- Page 1 User Manual EPIRB3 Class 2, Category 2 Emergency Position Indicating Radio Beacon with AIS and RLS English www.oceansignal.com...
- Page 2 The technical data, information and illustrations contained in this manual were believed to be correct at the time of print. Ocean Signal Ltd reserve the right to change specifica- tions and other information contained in this manual as part of our continual improvement process.
- Page 3 EPIRB3 USER MANUAL IN CASE OF EMERGENCY USE ONLY IN SITUATIONS OF GRAVE AND IMMINENT DANGER MANUAL ACTIVATION 14/11/2022 912S-03967 - 01.01...
-
Page 4: About Your Epirb
EPIRB3 USER MANUAL ABOUT YOUR EPIRB COSPAS/SARSAT System The basic Cospas-Sarsat concept is illustrated in the figure below. The System is composed of: • distress radio beacons (ELTs for aviation use, EPIRBs for maritime use, and PLBs for personal use) which transmit signals during distress situations •... -
Page 5: Return Link Service
EPIRB3 USER MANUAL Return Link Service The Galileo Return Link Service (RLS) is a free-of-charge global service available to Cospas-Sarsat RLS compatible beacons. The new functionality, currently offered uniquely by Galileo, enables a communication link that relays a Return Link Message (RLM) back to the originating beacon through the Galileo Navigation Signal in Space. -
Page 6: Table Of Contents
EPIRB3 USER MANUAL ABOUT YOUR EPIRB COSPAS/SARSAT System Return Link Service AIS System GENERAL Introduction Exposure to RF Electromagnetic Energy Warnings What’s in the Box Operating Modes EPIRB3 OVERVIEW INSTALLATION Location Mounting Dimensions Remove the EPIRB3 from the Mounting Bracket Fit the Manual Mounting Bracket Fitting the EPIRB3 into the Mounting Bracket OPERATION... -
Page 7: General
‘used’, or if the expiry date marked on the unit has been exceeded. Battery replacement must be carried out at an Ocean Signal authorised battery replacement centre using manufacturer supplied battery components. -
Page 8: What's In The Box
EPIRB3 USER MANUAL What’s in the Box EPIRB3 Manual Mounting Bracket User Guide & Labels Mounting Screws (x3) Operating Modes Your EPIRB3 may be operated in a variety of modes. 2.5.1 Manual Release and Automatic Activation Should the vessel be in danger of sinking the EPIRB3 should be removed from its bracket, the antenna extended and then placed in the sea. -
Page 9: Epirb3 Overview
EPIRB3 USER MANUAL EPIRB3 OVERVIEW ON/OFF Key (Under flap) Indicator LED Break Off Tab Antenna Antenna Rewind Knob Strobe light TEST Key NFC Antenna Lanyard under rubber band Serial Number/ UIN Label Programming Details Label The lanyard is provided to attach the EPIRB3 to the life raft or your person, once it is activated. -
Page 10: Installation
EPIRB3 USER MANUAL INSTALLATION Failure to follow the following installation guidelines may cause the EPIRB3 to operate incorrectly. Do not mount the EPIRB3 closer than 1.0 metre to any steering compass as this may affect the accuracy of the compass. Keep the EPIRB3 away from any strong magnetic sources such as loudspeakers, compass compensation magnets, etc. -
Page 11: Fit The Manual Mounting Bracket
EPIRB3 USER MANUAL Fit the Manual Mounting Bracket Using the dimensions shown, use the three No.6 x 3/4” Countersunk screws supplied to secure the mounting bracket to a suitable bulkhead in a position that will allow easy access in the event of abandoning the vessel. Fitting the EPIRB3 into the Mounting Bracket Following installation the EPIRB3 should be refitted to the bracket. -
Page 12: Operation
EPIRB3 USER MANUAL IN CASE OF EMERGENCY USE ONLY IN SITUATIONS OF GRAVE AND IMMINENT DANGER OPERATION The EPIRB3 is designed for best operation while floating in water. If used in other situations ensure that the EPIRB3 is placed in the open, clear of any cover and kept upright. Do not place the EPIRB3 close to large structures or under cover. - Page 13 EPIRB3 USER MANUAL 5.1.2 Fully extend the antenna 5.1.3 Break off the red protective tab 5.1.4 Lift the yellow flap up to expose the Red ON/OFF button. 14/11/2022 912S-03967 - 01.01...
- Page 14 EPIRB3 USER MANUAL 5.1.5 Press and hold the red ON/OFF button for 1 to 2 seconds to activate. (Until the green LED starts to flash) The EPIRB3 will now be operational. The strobe lights will begin to flash at a rate of once every 2.5 seconds as soon as the unit is activated.
