Introduction
Function overview
Your Stereo Bluetooth® Headset AM-BT01 is designed to make life more convenient
when you're on the go. You can use it together with an Android™ powered device
such as a phone or tablet, or with a Bluetooth® compatible device such as a non-
Android phone, a computer or a music player. When paired with a compatible device,
you can use your headset to control incoming and outgoing phone calls or to listen to
music.
Hardware overview
⑤
③
②
①
④
Notification light
1
Power key
2
NFC detection area
3
Call key/Music key
4
Microphone
5
Volume up key
6
Volume down key
7
Red light: 5%-15% battery level
Orange light: 15%-50% battery level
Green light: 50%-100% battery level
Flashing blue light: headset is in pairing mode.
Flashing purple light: a call is coming in.
Press and hold down to turn the headset on or off.
When the headset is on, briefly press to show a
notification light indicating battery level.
Touch other devices to this area during NFC pairing.
Press to answer incoming calls.
Press and hold down to reject incoming calls.
Press to play or pause the current track.
Press to turn up the volume.
Press to turn down the volume.
⑥
⑦
Advertisement
Related Manuals for Sony AM-BT01
Summary of Contents for Sony AM-BT01
- Page 1 All manuals and user guides at all-guides.com Introduction Function overview Your Stereo Bluetooth® Headset AM-BT01 is designed to make life more convenient when you're on the go. You can use it together with an Android™ powered device such as a phone or tablet, or with a Bluetooth® compatible device such as a non- Android phone, a computer or a music player. When paired with a compatible device, you can use your headset to control incoming and outgoing phone calls or to listen to music. Hardware overview ⑥ ⑦ ⑤ ③ ② ① ④ Notification light Red light: 5%-15% battery level Orange light: 15%-50% battery level Green light: 50%-100% battery level Flashing blue light: headset is in pairing mode. Flashing purple light: a call is coming in. Power key Press and hold down to turn the headset on or off. When the headset is on, briefly press to show a notification light indicating battery level. NFC detection area Touch other devices to this area during NFC pairing. Call key/Music key Press to answer incoming calls. Press and hold down to reject incoming calls. Press to play or pause the current track. Microphone ...
-
Page 2: Battery And Power Management
All manuals and user guides at all-guides.com Basics C harging the battery Before using the Stereo Bluetooth® Headset AM-BT01 for the first time, you need to charge the headset for approximately 2.5 hours. Sony chargers are recommended. To charge your headset Plug one end of the USB cable into the charger or into the USB port of a computer. Plug the other end of the cable into the Micro USB port of your Stereo Bluetooth® Headset AM-BT01 device. B attery and power management You can check the battery status of your headset before the remaining power reaches a critical level. To check the battery status from your headset • Press the power key. The notification light colour indicates the amount of battery power remaining. Turning the headset on and off To turn on the headset • Press and hold down until the headset vibrates and the notification light turns green. To turn off the headset • Press and hold down until the headset vibrates. Adjusting the volume To change the call or music volume • During a call, or when listening to music, press or . -
Page 3: R Estarting And Resetting The Headset
All manuals and user guides at all-guides.com reconnection attempts. When this happens, you can use any key to force the accessory to try reconnecting, or you can use NFC to reconnect the two devices. To force the headset to try reconnecting Android™ device: Make sure that the Bluetooth® function is turned on. Press any key on the headset. To reconnect your headset using NFC Android™ device: Make sure that the NFC function is turned on and that the screen is active and unlocked. Place the Android™ device over your headset so that the NFC detection area of each device touches the other. R estarting and resetting the headset You can force your headset to shut down in situations where it stops responding or won't restart normally. No information about paired devices gets deleted. You can also reset your headset to its original factory settings, which deletes all information about paired devices. To force the headset to shut down • Press and hold down the power key for at least 6 seconds. To reset the headset Turn off the headset, then connect the charger so that the headset starts to charge. Press and hold down until the headset vibrates briefly. Wearing instruction To get the best performance from your headset when using it outdoors, it is recommended that you carry the device that you have paired with the headset on the same side of your body as the antenna of the headset unit. -
Page 4: Getting Started
All manuals and user guides at all-guides.com Getting started Preparing to use your headset with a B luetooth® device Before you can start using your headset with a Bluetooth® device, you need to pair the headset with the Bluetooth® device manually using Bluetooth® or automatically using NFC. A setup wizard in the Stereo Bluetooth® Headset application guides you through the process of setting up your headset for the first time. To manually pair your headset with a Bluetooth® device Bluetooth® device: Make sure the Bluetooth® function is turned on. Turn off your headset. Headset: Press and hold down the Power key until a blue notification light starts flashing rapidly. Bluetooth® device: Scan for Bluetooth® devices, then select “ambie AM-BT01” in the list of available devices. Bluetooth® device: Follow the pairing instructions that appear on the screen. To automatically pair your headset with a Bluetooth® device Bluetooth® device: Make sure that the NFC function is turned on and that the screen is active and unlocked. Place the Bluetooth® device over your headset so that the NFC detection area of each device touches the other. Bluetooth® device: Follow the pairing instructions that appear. The illustration is for reference purposes only. The location of the NFC detection area varies between devices. -
Page 5: Using Your Headset To Handle Phone Calls
All manuals and user guides at all-guides.com Using your headset Using your headset to handle phone calls Use the headset to handle incoming calls, for example, to answer or reject a call. To answer a call with the headset • When you hear an incoming call signal, press To end a call • During an ongoing call, press To reject a call • When you hear an incoming call signal, press and hold down To answer a second call • When you hear an incoming call signal during an ongoing call, press The ongoing call is put on hold. You can also double press to switch to another call and put the current call on hold. To reject a second call • When you hear an incoming call signal during an ongoing call, press and hold down To mute and unmute the microphone during a call • Press and hold down to mute the microphone. To unmute the microphone, press and hold down again. To make a call using voice dialler Headset: Press and hold down until you hear a beep. Bluetooth® device: Follow the instructions that appear on your screen. Speak clearly so your device accepts the contact name or phone number. - Page 6 You can only connect to a maximum of two devices in Multipoint mode. If you pair the headset with a third device, the first paired device gets disconnected. To switch between Multipoint mode and Singlepoint mode Make sure that the headset is turned off. Place the headphones over your ears. To enter Multipoint mode, press and hold down the volume up key while turning on the headset. After Multipoint mode is activated, you will hear two beeps. To enter Singlepoint mode, press and hold down the volume down key while turning on the headset. After Singlepoint mode is activated, you will hear one beep. In order to connect to both paired devices in Multipoint mode, you need to restart the headset. To manually pair your headset with two Bluetooth® devices Make sure that the headset is in Multipoint mode and is paired successfully with the first Bluetooth® device. Turn off the headset. Headset: Press and hold down the Power key until a blue notification light starts flashing rapidly. Second Bluetooth® device: Scan for Bluetooth® devices, then select ”ambie AM-BT01” in the list of available devices. Follow the pairing instructions that appear on the screen. First Bluetooth® device: To reconnect to the headset, select “ambie AM-BT01” in the list of paired devices on the Bluetooth® settings screen. To automatically pair your headset with two Bluetooth® devices Make sure that the headset is in Multipoint mode and is paired successfully with the first Bluetooth® device. Turn off the headset. Second Bluetooth® device: Make sure that the NFC function is turned on and that the screen is active and unlocked. Place the second Bluetooth® device over your headset so that the NFC detection area of each device touches the other, then follow the pairing instructions that appear on the screen. First Bluetooth® device: To reconnect to the headset, select “ambie AM-BT01” in the list of paired devices on the Bluetooth® settings screen.
