Pioneer RC310TG Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Instructions
Remote Buttons Overview
Button
Turns the air conditioner on or off
Decreases set temperature, set timing,
TEMP
or navigates the functional menu
Increases set temperature, set timing,
TEMP
or navigates the functional menu
Selects the mode of operation (Auto,
MODE
Cool, Dry, Fan, and Heat modes)
Activates/deactivates the ECO feature
ECO
Long press to activate the 46°F "Away
from Home" freeze protection setting.
Activates/deactivates the TURBO
TURBO
feature, which allows the system to
reach set temperatures quicker
Configures the fan speed
FAN
(Auto, Low, Mid, and High)
TIMER
Configures the automatic on/off times
SLEEP
Toggles the system's Sleep Mode
Turns the LED display on or off
DISPLAY
Activates the up-down louver motor
SWING
Activates the left-right louver motor
SWING
I FEEL
Activates the system's Follow Me mode
Puts the system into silent mode
MUTE
LOCK
Press MODE+TIMER for child-lock
The display and some features of the remote control may
vary according to the model of the system.
The shape and positions of the buttons and indicators may
vary according to the model of the system, but the features
and functionality would remain the same.
The unit will confirm the successful reception of each button
command with a beep.
Description

Advertisement

Table of Contents
loading

Related Manuals for Pioneer RC310TG

Summary of Contents for Pioneer RC310TG

  • Page 1 Operating Instructions Remote Buttons Overview Button Description Turns the air conditioner on or off Decreases set temperature, set timing, TEMP or navigates the functional menu Increases set temperature, set timing, TEMP or navigates the functional menu Selects the mode of operation (Auto, MODE Cool, Dry, Fan, and Heat modes) Activates/deactivates the ECO feature...
  • Page 2 Operating Instructions Remote Controller LED Screen and Icons 4 5 6 7 8 9 10 Description Description Icon Icon Temperature Indicator Directional Swing Indicators Unit of Temperature (°C/°F) I Feel/Follow Me Mode Turbo Mode Gentle Wind (Some Models) Signal Transmit Indicator Child Lock Indicator Auto Mode Fan Speed (Auto or Fixed)

  • Page 3: Replacement Of Batteries

    Operating Instructions Replacement of Batteries Remove the battery cover from the rear of the remote controller, by sliding it downward in the direction of the arrow as depicted below. Install batteries according to the depicted directions (+ and -) as shown on the remote controlller. The cover then slides back into place. Use 2x AAA batteries.
  • Page 4 Operating Instructions Regarding the Airflow of the Indoor Unit Filter The air that is pulled in by the fan (the “return air”) enters the grille and is passed through the filter. It is then Heat cooled/dehumidified/heated through the heat exchanger. The direction of the air output is manipulated up and down by the motorized louver, and left to right via manually controlled vertical deflectors.

  • Page 5: Cooling Mode

    Operating Instructions COOLING Mode Cooling mode allows the air conditioner to cool the room while also reducing the humidity of the air in the room. To put the system into cooling mode, press the button until the symbol appears on the remote’s display. buttons can then be used to set a temperature lower than that of the room.

  • Page 6: Dry Mode

    Operating Instructions DRY Mode Dry mode is a limited function that can rapidly reduce the humidity/moisture of the room. To put the system into dry mode, press the button until the symbol appears on the remote’s display. An automatic preset of this mode is then activated.

  • Page 7: Turning The Display On Or Off

    Operating Instructions Turning the Display On or Off The LED display on the front panel of the system can be turned on or off as desired. To do so, press the button in order to switch off the LED display on the front panel. This button can be pressed again to turn the LED display back on.

  • Page 8: Child Lock Function

    Operating Instructions Energy Saver (ECO) Option In this mode, the appliance will automatically manage the operation in order to save energy. To turn the ECO feature on, press the button on the remote, and the icon will appear. The system is now running in ECO, and the process can be repeated to turn it off.
  • Page 9 Operating Instructions Using the Timer - TIMER ON The TIMER feature allows you to set a time delay for the system to turn itself on or off. To set a time delay for the system to turn itself on in X amount of hours: 1.

  • Page 10: Mute Mode

    Operating Instructions 46°F Freeze Protection Function This feature is meant to be used to prevent freezing while the user is away from home. When turned on, it sets the system to keep a temperature of 46°F. If the unit is in standby, then the setting will automatically start the heating mode when the room temperature is equal to or lower than 46°F.

  • Page 11: Self-Clean Feature

    Operating Instructions I FEEL - To Ensure Comfort The I FEEL feature enables the remote to act as the temperature sensor and relay the current air temperature of where the remote is physically placed within the room. In some cases, this can aid with reducing thermal drift between the set temperature and the actual room temperature.
