inSTAllATion AnD MAinTEnAncE inSTRucTionS
BEAM355A, BEAM355SA
Single-ended Reflected Type
Projected Beam Smoke Detector
SPEcificATionS
GEnERAl
Range:
Sensitivity:
Spacing:
Response Time:
Trouble Conditions:
Test/Reset Features:
Indicators:
Style 7 Operation:
ENVIRONMENTAL
Temperature:
Humidity:
MECHANICAL
Shipping Weight:
Shipping Size:
Mounting:
Wiring:
Adjustment Angle:
Paintable Trim Ring:
Electrical
Standby Current:
External Supply (BEAM355SA only):
Remote Output: (alarm)
GEnERAl DEScRiPTion
Fire•Lite Model BEAM355A/BEAM355SA is a long range projected beam
smoke detector designed to provide open area protection. It is to be used
with ULC-listed compatible control panels only. The detector consists of a
transmitter/receiver unit and a reflector. Smoke entering the area between the
transmitter/receiver and reflector causes a reduction in signal. When the ob-
scuration reaches alarm thresholds (chosen at the transmitter/receiver unit),
the detector generates an alarm signal. Complete blockage of the beam causes
a trouble signal. Slow changes in obscuration due to a build up of dirt or dust
on the lens of the detector are compensated for by a microcontroller that con-
tinuously monitors the signal strength and periodically updates the alarm and
trouble thresholds. When the self-compensation circuit reaches its limit, the
detector generates a trouble signal, indicating the need for service.
F300-30-00
16 to 230 Feet (5 to 70m); 230 to 328 Feet (70 to 100m) using optional accessory BEAMLRK
25% to 50% Total Obscuration in 6 levels
Level 1 = 25%
Level 2 = 30%
Level 3 = 40%
Level 4 = 50%
Level 5 = 30% to 50% (Acclimate)
Level 6 = 40% to 50% (Acclimate)
30 to 60 Feet (9.1 to 18.3m)
ALARM - 20 seconds typical; TROUBLE - 30 seconds typical
Beam Blockage (96% or More Obscuration)
Improper Initial Alignment
Self-compensation limit reached (service needed)
In Alignment mode
Integral Sensitivity Test Filter (BEAM355SA only, requires additional external power supply)
Sensitivity Filter (Incremental scale on reflector)
Local Alarm Test Switch
Local Alarm Reset Switch
Remote Test and Reset Switch Capability (compatible with RTS451/RTS451KEYA)
ALARM - Remote Output, Local LED (red)
TROUBLE - Remote Output, Local LED (yellow); Blink Pattern Indicates Trouble Diagnostics
NORMAL OPERATION - Local LED (flashing green with communication)
ALIGNMENT AIDS - Optical Gunsight (coarse adjustment); 00 to 99 Digital Display (fine adjustment)
SENSITIVITY - Digital Display Readout in Percent Obscuration
On-board isolators provide style 7 operation. (may be disabled via shunts on circuit board)
–22°F to 131°F (–30°C to 55°C); NOTE: for applications below 32°F (0°C) see Special Applications section of this manual.
10% to 93% RH Noncondensing
3.9 lbs. (1.77 kg)
15˝ × 10.5˝ × 6.5˝ (381mm × 267mm × 165mm)
Wall only without optional accessories
Plug-in Terminal Blocks (12 to 22AWG)
±10° Horizontal and Vertical
May be painted using enamel or acrylic type paints
VOLTAGE - 15 to 32 VDC
Avg. Standby:
Max. Alarm (LED on):
Max. Trouble (LED on):
Max. Alignment:
VOLTAGE: 15 to 32 VDC
CURRENT: 0.5A Max.
VOLTAGE: 15 to 32 VDC; NOTE: Output voltage same as device input voltage.
CURRENT: 15mA maximum; 6mA minimum; NOTE: Output current is limited by 2.2Kohm resistor
2mA Max. (1 communication every 5 sec., LED flashing, SLC @ 24 V)
8.5mA Max.
4.5mA Max.
20mA Max.
Three LEDs on the detector indicate the current status: a red LED for alarm, a
yellow LED for trouble, and a blinking green LED for standby operation. Note:
The panel controls the status of the red and green LEDs. The local reset but-
ton is accessible by removing the outer paintable trim ring. The yellow LED
will blink in specific patterns to provide a diagnostic aid when diagnosing the
cause of a trouble signal. It will also blink the amount of drift compensation
that has been used at the conclusion of the test. Trouble signals automati-
cally reset upon removing the cause of trouble. Red and yellow LEDs can be
remotely connected to the remote Alarm and Trouble outputs. These outputs
mimic the functions of the detector's red and yellow LEDs. In addition to these
indicators, there is a dual digital display that reads 00 to 99. This display is
used to indicate the signal strength of the beam in alignment mode and to
indicate the sensitivity setting of the detector in percent obscuration when
1
