JVC LT-43C888 Unpacking Manual

Unpacking
Guide
LT-43C888
TV
Instruction Book
& Quick Start Guide
TV Stand Neck Cover and
Neck
Accessories
Pack TV Stand Base
Fitting the Neck and Neck Cover Together
1. Fit the neck cover over the neck.
2. Using 2 of the supplied screws (A), screw the neck and neck cover together.
Fitting the Neck and Stand to the TV
3. Ensure the TV is switched off and not connected to the mains power supply.
4. Lay the TV down on a flat surface ideally on the edge of a table so the base of the
TV slightly overhangs the edge of the table, with the back side facing up. Please
make sure a soft cushioned material (such as a dry bath towel or thick piece
of foam) is placed beneath the screen. You can leave the protective bag on to
protect the TV at this point.
5. Slide the Neck and Neck cover under the lip, the neck will fit snugly over the
screw holes. Then screw the Neck to the TV using the 6 screws (B) supplied.
6. Once the Neck is secure screw the base to the neck using the 3 screws (A)
supplied. Be careful not the drop the base, its heavy.
• Keep the protective bag on your TV until you have attached the
stand and positioned the TV.
• The LCD display is very fragile, and must be protected at all times
when installing and removing the base stand. Be sure that no hard
or sharp object, or anything that could scratch or damage the LCD
display, comes into contact with it. DO NOT exert pressure on the
front of the TV at any time because the screen could crack.
JVC 43' LED Smart 4K HDR TV LT-43C888 Unpacking Guide.indd 1
✔
2 people are required
when unpacking your TV.
A
A
If you don't have a table
big enough, you can use
the TV box. Lie the box flat,
make sure you place the
polystyrene back in the box
first to give the box some
rigidity and strength.
✘
B
A
Don't lift the TV from the top
Remove the Protective Bag
