ThinkSmart View Plus
Hardware Maintenance Manual

Advertisement

Table of Contents
loading

Related Manuals for Lenovo ThinkSmart View Plus

Summary of Contents for Lenovo ThinkSmart View Plus

  • Page 1 ThinkSmart View Plus Hardware Maintenance Manual...
  • Page 2 • Generic Safety and Compliance Notices First Edition (May 2023) © Copyright Lenovo 2023. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...

  • Page 3: Table Of Contents

    Remove the heat sink ... . trademarks ....41 Remove the system board thermal pad ..© Copyright Lenovo 2023...
  • Page 4 ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 5: About This Manual

    About this manual • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. • This manual contains service and reference information for the following Lenovo products. Machine type...
  • Page 6 ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 7: Chapter 1. Product Overview

    Chapter 1. Product Overview This chapter provides introductions to the connectors of ThinkSmart View Plus. For detailed technical specifications, go to Product Specifications Reference at: psref.lenovo.com. Stylus Pen Camera Description Description 1. Camera LED 2. Camera lens 3. Privacy shutter 4.

  • Page 8: Soundbar

    Soundbar Description Description 1. Microphone-mute button 2. Speaker-mute button 3. Volume-down button 4. Volume-up button 5. Speaker-mute LED 6. Microphone-mute LED 7. Microphone-status LED 8. Guide tabs 9. Pogo pins ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 9: Monitor And Stand

    Monitor and stand Chapter 1 Product Overview...
  • Page 10 3. USB-C (3.2 Gen 1) connector 4. DisplayPort in connector 5. DisplayPort out connector (works only when there is 6. Ethernet connector DisplayPort input from a computer) 7. USB-A (3.2 Gen 1) connectors 8. Power connector ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 11: Statement On Usb Transfer Rate

    Description Description 10. Pogo pad 9. Soundbar tab holes 11. Mode-switch button 12. Mode-switch LED Statement on USB transfer rate Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual transfer rate using the various USB connectors on this device will vary and will be slower than the data rate listed below for each corresponding device.
  • Page 12 ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 13: Chapter 2. General Checkout

    • Damage caused by the improper insertion of a PC Card or the installation of an incompatible card • Forgotten product password (making the product unusable) • Use of an incorrect ac power adapter on laptop products © Copyright Lenovo 2023...
  • Page 14 • Missing parts might be a symptom of unauthorized service or modification. • Check for obvious damage to a hard disk drive. If the spindle of a hard disk drive becomes noisy, the hard disk drive might have been dropped or subject to excessive force. ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 15: Chapter 3. Hardware Removal And Installation

    H5 mm or 4.8 mm ThinkCentre/Tiny Common tool VGA ) Hexagonal socket (for H8 mm ThinkCentre/Tiny Common tool Tiny antenna) Silicone grease for CPU Consumable or heatsink repairing Polyamide tape Consumable Mylar tape Consumable Eraser Consumable Electrical tape Consumable © Copyright Lenovo 2023...

  • Page 16: Major Frus And Crus

    • FRUs: Refer to parts that must be installed or replaced only by trained service technicians. If customers choose to replace the FRUs by themselves, the product warranty might be affected. For detailed FRU and CRU information, such as the FRU part numbers and supported models, go to: http://www.lenovo.com/serviceparts-lookup ThinkSmart View Plus Hardware Maintenance Manual...
  • Page 17 Number Description Self-service CRU Optional-service CRU Camera module Camera rubber Chapter 3 Hardware removal and installation...
  • Page 18 Cable hooks with ties Soundbar System board touch cable Power button cable System board panel cable P sensor cable Wi-Fi antennas LVDS cable System board Camera cable Power cord AC power adapter Screw kits USB-C cable ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 19: Board Connectors

    Board connectors Figure 1. System board Description Description System board panel cable connector Wi-Fi antennas cable connector Camera cable connector System board touch cable connector Audio cable connector Power connector USB-A connector USB-A connector Ethernet connector DisplayPort out connector DisplayPort in connector USB-C connector P sensor cable connector LVDS cable connector...

  • Page 20: General Guidelines

    For access, do the following: 1. Place the device on a flat surface. Removal step Remove the cable tie if any. Remove the camera rubber For access, do the following: 1. Place the device on a flat surface. ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 21: Remove The Camera Module

    Removal step Remove the camera module For access, do the following: 1. Place the device on a flat surface. Removal step Remove the Soundbar For access, do the following: 1. Place the device on a flat surface. Chapter 3 Hardware removal and installation...

  • Page 22: Remove The Stylus Pen

    Removal step Remove the stand with base Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool. For access, do the following: 1. Remove the cable tie. See “Remove the cable tie” on page 14. 2. Remove the camera module. See “Remove the camera module” on page 15.
  • Page 23 5. Disconnect the power cord from electrical outlet and disconnect all the cables from the device. 6. Place a clean soft cloth, and then lay down the device with the back cover facing up. Removal steps Attention: Use the screws provided by Lenovo to avoid any unpredictable damage to your device. Step Screw (quantity)

  • Page 24: Remove The Heat Sink

    6. Place a clean soft cloth, and then lay down the device with the back cover facing up. 7. Remove the stand with base. See “Remove the stand with base” on page 16. Removal steps Attention: Use the screws provided by Lenovo to avoid any unpredictable damage to your device. Step Screw (quantity)

  • Page 25: Remove The System Board Thermal Pad

    Attention: Use the screws provided by Lenovo to avoid any unpredictable damage to your device. Step Screw (quantity) Torque Color M3 × 8 mm, flat-head (3) Silver 0.18±0.05 Nm (1.8±0.5 kgf-cm) M3 × 3.5 mm, flat-head (2) Black 0.18±0.05 Nm (1.8±0.5 kgf-cm)

  • Page 26: Remove The Wi-Fi Thermal Pad

    Remove the Wi-Fi thermal pad Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool. For access, do the following: 1. Remove the cable tie. See “Remove the cable tie” on page 14. 2. Remove the camera module. See “Remove the camera module” on page 15.

