- Page 1 WQP12-EFMS Dishwasher Service Manual Models: Features Eco wash Water overflow protection is provided Three spraying instruction, which makes washing more thorough Haier Group Manual code: 0120501827 Edition:2003.01.01...
-
Page 2: Table Of Contents
Contents 1. Product Code illumination and Series introduction …………………….………...2 2. Features………………………………………………… ……………………………….3 3. Specifications…………………………………………… ……………………………….4 4. Safety Precaution………………………………………… ………………………….…...6 5. Warning and Cautions………………………………… ………………………………..8 6. Net Dimension……………………………………………………………………………9 7. Installation and Accessory Parts…………………… …………………………………10 8. Parts and Functions………………………………… ………….. ………………...…...12 9. Function Schedule………………………………………………………………………..17 10. -
Page 3: Product Code Illumination And Series Introduction
Product Code illumination and Series Introduction 1.Product Code Illurmination and Series Introduction Model Identification W □ □ □□─□ □ □ □ A B C A: Abbreviation of dishwasher B: Automatic/semi-autometic C: Type of washing D: Code name of Nominal capacity E: Series of factory design F: Freestanding/built –in/semi-built-in G: Mechnical/electronic... -
Page 4: Features
2.4 Water softening function is provided which can prevent incrustation forming. 2.5 Water overflow protection is provided. 3.Specifications DISH WASHER FREE STANDING Last update 2002-5-23 Supplier Type N°. WQP12-EFMS Suppliers bar code N°. Sales Brand / Model GXCH Sales bar code N°. Key-features Energy efficiency Class Washing efficiency... - Page 5 Interior S= stainless steel / P= plastic Dispenser system Detergent / Rinse aid Water softening system / n°. of water hardness levels Electronically controlled water hardness Easy clean filter system / self cleaning micro filter Height adjustable top basket Cuttlery sliding tray / removable basket Plates sizes...
- Page 6 Net weight Built-In Requested measures of niche (H x W x D) Dimensions of door panel (H x W) Packing Dimensions of packing (H x W x D) 88X66X67.5 Weight of packing (all materials) 48.00 Informations for importer 14,5 m (84 CBM.) Truck load capacity Jumbo (120 CBM.) Truck load capacity 40' Container load capacity 40' HC load capacity...
-
Page 7: Safety Precaution
Safety Precaution 4. Safety Precaution... - Page 8 Safety Precuation...
-
Page 9: Warning And Cautions
Warning and Cautions 5. Warning and Cautions 1.Shelf(The container which dishes are put in is called shelf) 2.Put the shelf into the washing box 3.Put in detergent 4.End of cycle... - Page 10 Warning and Cautions 5.Weekly maintenance...
-
Page 11: Net Dimension
Net dimension / Installations and Accessory Parts Net dimension 7. Installations and Accessory Parts 7.1 Positioning the Appliance Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply and drain hoses that can be positioned on the right or the left to facilitate proper installation. - Page 12 Installationan and Accessory Parts appliance is level,it will help ensure proper performance. 7.3 Cold Water Connection Connect the cold water supply hose to a threaded 3/4(gas) connector and make sure that it is fastened tightly in place (see Fig 1). If the water pipes are new or have not been used for an extended period of time,let the water run to make sure that the water is clear and free of impurities.If this precaution is not taken,there is a risk that the water inlet can get blocked and damage the appliance.
-
Page 13: Parts And Functions
Parts and Functions 8. Parts and functions... - Page 14 Parts and functions Salt The hardness of the water varies from place to place. If hard water is used in the shwasher,deposits will form on the dishes utensils. The appliance is equipped with a special softener that uses a salt specifically designed to eliminate lime and minerals from the water.
- Page 15 Parts and functions hardness of the water being used. It is recommended that adjustments be made in accordance with the following scheme: Detergent Detergent specifically intended for use with dishwashers must be used.The dispenser must be refilled before the start of each wash cycle following the instructions provided in the "Wash Cycle Table."...
- Page 16 Parts and functions There are 6 different settings; the normal dosage setting is 3. Important Proper dosage of the rinse aid improves drying. If drops of water remain on the dishes or spotting occurs,the dosage adjustor should be turned to a higher setting. If the dishes have white streaks,turn the dosage adjustor to a lower setting.
