- Page 1 LECTUS select ARD‑SELECT‑BOM | ARD‑SELECT‑WOM | ARD‑SELECT‑BOKM | ARD‑SELECT‑WOKM Manual de instalación...
-
Page 3: Table Of Contents
Assembling the reader Assembling the reader module 3.5.1 Configuring the reader (DIP switches) Connecting and mounting the reader module Unmounting the reader module Resetting OSDP-key Care instructions Technical specifications More information Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación... -
Page 4: Safety
(limit switches, protective equipment, etc.). Notice! Installation and assembly of electrical components must be carried out by a qualified electrician. 2023-04 | V02 | Bosch Security Systems B.V. Manual de instalación... -
Page 5: Fcc Class B
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación... -
Page 6: General
Introduction This installation manual is aimed at authorized service providers. The installation manual contains instructions on the installation and configuration of the Bosch Security Systems proximity reader LECTUS select. Figure 2.1: LECTUS select readers 2023-04 | V02 | Bosch Security Systems B.V. -
Page 7: Disposal
This will help in conserving resources, and in protecting human health and the environment. Components Quantity Component Reader module Locking bar Screws Quick installation guide Safety and security information OSS information Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación... -
Page 8: Functional Requirements
Connection type: 8-pin screw / plug-in terminal The LECTUS select reader reads data from contactless RFID credentials and sends the data to a higher-level control center. This is where the evaluation takes place as to whether a credential is authorized or not. The result is sent back to the reader, which then provides a visual and an acoustic signal. -
Page 9: Rfid Technology
LECTUS select General | en RFID technology The LECTUS select readers support by default the following technologies: – LEGIC advant – MIFARE DESFire EV1 – MIFARE DESFire EV2 – Mobile Access For LEGIC prime and MIFARE Classic, a special configuration is needed and is not offered as standard. -
Page 10: Transponder Data
Recommendation when using smart card chips for LEGIC "card in card" solutions: A suitability and functional test of the corresponding medium should be carried out before use or if it is planned to be used. 2023-04 | V02 | Bosch Security Systems B.V. Manual de instalación... -
Page 11: Reading Distances
If other transponder media are used (chip type, design, size, production process), the distance ranges may differ and it is recommended to carry out a suitability and functional test of the respective medium before using or planning to use the reader. Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación... -
Page 12: Bluetooth® Low Energy
Mobile Access, refer to the Datasheet and Quick user guide of the Mobile Access – how to adjust the read range, refer to the User manual of the Credential Management. These documents are available in the online catalog. 2023-04 | V02 | Bosch Security Systems B.V. Manual de instalación... -
Page 13: Installation
High-energy sources of interference in the range of the modulation and carrier frequencies can also interfere with the transmission. 3.1.1 Mechanical structure of the flush-mount version 3.1.2 Mechanical structure of the surface-mount version Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación... -
Page 14: Installing Data And Supply Lines
When dimensioning the power supply and the cable cross-sections of the cabling, the maximum current consumption must be taken into account. It is essential to ensure that the input voltage remains constant and corresponds to the technical specifications of the reader. 2023-04 | V02 | Bosch Security Systems B.V. Manual de instalación... -
Page 15: Assembly Preparation
Do not connect DC- (0V) DC+ (from 8V to 30V) Wire diameter Stranded wire AWG 28 - 16 Solid wire AWG 28 - 16 Cable stripping length 6 to 7 mm Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación... -
Page 16: Assembling The Reader
Use the provided screws to screw the wall bracket onto a DIN device socket with a device screw distance of 60 mm. Support the reader's tear detection by fixing the perforated tear-off tab with an additional locking screw. 2023-04 | V02 | Bosch Security Systems B.V. Manual de instalación... - Page 17 Screw the wall-mount frame to the wall using the screws. The connection cable can be inserted from above, below or directly from the wall. Tear detection is supported by fixing the upper left screw. Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación...
-
Page 18: Assembling The Reader Module
To change the reader configuration: Power-off the reader. Set the DIP switches correctly. Power-on the reader. OSDP protocol Address Reserved (default - OFF) Bus terminator resistor (default - OFF) 2023-04 | V02 | Bosch Security Systems B.V. Manual de instalación... -
Page 19: Connecting And Mounting The Reader Module
After it has successfully clicked into place, slide the locking bar into the reader module until it also clicks into place. – NOTE: A clear click can be heard each time it clicks into place. Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación... -
Page 20: Unmounting The Reader Module
Notice! After the reset, the Mobile Access configuration of the Bluetooth® Low Energy module is also deleted. The configuration may have to be repeated in the Setup Access app. 2023-04 | V02 | Bosch Security Systems B.V. Manual de instalación... -
Page 21: Care Instructions
Do not use cleaning agents with mechanical effects such as scouring milk, scouring sponge, etc. Only clean the reader with a soft, damp cloth and only use clear water. Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación... -
Page 22: Technical Specifications
Audible indication Credential type Cards/keyfobs/tokens; PIN; Mobile credential Optical indication Reading format MIFARE Classic*; MIFARE DESFire EV1; MIFARE DESFire EV2; ISO14443A CSN 32 bit*; LEGIC prime*; LEGIC advant; ISO1593 CSN* 2023-04 | V02 | Bosch Security Systems B.V. Manual de instalación... - Page 23 Keypad ARD-SELECT-BOM, ARD-SELECT-WOM Keypad System integration Protocols / standards OSDP * It is not set by default. Requires specific configuration with OSDP protocol. Ask for more information in advance. Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación...
-
Page 24: More Information
| More information LECTUS select More information Visit the Bosch online product catalog for the latest technical documentation for this product. Manufacturing dates For product manufacturing dates, go to www.boschsecurity.com/datecodes/ and refer to the serial number on the product label. - Page 25 LECTUS select More information | Bosch Security Systems B.V. 2023-04 | V02 | Manual de instalación...
- Page 26 | More information LECTUS select 2023-04 | V02 | Bosch Security Systems B.V. Manual de instalación...
- Page 28 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2023 Building solutions for a better life. 202304111828...