-
Page 15: Optical Indications On Activation
EPIRB3 USER MANUAL Optical Indications on activation • The LED will illuminate green (blue if RLS is enabled) for 1 second. • The strobe light will start flashing. • Within 1 minute* of activation, the indicator LED will flash a quick burst of 5 indicating 406MHz transmission. -
Page 16: Deactivation
It is not possible for the user to replace the red protective cover. Return the EPIRB3 to an Ocean Signal authorised service centre for checking and replacement. 5.3.2 Deactivation if Automatically Activated If the EPIRB3 was automatically activated by placing in water, remove from the water and dry. -
Page 17: Nfc And Mobile App
The Ocean Signal mobile App allows a user to access the EPIRB3 and see the programmed details and the latest test results giving a clear indication of the beacon’s condition. -
Page 18: Beacon Test
EPIRB3 USER MANUAL Beacon Test Ensure the antenna is fully deployed and above the EPIRB3 before commencing the test. Rewind the antenna before placing the EPIRB3 back in its bracket. Because the test transmits a short burst on the aircraft distress frequency of 121.5MHz, please only carry out this test in the first five minutes of each hour. - Page 19 EPIRB3 USER MANUAL Because this test transmits a short burst on the aircraft distress frequency of 121.5MHz, please only carry out this test in the first 5 minutes of each hour. The battery must be replaced either prior to the expiry date shown on the rear label or after the EPIRB3 has been activated.
-
Page 20: Gnss Test
The test can be ended at any time by holding the TEST key for 1 to 2 seconds. For further information regarding Self Test and Self Test history use the Ocean Signal App to connect to your EPIRB3 using Near Field Communication (NFC). -
Page 21: Beacon Registration
EPIRB3 USER MANUAL BEACON REGISTRATION It is the owner’s responsibility to register this beacon with the appropriate National Authority before operation. Documentation is provided within the packaging with information regarding registration with the relevant body to comply with the required configuration of the beacon. Advice to owners of EPIRBs Registration of 406 MHz satellite EPIRBs: •... -
Page 22: Unregistered Beacon
EPIRB3 USER MANUAL UNREGISTERED BEACON It is important to register your beacon. Operation of a beacon that is unregistered or incorrectly registered could lead to delays in providing the rescue services required by the operator of that beacon. APPENDIX Maintenance EPIRBs require little maintenance except periodic cleaning, if required. -
Page 23: Batteries
The battery condition can be determined by carrying out the Self Test procedure shown in section 7 of this manual. Battery replacement must be carried out at an Ocean Signal authorised battery replacement centre using manufacturer supplied battery components. -
Page 24: Transport
IATA packing instruction 970 section II. If you are hand carrying your EPIRB3 on an aircraft please contact your airline for advice. Safety Data sheets for all Ocean Signal products can be found on the Ocean Signal website: www.oceansignal.com/safety-data-sheets/ 912S-03967 - 01.01... -
Page 25: Specifications
EPIRB3 USER MANUAL Specifications 406MHz Transmitter Transmit Power (EIRP) Frequency 406.031 MHz ±1KHz Modulation Phase ±1.1 Radians (16K0G1D) Encoding Biphase L Rate 400 bps AIS Transmitter Transmit Power (EIRP) 1Watt±3dB Frequency 161.975/162.025MHz ±500Hz Baud rate 9600baud Synchronisation Messages Message 1 (Position), Message 14 (Status) Repetition interval 8 messages/minute Message 14 sent twice every 4 minutes... -
Page 26: Approvals
EPIRB3 USER MANUAL General Dimensions of EPIRB (Inc. antenna) 410mm x 90mm x 101mm (16.1 x 3.5 x 3.9 in.) Weight (EPIRB Only) 422grams (0.92lbs) IEC60945 Category Portable Operating Temperature Class 2 -20C to +55C Storage Temperature Class 2 -30C to +70C Waterproof (EPIRB) 10m depth for 1 hour Expected Life (EPIRB and Bracket) -
Page 27: 10. Warranty Information
Proof of purchase shall be required in order for a warranty claim to be valid from the original purchaser. All claims shall be made in writing to Ocean Signal or an approved service dealer or distributor. - Page 28 Ocean Signal Ltd. Unit 4, Ocivan Way Margate CT9 4NN United Kingdom info@oceansignal.com www.oceansignal.com...
- Page 29 EPIRB3 Specifications 406MHz Transmitter Transmit Power (EIRP) Frequency 406.031 MHz ±1KHz Modulation Phase ±1.1 Radians (16K0G1D) Encoding Biphase L Category 2 Rate 400 bps 406MHz EPIRB AIS Transmitter Transmit Power (EIRP) 1Watt±3dB Frequency 161.975/162.025MHz ±500Hz (With AIS and RLS) Baud rate 9600baud Synchronisation Messages...
- Page 30 1 to 2 seconds. 10hrs + For further information regarding Self Test and Self Test history use the Ocean Signal App to connect LED Indications for units configured with non-RLS Protocol to your EPIRB3 using Near Field Communication (NFC).
