Operating Instructions
Thank you for purchasing this Panasonic product.
• Please read this Operating Instructions carefully in order to use this product correctly and safely.
• Before using this product, please give your special attention to the Safety Precautions.
• Please keep this Operating Instructions for future use.
• Panasonic will not accept any liability if the appliance is subject to improper use, or failure to
comply with these instructions.
•
•
•
•
01_OM_NC-DG3000-PZ05H6903_EN.indd 1
01_OM_NC-DG3000-PZ05H6903_EN.indd 1
Electric Thermo Pot Household Use
Model No./
NC-DG3000
1
25/11/2564 BE 14:10
25/11/2564 BE 14:10
Advertisement
Table of Contents
Related Manuals for Panasonic NC-DG3000
Summary of Contents for Panasonic NC-DG3000
- Page 1 • Before using this product, please give your special attention to the Safety Precautions. • Please keep this Operating Instructions for future use. • Panasonic will not accept any liability if the appliance is subject to improper use, or failure to comply with these instructions.
-
Page 2: Table Of Contents
Table of Contents Main Features....................4 Safety Precautions .................5-7 Part Names and Handling Instructions ...........8-9 How to Use ..................10-11 Convenient use methods ..............12-13 Daily Maintenance ...................14 • How to clean the inner container using citric acid ......15 Troubleshooting ..................16 Replacement of Parts ................17 Specifications ..................17 01_OM_NC-DG3000-PZ05H6903_EN.indd 2 01_OM_NC-DG3000-PZ05H6903_EN.indd 2... - Page 3 ....................18 ..................19-21 ................22-23 .....................24-25 ..................26-27 ...................28 • ............29 ....................30 ....................31 ......................31 01_OM_NC-DG3000-PZ05H6903_EN.indd 3 01_OM_NC-DG3000-PZ05H6903_EN.indd 3 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
-
Page 4: Main Features
Main Features Easy to Clean Charcoal coated non-stick inner ● container The inner container is fluoridated with floury charcoal, which is easy to clean and maintain. Convenient Electric dispense Air dispense ● ● (See “Dispensing” on P.10) Can also be used in cordless operation. -
Page 5: Safety Precautions
Safety Precautions Please take these precautions strictly For your safety and in order to prevent the property damage and the hazards to the users and others, please read the following instructions strictly. The signals indicate harm and damage when the product is used wrongly. Indicating “it may Indicating “the user may get WARNING... - Page 6 Safety Precautions Please take these precautions strictly WARNING Power Cord Never do anything that might cause damage to ● Power cord the cord, power plug or body plug. Do not damage them, modify them, place hot objects near to them, bend them, twist them, Power plug* stretch them, place heavy objects on them, or bundle them together.
- Page 7 CAUTION To Prevent Burns Do not place the unit on unstable surfaces. ● The appliance may topple over causing burns. Do not open the lid or dispense hot water while boiling. ● Splashing hot water or steam may cause burns. Do not rotate the unit while dispensing hot water.
-
Page 8: Part Names And Handling Instructions
Part Names and Handling Instructions Operation panel Steam vent Push plate Liquid crystal Push plate display lock Handle Lid opening lever Dispensing Main unit spout Inner Window rim container Red ball Water level indicator cannot be seen when water Minimum level is above the water level window rim. - Page 9 How to Remove the Lid Press and lift the lid opening Pull it up slantwise while pressing lever to open the lid. the lid release lever. Lid opening lever Lid release lever To close To attach Press down until hearing “click” sound. Insert the lid slantwise.
-
Page 10: How To Use
How to Use Boiling water Pour in water with another container. Preparation Close the lid securely. Securely plug the body plug horizontally Indicate as below when boiled. into the body. Plug into wall outlet. (P.11 1➛2) Time required to boil water Light on approx. - Page 11 Pour in water with another container ! w MAX. WATER LEVEL. Do not fill water above maximum water level. w Minimum water level Fill the water higher than the minimum water level. Flash Press key twice, then press key for making drip coffee. Slow Drip mode for making drip Count streaming time.
-
Page 12: Convenient Use Methods
Convenient use methods Setting the Timer When the unit will not be used for a short time, such as when you go out for a day... Keep-warm function Each time ● is pressed, the light Each time will shift to the next ●... - Page 13 Dispensing in cordless (Air-dispense) Slide “Push Plate” to “Unlock”. Press “Push Plate” slowly. Reboil Press key to reboil water that is being kept warm. Light on After a few minutes, water will be boiled. Hot water will spurt out just after boiling. ●...
