- Page 1 Operating Instructions Color CCTV Camera WV-CW500S/G Model No. WV-CW504SE Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. The model number is abbreviated in some descriptions in this manual.
-
Page 2: Preface
Preface About the user manuals The operating instructions of the camera consist of 2 sets: these operating instructions (PDF) and Installation Guide. This document explains how to configure the settings of the camera. Refer to the installation guide for further information about how to install the camera. ®... -
Page 3: Table Of Contents
Contents Back focus setting [BACK-FOCUS SETUP] ....... 25 Preface ................2 About the user manuals ..........2 Special menu setting [SPECIAL SETUP] ......27 Trademarks and registered trademarks ......2 Chroma level adjustment [CHROMA GAIN] ....27 About the setup menus ............4 Aperture level adjustment [AP GAIN] ...... -
Page 4: About The Setup Menus
About the setup menus Performing each setting item in the setup menu should be completed in advance to use this unit. Perform the settings for each item in accordance with the conditions of the camera shooting area. The following is an example of setup procedure when LANGUAGE is set to ENGLISH. Setup menu list Reference Setup item... -
Page 5: Basic Operation
Basic operation The description below explains how to operate the setup menu basically. The operations in the setup menu are performed with the operation buttons after calling up the setup menu on the connected video monitor. Refer to the installation guide for further information about the operation buttons. The operations in the setup menu can also be performed through the system controller (option). -
Page 6: Screen Transition Diagram
SENS UP WHITE BAL ATW1 HIGH BW MODE AUTO1 i-VMD RET TOP END "SYSTEM SETUP" screen **SYSTEM SETUP** SYNC LENS PANASONIC PRIVACY ZONE STABILIZER EL-ZOOM UPSIDE-DOWN RET TOP END "BACK-FOCUS SETUP" screen **BACK-FOCUS SETUP** PUSH SW MANUAL-ADJ AUTO SETUP-SW LOCK OFF NEAR .. -
Page 7: Camera Title Setting [Camera Id]
Camera title setting [CAMERA ID] This item specifies the camera title. The camera title that indicates the camera location and other information about the camera is cre- ated with alphanumerics and symbols, and is displayed on the screen. The camera title is named with up to 16 characters. Follow the procedure below to specify the camera title. -
Page 8: Camera Operation Setting [Camera Setup]
Camera operation setting [CAMERA SETUP] The following describes the camera operation settings. The following settings can be configured on the "CAMERA SETUP" screen displayed from the top screen. Refer to page 5 for how to call up the screen. The settings configured on the "CAMERA SETUP" screen will be saved as a scene file. "CAMERA SETUP"... -
Page 9: Light Quantity Control Method Selection [Alc]
Step 5 Move the cursor to "SCENE1" and press the right or left button to select "SCENE1" to resume normal operation. 2. Light quantity control method selection [ALC] The method of controlling the quantity of light is selected from the following. ALC (default): The iris of the lens is automatically adjusted in accordance with the brightness of a subject. - Page 10 Note: • When "ON" or "ON(i-VMD)" is selected for "SUPER-D5", the following settings will be restricted. SHUTTER: Only OFF and 1/120 are available. (+ page 11) SENS UP: Only "OFF" and "AUTO" become available. (+ page 12) • When "ON" or "ON(i-VMD)" is selected for "SUPER-D5", a shadow (black line) may appear at the boundary between a brighter area and a darker area. This is not a malfunction. • When "ON" or "ON(i-VMD)" is selected for "SUPER-D5", the SUPER-D5 function will become more effective by slightly increment- ing "LEVEL". However, flickering or noise may be observed frequently when "LEVEL" is too much incremented. • When flickering or noise is observed frequently due to the illumination of light, select "OFF".
