- Page 1 DATA LOGGER Model DL-SA11 User’s Manual For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd. Wilmington, NC 28411 (800) 507-0482 / (910) 686-4281 R3-081016...
- Page 2 Report type: Excel and AI/PDF Power supply: single-use lithium battery 3.6V (replaceable) Battery life: at least 12 months at 25°C with 15 min record interval In the package…………………………………………………………………….. DL-SA11 temperature data logger User’s manual ……… …………………………………………… Using the data logger Download the data management software from the link below: http://accucoldloggers.com/dlsa11...
- Page 3 Configure parameters Refer to the data management software instructions for details (pages 8 –14) Caution! Make sure you have saved selected parameters. Default Settings Other settings Logging interval 5 minutes 0-11 hours; 0-59 minutes; 0-50 seconds Stop mode: Software Manual stop (see pp. 3-4 ) Start Mode: Instant on Manual and timing start (pg.
- Page 4 and the data logger is not stopped manually, the data logger will save the data by overwriting the initial data. (It keeps the statistical information of the whole transportation process.) NOTE: When the record capacity exceeds the Max capacity (32,000 points) in the manual mode, the data logger can continue recording the temperature state of the whole transportation process but only keep the details of the last 32,000 points.
- Page 5 Menu 4: Current record interval. (e.g., the digit N following the decimal point represents N*10 sec. Fig.6 shows the record interval is set to 12 min 50 sec.) Fig.6 Record interval Menu 5: MKT value. Menu 6: Average temperature value. Fig.7 Fig.8 Static...
- Page 6 Content of exported report The report varies based on the set alarm types. When unit is set to ―no alarm‖, there is no alarm info on the top right corner of the first page or color mark among data. When it is set to ―alarm‖, relative alarm info appears in the alarm info column based on the selected alarms.
- Page 7 Step 2. Press the snap to remove the compartment. See Fig. 21. Fig.21 Step 3. Remove the battery compartment. See Fig. 22. Fig.22 Step 4. Remove the old battery and Install the new one. See Fig. 23. Fig.23 Step 5. Adjust the button and the internal light pipe to the same side; snap the compartment shut.
- Page 8 Data Management Software Instructions Data Management Software can upload all recorded data to a computer and systematically analyze, collect and manage data. Installation environment Hardware environment： Operation system: CPU：above PII600MHZ Windows XP（32bit、64bit, Windows Vista（32bit、 64bit, Win7（32bit、64bit） ，Windows8(x86/x64) Hard disk：above 40G Memory：above 512M Main functions 2.1：Main interface...
- Page 9 Parameter information： Serial Number——Data logger ID Stop Time——Stop time Log Interval——Record interval Data points——Total record points Time Base——Time Zone Elapsed time——Total record time Start Mode——Logger start mode MKT——Mean kinetic temperature Start Delay——Logger start delay time Over——Alarm upper limit Buffer Ring——Buffer Ring Below——Alarm lower limit Trip ID——Trip ID number Allow Time——Alarm delay time...
- Page 10 Data table ——Displays first page data ——Displays previous page data ——Displays next page data ——Displays last page data ——Skips to a specific page For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd. Wilmington, NC 28411 (800) 507-0482 / (910) 686-4281 R3-081016...
- Page 11 3. Data query page Selects all loggers Views the detailed information of the selected logger Deletes the data of selected logger Displays all loggers that have exceeded upper/lower limit Displays all recording (including normal temperature data and over temperature data) Data management function Back to home page For Sales Information Please Contact...
- Page 12 4. Data management page ——Data backup (saves data in the format of ELT) ——Data restore (restores ELT file and reads it by software) ——Back to home page 5. Parameter setting page R3-081016 For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.
- Page 13 Parameter information： Start Mode——Logger start mode Serial Number——Data logger ID Trip ID——Travel ID number Travel DSC——Travel description Log Interval——Record interval Report Language——Report Language Time Base——Time Base Battery——Battery display No Alarm ——Alarm threshold not set Cycle—— Total record time available Password——Setting password Stop Mode——Logger stop modes Multiple Alarm——Set several alarm thresholds Multiple Work——Permit logger to be started or stopped several times...
