- Page 1 For detection: Seal Type Switches ABV ( BV ) Turquoise Switches Product Catalog 2022.4...
-
Page 2: Typical Applications
6: Wire leads 1: AgNi alloy + Auclad Note) Not every combination is available. Please refer to the following table, “PRODUCT TYPES” . Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 1 ー AECTB7E 202204 Panasonic Industry Co., Ltd. 2022... - Page 3 ABV163650 Notes: 1. For items with international safety certification, please put “3” in the tenth digit of the part number when ordering. 2. Push plunger color: black Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 2 ー AECTB7E 202204 Panasonic Industry Co., Ltd.
- Page 4 Notes: 1. For items with international safety certification, please put “3” in the tenth digit of the part number when ordering. 2. Push plunger color: dark red Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 3 ー AECTB7E 202204 Panasonic Industry Co., Ltd.
-
Page 5: Specifications
15 V 250 V Note) The diagram above is intended as a reference. Please use the product within the rated voltage and current. Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 4 ー AECTB7E 202204 Panasonic Industry Co., Ltd. 2022... - Page 6 Pretravel (PT) Max. 3.2 mm Movement Differential (MD) Max. 1.2 mm Overtravel (OT) Min. 1.2 mm Operating Position (OP) 15.3±1.2 mm Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 5 ー AECTB7E 202204 Panasonic Industry Co., Ltd. 2022 industrial.panasonic.com/ac/e/...
- Page 7 Pretravel (PT) Max. 3.2 mm Movement Differential (MD) Max. 1.2 mm Overtravel (OT) Min. 1.2 mm Operating Position (OP) 20.7±1.2 mm Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 6 ー AECTB7E 202204 Panasonic Industry Co., Ltd. 2022 industrial.panasonic.com/ac/e/...
- Page 8 * With UL and CSA approved products, lead wire is changed to UL compliant (AWG18). Please refer to "the latest product specifications" when designing your product. •Requests to customers: https://industrial.panasonic.com/ac/e/salespolicies/ Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 7 ー AECTB7E 202204 Panasonic Industry Co., Ltd. 2022 industrial.panasonic.com/ac/e/...
- Page 9 Allow for up to 20% variation of the specified characteristics values to compensate for long term operational wear of the switch in your design. Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 8 ー AECTB35E 202204 Panasonic Industry Co., Ltd. 2022...
- Page 10 Please contact us if cleaning is necessary. 1000 Standard value 30 minutes 8 10 12 14 16 18 20 22 24 Elapsed time (h) Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 9 ー AECTB35E 202204 Panasonic Industry Co., Ltd. 2022 industrial.panasonic.com/ac/e/...
- Page 11 Underwater type Unit can be used underwater Note: Details of test conditions are the same as NECA C 0920. Please refer to them. Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 10 ー AECTB35E 202204 Panasonic Industry Co., Ltd. 2022...
-
Page 12: Technical Terminology
Malfunction shock ... Shock range where a closed contact does not open for longer than a specified time due to shocks during use of the snap-action switches. Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 11 ー AECTB36E 202204 Panasonic Industry Co., Ltd. - Page 13 Position degree position to its original position. Total travel The stopping position of the actuator after Position degree total travel. Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 12 ー AECTB36E 202204 Panasonic Industry Co., Ltd. 2022 industrial.panasonic.com/ac/e/...
- Page 14 8) If snap-action switch operation is synchronized with the AC supply phase, this may cause: shortened electrical life, contact fusion failure, contact transfer, or other reliability problems. Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 13 ー AECTB36E 202204 Panasonic Industry Co., Ltd.
- Page 15 Varistor Load 3) Avoid circuits which apply voltage between contacts. (This may lead to mixed deposition.) Wrong 200 V 100 V Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 14 ー AECTB36E 202204 Panasonic Industry Co., Ltd. 2022 industrial.panasonic.com/ac/e/...
- Page 16 OP Min - 100% of OT = 8.0 - 1.2 = 6.80 mm The plunger/lever should be pressed down to the position of 6.80 to 7.16 mm from the mounting hole. Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 15 ー AECTB36E 202204 Panasonic Industry Co., Ltd.
-
Page 17: Ambient Temperature
In terms of the packing format used, make every effort to keep the effects of moisture, organic gases and sulfide gases to the absolute minimum. Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 16 ー AECTB36E 202204 Panasonic Industry Co., Ltd. 2022... - Page 18 Possible lever The force required for pin plunger action is lighter than that of the lever, and the stroke is longer. Panasonic Industry Co., Ltd. Electromechanical Control Business Division ー 17 ー AECTB36E 202204 Panasonic Industry Co., Ltd. 2022 industrial.panasonic.com/ac/e/...
- Page 19 Electromechanical Control Business Division 1006, Oaza Kadoma, Kadoma-shi, Osaka 571-8506, Japan industral.panasonic.com/ac/e/ Specifications are subject to change without notice. 2022.4 ©Panasonic Industry Co., Ltd. 2022 AECTB7E 202204...