-
Page 11: Electronic Shutter Setting [Shutter]
"ALC CONT" screen Mask setting screen Area setting screen **ALC CONT**(1) **AREA **(1) BACK LIGHT COMP POSITION PUSH SW SUPER-D5 UPPER LEFT MASK SET ... | ... 0 LEVEL MANUAL ABS RET TOP END RET TOP END Step 2 Mask bright areas. Use the up, down, right, and left buttons to select an area to be masked and press the setting button. -
Page 12: Gain Control Setting [Agc]
4. Gain control setting [AGC] Select a gain control setting from the following. ON (HIGH) (default)/ON (MID)/ON (LOW): Automatically increases the gain to make the screen brighter when the illuminance of the subject becomes darker. HIGH, MID and LOW indicate the gain level. OFF: Does not increase the gain. -
Page 13: Manual Fine Adjustment Of White Balance
When "AWC" is selected, follow the steps below to adjust the white balance. "CAMERA SETUP" screen **CAMERA SETUP** SCENE1 SHUTTER ON(HIGH) SENS UP WHITE BAL AWC PUSH SW HIGH BW MODE AUTO1 i-VMD RET TOP END Step 1 Set "WHITE BAL" to "AWC" and press the left button to change to "AWC → PUSH SW". Step 2 Press the setting button and adjust the white balance. -
Page 14: Digital Noise Reduction Function Setting [Dnr]
7. Digital noise reduction function setting [DNR] The digital noise reduction function reduces noise automatically under the condition of low illuminance. The effect level of the noise reduction function is selectable from the following: LOW: Low level of noise reduction (small residual image) HIGH (default): High level of noise reduction (large residual image) 8. -
Page 15: I-Vmd Setting [I-Vmd]
Step 4 Move the cursor to "DURATION TIME" and select a time for switching between color and black-and-white images from the following: (default: 10 seconds) 2 sec. - 10 sec. - 30 sec. - 60 sec. Step 5 Move the cursor to "BURST (BW)", and decide whether or not to provide a burst signal output in the black-and-white mode. ON (default): Provides a burst signal output. -
Page 16: Perform The Settings Relating To The Motion
Perform the settings relating to the motion detection Perform the settings relating to the motion detection as follows. It is possible to detect only objects that moves to the direction speci- fied in advance or objects that keeps on moving for a certain duration. Up to 4 motions can be simultaneously detected. Follow the procedure below. -
Page 17: Perform The Settings Relating To The Detection Of Appearance/Disappearance Of Stationary Objects
Step 6 Set the detection sensitivity and the minimum size of objects detected. Perform the setup while viewing the detection result displayed on the screen. Set the detection sensitivity Move the cursor to "SENSITIVITY" and select one of the following options for the detection sensitivity: LOW (default)/MID/HIGH Set the minimum size of objects detected Move the cursor to "MIN SIZE"... -
Page 18: Set The Detection Areas
Step 4 Move the cursor to "AREA" and select the area for which the detection of appearance/disappearance of stationary objects is to be set. ALL (default): All areas will be set as the detection area. SETUP: When the setting button is pressed after selecting "SETUP", up to 2 areas can be set as the detection area. Refer to the description below for how to configure the settings. -
Page 19: Setting Of Scene Change Detection
Step 4 Use the up, down, right, and left buttons to determine the left upper position of the area to be set and press the setting button. Note: • The area corresponding to the selected number will be displayed in a green frame, while the other set areas are shown in a white frame. Step 5 Use the up, down, right, and left buttons to determine the right lower position of the area to be set and press the setting button. →... -
Page 20: Configure Frame Display
Configure frame display Follow the procedure below. "CAMERA SETUP" screen "i-VMD SETUP" screen **i-VMD SETUP**(1) **CAMERA SETUP** MOTION DET SCENE1 OBJECT DET SCENE CHANGE SHUTTER ON(HIGH) INDICATOR SENS UP ALARM CONT WHITE BAL ATW1 HIGH BW MODE AUTO1 i-VMD RET TOP END RET TOP END Step 1 Move the cursor to "i-VMD"... -
Page 21: Camera System Setting [System Setup]
