Pioneer DEH-S6200BS Operation Manual

Cd rds receiver
Hide thumbs Also See for DEH-S6200BS:
Table of Contents

Advertisement

Quick Links

CD RDS RECEIVER
AUTORADIO CD RDS
REPRODUCTOR DE CD CON RECEPTOR RDS
DEH-S6220BS
DEH-S6200BS
Important (Serial number)
The serial number is located on the bottom of this unit. For your own security and convenience, be sure to
record this number on the enclosed warranty card.
Important (Numéro de série)
Le numéro de série se trouve au bas de cet appareil. Pour votre sécurité et votre commodité, veillez à noter ce
numéro sur la carte de garantie fournie.
Importante (Número de serie)
El número de serie se encuentra en la parte inferior de esta unidad. Por su propia seguridad y comodidad,
asegúrese de anotar este número en la tarjeta de garantía que se adjunta.
Operation Manual
Mode d'emploi
Manual de operación

Advertisement

Table of Contents
loading

Related Manuals for Pioneer DEH-S6200BS

Summary of Contents for Pioneer DEH-S6200BS

  • Page 1 REPRODUCTOR DE CD CON RECEPTOR RDS DEH-S6220BS Operation Manual Mode d’emploi DEH-S6200BS Manual de operación Important (Serial number) The serial number is located on the bottom of this unit. For your own security and convenience, be sure to record this number on the enclosed warranty card.

  • Page 2: Table Of Contents

    CD/USB/iPhone®/AUX................8 Bluetooth ....................10 Pandora® ....................14 Spotify® ....................16 SiriusXM Satellite Radio ..............18 Using Pioneer Smart Sync/APP............21 Audio Adjustments ................24 Settings ....................26 FUNCTION settings ................26 AUDIO settings ..................28 SYSTEM settings ..................31 ILLUMINATION settings................

  • Page 3: Getting Started

    Getting Started Basic operation DEH-S6220BS/S6200BS M.C. (multi-control) dial USB port SRC (source)/OFF (eject) Disc loading slot DISP (display) BAND/ Display window BASS (navigation)/LIST Detach button AUX input jack (3.5 mm stereo jack) Optional remote control The remote control CD-R510 is sold separately. Frequently used operations Purpose Operation...
  • Page 4 Appears when a Bluetooth connection is made (page 10). Appears when a Pioneer Smart Sync connection is made (page 21). Detaching the front panel Detach the front panel to prevent theft. Remove any cables and devices attached to the front panel and turn off the unit before detaching it.
  • Page 5 Resetting the microprocessor The microprocessor must be reset in the following situations: – Before using this unit for the first time after installation – If the unit fails to operate properly – When strange or incorrect messages appear on the display Remove the front panel (page 4).
  • Page 6 Menu Item Description SPEAKER MODE Switch between two operation modes: the 2-way network mode (NETWORK) and the standard mode (STANDARD) according to [STANDARD], the connections you have established. For details on operation [NETWORK] modes, see page 24. After selecting the appropriate mode, turn the M.C. dial to select [YES], then press to confirm.

  • Page 7: Radio

    Menu Item Description REAR-SP Select when there is a full-range speaker connected to the rear speaker output leads. [FUL] [SW] Select when there is a subwoofer connected directly to the rear speaker output leads without any auxiliary amplifier. SYSTEM UPDATE Select [SYSTEM INFO] to confirm the latest system information on the unit.

  • Page 8: Cd/Usb/Iphone®/Aux

    To seek a station manually After selecting the band, press to select a station. Press and hold then release to seek an available station. Scanning stops when the unit receives a station. To cancel seek tuning, press NOTE [SEEK] needs to be set to [MAN] in the FUNCTION settings (page 26). To store stations manually While receiving the station you want to store, press and hold one of the number buttons (1/...
  • Page 9 AOA connections A device running Android OS 4.1 or later installed and also supports AOA (Android Open Accessory) 2.0 can be connected to the unit via AOA, using the cable supplied with the device. NOTE If you use an AOA connection, [APP CONTROL] needs to be set to [WIRED] (page 32) and [USB MTP] needs to be set to [OFF] (page 32) in the SYSTEM settings.

