- Page 1 Video Cassette Recorder VRB615AT VRB665AT Hookup Pages I m p o r t a n t ! R e t u r n y o u r W a r r a n t y R e g i s t r a t i o n...
-
Page 2: Hookups Without A Cable Box
6 Hookups without a Cable Box The basic VCR/TV connection – antenna/cable to VCR to TV – is shown below. If you have a Cable Box or a Direct Broadcast System, please refer to pages 8-9. After you hook up the VCR, please go to page 10 to turn on the VCR. - Page 3 Set the CH3/CH4 switch on the back of the VCR to CH3 or CH4, whichever channel is not used or least used in your area. To operate your VCR with your TV, set the TV to the same channel. For example, when playing a tape, if the CH3/CH4 switch is set to CH3, the TV should be on channel 3.
-
Page 4: Hookups With A Cable Box/Direct Broadcast System
• You can only program a timer recording for one channel at a time. Set the TV and the VCR to the Cable Box/DBS output channel (channel 03 or 04); set the CH3/CH4 switch to the same channel. Set your Cable Box/DBS to the channel you want to record. -
Page 5: Recording One Channel/Watching Another
CH3/CH4 switch. Set the TV to the Cable Box/DBS output chan- nel (03 or 04). Then, with the VCR in VCR position (the VCR light will appear on the display panel), use the CH(annel) o/p button to select the channel you want to record at the VCR. Start the recording. -
Page 6: Rewind / Button
TV broadcast using the CH(annel) o/p or Number buttons to change channels at the VCR. The VCR light will appear on the display panel when the VCR is in VCR position. TV Position: Use to watch TV or to watch one program while recording another. -
Page 7: Rear Panel
Details are on pages 32 and 45. VRB665 CH3/CH4 Switch Set to channel 3 or 4 to use your TV with your VCR. Set your TV to the same channel. Details are on pages 6-9. VIDEO IN Jack Connect a video cable coming from the VIDEO OUT jack of a camcorder, a Cable Box/DBS, or another VCR here. -
Page 8: Helpful Hints
The instructions on this page show you how to copy tapes. Different VCRs may operate differently. To duplicate a tape, make the connections shown, then follow steps 1-6. (You may use the AUDIO and VIDEO In jacks on the front of VCR 2 instead if you prefer.) VCR 1 Playing VCR ANT.IN... - Page 9 VCR SET UP TUNER SET UP INITIAL SET UP SELECT: ,9 CONFIRM: OK END: MENU Press the PLAY 8 or STOP 9 button to select VCR SET UP, then press the OK/STATUS button. DSPC ON SCREEN MODE BLUE BACKGROUND TIMER REC SPEED...
