Sanyo VHR-757G Service Manual

FILE NO.
SANYO
SERVICE MANUAL
Video Cassette Recorder
VHR-757G
(Product Code : 143 171 65)
(Switzerland & Italy)
VHR-757EX
(Product Code : 143 171 64)
(Europe)
VHR-757NL
(Product Code : 143 171 66)
(Netherlands)
VHR-777EV
(Product Code : 143 171 67)
(Europe)
(VHR-757G, VHR-757EX, VHR-757NL) VHS V H R 777 EX
=
an (Product Code : 143 171 23)
CONTENTS (Europe)
SELF-DIAGNOSIS DISPLAY cssscscccscsssseccesssssssesenssesesnseseveneee 2 V - R-797 S P
1. DISASSEMBLY .....ccccccccccsssccsecssescecsesessucssesecssuessessnessuseneeness 5
2. ELECTRICAL ADJUSTMENT .....scssssssssssssssesscssssessessseeeesnes 9 (Product Code : 143 171 12)
3. TEST POINTS FOR TAPE PATH ADJUSTMENT ...........+. 13
(Spain & Portugal)
4. PARTS LIST Please see other materials with Reference
MECHANISM PARTS .....csscsscsseecsseecsescsvsesseceseessesssseesseesseens 14 number given in table below.
CABINET & CHASSIS PARTS ...cccescccssscsscsesesseesseessecesseenes 16
ELECTRICAL PARTS ..cccccessccoscsccusecsnscccssseccuccscneecsneecosecese 17 | Materials | Model No.
ACCESSORIES ....cccccsscesssescseccuscccconesueesuscuessasessesaseoneseeeene 27 V95 |
PACKING MATERIALS cccsssssssssssssssssssssscssssesescssescescssseseeeee 27 KiSchanicn'l'Mechanaml ee
CIRCUIT DIAGRAMS (Refer to the separate volume) Manual | V95 II aaesaees
Mechanism 5315
PRODUCT SAFETY NOTICE
The components designated by a symbol (/\\) in this schematic diagram designates components whose value are of special
significance to product safety. Should any component designated by a symbol need to be replaced, use only the part designated
in the parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
NOTE: 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N.S.P. : Not available as service parts.
Design and specifications are subject to change without notice.
REFERENCE No.SM531579
MP4H/G5, EX5, NL5, EV3, EX3, SP