  • Page 10: Bluetooth

    For details on MIXTRAX settings, see page 35. NOTES • iPhone needs to be connected with Pioneer Smart Sync via USB for using this function (page 21). • Depending on the file/song, sound effects may not be available.
  • Page 11 Press to display the [ADD DEVICE] setting. The unit starts to search for available devices, then displays them in the device list. • To cancel searching, press the M.C. dial. • If the desired device is not in the list, select [RE-SEARCH]. •...
  • Page 12 For details on the voice recognition features, refer to the manual supplied with your device. When a Pioneer Smart Sync connection is made (page 21), you can also use the voice recognition function from Pioneer Smart Sync installed on your iPhone/Android device by pressing and holding .
  • Page 13 Phone menu Press to display the phone menu. Menu Item Description RECENTS Display the missed call history. [MISSED] [DIALED] Display the dialed call history. [RECEIVED] Display the received call history. PHONE BOOK Display the contacts in your phone. PRESET 1-6 Recall the preset phone numbers.

  • Page 14: Pandora

    * Depending on the connected device, these operations may not be available. Pandora® (Not available when [USB MTP] is set to [ON] in the SYSTEM settings (page 32).) Pandora music is a music service not affiliated with Pioneer. More information is available at http://www.pandora.com. - 14 -...
  • Page 15 The Pandora mobile application is available for iPhone and Android phones. Please visit www.pandora.com/everywhere/mobile for the latest compatibility information. Listening to Pandora Update the firmware of the Pandora application to the latest version before use. Connect this unit with the mobile device. •...

  • Page 16: Spotify

    Spotify® (Not available when [USB MTP] is set to [ON] in the SYSTEM settings (page 32).) Spotify is a music streaming distribution service not affiliated with Pioneer. More information is available at http://www.spotify.com. The Spotify application is available for compatible smartphones, please visit https:// support.spotify.com/ for the latest compatibility information.
  • Page 17 Press and hold 1/ to display [APP CONTROL]. Turn the M.C. dial to select one of the below. • Select [WIRED] for the USB connection. • Select [BLUETOOTH] for the Bluetooth connection. Press SRC/OFF to select [SPOTIFY]. Launch the Spotify application on the mobile device and start playback. NOTE When you connect a mobile device other than an iPhone/Android device, it may not operate correctly depending on your mobile device.

  • Page 18: Siriusxm Satellite Radio

    SiriusXM Satellite Radio Only SiriusXM® brings you more of what you love to listen to, all in one place. Get over 140 channels, including commercial-free music plus the best sports, news, talk, comedy and entertainment. Welcome to the world of satellite radio. A SiriusXM Vehicle Tuner and Subscription are required.
  • Page 19 The Radio ID appears on the display. In addition, the Radio ID is located on the bottom of the SiriusXM Connect Vehicle Tuner. NOTE The Radio ID does not include the letters I, O, S or F. Activate the SiriusXM service online or by phone. For US Subscriptions: •...
  • Page 20 Purpose Operation 1 Set the operation mode to [REPLAY]. Skip backward/forward 2 Press 1 Set the operation mode to [REPLAY]. Fast forward or reverse 2 Press and hold NOTE You can also make various adjustments in the SiriusXM settings (page 27). Category scan The live broadcast for each channel in the current category plays for six seconds at a time.

  • Page 21: Using Pioneer Smart Sync/App

    For details on what operations are available on the application, see the application’s help section. NOTE The APP source is not available when a Pioneer Smart Sync connection is not made or [USB MTP] is set to [ON] in the SYSTEM settings (page 32). WARNING Do not attempt to operate the application while driving.
  • Page 22 7.1.2 and also supports AOA (Android Open Accessory) 2.0. However, the compatibility depends on the smartphone. You can download Pioneer Smart Sync on Google Play. NOTE Some Android devices connected via AOA 2.0 may not work properly or emit sounds due to their own software design, regardless of the OS version.
  • Page 23 • The 31 Band EQ setting is converted into 13 bands when a music source from this product is engaged. It is recommended to enter the search term "Pioneer Smart Sync" in the search field to search for the application.

