No.
LED
ACT
WAN2/ WAN1
QoS
USB
(1)
Phone1/
Phone2
2.4G/ 5G
(2)
WAN1, WAN2 / P6
Lef t LED
Right LED
All manuals and user guides at all-guides.com
V
a
c
7
V
a
c
St at us
Explanat ion
Of f
The rout er is powered of f .
The rout er is powered on and running
Blinking
normally.
On
Int ernet connect ion is ready.
Of f
Int ernet connect ion is not ready.
Blinking
The dat a is t ransmit t ing.
On
The QoS f unct ion is act ive.
Of f
The QoS f unct ion is inact ive.
On
USB device is connect ed and ready f or use.
Of f
No USB device is connect ed.
Blinking
The dat a is t ransmit t ing.
On
The phone connect ed t o t his port is of f -hook.
Of f
The phone connect ed t o t his port is on-hook.
Blinking
A phone call comes.
5G / 2.4G: Wireless access point wit h
bandwidt h of 5GHz/ 2. 4GHz is ready.
On
WLAN: Wireless access point is ready.
Of f
Wireless f unct ion is disabled.
It will blink slowly while wireless t raf f ic goes
t hrough.
ACT and WLAN LEDs blink quickly and
Blinking
simult aneously when WPS is working, and will
ret urn t o normal condit ion af t er t wo minut es.
(You need t o set up WPS wit hin 2 minut es. )
On
The port is connect ed.
Of f
The port is disconnect ed.
Blinking
The dat a is t ransmit t ing.
On
The port is connect ed wit h 1000Mbps.
Of f
The port is connect ed wit h 10/ 100Mbps.