- Page 17 Parts and functions the front of the upper rack. How to Use the Upper Rack The upper rack is designed to hold more delicate and lighter dishware, such as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty).
-
Page 18: Function Schedule
Function Schedule 9. Function Schedule Intensive wash 1、 Pre-wash 26min 55℃Main-wash 55min Pre-wash 10min Hot rinse 35min Normal wash 2、 55℃Main-wash 55min Pre-wash 10min Hot rinse 35min Drying 37min Rinse wash 3、 Drying 37min Hot rinse 35min Glasses wash 4、 40℃Main-wash 33min Drying 9min Hot rinse 25min... -
Page 19: Program Diagram
Program Diagram 10. Program Diagram... -
Page 20: Maintenances Service And Trouble Shooting
Maintenances Services and Trouble Shooting 11.1Maintenances Services It may occur that the dishwasher does not function or does not function properly Before calling for assistance,Iet us see what can be done first :have you forgotten to press one of the buttons or to perfom an essential operation? 11.2 Trouble Shooting analysis of the common breakdowns Door switch trouble... - Page 21 Maintenances Services and Trouble Shooting analysis of the common breakdowns water supply trouble Whether water is flowing in the hose Turn on the stopcock Whether the stopcock is turned on Whether solenoid valve measure whether solenoid valve is working is electrified Change the solenoid valve Check whether...
- Page 22 Maintenances Services and Trouble Shooting analysis of the common breakdowns Water discharge trouble Whether the pipe work is in good condition Repair it whether discharge The pump is possibly damaged pump works properly Whether the water level switch is damaged Replace the water level switch position discharge pipe is probably...
- Page 23 Maintenances Services and Trouble Shooting analysis of the common breakdowns Heating trouble Check: Whether socket connector is connected well Connect it well Check resistence Replace the heater between the heater resistor Check whether the circuit Replace the temperature limiting between the two teminals device is open The cable or the controller...
- Page 24 Maintenances Services and Trouble Shooting analysis of the common breakdowns Overflow trouble Whether there is water in the bottom of the A water leakage has machine developed Whether the overflow Replace it switch works properly The controller board or the cable should be suspected damaged...
- Page 25 Maintenances Services and Trouble Shooting analysis of the common breakdowns power trouble check whether the power connector Connect it properly check whether the power connector is in position is in position check whether the circuit the cable or the controller board between the two terminals should be suspected is open...
-
Page 26: Circuit Diagram
Circuit Diagram 12.Circuit Diagram... -
Page 27: Exploded View
Exploded View / List of Parts 13 exploded View 14.List of Parts Unit Inexploded Name of part Part specialized code QTY. Remark Price(EURO) view 0120801757 Complete top 012G2150035 Shelf fastening small block 012G1310022 Upper front crosspiece Right upright assembly 012G9350003 0120801625 Painted right side pannel 0120800590... - Page 28 012G1451092 Adjustable foot 0120200074 Cutlery basket 0120800591 Lower basket 012G1310023 Rear intermediate crosspiece 012G2160204 Drain hose stop 012G1310028 Lower rear crosspiece 012G2150046 Terminal box assembly 012G2150053 Wheel for lower basket 012G2150052 Wheel for upper basket 012G2160208 Wheel support pin 012G2150054 Basket rail stop 012G1020069 Mobile rail for basket...
- Page 29 Breather ring nut 012G2150044 012G4050242 Duct coupling 012G6040016 Heater assembly 012G9381036 Acquastop device 012G2160212 Extractable glass filter 012G1040012 Stainless steel extractable filter 012G4050162 Heater jacket 012G2140093 Connector 012G1040013 Cylindric stainless steel filter 012G1040014 Microfilter (polyesthere) 012G1020070 Lower sprayer 0120200252 Lower sprayer column 012G4050152 Rubber coupling 012G2150040...
-
Page 30: Damageable Parts List
012G1040017 Spring for closing lever 012G2150051 Pin for closing lever 012G2150050 Closing lever 0120200640 Handle small block 0120801756 Inlay stainless steel piece 012G9381040 Detergent dispenser 012G4050243 Door gasket 012G2130193 Drain hose support bracket 0120501524 instruction manual 15. Damageable Parts List Unit Inexploded Name of part...