  • Page 24: Audio Adjustments

    • When you connect a mobile device other than an iPhone/Android device, it may not operate correctly depending on your mobile device. • If Pioneer Smart Sync has not been installed on your iPhone/Android device yet, a message that prompts you to install the application will appear on your iPhone/Android device (except for the Android device connected via Bluetooth).
  • Page 25 Network mode You can create a 2-way + SW multi-amp and multi-speaker system with high range speaker, middle range speaker and subwoofer for reproduction of high, middle and low frequencies (bands). Standard mode You can create a 4-speaker system with front and rear speakers or front speakers and subwoofers, or a 6-speaker system with front and rear speakers and subwoofers.

  • Page 26: Settings

    Turn the M.C. dial to select an appropriate slope for the speaker unit (filter) selected in step 4. Network mode: [–6] to [–24] (if you choose [HIGH], [MID HPF] or [MID LPF]) [–12] to [–36] (if you choose [SUBWOOFER]) Standard mode: [–6] to [–24] (if you choose [FRONT] or [REAR]) [–6] to [–36] (if you choose [SUBWOOFER]) Settings...
  • Page 27 Menu Item Description SAVE Store the information about the song currently being played to your music list on Spotify. UNSAVE Remove the song information stored in [SAVE]. SEL DEVICE iPhone Connect a Bluetooth device in the list. BOOKMARK Store the track information currently being played in your Pandora account.

  • Page 28: Audio Settings

    1 Repeat steps 1 to 3 to enter a new passcode. 2 After inputting the passcode, press the M.C. dial. The new passcode is saved. AUDIO settings NOTE [CHK APP SETTG.] may be displayed when the setting is performed from Pioneer Smart Sync. - 28 -...
  • Page 29 M.C. dial, then store the preset equalizer curve that is the customized equalizer curve in [CUSTOM1]. not available in the unit has been set from Pioneer Smart Sync. Select an equalizer band and level for further customizing. Equalizer band: [50HZ] to [12.5kHZ]...
  • Page 30 [CROSSOVER], [SPEAKER LEVEL], [EQ SETTING], [POSITION], [TIME ALGNMNT], [D.BASS], [SUBWOOFER]. • The settings that can be saved differ when a Pioneer Smart Sync connection is made. LOAD SETTINGS Load the sound settings, when you have already performed [SAVE SETTINGS].

  • Page 31: System Settings

    CLOCK SET [12H], [24H] Set the clock (page 5). • This setting is not available when a Pioneer Smart Sync connection is made. SCROLL SET [ONCE], [LOOP], [OFF] Select the way to scroll the text in the display window.
  • Page 32 The following sources are not available when the setting is set to [ON]. • APP, PANDORA, SPOTIFY, iPhone, and USB (AOA) AUTO APP CONN [ON], [OFF] Select [ON] to automatically launch Pioneer Smart Sync when the iPhone/Android device is connected to the unit. - 32 -...
  • Page 33 The available sources differ depending on the setting value. Please set [APP CONTROL] according to the table for the source you want to use. For details on Pioneer Smart Sync connection, see page 21. When Pioneer Smart Sync connection is NOT performed...

  • Page 34: Illumination Settings

    ILLUMINATION settings Menu Item Description COLOR [KEY COLOR], [DISP COLOR], Select color for the keys/display of the unit from 12 [BOTH COLOR] preset colors, [SCAN] or [CUSTOM]*. • [SCAN]: Cycle through a variety of colors automatically. • [CUSTOM]*: 1 Press and hold the M.C. dial until the color setting display appears.

  • Page 35: Mixtrax Settings

    [PHONE COLOR] – you are on a phone call – the message received on the device is being read when a Pioneer Smart Sync connection is made – a CD is inserted/ejected – the front panel is attached.
  • Page 36 Menu Item Description DISPLAY FX [ON], [OFF] Set the MIXTRAX special effects on/off. CUT IN FX [ON], [OFF] Turn the MIXTRAX sound effects on/off while manually changing the tracks. - 36 -...

