Panasonic WV-CW474F Operating Instructions Manual

please read these instructions carefully and save this manual for future use.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrow-
head symbol, within an equilat-
eral triangle, is intended to
alert the user to the presence
of uninsulated "dangerous volt-
age" within the product's enclo-
SA 1965 sure that may be of sufficient
magnitude to constitute a risk
of electric shock to persons.
The exclamation point within
an equilateral triangle is intend-
ed to alert the user to the pres-
ence of important operating
and maintenance (servicing)
instructions in the literature
accompanying the appliance.
SA 1966
WARNING:
To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
PREFACE
Panasonic's WV-CW474F/CW474S series color digital camera introduces a new level of high
picture quality and high resolution through the use of a 1/3-inch interline transfer CCD image
sensor having 768 horizontal pixels (picture elements), and digital signal processing LSIs.
This model offers cutting-edge technology for advanced video surveillance.
PRECAUTIONS
1. Do not attempt to disassemble the camera.
To prevent electric shock, do not remove screws or covers.
There are no user-serviceable parts inside. Ask qualified service personnel for servic-
ing.
2. Handle the camera with care.
Do not abuse the camera. Avoid striking, shaking, etc. The camera could be damaged
by improper handling or storage.
3. Do not expose the camera to rain or moisture, not try to operate it in wet areas.
If the camera becomes wet, turn the power off immediately and ask qualified service
personnel for servicing. Moisture may damage the camera and also cause electric
shock.
4. Do not use strong or abrasive detergents when cleaning the camera body.
Use a dry cloth to clean the camera when dirty. When the dirt is hard to remove, use a
mild detergent and wipe gently. Then wipe off the remaining detergent with a dry cloth.
5. Clean the CCD faceplate with care.
Do not clean the CCD with strong or abrasive detergents. Use lens tissue or a cotton
tipped applicator and ethanol.
6. Never face the camera towards the sun.
Do not aim the camera at bright objects. Whether the camera is in use or not, never
aim it at the sun or other extremely bright objects. Otherwise, blooming or smear may
be caused.
7. Do not operate the camera beyond the specified temperature, humidity or power
source ratings.
Use the camera at temperatures within –10 °C to +50 °C (14 °F - 122 °F), and humidity
below 90 %. The input power source is 24 V AC.
8. Turn the circuit breaker off which supplies the camera with the power when
abnormal conditions are encountered.
Caution:
To prevent fire or electric shock hazard, use a UL listed cable (VW-1, style 1007) for
the 24 V AC Input Cable.
Before attempting to connect or operate this product,
Color CCTV Cameras

Operating Instructions

WV-CW474F
Model No.
WV-CW474S
N1101-1121 V8QA5931BN
