Sharp PN-ZK10 Operation Manual

Main specifications
Model PN-ZK10
Dimensions See the figure below.
Weight Approx. 23 kg (50.7 lbs.) (Weight includes two mounting brackets and bolts)
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement
without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from
these values in individual units.
116 (4 /
9
16
Unit: mm (inch)
(The figure shows the approximate values.)
) 97 (3 / )
13
16
Printed in Japan
- 4 -
Operation Manual
Mounting Bracket
Applicable models (as of July 2008) LCD MONITOR LB-1085
•
Thank you for purchasing a SHARP product.
Before using the product, please be sure to read this operation manual carefully. In particular, be sure to read the
section "To ensure safe and correct use". After reading the manual, keep it in a convenient location where it can be
accessed at any time.
TIPS
- Please understand that Sharp Corporation bears no responsibility for errors made during use by the customer or a third party,
nor for any other malfunctions or damage to this product arising during use, except where indemnity liability is recognized
under law.
- This product and its accessories may be upgraded without advance notice.
To ensure safe and correct use
This operation manual and the product use various displays and labels to ensure safe use. Ignoring these displays and labels
and incorrectly using the product could have results as classified below.
Please read the following warning symbol information before reading the rest of this section, and be sure to strictly observe all
instructions.
Warning:
Not following these instructions could result in death or serious injury.
• The installation must be performed by qualified service personnel.
Improper installation work may cause the monitor to fall or topple over, resulting in injury.
• Only use the accessories with specified models. Do not modify the LCD Monitor or the accessories.
Otherwise, the monitor may fall or topple over, resulting in injury.
• Install the LCD Monitor in a location with minimal vibration and that is strong enough to hold the weight of
the LCD Monitor and mounting brackets.
Otherwise, the monitor may fall or topple over, resulting in injury.
• Do not apply a load other than the LCD Monitor to the mounting brackets.
Otherwise, the monitor may fall or topple over, resulting in injury.
Caution:
Not following these instructions could result in injury or property damage.
• Tighten all the screws and bolts fully and securely.
Insufficient tightening may cause the monitor to fall or topple over, resulting in injury.
• When any deformation or cracks are found please stop using the LCD Monitor.
Using the monitor without repairing the problem may cause the monitor to fall or topple over, resulting in injury.
EN(1)
Get other manuals https://www.bkmanuals.com
PN-ZK10
- 1 -