-
Page 14: Daily Maintenance
Daily Maintenance Before cleaning, be sure to disconnect the power plug from outlet, dispense water and cool down the unit. Main unit and lid Clean with a damp, well-wrung cloth. Do not wet or soak the main unit in water. ●... -
Page 15: How To Clean The Inner Container Using Citric Acid
How to clean the inner container using citric acid. Once every two or three months to clear scale. More frequent cleaning may be required depending on the usage conditions. Make sure that the mesh filter is attached to the inner container. Put citric acid in the inner container. -
Page 16: Troubleshooting
Before calling a service supplier, Troubleshooting please check the following possible causes. If... Possible cause How to fix White or glittering flakes floating in the ● The cause of this is “scale”. (see P.14) hot water. It is not flakes of fluororesin. Rough milky white ●... -
Page 17: Replacement Of Parts
Remove lid, unscrew 4 tapping screws and remove the lid cover. Exchange the gaskets and then place Mesh filter APB97-480-0U the lid cover back and secure with the tapping screws. Specifications NC-DG3000 Model No. Power supply 220V 50Hz Power consumption 700 W... - Page 18 ● ● ● ● ● ● ● 02_OM_NC-DG3000-PZ05H6903_HK.indd 18 02_OM_NC-DG3000-PZ05H6903_HK.indd 18 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 19 ● Pour Out ● ● ● ● ● ● ● ● 02_OM_NC-DG3000-PZ05H6903_HK.indd 19 02_OM_NC-DG3000-PZ05H6903_HK.indd 19 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 20 ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● 02_OM_NC-DG3000-PZ05H6903_HK.indd 20 02_OM_NC-DG3000-PZ05H6903_HK.indd 20 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 21 ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● 02_OM_NC-DG3000-PZ05H6903_HK.indd 21 02_OM_NC-DG3000-PZ05H6903_HK.indd 21 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 22 APB97-480-0U 02_OM_NC-DG3000-PZ05H6903_HK.indd 22 02_OM_NC-DG3000-PZ05H6903_HK.indd 22 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 23 ● ● 02_OM_NC-DG3000-PZ05H6903_HK.indd 23 02_OM_NC-DG3000-PZ05H6903_HK.indd 23 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 24 1➛2 ● 02_OM_NC-DG3000-PZ05H6903_HK.indd 24 02_OM_NC-DG3000-PZ05H6903_HK.indd 24 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 25 ● ● ● ● ● ● DRAIN ● ● 02_OM_NC-DG3000-PZ05H6903_HK.indd 25 02_OM_NC-DG3000-PZ05H6903_HK.indd 25 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 26 ● ● ● 02_OM_NC-DG3000-PZ05H6903_HK.indd 26 02_OM_NC-DG3000-PZ05H6903_HK.indd 26 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 27 ● ● ● ● ● ● ● ● ● ● Vacuum Insulation Panel (VIP) ● 02_OM_NC-DG3000-PZ05H6903_HK.indd 27 02_OM_NC-DG3000-PZ05H6903_HK.indd 27 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 28 ● ● ● ● ● ● ● ● ● APB97-480-0U 02_OM_NC-DG3000-PZ05H6903_HK.indd 28 02_OM_NC-DG3000-PZ05H6903_HK.indd 28 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 29 ● ● ● ● ● ● 02_OM_NC-DG3000-PZ05H6903_HK.indd 29 02_OM_NC-DG3000-PZ05H6903_HK.indd 29 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 30 ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● 50°C ● ● ● ● ● ● ●...
- Page 31 APB97-480-0U NC-DG3000 02_OM_NC-DG3000-PZ05H6903_HK.indd 31 02_OM_NC-DG3000-PZ05H6903_HK.indd 31 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
- Page 32 Panasonic Corporation Website : http://www.panasonic.com © Panasonic Corporation 2015 PZ05H6903 TP0815E31021 Printed in Thailand 02_OM_NC-DG3000-PZ05H6903_HK.indd 32 02_OM_NC-DG3000-PZ05H6903_HK.indd 32 25/11/2564 BE 14:10 25/11/2564 BE 14:10...