The following settings can be configured on the "SYSTEM SETUP" screen displayed from the top screen. Refer to page 5 for how to call up the screen. "SYSTEM SETUP" screen **SYSTEM SETUP** SYNC LENS PANASONIC PRIVACY ZONE STABILIZER EL-ZOOM UPSIDE-DOWN RET TOP END 10. -
Page 22: Lens [Lens]
Move the cursor to "FINE", and fine adjust vertical phases. 11. lens [LENS] Select "PANASONIC". 12. Privacy zone setting [PRIVACY ZONE] When undesired portions in the camera shooting area (on the screen) exist, those portions (privacy zone) are hidden. Up to 8 portions can be specified for the privacy zone. -
Page 23: Image Stabilizer Setting [Stabilizer]
Step 3 Move the cursor to "POSITION" and press the setting button. Step 4 Use the up, down, right, and left buttons to determine the left upper position of the zone to be set and press the setting button. Step 5 Use the up, down, right, and left buttons to determine the lower right position of the zone to be set and press the setting button. -
Page 24: Electronic Zoom Setting [El-Zoom]
Follow the procedure below. "SYSTEM SETUP" screen EL-zoom setting screen Zoom setting screen Pan/tilt setting screen **SYSTEM SETUP** **EL-ZOOM** **EL-ZOOM** **EL-ZOOM** SYNC LENS PANASONIC ZOOM PUSH SW ZOOM PUSH SW ZOOM PUSH SW PAN/TILT PUSH SW PAN/TILT PUSH SW PAN/TILT... -
Page 25: Back Focus Setting [Back-Focus Setup]
Back focus setting [BACK-FOCUS SETUP] Selects the back focus setting type and performs fine adjustment. The following setting can be configured on the "BACK-FOCUS SETUP" screen displayed from the top screen. Refer to page 5 for how to call up the screen. The lens adjustment (+ Installation Guide) shall be performed before the back focus adjustment. - Page 26 Step 3 Move the cursor to "C/L ← → B/W" and select the back focus adjustment type from the following: AUTO (default): Adjusts the back focus function automatically and corrects out of focus when switching between color and black- and-white images. PRESET: Performs the preset movement to each specified back focus position when switching between color and black-and-white images.
-
Page 27: Special Menu Setting [Special Setup]
Special menu setting [SPECIAL SETUP] The special menu setup is performed including the setting of the camera image quality and the communication configuration when a receiver is used. The following settings are to be configured on the "SPECIAL SETUP" screen displayed from the top screen. Refer to page 5 for how to call up the screen. -
Page 28: Flaw Compensation [Pix Off]
Flaw compensation [PIX OFF] Flaws in the displayed camera image are corrected. Up to 16 points can be corrected. Follow the procedure below. "SPECIAL SETUP" screen "PIX OFF" screen Pixel compensation positioning screen **SPECIAL SETUP** **PIX OFF** ...128 CHROMA GAIN ... -
Page 29: Language Selection [Language Setup]
Language selection [LANGUAGE SETUP] A language for the setup menu is selected from the following: The language selection can be made on the "LANGUAGE SETUP" screen displayed from the top screen. Refer to page 5 for how to call up the screen. JAPANESE/ENGLISH (default)/FRANÇAIS/ESPAÑOL/DEUTSCH/ITALIANO/êìëëäàâ... -
Page 30: Shortcut Operation
Shortcut operation Use of a system controller with the "camera function" button allows users to perform the shortcut settings with use of the numeric keypad and camera function button. The available shortcut operations with this unit are shown as follows: System controller operation Setting contents [8] + [3] + [Camera function]... - Page 31 System controller operation Setting contents [2] + [1] + [1] + [Camera function] Scene change ON [2] + [1] + [2] + [Camera function] Scene change OFF [2] + [1] + [3] + [Camera function] Scene file 1 [2] + [1] + [4] + [Camera function] Scene file 2 [2] + [1] + [5] + [Camera function] Gain (AGC), 1 step up [2] + [1] + [6] + [Camera function] Gain (AGC), 1 step down...
- Page 32 Panasonic Corporation http://panasonic.net Importer's name and address to follow EU rules: Panasonic Testing Centre Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg F.R.Germany © Panasonic System Networks Co., Ltd. 2010 N0409-2109 3TR006045CZB Printed in China...
