Philips 3CDC-LC-MP3CD2002 Service Information

3 disc carousel changer+мрз board for fw-m355
Hide thumbs

Advertisement

Quick Links

Download this manual
Service
Service
Service
Service Information
Already published Service Informations:
CHANGES DURING PRODUCTION
* From production wk233 onwards a new 3CDC-LC-
MP3CD2002 module will be introduced due to cost reduc-
tion.
This new 3CDC-LC-MP3CD2002 module can be recog-
nized by the much smaller square shape MP3CD2002
board instead of a shielded MPEG board.
A completely new chapter 10 is attached.
This chapter will replaced the existing MPEG-01B board
(chapter 8) and 3CDC-LC-VCD module (chapter 10).
This changeover must be synchronized with the following
changes on the Front and Combi board:
Front Board:
7400 3103 308 84531 TMP87CS71BF "M355TIV85431"
Combi Board:
3507 4822 051 30562 5k6 5% 0,1W
3508 4822 051 30562 5k6 5% 0,1W
2002 - 07 - 17
Product Service Group CE Audio
A02-162
3139 785 30076
FW-M355
A02 - 163
3139 785 30094
