Philips DVDR1000 Technical Specifications

Technical Specification DVDR 1000
Disc Formats Supported Audio Format
Disc type Playback Recording Recording MPEG1
DVD+RW • • 16 bit, fs 48 kHz
DVD-R • Playback MPEG1/2,AC-3, DTS PCM
DVD-Video • 16, 20, 24 bit
Video CD / S-VCD • fs 48, 96 kHz
Audio CD •
CD-R • Audio Performance
CD-RW • DA Converter 24 bit
AD Converter 16 bit
DVD+ReWritable Disc Format
DVD fs 96 kHz 4 Hz - 44 kHz
Medium Phase-Change Rewritable
fs 48 kHz 4 Hz - 22 kHz
Diameter 12cm
Video CD fs 44.1 kHz 4 Hz - 22 kHz
Capacity (single side) 4.7 Gbyte
Audio CD fs 44.1 kHz 4 Hz - 20 kHz
Recording time HQ 60' 9.72 Mbit/s
Signal-Noise (1kHz) 105 dB
SP 120' 5.07 Mbit/s
Dynamic Range (1kHz) 100 dB
LP 180' 3.38 Mbit/s
Crosstalk (1kHz) 110 dB
EP 240' 2.54 Mbit/s
Distortion / Noise (1kHz) 90 dB
TV Standard PAL/SECAM NTSC
Front Connections
Scan Frequency 50Hz 60Hz
i.link DV IEEE 1394 4-pin
Number of lines 625 525
S-Video Input Hosiden 4-pin*
Playback Multi-standard
Video Input Cinch (yellow)*
Recording Multi-standard
Audio Left/Right Input Cinch (white/red)*
Internal tuner PAL/SECAM
* gold-plated
Video Format
Rear Connections
Digital Compression MPEG2 for DVD
SCART 1 CVBS, S-Video / RGB,
MPEG1 for VCD
Decoder
DVD-VIDEO SCART 2 CVBS, S-Video / RGB
S-Video In Hosiden 4-pin
DVD+RW (HQ/SP) 50Hz 60Hz
S-Video Out Hosiden 4-pin
Horizontal Resolution 720 pixels 1 720 pixels 1
Video In Cinch (yellow)*
Vertical Resolution 576 lines 480 lines
Video Out (2x) Cinch (yellow)*
DVD+RW (LP/EP) 50Hz 60Hz
Audio L/R In (2x) Cinch (white/red)*
Horiz. Resolution 360 pixels 2 360 pixels 2 Audio L/R Out (2x) Cinch (white/red)*
Digital Audio Out 1 coaxial,* 1 optical
Vertical Resolution 576 lines 480 lines
IEC958 for CDDA / LPCM
VCD 50Hz 60Hz
IEC1937 for MPEG2,AC-3,
Horiz. Resolution 352 pixels 352 pixels
DTS
Vertical Resolution 288 lines 240 lines
RF Antenna In Coaxial 75 ohms
RF TV Out Coaxial 75 ohms
Video Performance
Mains Standard (IEC type)
DA Converter 10 bit
* gold-plated
AD Converter 9 bit
Signal handling Components
User Interface
Video Output 1 Vpp into 75 ohm
OSD Languages English, French, Spanish,
S-Video Output Y: 1 Vpp into 75 ohm
German, Dutch, Italian,
C: 0.300 1Vpp into 75 ohm
Swedish, Portuguese
RGB Output 0,7 Vpp into 75 ohm
Programming
1 equivalent to 500 lines on your TV
Number of events 6; 1 month
2 equivalent to 250 lines on your TV
Daily/Weekly
Programming mode OTR, Remote
Recorder Control and PDC,VPS
transmitter identification
Timer programming Manual,
ShowView/VideoPlus+,
NEXTView Link
DVDR
DVDR
Disc Recording
• Direct Record
• One-Touch Record (OTR)
• Append
• Divide
• Erase
• Automatic/Manual Chapter Marker insertion
• Disc write lock
• Favorite Scene Selection
• Index Picture Screen
• Custom Index Pictures
Disc playback
• Auto Resume
• Play / Stop / Pause
• Fast Forward/Backward (3-speed)
• Step Forward/Backward
• Slow (3-speed)
• Title / Track Select
• Next / Previous Title / Track / Chapter
• Repeat (Chapter / Title / All) or (Track / All)
• A-B Repeat
• Intro Scan
• Perfect Still with digital multi-tap filter
• Zoom (1.33x, 2x, 4x) with picture enhancement
• Pan
General Functionality
• 3D sound (SRS TruSurround)
• Beep Feedback for Remote Control
• Backup Presets & Timer Events: 1 year
• Backup Clock & Calendar: 7 hrs
• Time & Date Download
• Automatic/Manual Audio Recording Level
• Resume (5 discs) after stop/standby
Power Supply
Power Inlet: 200-240 V, 50/60 Hz
Power consumption Operation 49 W
Low-power standby 3 W
Cabinet
Dimensions (w x h x d) 435 x 110 x 330 mm
Net Weight 8.5 Kg
Front Panel Aluminium
Remote Control
• Universal remote for control of main TV functions
• Aluminium top
• Hard coated keys
• Dome foil for tactile feedback
Philips Consumer Electronics
P.O. Box 77900
1070 MX Amsterdam
Tel: +31.20.5977683
Fax: +31.20.5977880
Internet: http://www.philips.com
Dolby Digital is trademark of Dolby Laboratories Licensing Inc.
ShowView and and VideoPlus+ are trademarks of Gemstar Development Group
, , and the symbol are trademarks of SRS Labs, Inc.
DVDR 1000
