specifications ■ AC100V Power Cords AC100V power cords are used to connect devices to the NEMA 5-15R power socket type. These power cords can be used if the specifications of the connection device allow AC100V. Table 26 Specifications for AC100V Power Cords (IEC60320 C13 - NEMA 5-15P) Plug type Socket type Power cord... -
Page 42: Figure 18 Power Distribution Unit (Ac24A/200V, 2U, 16 Outlets)
ETERNUS AB/HB Installation Outlet/Socket Specifications ■ Power Distribution Unit (AC24A/200V, 2U, 16 Outlets) There are 16 outlets and two inlets. Estimate the maximum current consumption to supply power to all the connected devices using one of the modules of the power distribution unit. Figure 18 Power Distribution Unit (AC24A/200V, 2U, 16 Outlets) Two inlets Sixteen outlets... -
Page 43: Figure 19 Power Distribution Unit (Ac24A/200V, 2U, Six Outlets)
ETERNUS AB/HB Installation Outlet/Socket Specifications ■ Power Distribution Unit (AC24A/200V, 2U, Six Outlets) There are six outlets and two inlets. Estimate the maximum current consumption to supply power to all the connected devices using one of the modules of the power distribution unit. Figure 19 Power Distribution Unit (AC24A/200V, 2U, Six Outlets) Two inlets Six outlets... -
Page 44: Required Number Of Outlets/Sockets
ETERNUS AB/HB Installation Outlet/Socket Specifications Required Number of Outlets/Sockets The number of power outlets/sockets required to install the ETERNUS AB/HB depends on the num- ber of shelves and power distribution units. It is recommended that the power cords of the shelves are connected to the power distribution units that are installed in the same rack. -
Page 45: Figure 20 Breaking Characteristics Of Distribution Board Circuit Protectors
ETERNUS AB/HB Installation Outlet/Socket Specifications ■ Breaking Characteristics The breaking characteristics (*1) of the distribution board circuit protectors must be the long-time delay type and must be equivalent to or slower than the D (IEC/EN60898-1) shown in Figure If the distribution board's circuit protectors have a breaking characteristic that is faster than D, the breaker may trip when a power supply unit in the storage system fails. -
Page 46: Figure 21 Example Of A Power Supply Connection When A Power Distribution Unit (Six Outlets) Is Used
ETERNUS AB/HB Installation Outlet/Socket Specifications ■ Connection Diagrams The following diagrams show connections between the power distribution units, the ETERNUS AB/ HB and the power sockets of the distribution boards. Do not connect just one power distribution unit to multiple ETERNUS storage systems. In addition, do not connect just one circuit protector of a power distribution unit to multiple ETERNUS storage systems. -
Page 47: Figure 22 Example Of A Power Supply Connection When A Power Distribution Unit (16 Outlets) Is Used
ETERNUS AB/HB Installation Outlet/Socket Specifications ● For Power Distribution Unit (16 Outlets) Connections The following diagram shows an example of a power supply connection when a power distribu- tion unit (16 outlets) is used. Current consumption of each outlet: 10A or less Current consumption of each CP (four outlets: OUT1 to OUT4, or OUT5 to OUT8): 12A or less Current consumption of each inlet cable: 24A or less Figure 22 Example of a Power Supply Connection When a Power Distribution Unit (16 Outlets) Is... -
Page 48: Input Power Supply Lines
ETERNUS AB/HB Installation Outlet/Socket Specifications ● For Direct (No Power Distribution Unit) Connections The following diagram shows a power supply connection example when no power distribution units are used. Figure 23 Example of a Power Supply Connection When a Power Distribution Unit Is Not Used ETERNUS Drive shelf Drive shelf... -
Page 49: Figure 25 Single-Line Power Supply (When Connecting To Power Sockets)
ETERNUS AB/HB Installation Outlet/Socket Specifications Figure 25 Single-Line Power Supply (When Connecting to Power Sockets) Power distribution unit ETERNUS Line 0 Figure 26 Single-Line Power Supply (When Connecting to a UPS Unit) Power distribution unit ETERNUS Line 0 When the power distribution units are separately connected to line 0 (PSU#0) and line 1 (PSU#1), the availability of the power supply facilities is improved. -
Page 50: Rack Installation Specifications
Rack Installation Specifications This chapter provides the installation specification of the ETERNUS AB/HB. Rack Installation Requirements This section explains the requirements for installing the ETERNUS AB/HB in a 19-inch rack. Placement in the Rack Note the following when installing the ETERNUS AB/HB in the rack. •... -
Page 51: Cable Connection
Rack Installation Specifications Rack Installation Requirements Cable Connection Cable Connection (Power) This section explains the requirements for connecting a power distribution unit with the ETERNUS AB/HB. ● Power Distribution Units (2U, 16 Outlets, 24A) • For each power distribution unit, the total current capacity of the current consumption value of the power cords that connect from outlets OUT1 to OUT8 must be 24A or less. -
Page 52: Figure 27 Cable Connection (Mini Sas Hd Cable)
Rack Installation Specifications Rack Installation Requirements Cable Connection (Mini SAS HD Cable) Mini SAS HD cables are used to connect between shelves in the ETERNUS AB/HB. Four (2 m) are provided with each drive shelf. For extended connections, 5 m cables are available. To connect between shelves across racks, use 5 m cables. -
Page 53: Installable Racks
Because the depth is larger than other shelves, install the shelf in a 19-inch rack designated by Fujitsu or a rack with a rack space of 922 mm (external depth of the drive shelf) plus an additional 100 mm or more cable area. -
Page 54: Non-Fujitsu Racks
Any problem that may occur by installing the ETERNUS AB/ HB in non-Fujitsu racks is not covered by the warranty. If the ETERNUS AB/HB needs to be installed in a non-Fujitsu rack, the following conditions must be satisfied. - Page 55 Rack Installation Specifications Installable Racks Specification Condition Rack space The depth of the shelf body (*1) + 100 mm (Space between the fixed part of the ETERNUS or more (recommended for the extra AB/HB on the front side and the rear of the rack) cable length) Rack mount kit installation area 483 mm or more (recommended)
- Page 56 However, Fujitsu shall assume no responsibility for any operational problems as the result of errors, omissions, or the use of information in this manual. • Fujitsu assumes no liability for damages to third party copyrights or other rights arising from the use of any information in this manual. •...
