Read this manual carefully before installation. This manual can be accessed and downloaded from the Tripp Lite website—in the Support section, enter “TLNETCARD” in the search field. Refer to the User's Guide for additional information about configuration and operation. PROTECT YOUR INVESTMENT! Register your product for quicker service and ultimate peace of mind.
Page 2
Features The TLNETCARD allows users to operate any compatible Tripp Lite UPS System as a managed device on the network, accessible via Web browser, Network Management Station or telnet/SSH. Network Port: Connects to the Ethernet Network. LED Indicators: When the TLNETCARD is initializing or upgrading firmware, the two LED indicators simultaneously flash to show its status.
Page 3
1. Connects to a workstation with the provided RJ45 to DB9 cable for system configuration. 2. Connects to a TLNETEM environmental monitoring device (optional). Reset Button: Resets the TLNETCARD. This does not affect the operation of the UPS. DIP Switches: Set up operation modes.
Page 4
Tripplite.mib and RFC1628.mib - must be loaded on each Network Management Station that will monitor the UPS system via SNMP . The files can be found by going to tripplite.com/support and typing TLNETCARD in the search field. 16-01-412-933525.indb 4 1/28/2016 3:02:05 PM...
Insert TLNETCARD into Accessory Slot: Ensure that the two DIP switches on the TLNETCARD are in the OFF position (Normal Mode). While the UPS is turned on, align the TLNETCARD with the guides in the accessory slot and push the card into the slot until the ports are nearly even with the rear side of the UPS.
RJ45 Ethernet port on the card. Note: This port does not support PoE (Power over Ethernet) applications. If a DHCP Server is unavailable, the TLNETCARD can be accessed via web browser or telnet/SSH using its default IP address: 192.168.1.100. The Administrator login credentials are: admin / password.
Service under this Warranty can only be obtained by your delivering or shipping the product (with all shipping or delivery charges prepaid) to: Tripp Lite, 1111 W. 35th Street, Chicago, IL 60609, USA. Seller will pay return shipping charges. Visit www.tripplite.com/support before sending any equipment back for repair.
Page 8
Do not use this equipment in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide. Tripp Lite has a policy of continuous improvement. Product specifications are subject to change without notice.
Antes de la instalación, lea cuidadosamente este manual. Este manual se puede acceder y descargar desde el sitio web de Tripp Lite—en la sección de Soporte, ingrese “TLNETCARD” en el campo de búsqueda. Para obtener más información sobre la configuración y operación, consulte la Guía del Usuario.
Page 10
Características La TLNETCARD permite a los usuarios operar cualquier sistema UPS compatible de Tripp Lite, como un dispositivo administrado en la red, accesible mediante navegador web, Estación de Administración de Red o telnet/SSH. Puerto de Red: Se conecta a la Red Ethernet.
Page 11
1. Se conecta a una estación de trabajo con el cable RJ45 a DB9 suministrado para la configuración del sistema. 2. Conecta un dispositivo de monitoreo ambiental TLNETEM (opcional). Botón de Restaurar: Restaura la TLNETCARD. Esto no afecta la operación del UPS. Switches para configuración [DIPs]: Configuran los modos de operación.
Page 12
Instale el UPS: Instale su sistema UPS y enciéndalo antes de instalar la TLNETCARD. Asegúrese de que la ranura para la tarjeta sea accesible. Ubique la dirección MAC: La dirección MAC de 12 dígitos (000667xxxxxx) está...
TLNETCARD están en la posición OFF [Apagado] (Modo Normal). Mientras el UPS está encendido, alinee la TLNETCARD con las guías en la ranura auxiliar y empuje la tarjeta en la ranura hasta que los puertos estén parejos con el lado posterior del UPS.
Page 14
Ethernet al puerto Ethernet RJ45 en la tarjeta. Nota: Este puerto no admite aplicaciones de PoE (Energía sobre Ethernet). Si no está disponible un Servidor DHCP , la TLNETCARD puede ser accedida una a la vez mediante explorador de web o telnet/SSH usando su dirección IP predeterminada: 192.168.1.100.
(con todos los cargos de envío o entrega prepagos) a: Tripp Lite; 1111 W. 35th Street; Chicago IL 60609; EE. UU. El vendedor abonará los cargos de envío de devolución. Visite www.tripplite.com/support antes de enviar cualquier equipo para reparación.
Page 16
No use este equipo en la presencia de una mezcla anestésica inflamable con aire, oxigeno u óxido nitroso. Tripp Lite tiene una política de mejora continua. Las especificaciones están sujetas a cambio sin previo aviso.
être téléchargé depuis le site Web de Tripp Lite—dans la section Soutien, saisir « TLNETCARD » dans le champ de recherche. Consulter le guide de l'utilisateur pour des renseignements supplémentaires au sujet de la configuration et du fonctionnement.
Caractéristiques La TLNETCARD permet aux utilisateurs d'utiliser tout onduleur compatible Tripp Lite comme un dispositif géré sur le réseau, accessible par le biais d'un navigateur Web, une station de gestion de réseau ou telnet/SSH. Port de réseau : Connecte au réseau Ethernet.