  • Page 37: Additional Information

    ON again. If the message remains, – Select the repeat play range again. contact your dealer or an authorized Pioneer Service Station for assistance. A subfolder is not played back. → Subfolders cannot be played when NO XXXX (NO TITLE, for example) [FLD] (folder repeat) is selected.
  • Page 38 – Replace the USB device. FORMAT READ → Sometimes there is a delay between the N/A USB start of playback and when you start to → The connected USB device is not hear any sound. supported by this unit. – Wait until the message disappears and –...
  • Page 39 → iPhone failure. NOT FOUND – Disconnect the cable from the iPhone. → The Pandora application has not started Once the iPhone’s main menu is running yet. displayed, reconnect the iPhone and – Start up the Pandora application. reset it. RATING ERROR STOP →...
  • Page 40 → No Bluetooth device found. – Connect the unit and the device via Bluetooth (page 10). CONNECT APP CONN. FAILED PRESS BAND KEY TO → Pioneer Smart Sync connection is not RETRY made. → Bluetooth connection failed. – Make a connection with Pioneer Smart –...
  • Page 41 – Press BAND/ to make a – Move the SiriusXM antenna away from connection again. any obstructions. CHECK APP PRESS BAND KEY TO RETRY SUBSCRIPTION UPDATED → Connection to the Spotify application → This unit has detected a change in your failed.
  • Page 42 CAUTION the equipment. • Pioneer cannot guarantee compatibility USB storage device with all USB mass storage devices, and assumes no responsibility for any loss of • Connections via USB hubs are not data on media players, smartphones, or supported.
  • Page 43 Stereo Bit Rate 16 kbps to 320 kbps, WMA files File extension .wma Apple Lossless Not compatible AAC file bought from Not compatible Bit rate 48 kbps to 320 kbps (CBR), 48 kbps to 384 the iTunes Store (.m4p kbps (VBR) file extension) Sampling frequency 32 kHz, 44.1 kHz, 48...
  • Page 44 • Users of iPhone with the Lightning® registered trademarks owned by Bluetooth SIG, Connector should use the Lightning to Inc. and any use of such marks by PIONEER USB Cable (supplied with iPhone). CORPORATION is under license. Other • Refer to the iPhone manuals for trademarks and trade names are those of their respective owners.
  • Page 45 INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER MIXTRAX IN CONTRACT, STRICT LIABILITY, OR TORT MIXTRAX is a trademark of the PIONEER (INCLUDING NEGLIGENCE OR OTHERWISE) CORPORATION. ARISING IN ANY WAY OUT OF THE USE OF - 45 -...
  • Page 46 Spotify® SPOTIFY and the Spotify logo are among Chassis: 178 mm × 50 mm × 165 mm the registered trademarks of Spotify AB. (7 in. × 2 in. × 6-1/2 in.) Compatible mobile digital devices and Nose: 170 mm × 46 mm × 17 mm (6- premium subscription required, where 3/4 in.
  • Page 47 Frequency: 1.25 kHz/1.6 kHz/2 kHz/ 2.5 kHz/3.15 kHz/4 kHz/5 kHz/6.3 kHz/ USB standard specification: USB 2.0 full 8 kHz/10 kHz/12.5 kHz speed Slope: –6 dB/oct, –12 dB/oct, –18 dB/ Maximum current supply: 1.5 A oct, –24 dB/oct USB Protocol: High pass filter (MID) (Network mode): MSC (Mass Storage Class) Frequency: 25 Hz/31.5 Hz/40 Hz/50 MTP (Media Transfer Protocol)
  • Page 48 SDAP (Service Discovery Application Profile) HFP (Hands Free Profile) 1.6 PBAP (Phone Book Access Profile) A2DP (Advanced Audio Distribution Profile) AVRCP (Audio/Video Remote Control Profile) 1.5 SPP (Serial Port Profile) 1.1 CTA2006 Specifications Power output: 14 W RMS × 4 Channels (4 Ω <...
  • Page 49 © 2019 PIONEER CORPORATION. All rights reserved. © 2019 PIONEER CORPORATION. Tous droits de reproduction et de traduction réservés. <OPM_DEHS6200BSUC_3L_A> UC...
