Model
CIVIC 4D
CIVIC 4D DIESEL
CIVIC 5D
CIVIC 5D DIESEL
CIVIC 5D TYPE R
Civic 17 & 18 Year Model PDI and New Model Service information.
Introduction
This service bulletin includes the following information
for the Civic 17 & 18 year model :
•
Model specific PDI related items.
•
Reminders of some important items that shouldn't
be forgotten when carrying out the PDI process.
•
New model service and maintenance related items
NOTE: 18YM Civic diesel only is the first model to use
the full functionality of i-HDS diagnostic software, See
i-HDS/SvRS section of this bulletin for details. Please
ensure you are using the latest version of i-HDS.
List of enclosed parts
These loose Items will be found in the car as follows:
Location: Centre console / cup holder
Parts name
Shipping fuse (10A)
Shipping fuse (15A)
Shipping fuse (30A)
Shift lock release cover
Location: Cargo area
Parts name
Tie down grommet
Wheel covers
Backup starting function.
This method is used for starting keyless access system
vehicles when the shipping fuses are not installed or
when the remote battery is dead.
Service Bulletin
Model Code
FC1, FC9
FC8
FK6, FK7
FK9
FK8
(4dr Temporary spare wheel kits corrected)
Qty Remarks
1
p
1
1.5 CVT models only
2
All models except 1.5 CVT
1
p
Qty
Remarks
4
p
4
Steel wheel models only
Year Model
17, 18
18
17, 18
18
17, 18
1. Press the ENGINE START/STOP button and the
button starts to flash.
2. Bring the H-mark(emblem) of the remote in front of
the ENGINE START/STOP button while it is flashing
(within 30 seconds).
3. As soon as communication is completed, the button
changes from flashing to illuminating mode.
4. Within 10 seconds, depress the clutch pedal (MT) or
brake pedal (CVT) and push the ENGINE
START/STOP button simultaneously, then the engine
will start.
Bulletin No
SR-18-001-06
PDI and Maintenance
Issue Date
18-06-18
Originator
PAGE 1 OF 10
Advertisement
Table of Contents
Related Manuals for Honda CIVIC 4D 2017
Summary of Contents for Honda CIVIC 4D 2017
- Page 1 Bulletin No Service Bulletin SR-18-001-06 PDI and Maintenance Model Model Code Year Model Issue Date 18-06-18 CIVIC 4D FC1, FC9 17, 18 CIVIC 4D DIESEL Originator CIVIC 5D FK6, FK7 17, 18 CIVIC 5D DIESEL CIVIC 5D TYPE R 17, 18 Civic 17 &...
- Page 2 Bulletin No CONTINUATION SHEET SR-18-001-06 (A) All models except 1.5 CVT. Location 18 = 10A Location 25 = 30A Location 28 = 30A (B) 1.5 CVT models. Location 18 = 10A Location 19 = 15A To stop the engine push the ENGINE START/STOP button again.
-
Page 3: Setting The Clock
NOTE: A Security code is normally only required if an audio unit is swapped to another vehicle. All customisation is carried out in the settings menu of the Display Audio (Honda Connect), this includes audio, phone, system, meter and vehicle settings. Setting the clock... -
Page 4: Setting The Language
2. Turn the LIST/SELECT knob (B) to highlight "Settings" and press it to select it. Setting the language Models with Display Audio (Honda Connect) This language setting sets the language for both the audio display and meter display, to set the language based on the customers request complete the following: 1. - Page 5 English. Update Honda Connect Some models of Civic will be fitted with the Honda Connect audio, this is an internet connected audio With the vehicle stationary and the handbrake on: system that uses the customers Smartphone or mobile Wi-Fi device as an internet source.
- Page 6 2. Remove the suspension blocks from both sides of the front suspension springs. (There are 4 blocks per Models with Display Audio (Honda Connect) vehicle side.) Initialisation is done via the vehicle settings: [Home] > Settings > Vehicle > Deflation Warning System >...
- Page 7 Bulletin No CONTINUATION SHEET SR-18-001-06 4. SvRS start-up is found in "Pre-delivery Inspection" New Model information Diesel oil change frequency i-HDS / SvRS The 18YM Civic diesel will be approved under Euro 6d emission requirements which includes World 18 YM Civic diesel will be the first model to use the full Harmonised Light Vehicle Test Procedure (WLTP) and functionality of i-HDS.
-
Page 8: Windscreen Wipers Service Position
Bulletin No CONTINUATION SHEET SR-18-001-06 While this warning is displayed the Vehicle Stability position, turn the vehicle to ON [II] and then to OFF Assist (VSA) system is inactive as the system is [LOCK] position. initialising, for this initialisation to complete the vehicle The wiper arms will move to the service position. -
Page 9: Wireless Charger
Apple Carplay / Android Auto replacement, the replacement procedure is in MaRIS and there are tools available in the loan tool programme The Display Audio (Honda Connect) system supports as a kit 07000-CAPLESS. both Apple CarPlay and Android Auto. For either system, the smartphone must be connected The kit contains the following tools. - Page 10 Bulletin No CONTINUATION SHEET SR-18-001-06 Android Auto app from Google Play to your Android As the Type R bonnet is made of aluminium, pressing smartphone. on the bonnet to close it can cause dents or distortion, Only Android 5.0 (Lollipop) or later versions are so the correct procedure should be used when closing compatible with Android Auto.
