Owner's Manual
USB-C
®
Station, Gray
Model: U442-DOCK5-GY
USB Type-C and USB-C are trademarks of USB Implementers Forum
Este manual está disponible en español en la página
de Tripp Lite: tripplite.com
Ce manuel est disponible en français sur le site Web
de Tripp Lite : tripplite.com
Русскоязычная версия настоящего руководства
представлена на веб-сайте компании
Tripp Lite по адресу: tripplite.com
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR
®
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Portable Docking
surge protector in our monthly drawing!
1
Advertisement
Table of Contents
Related Manuals for Tripp Lite 26399377
Summary of Contents for Tripp Lite 26399377
- Page 1 Tripp Lite по адресу: tripplite.com WARRANTY REGISTRATION Register your product today and be automatically entered to win an ISOBAR surge protector in our monthly drawing! ® tripplite.com/warranty 1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support Copyright © 2021 Tripp Lite. All rights reserved.
-
Page 2: Product Features
Product Features • Supports DisplayPort Alternate Mode for connecting an HDMI monitor via USB-C or Thunderbolt 3 port ™ • Supports connection of DVI monitor via HDMI to DVI adapter (see Optional Accessories for more information) • HDMI port supports 4096 x 2160 30 Hz 4:4:4 video resolutions •... -
Page 3: System Requirements
Product Features • Supports PD 3.0 Fast Role Swap to maintain data and power connection upon removal of charging power • Automatically resumes operation from hibernation and suspend mode • IEEE 802.3az (Energy Efficient Ethernet) compliant • Supports full-duplex and half-duplex operations •... - Page 4 Package Includes • U442-DOCK5-GY • Owner’s Manual Optional Accessories • N201-Series Cat6 Gigabit Snagless Patch Cables • P566-Series HDMI to DVI Adapter Cables • P568-Series High-Speed HDMI Cables • U322-Series USB 3.2 A/B Device Cables • U326-Series USB 3.2 Micro-B Device Cables •...
-
Page 5: Product Overview
Product Overview Side 1 Side 2 Rear USB-A 3.2 Ports (Female) – Connect up to 2 USB peripherals/devices for charging or data transfer. Micro SD Memory Card Slot – Connects a Micro SD Memory Card. SD/MMC Memory Card Slot – Connects an SD/MMC Memory Card. -
Page 6: Installation
Product Overview USB-C Charging and Data Port (Female) – Connects your device to a USB-C PD charger for charging or data transfer. RJ45 Port (Female) – Connects to a 10/100/1000 Mbps network. Installation Note: • When the USB-C port is connected to a power source, 15W of power is dedicated to the docking station and other devices. - Page 7 1. Connect the dock’s USB Type-C connector to the USB-C or Thunderbolt 3 port on your laptop, tablet or other device. 2. Using an HDMI cable (such as Tripp Lite P568- Series High-Speed HDMI cables), connect the dock’s HDMI port to the HDMI port on a monitor.
-
Page 8: Specifications
Specifications Connectors-Input USB-C (Male) Connectors-Output USB-A (x3) USB 3.2 A (Female) USB PD Charging and USB-C (Female) Data 10/100/1000 Ethernet RJ45 (Female) HDMI HDMI (Female) Memory Card Slots Micro SD and SD/MMC Environmental Operating Temperature 32°F to 113°F (0°C to 45°C) Operating Humidity 10% to 85% RH, Non-Condensing... -
Page 9: Warranty And Product Registration
Warranty and Product Registration 3-Year Limited Warranty Tripp Lite warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. Tripp Lite’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. - Page 10 Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
- Page 11 • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user’s authority to operate this equipment. WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)
- Page 12 1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support 21-08-257 93-3957_RevB...