Page 19
1. Connecte la station de travail avec le câble RJ45 à DB9 pour la configuration du système. 2. Connecte un appareil de surveillance environnementale TLNETEM (en option). Bouton de réinitialisation : réinitialise la TLNETCARD. Cela n'affecte pas le fonctionnement de l'onduleur. Commutateurs DIP : configurent les modes de fonctionnement. Commutateurs...
Page 20
S'il manque quelque chose, contacter immédiatement le fournisseur. Installation de l'onduleur : Installer l'onduleur et le mettre sous tension avant d'installer la TLNETCARD. S'assurer que la fente pour la carte auxiliaire est accessible. Localiser l'adresse MAC : L'adresse MAC de 12 chiffres (000667xxxxxx) est imprimée à...
Page 21
Installation Accès à la fente pour accessoires de la TLNETCARD : Utiliser un tournevis pour retirer le couvercle de la fente à accessoires de l'onduleur. Conserver les vis pour sécuriser la plaque de recouvrement de votre onduleur. Insérer la TLNETCARD dans la fente à accessoires : S'assurer que les deux commutateurs DIP sur la TLNETCARD sont configurés en...
Page 22
Ethernet (PoE). Si un serveur DHCP n'est pas disponible, il est possible d'accéder aux TLNETCARD une à la fois via un navigateur Web ou telnet/SSH en utilisant son adresse IP par défaut : 192.168.1.100. Les identifiants de connexion de l'administrateur sont : admin / password.
(avec les frais d’expédition et de livraison prépayés) à : Tripp Lite, 1111 W. 35th Street, Chicago, IL 60609 USA. Le vendeur paiera les frais d’expédition de retour. Visitez www.tripplite.com/support avant de retourner de l’équipement pour réparation.
Page 24
Garantie Numéros d’identification de conformité aux règlements À des fins de certification et d’identification de conformité aux règlements, votre produit Tripp Lite a reçu un numéro de série unique. Ce numéro se retrouve sur la plaque signalétique du produit, avec les inscriptions et informations d’approbation requises. Lors d’une demande d’information de conformité...
English 1 • Español 9 • Français 17 Перед установкой внимательно изучите настоящее руководство. Данное руководство находится и доступно для скачивания на веб-сайте компании Tripp Lite. Для этого в разделе "Поддержка" введите "TLNETCARD" в поле поиска. Дополнительные сведения о настройке и режимах...
Page 26
Возможности TLNETCARD позволяет пользователям эксплуатировать любой совместимый ИБП Tripp Lite как устройство, управляемое через сеть и доступное через веб- браузер, станцию управления сетью или протокол telnet/SSH. Сетевой порт: служит для подключения к локальной сети (Ethernet). Светодиодные индикаторы: во время инициализации или обновления...
Page 27
комплекте кабель с разъемами RJ45 и DB9 для настройки системы. 2. Обеспечивает подключение к TLNETEM устройства контроля параметров окружающей среды (приобретается отдельно). Кнопки перезапуска: обеспечивают перезапуск карты TLNETCARD. Данная операция не влияет на работу ИБП. DIP-переключатели: Обеспечивают установку режимов работы.
Page 28
Два файла Управляющей информационной базы – Tripplite.mib и RFC1628.mib – должны быть загружены на каждую Станцию управления сетью, которая будет контролировать работу ИБП по протоколу SNMP. Указанные файлы можно найти на странице tripplite.com/support путем ввода TLNETCARD в поле поиска. 16-01-412-933525.indb 28...
Page 29
Установка Обеспечение доступа к разъему для аксессуаров под устройство TLNETCARD: при помощи отвертки снимите с ИБП заглушку разъема аксессуаров. Оставьте винты для крепления соответствующей лицевой панели ИБП. Вставка TLNETCARD в разъем для аксессуаров: убедитесь в том, что два DIP-переключателя устройства TLNETCARD находятся в...
Page 30
умолчанию: 192.168.1.100. Регистрационные данные администратора: admin / password Внесетевой: указания в отношении порядка доступа к устройству TLNETCARD и его настройки через последовательный порт см. в руководстве пользователя TLNETCARD. Указания по настройке других параметров устройства TLNETCARD см. в руководстве пользователя TLNETCARD. Данное руководство можно...
Техническая поддержка Информация по технической поддержке представлена на странице по адресу: www.tripplite.com/support Гарантийные обязательства Условия 2-летней ограниченной гарантии Продавец гарантирует отсутствие изначальных дефектов материала или изготовления в течение 2 лет с момента первой покупки данного изделия при условии его использования в соответствии со всеми...
Page 32
когда его сбой с большой вероятностью приведет к сбою оборудования жизнеобеспечения или значительному снижению его безопасности или. Компания Tripp Lite постоянно совершенствует свою продукцию. В связи с этим возможно изменение технических характеристик без предварительного уведомления. 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support 16-01-412 93-3525_RevB 16-01-412-933525.indb 32...