  • Page 27: Remove The Power Lens

    Removal step Attention: Use the screws provided by Lenovo to avoid any unpredictable damage to your device. Step Screw (quantity) Torque Color 0.18±0.05 Nm M3 × 4.5 mm, flat-head (4) Silver (1.8±0.5 kgf-cm) Remove the power lens Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool.

  • Page 28: Remove The Power Button Board

    Removal step Attention: Use the screws provided by Lenovo to avoid any unpredictable damage to your device. Step Screw (quantity) Torque Color M2 × 4.5 mm, flat-head (2) Black 0.18±0.05 Nm (1.8±0.5 kgf-cm) Remove the power button board Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool.

  • Page 29: Remove The Shielding Bracket With Cover

    Removal step Attention: Use the screws provided by Lenovo to avoid any unpredictable damage to your device. Step Screw (quantity) Torque Color Black 0.18±0.05 Nm M2 × 4.5 mm, flat-head (1) (1.8±0.5 kgf-cm) Remove the shielding bracket with cover Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool.

  • Page 30: Remove The Camera Cable

    Removal step Attention: Use the screws provided by Lenovo to avoid any unpredictable damage to your device. Step Screw (quantity) Torque Color M3 × 3.5 mm, flat-head (11) Black 0.18±0.05 Nm (1.8±0.5 kgf-cm) Remove the camera cable Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool.

  • Page 31: Remove The Power Button Cable

    Removal steps Attention: Use the screws provided by Lenovo to avoid any unpredictable damage to your device. Step Screw (quantity) Torque Color M2 × 4.5 mm, flat-head (2) Black 0.18±0.05 Nm (1.8±0.5 kgf-cm) Remove the power button cable Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool.

  • Page 32: Remove The System Board Panel Cable

    Removal steps Remove the system board panel cable Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool. For access, do the following: 1. Remove the cable tie. See “Remove the cable tie” on page 14.

  • Page 33: Remove The P Sensor Cable

    Removal steps Remove the P sensor cable Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool. For access, do the following: 1. Remove the cable tie. See “Remove the cable tie” on page 14. 2. Remove the camera module. See “Remove the camera module” on page 15.

  • Page 34: Remove The System Board Touch Cable

    Removal steps Remove the system board touch cable Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool. For access, do the following: 1. Remove the cable tie. See “Remove the cable tie” on page 14.

  • Page 35: Remove The Wi-Fi Antennas

    Removal steps Remove the Wi-Fi antennas Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool. For access, do the following: 1. Remove the cable tie. See “Remove the cable tie” on page 14. 2. Remove the camera module. See “Remove the camera module” on page 15.

  • Page 36: Remove The System Board

    Removal steps Remove the system board Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool. For access, do the following: 1. Remove the cable tie. See “Remove the cable tie” on page 14. 2. Remove the camera module. See “Remove the camera module” on page 15.

  • Page 37: Remove The Back Bracket

    Removal steps Attention: Use the screws provided by Lenovo to avoid any unpredictable damage to your device. Step Screw (quantity) Torque Color Black 0.18±0.05 Nm M3 × 3.5 mm, flat-head (4) (1.8±0.5 kgf-cm) Remove the back bracket Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool.
  • Page 38 14. Remove the heat sink. See “Remove the heat sink” on page 18. 15. Remove the system board. See “Remove the system board” on page 30. Removal steps Attention: Use the screws provided by Lenovo to avoid any unpredictable damage to your device. Step Screw (quantity)

  • Page 39: Remove The Lvds Cable

    (1.8±0.5 kgf-cm) Remove the LVDS cable Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool. For access, do the following: 1. Remove the cable tie. See “Remove the cable tie” on page 14. 2. Remove the camera module. See “Remove the camera module” on page 15.

  • Page 40: Remove The Bezel

    Remove the bezel Prerequisite Turn off ThinkSmart View Plus and wait several minutes until it is cool. For access, do the following: 1. Remove the cable tie. See “Remove the cable tie” on page 14. 2. Remove the camera module. See “Remove the camera module” on page 15.
  • Page 41 1. Remove the cable tie. See “Remove the cable tie” on page 14. 2. Remove the camera module. See “Remove the camera module” on page 15. 3. Remove the Soundbar. See “Remove the Soundbar” on page 15. 4. Remove the Stylus Pen. See “Remove the Stylus Pen” on page 16. 5.
  • Page 42 ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 43: Chapter 4. Help And Support

    Machine Type or Serial Number and find the • Troubleshooting resources you want. • Recovery • Drivers and Software Go to: Microsoft Teams display https://support.lenovo.com/solutions/ht514685 Go to: Lenovo ThinkSmart Manager Service* https://support.lenovo.com/solutions/tsm * for selected models © Copyright Lenovo 2023...
  • Page 44 ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 45: Appendix A. Serial Number Location

    Appendix A. Serial Number Location Refer to the illustrations to find your product Serial Number. © Copyright Lenovo 2023...
  • Page 46 ThinkSmart View Plus Hardware Maintenance Manual...

  • Page 47: Appendix B. Notices And Trademarks

    Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
  • Page 48 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
